AVI AVIMX402 User manual

材质: 80克书写纸+双面单黑+打印8页 最后成品尺寸: 105*145MM
红色线框不需要印刷
www.avishop.com
Tel: [phone]
Support: [email protected]
Model: AVIMX402
1 2
3 4
HDMI MATRIX 4x2 SUPPORT 3D 1080P
4x2 HDMI Matrix, Support 3D
Operating Instructions
Dear Customer
Thank you for purchasing thisproduct. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
FEATURES
4 HDMI inputs, 2 HDMI standard outputs.
High Definition Audio support: Dolby TrueHD, and DTS-HD Master Audio.
The 2 HDMI output ports can be from the same or different sources.
Manual or remote select source input signal to different sink.
Auto Signal Enhancement feature can improve signal quality after long
distance transmission.
With remote controller.
High-definition Resolutions support: HDTV-up to 1080p.
Support 3D.
Supports 30/36bit deep color display
NOTICE
Our company reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
TABLE OF CONTENTS
Specifications
Package Contents
Panel Descriptions
Connecting and Operating
Maintenance
Product Service
Warranty
SPECIFICATIONS
Operating Temperature Range -5 to +35℃(+23 to +95℉)
Operating Humidity Range 5 to 90%RH (No Condensation)
Input Video Signal 0.5-1.0 Volts P-P
Input DDC Signal 5 volts p-p(TTL)
Data transfer speed rate 6.75Gbps(Maximum)
Video Format Supported
DTV/HDTV:
480i/576i/480P/576P/720P/1080i/1080P
3D video support
IMDHtuptuOoediV
Support Video Color Format xv-YCC/deep color 36bit
Support Audio Format DTS-HD/true-HD/LPCM7.1/AC3/DTS/DSD
Transmission Distance 15m(Maximum)over standard HDMI cable/26AWG
Power consumption 5watts(Maximum)
Dimension (L×W×H) 115x60x32mm
g542thgieWteN
Note: Specifications are subject to change withoutnotice. Mass and
dimensions are approximate.
PACKING CONTENTS
1) Main Unit. 4x2 HDMI Matrix
2) 5VDC 2A Power Supply.
3) Operating Instructions
4) Remote Controller
PANEL DESCRIPTIONS
Front Panel
Remote
1) IR Receiver
2) Output B Select Button: Press the "Switch B" button to switch signal source
from input 1 to 4.
3) Output A Select Button: Press the "Switch A" button to switch signal source from
input 1 to 4
4) Indicator of HDMI output B:A red LED light will illuminate when output B works.
5) Indicator of HDMI output A:A blue LED light will illuminate when output A works.
Left Panel Rear panel Right Panel
6) Indicator of OutputB's Input source: The corresponding red LED light will
illuminate according to which input you connect.
7) Indicator of OutputA's input source: The corresponding blue LED light will
illuminate according to which input you connect.
8) Output A port
9) Power input
10) Input ports
11) Output B port

材质: 80克书写纸+双面单黑+打印8页 最后成品尺寸: 105*145MM
红色线框不需要印刷
5 6
7
A/V Integration, Inc
www.avishop.com
Tel: [phone]
Support: [email protected]
Address: 9950 Westpark Dr 126 Houston TX 77063 USA
Connecting and Operating
1).Connect the HDMI signal sources (Such as PS3, STB etc) into HDMI input.
2).Connect the cables from your displays (monitor or projector) into the HDMI
outs of the output A and output B.
3).Plug the 5VDC power supply into Power input and the unit is ready to use.
4).Use the remote controller or press buttons to select input signal source for
output A and output B
Attention: Insert/Extract cable gently.
Please reset power when there is no signal.
Mail-In Service
When shipping the unit carefully pack and send it prepaid, adequately insured and
preferably in the original carton. Include a letter detailing the complaint and provide a
day time phone and/or email address where you can be reached.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
1) This Limited Warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage.
The Limited Warranty ALSO DOES NOT COVER damages which occurred in
shipment, or failures which are caused by products not supplied by warrantor, or
failures which result from accidents, misuse, abuse, neglect, mishandling,
misapplication, alteration, faulty installation, set-up adjustments, misadjustment of
consumer controls, improper maintenance, power line surge, lightning damage,
modification, or service by anyone other than a Factory Service center or other
Authorized Servicer, or damage that is attributable to acts of God.
2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
"LIMITED WARRANTY COVERAGE".THE WARRANTOR IS NOT LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF
THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRNTY. (As
examples, this excludes damages for lost time, cost of having someone remove or
re-install an installed unit if applicable, travel to and from the service, loss of or
damage to media or images, data or other recorded content. The items listed are not
exclusive, but are for illustration only.
3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
WARRANTY
If your product does not work properly because of a defect in materials or
workmanship, our Company (referred to as "the warrantor" ) will , for the length of the
period indicated as below, (Parts(2)Years ,Labor(90) Days) which starts with the date
of original purchase ("Limited Warranty period"), at its option either(a) repair your
product with new or refurbished parts, or (b) replace it with a new of a refurbished
product. The decision to repair or replace will be made by the warrantor.
During the "Labor" Limited Warranty period there will be no charge for labor.
During the "Parts" warranty period, there will be no charge for parts. You must mail-in
your product during the warranty period. This Limited Warranty is extended only to the
original purchaser and only covers product purchased as new. A purchase receipt or
other proof of original purchase date is required for Limited Warranty service.
PRODUCT SERVICE
1) Damage requiring service: The unit should be serviced by qualified service
personnel if:
(a)The DC power supply cord or AC adaptor has been damaged;
(b)Objects or liquids have gotten into the unit;
(c)The unit has been exposed to rain;
(d)The unit does not operate normally or exhibits a marked change in performance;
(e)The unit has been dropped or the cabinet damaged.
Servicing Personnel: Do not attempt to service the unit beyond that described in
these operating instructions. Refer all other servicing to authorized servicing
personnel.
2) Replacement parts: When parts need replacing ensure the servicer uses parts
specified by the manufacturer or parts that have the same characteristics as the
original parts. Unauthorized substitutes may result in fire, electric shock, or other
hazards.
3) Safety check: After repairs or service, ask the servicer to perform safety checks to
confirm that the unit is in proper working condition.
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean
this unit.
