Model: AVISW4K501
1 2
3 4
HDMI SWITCH 5x1 SUPPORT 3D 4K @30Hz
PRODUCT SERVICE
1) Damage requiring service: The unit should be serviced by qualified service
personnel if:
(a)The DC power supply cord or AC adaptor has been damaged;
(b)Objects or liquids have gotten into the unit;
(c)The unit has been exposed to rain;
(d)The unit does not operate normally or exhibits a marked change in performance;
(e)The unit has been dropped or the cabinet damaged.
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean
this unit.
5x1 HDMI Switch with remote, Support 3D, 4K2K
Operating Instructions
Dear Customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
FEATURES
Select one of 5 different HDMI Signal input sources and switch to 1 HDMI display.
Manual or with remote controller to select input signals.
Resolution reach up to 4k@60hz YUV 4:2:0.
Support 36bit deep color display.
Support High Definition Audio: Dolby TrueHD, DTS-HD Master Audio.
Support Resolution up to Ultra HD 4Kx2K@30Hz, Full HD 1080p.
Support CEC.
Support 3D.
NOTICE
Our company reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
TABLE OF CONTENTS
Specifications
Package Contents
Panel Descriptions
Connecting and Operating
Maintenance
Product service
Warranty
SPECIFICATIONS
Operating Temperature Range -5 to +35℃(+23 to +95℉)
Operating Humidity Range 5 to 90%RH (No Condensation)
Input Video Signal 0.5-1.0 Volts P-P
Input DDC Signal 5 volts p-p(TTL)
Support Video format 4Kx2K/1080P/1080i/720P/576P/576i/480P/480i
3D video
Support Video Color Format xv-YCC/deep color 36bit
Support Audio Format DTS-HD Master Audio、Dolby true-HD etc.
Data transfer speed rate 10.2Gbps(Maximum)
Power consumption 1.5watts(Maximum)
Dimension (L×W×H) 115x62x25mm
g212thgieWteN
Note:
Specifications are subject to change without notice. Mass and dimensions are
approximate.
PACKING CONTENTS
1) Main Unit. Mini 5*1 HDMI switch
2) DC 5V1A Power Supply.
3) Operating Instructions,
4) Infrared Remote Controller
PANEL DESCRIPTIONS
Front Panel Right Panel
Back Panel Right Panel
1) HDMI input ports 2) Power input3) Indicator of Power input
4) Input Select Button 5) IR Receiver 6) Indicator of HDMI Input
7) Indicator of HDMI output. 8) HDMI output port
Connecting and Operating
1) Connect the HDMI signal sources (Such as PS3, STB etc) into HDMI input.
2) Connect the HDMI display device (such as: HD-LCD, HD-DLP) into HDMI output.
3) Connect 5V DC power to the HDMI Switch.
Attention: Insert/Extract cable gently

材质: 80克书写纸+双面单黑+打印8页 最后成品尺寸: 105*145MM
红色线框不需要印刷
5 6
7
A/V Integration, Inc
www.avishop.com
Tel: [phone]
Support: [email protected]
Address: 9950 Westpark Dr 126 Houston TX 77063 USA
LIMITED WARRANTY LIMITS AND EXCLUSIONS
1) This Limited Warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage.
The Limited Warranty ALSO DOES NOT COVER damages which occurred in
shipment, or failures which are caused by products not supplied by warrantor, or
failures which result from accidents, misuse, abuse, neglect, mishandling,
misapplication, alteration, faulty installation, set-up adjustments, misadjustment of
consumer controls, improper maintenance, power line surge, lightning damage,
modification, or service by anyone other than a Factory Service center or other
Authorized Servicer, or damage that is attributable to acts of God.
2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
"LIMITED WARRANTY COVERAGE".THE WARRANTOR IS NOT LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF
THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRNTY. (As
examples, this excludes damages for lost time, cost of having someone remove or
re-install an installed unit if applicable, travel to and from the service, loss of or
damage to media or images, data or other recorded content. The items listed are not
exclusive, but are for illustration only.
3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
Mail-In Service
When shipping the unit carefully pack and send it prepaid, adequately insured and
preferably in the original carton. Include a letter detailing the complaint and provide a
day time phone and/or email address where you can be reached.
WARRANTY
If your product does not work properly because of a defect in materials or
workmanship, our Company (referred to as "the warrantor" ) will , for the length of the
period indicated as below, (Parts(2)Years ,Labor(90) Days) which starts with the date
of original purchase ("Limited Warranty period"), at its option either(a) repair your
product with new or refurbished parts, or (b) replace it with a new of a refurbished
product. The decision to repair or replace will be made by the warrantor.
During the "Labor" Limited Warranty period there will be no charge for labor.
During the "Parts" warranty period, there will be no charge for parts. You must mail-in
your product during the warranty period. This Limited Warranty is extended only to the
original purchaser and only covers product purchased as new. A purchase receipt or
other proof of original purchase date is required for Limited Warranty service.
Servicing Personnel: Do not attempt to service the unit beyond that described in
these operating instructions. Refer all other servicing to authorized servicing
personnel.
2) Replacement parts: When parts need replacing ensure the servicer uses parts
specified by the manufacturer or parts that have the same characteristics as the
original parts. Unauthorized substitutes may result in fire, electric shock, or other
hazards.
3) Safety check: After repairs or service, ask the servicer to perform safety checks to
confirm that the unit is in proper working condition.
