Avermedia AVerTV Box W9 User manual

R
R
R
e
e
e
l
ll
e
e
e
a
a
a
s
s
s
e
e
e
D
D
D
a
a
a
t
t
t
e
e
e
:
:
:
2
2
2
0
0
0
0
0
0
7
7
7
0
0
0
1
1
1
2
2
2
3
3
3
A
A
A
V
V
Ve
e
er
r
rT
T
TV
V
V
B
B
Bo
o
ox
x
x
W
W
W9
9
9
(
(
(M
M
M0
0
0B
B
B9
9
9)
)
)
Turn Your LCD into a TV Now ！
AVerTV Box W9 is the latest product aiming toward professional
grade video processor for TV/Video views with high resolution of
1440×900（WXGA）TV BOX. It provides the complete solution for
turning your LCD monitor into a TV and multimedia entertainment
center, even without the need of turning on your PC！
Watching TV with 13-Channel Preview, it is easy to choose which
channel you want. Use the convenient PIP function when your PC is
on, so you can work on your PC and watch TV at the same time！
Enjoy the plug-n-play connectivity with your DVD player, Game
Cube, Dreamcast, PlayStation2, XBOX and others！Cutting-edge
progressive scan technology and 3D-motion Adaptive De-Interlace
give you sharper images. In addition, 3:2 Pull-Down technology
provides you better picture quality in full-screen WXGA resolution.
At A Glance
zPlug & Play
zPicture Pause
zTransparent Picture-in-Picture
zSupport resolution up to 1440×900,
60Hz
zProgressive Scan
zSupport all LCD/CRT monitors
zSupport switch able input sources
(TV , S-Video, Composite-Video,
PC, Component YPbPr, 480i)
zAll Frequency/All Channel scan
zProvides user-friendly OSD（on
screen display）to control functions
Specifications
Input Signal
z75 ΩTV Antenna
zAudio（R/L）
zVGA
zS-Video
zComposite (RCA)
zComponent Input（YPbPr, 480i, via
S-Video/Component 2-in-1 Cable）
zPC Audio
Output Signal
zAudio（Earphone & Speaker）
zVGA
Comparison Table for AVerTV BoxW Series
Product Name AVerTV Box W7 AVerTV Box W9
Resolution 1440×900 / 1280×1024 1440×900 / 1280×1024
Aspect Ratio
Adjustment
4:3
16:9/16:10
4:3
16:9/16:10
PIP O O（Transparent PIP）
Preview O* 13
Product Image
AVerTV BoxW7 can only continuously display the next consecutive TV channels.

PIP Function
■You can work on your PC and
watch TV at the same time！
Progressive Scan
■With world-leading Progressive Scan technology, you will see no flicker and it
will deliver a sharper, clearer picture.
3D-motion Adaptive De-interlace
Advanced 3D-motion Adaptive De-interlace can eliminate jagged edges of TV
& DVD movie to improve the clarity and sharpness of the overall image.
3：2/ 2：2 Pull-Down
World leading progressive Scan
Technology and 3:2/2:2 Pull-down
(only for NTSC) correction can
eliminate jitters form TV/DVD
movies to improve the clarity and
sharpness of the overall image.
A
A
A
V
V
V
e
e
er
r
rT
T
T
V
V
V
B
B
B
o
o
ox
x
x
W
W
W
9
9
9
(
(
(
M
M
M
0
0
0B
B
B
9
9
9
)
)
)
Package Included
AVerTV Box W9
Vertical Stand
Remote Control
(Batteries Included)
Power Adapter
VGA Cable
Audio Cable
S-Video/Component
YPbPr(480i) 2-in-1 Cable
Manual
System Requirements
PC：LCD/CRT/Plasma monitors
with VGA input
Projector：With VGA input
AVerMedia’s Quality Insistence
AVerMedia’s products are not only commit to RoHS/WEEE Directive, but conduct EMI and safety countermeasure to ensure consumers’
health and environment protection. All products are available with lead-free finishes and flame retardant.
© 2007 by AVERMEDIA TECHNOLOGIES, Inc. All right reserved. AVerMedia is registered trademarks of
AVerMedia Technologies, Inc. All other trademarks belong to their respective companies.
Video with
Progressive scan
Video without
Progressive Scan
Video with 3D-motion
Adaptive De-interlace
Video without 3D-motion
Adaptive De-interlace
