Avermedia Averdigi eb1704 hybrid User manual

AVerMedia®

AVerDiGi EB1704 Hybrid

User’s Manual

http://www.avermedia.com

http://www.averdigi.com

FCC NOTICE (Class B)

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Federal Communications Commission Statement

NOTE- This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial environment. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to correct the interference at his own

expense.

CAUTION ON MODIFICATIONS

To comply with the limits for the Class B digital device, pursuant to Part 15 of the FCC Rules, this device must

be installed in computer equipment certified to comply with the Class B limits. All cables used to connect the

computer and peripherals must be shielded and grounded. Operation with non-certified computers or

non-shielded cables may result in interference to radio or television reception.

Changes and modifications not expressly approved by the manufacturer could void the user’s authority to

operate this equipment.

European Community Compliance Statement (Class B)

This product is conformity with the protection requirements of EU Council Directives 89/336/EEC

amended by 92/31/EEC on the laws of the Member States relating to electromagnetic compatibility.

Warning - This is a Class B product. In a domestic environment this product may cause radio interference in

which case the user may be required to take adequate measures to correct this interference.

DISCLAIMER

No warranty or representation, either expressed or implied, is made with respect to the contents of this

documentation, its quality, performance, merchantability, or fitness for a particular purpose. Information

presented in this documentation has been carefully checked for reliability; however, no responsibility is

assumed for inaccuracies. The information contained in this documentation is subject to change without notice.

In no event will AVerMedia be liable for direct, indirect, special, incidental, or consequential damages arising out

of the use or inability to use this product or documentation, even if advised of the possibility of such damages.

TRADEMARKS

AVerMedia is registered trademarks of AVerMedia TECHNOLOGIES, Inc. IBM PC is a registered trademark of

International Business Machines Corporation. Macintosh is a registered trademark of Apple Computer, Inc.

Microsoft is a registered trademark and Windows is a trademark of Microsoft Corporation. All other products or

corporate names mentioned in this documentation are for identification and explanation purposes only, and

may be trademarks or registered trademarks of their respective owners.

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means

without the written permission of AVerMedia TECHNOLOGIES, Inc.

The mark of Crossed-out wheeled bin indicates that this product must not be disposed of with your

other household waste. Instead, you need to dispose of the waste equipment by handing it over to

a designated collection point for the recycling of waste electrical and electronic equipment. For

more information about where to drop off your waste equipment for recycling, please contact your

household waste disposal service or the shop where you purchased the product.

Battery Safety Information

-Store the batteries in a cool dry place.

-Do not dispose of used batteries in domestic waste. Dispose of batteries at special collection points or

return to point of sale if applies.

-Remove the batteries during long periods of non-use. Always remove exhausted batteries from the

remote control. Battery leakage and corrosion can damage this remote control, dispose of batteries

safely.

-Do not mix old and new batteries.

-Do not mix different types of batteries: alkaline, standard (carbon-zinc) or rechargeable

(nickel-cadmium).

-Do not dispose of batteries in a fire. The batteries may explode or leak.

-Never short circuit the battery terminals.

WARNING

TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE

CAUTION

IF THERE IS ANY DAMAGE, SHORTAGE OR INAPPROPRIATE

ITEM IN THE PACKAGE, PLEASE CONTACT WITH YOUR LOCAL

DEALER. WARRANTY VOID FOR ANY UNAUTHORIZED

PRODUCT MODIFICATION

NOTICE

-INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE

WITHOUT NOTIEC.

-THE INFORMATION CONTAINED HEREIN IS TO BE

CONSIDERED FOR REFERENCE ONLY.

Table of Contents

Chapter 1 Introduction.......................................................................1

1.1 Package Content........................................................................................ 1

1.2 Features and Specifications ....................................................................... 1

1.3 Front Panel ................................................................................................2

1.4 Back Panel.................................................................................................4

1.5 Setting Up the DVR Unit ............................................................................5

1.5.1 Installing the Hard Disk.......................................................................... 5

1.5.2 Connecting Devices............................................................................... 7

1.5.3 Connecting the Sensor/Relay/PTZ Camera device ............................... 7

1.5.3.1 I/O Card Sensor and Relay pinhole allocation: .................................. 8

Chapter 2 Operating the EB1704 HYBRID........................................9

2.1 Familiarizing the Remote Control Buttons.................................................. 9

2.1.1 Using AB Repeat Function................................................................... 11

2.1.2 Using USB Backup Button................................................................... 11

2.1.3 Controlling PTZ Camera...................................................................... 11

2.1.3.1 To Enter the PTZ Mode .................................................................... 12

2.1.3.2 To Set Preset Position...................................................................... 12

2.1.3.3 To Control PTZ Camera ................................................................... 12

2.2 Using the EB1704 Hybrid for the First Time ............................................. 13

2.2.1 Set up the System Date and Time ....................................................... 13

2.3 Surveillance Screen ................................................................................. 13

2.4 Playback the Video .................................................................................. 15

Chapter 3 OSD Navigation Tree.......................................................17

3.1 Menu Function ......................................................................................... 18

Chapter 4 Using the USB Playback Console .................................30

4.1 Recommended system requirements....................................................... 30

4.2 Installing the USB Playback Console ....................................................... 30

4.3 Running the USB Playback Console........................................................ 31

4.3.1 To Cut and Save the Portion of the Recorded Video ........................... 33

4.3.2 Playback DVR Recorded File from Hard Disk ..................................... 33

4.3.3 Playback Backup File(*.dvr)................................................................. 33

Chapter 5 Backup Recorded Video File..........................................35

5.1 Recommended system requirements....................................................... 35

5.2 Familiarizing with HDD Backup Application.............................................. 35

5.3 To Backup Recorded Video File ............................................................... 36

Chapter 6 ImageVerification ............................................................37

6.1 To Run the ImageVerification ................................................................... 37

Chapter 7 i-Enhance.........................................................................38

7.1 To Use i-Stable ......................................................................................... 39

Chapter 8 Using the Remote Programs..........................................40

8.1 Familiarizing the Web Viewer Buttons...................................................... 41

8.1.1 To Setup Remote System Setting........................................................ 43

8.1.1.1 System Setup................................................................................... 43

8.1.1.2 Camera Setup.................................................................................. 44

8.1.1.3 Record Setup ...................................................................................46

8.1.1.4 Alarm/Sensor Setup......................................................................... 47

8.1.1.5 Network Setup .................................................................................49

8.1.1.6 Password Change............................................................................ 50

8.2 Familiarizing the Remote Console Buttons .............................................. 51

8.2.1 To Setup Remote Console Setting....................................................... 51

8.3 Familiarizing the WebViewer PTZ Buttons ............................................... 53

8.4 Using the Remote Playback..................................................................... 53

8.4.1 Familiarizing the Local Playback Buttons ............................................ 55

8.4.1.1 To Cut and Save the Wanted Portion of the Recorded Video........... 56

8.4.2 Familiarizing the Download and Playback Buttons .............................. 57

Chapter 9 Using Central Managment System................................58

9.1 Software Installation ................................................................................. 58

9.1.1 Minimum System Requirements.......................................................... 59

9.2 Installing the CM3000 and Drivers in Windows XP/2000 ......................... 59

9.3 Using the CM3000 ................................................................................... 60

9.3.1 Running the CM3000 Software............................................................ 60

9.3.2 Using the CMS Application .................................................................. 60

9.4 Customizing the CMS System ................................................................. 63

9.4.1 System Setting .................................................................................... 63

9.4.1.1 To change the Alarm Record Storage Path ...................................... 63

9.4.1.2 To Set the System to a Different Language...................................... 64

9.4.1.3 To Change the Status Date Format .................................................. 64

9.4.2 DVR Setup........................................................................................... 64

9.4.2.1 To Add and Remove DVR Server..................................................... 65

9.4.3 Camera Setup .....................................................................................65

9.4.4 E-MAP Setup ....................................................................................... 66

9.4.4.1 To Set Up the E-Map........................................................................ 66

9.4.4.2 To Use the E-Map ............................................................................ 69

9.4.5 Alarm Setting ....................................................................................... 70

9.4.5.1 To setup an alarm condition ............................................................. 70

9.4.6 User Setting......................................................................................... 72

9.4.6.1 To Set the User Setting .................................................................... 73

9.5 Using the Playback Function.................................................................... 73

9.5.1 To Playback the video.......................................................................... 73

9.5.2 Using the Local Playback Application .................................................. 74

9.5.3 Using the Remote Playback Application .............................................. 75

9.5.3.1 To Cut and Save the Wanted Portion of the Recorded Video........... 76

9.5.3.2 To Search Using the Visual Search.................................................. 76

9.5.3.3 To Search Using the Event Search .................................................. 77

9.5.3.4 To Search Using the Intelligent Search ............................................ 77

9.5.4 Using the Event Viewer ....................................................................... 78

Appendix A Registering Domain Names .......................................................... 79

Appendix B Dual Monitors setting .................................................................... 80

Graphic card with ATi chipset........................................................................... 80

Graphic card with NVIDIA chipset.................................................................... 82

Chapter 1 Introduction

1.1 Package Content

(1)

RIGHT

LEFT

EBDVR

▼

▲

REC

A-B

MEN

SELECT

ZOO

SPEED

SPEE

FOCU

ZOOM

OWN

FOCUS

▲

▼

RM-H6

▼

PTZ

(2)

AVerMedia

AVerDiGiEB1704Hybrid

QuickInstallationGuide

(3)

(4)

(5)

(6)

(7)

(8)

(1) AVerDiGi EB1704 Hybrid unit

(2) Remote Control (batteries included)

(3) Quick Installation Guide

(4) Power Cord

* The power cord varies depending on the standard power outlet of

the country where it is sold.

(5) Power Adapter

(6) Removable hard disk drawer accessories (with spare screws)

(7) Software CD (User Manual included)

(8) DVR accessories(including 8 screws and 1 Ωhook)

1.2 Features and Specifications

Non-PC hybrid network video recorder

4 composite video inputs and 1 composite output

VGA output for LCD or CRT monitor display

On Screen Display(OSD) control menu

MPEG4 video compression

Auto-detect NTSC or PAL video system

Analog / IP camera/ PTZ camera support (extendable by customer’s

request)

Support 4 channels Analog/IP cameras

Audio support up to 4 channels

Support network time synchronize function (Auto correction time delay &

Day light saving)

Support Web viewer on Internet Explorer

Support Central Management System(CMS)

Support remote console

Support USB backup to pen drive and external hard disk

Support network, playback, and recording simultaneously

Supports 1 hard disk drive (not included)

Full-screen resolution:

Display: 720 x 480 (NTSC) / 720 x 576 (PAL)

Recording: 720 x 480 (NTSC) / 720 x 576 (PAL)

Recording frame rate:

D1 mode: 60fps (NTSC) / 50fps (PAL)

CIF mode: 120 fps (NTSC) / 100fps (PAL)

Scheduled recording (00:00~23:00 set by hour )

Search for recorded video files by date/time/event

Support daylight saving and network time synchronize

Input/Output: 4 sensor inputs and 1 relay output control

Multiple language operation screens

1.3 Front Panel

(1)(11)(10)(9) (2) (3) (4) (6)

(7)

(8)

(5)

(12)

Name Function

(1) Record : Start video recording. To stop recording, press

(2) Menu : Call up and exit the OSD main and sub menu

(3) UP/DOWN/SELECT

: Use the UP and DOWN buttons to change setting and move

to the left and right, and SELECT to enter or make a selection

Use these buttons in playback mode to switch to display each

channel in full screen or view all channels at the same time

Use the buttons in setting password of OSD menu to:

: For ”1”

: For “2”

: For “3”

: For “4”

: For “0”

(4) 1/2/3/4/Quad

If in QUAD record mode, user would not be able to

view single channel in full screen

Use the buttons in playback mode to:

: Display the play list and play the recorded video

:Wind back the video playback at the speed of 2x,

4x, 8x or 16x

(5) Playback/OSD Menu

Control Buttons

:Fast play the video playback at the speed of 2x, 4x,

8x or 16x

Name Function

: Temporarily freeze the video playback

: Stop video playback

Use the buttons in navigating OSD menu to :

 : Move to the left and right

 : Change the setting

: Make a selection

(6) IR Sensor : Receive the signal from the remote control to operate the unit

(7) HDD LED : Indicate running state of the hard disk. Lights when the HDD is

running

(8) DVR Power LED : Lights when the unit is on

(9) Removable HDD

LED

Indicate running state of the removable hard disk. Lights when

the HDD is running

(10) Removable HDD

Power LED

Indicate power of the removable hard disk. Lights when the

HDD power is connected

(11) USB 2.0 Port : Connect to PC for video transfer or playback

Lock/unlock the hard disk rack

Make sure to TURN OFF the unit BEFORE removing

the hard disk

(12) Removable HDD

Keylock

1.4 Back Panel

(1) (2) (3) (4) (5) (6) (10)

)

(8)

)

(11) (12)

Name Function

(1) LAN Port : For Ethernet connection

(2) CH1/2/3/4 Input the video camera signal and display it on channel 1/2/3/4

(3) Audio Out : Output the audio signal to a speaker

The audio output device needs to be powered by

external power.

(4) Audio In : Input the audio signal from a mic or audio output device. The audio

is embedded with channel 1/2/3/4

The audio input device needs to be powered by

external power.

(5) VGA Out : Output the video signal to a CRT or LCD monitor

Output the video signal to a TV(6) Video Out

(BNC)

The DVR unit support 2 video output ports and you can

only select to output the video either from the VGA OUT or

VIDEO OUT

(7) Sensor In : Support up to 4 sensor devices

(8) Alarm Out : Support 1 relay device (Relay: 1A @ 125V AC/30V DC)

(9) RS485 : For PTZ camera connection (also see 1.5.3.1)

(10) TV-VGA : Switch to select the video output. Make sure to set the video output

before turning on the unit

(11) 12V DC : Connect the power adapter into this port

1.5 Setting Up the DVR Unit

1.5.1 Installing the Hard Disk

The DVR unit allows user to install one hard disk. Before installing the hard disk,

make sure to set the hard disk master jumper setting. Adjust the jumper setting

according to the instructions on the hard disk label.

For hard disk spec, please referring to

http://www.avermedia.com/nvd/hardware-recom_eb.asp

The “compatible hard disks” indicated in the above recommendation list only

means that these commercially available hard disks were tested with

AVerMedia®products and functioned well under normal operation conditions.

AVerMedia®does not guarantee or provide warranties, explicitly, implied or

statutory with respect to the reliability of the hard disk function or its

compatibility. In no event AVerMedia®shall be liable for damages, with respect

to any business interruption of clients, lost profits, loss of programs or other

data on your information handling system or otherwise. This includes direct,

indirect, incidental, special, or consequential damages, resulting from the

incompatibility caused by the usage of these hard disks, even if AVerMedia®

has expressly advised about the risk of such damages. The entire risk arising

out of the use of any information attached here with is borne by the recipient.

Follow the illustrated instructions below to install the hard disk:

1. Unlock the removable hard disk

drawer

2. And then, pull out the removable

hard disk drawer

3. Remove the removable rack cover

4. Connect the power connector to the

hard disk

5. Carefully insert the hard disk in the

removable rack then replace the

removable rack cover

6. Slide the drawer back

7. Lock the removable keylock

8. You may now connect all the cables.

When the power is connected, the

Power LED light turns on

1.5.2 Connecting Devices

The back panel of the DVR unit, user can connect up to 4 video cameras, 4 sensor

devices, 1 alarm device and output video to a TV or CRT/LCD monitor. Connecting

the unit to a pen drive or external hard disk through USB connection for backup,

then use the bundled software enables user to transfer, playback and segment the

video. Follow the illustration below to make the connection:

Pen drive/ External hard disk

CRT/LCD Monitor

Microphone

Spearker

Camera 1

Camera 3

PTZ Camera

Internet

Web Viewer

PDA Viewer

CMS

Cente r Moni tor Playbac kEmap

Remote Console

CCTV Monitor

Power

Cord

Power

Outlet

Power

adapter

Camera 2 Camera 4

Sensor

Alarm

Each time you change the video display output, the power must be

turned off and on to reset the DVR unit.

All connected devices need to be powered by external power.

1.5.3 Connecting the Sensor/Relay/PTZ Camera device

The Sensor, Alarm, and PTZ camera ports enable you to connect 4 sensor inputs,

1 relay outputs, and 1 PTZ camera. Just connect the external sensor, relay, and

PTZ camera pin directly to the pinhole. Check the table below and locate which

pinhole is assigned to sensor input and relay output.

1110987654321 121314

Sensor Alarm PTZ Camera

1.5.3.1 Sensor and Relay pinhole allocation:

The signal from the sensor (i.e., infrared sensors, smoke detectors, proximity

sensors, door sensors, etc.) is being transmitted to the unit and this triggers the

system to respond and send signal to relay device (i.e., alarm, telephone etc).

Pin # Definition

1 Sensor 1 Ground signal

2 Sensor 1 signal

3 Sensor 2 Ground signal

4 Sensor 2 signal

5 Sensor 3 Ground signal

6 Sensor 3 signal

7 Sensor 4 Ground signal

8 Sensor 4 signal

9 Relay signal

10 Relay signal

11 RS485 TX+ signal

12 RS485 TX- signal

13 RS485 RX+ signal

14 RS485 RX- signal

Chapter 2 Operating the EB1704 HYBRID

2.1 Familiarizing the Remote Control Buttons

Use the Remote control to operate the OSD menu on surveillance screen.

RIGHTUPLEFT

EB DVR

897

▼

▲

REC

A-B

MENUSELECT

ZOOM

SPEED

FOCUS

ZOOM

DOWNFOCUS

▲

▼

RM-H6

▼

PTZ

(2)

(1)

(3)

(4)

(5)

(6)

(7)

(8)

(9)

(10)

(11)

(22)

(21)

(20)

(19)

(18)

(17)

(12)

(13)

(14)

(15)

(16)

Button Function

(1)

A functional key for multiple DVR system remote control

Switch to Channel 1

(2)
