Avigilon 2.0C-H6X-B User manual







InstallationGuide
AvigilonH6XBoxCameraModels:
2.0C-H6X-B 6.0C-H6X-B  
4.0C-H6X-B 8.0C-H6X-B  

2
LegalNotices
©2024,AvigilonCorporation.Allrightsreserved.AVIGILON,theAVIGILONlogo,AVIGILONCONTROL
CENTER,andACCaretrademarksofAvigilonCorporation.ONVIFisatrademarkofOnvif,Inc.Coveredbyoneor
moreclaimsofthepatentslistedatpatentlist.hevcadvance.com.Othernamesorlogosmentionedhereinmaybe
thetrademarksoftheirrespectiveowners.Theabsenceofthesymbols™and®inproximitytoeachtrademarkin
thisdocumentoratallisnotadisclaimerofownershipoftherelatedtrademark.
Disclaimer
Thisdocumenthasbeencompiledandpublishedusingproductdescriptionsandspecificationsavailableatthetime
ofpublication.Thecontentsofthisdocumentandthespecificationsoftheproductsdiscussedhereinaresubjectto
changewithoutnotice.AvigilonCorporationreservestherighttomakeanysuchchangeswithoutnotice.Neither
AvigilonCorporationnoranyofitsaffiliatedcompanies:(1)guaranteesthecompletenessoraccuracyofthe
informationcontainedinthisdocument;or(2)isresponsibleforyouruseof,orrelianceon,theinformation.Avigilon
Corporationshallnotberesponsibleforanylossesordamages(includingconsequentialdamages)causedby
relianceontheinformationpresentedherein.
AvigilonCorporation
avigilon.com
PDF-H6X-B
Revision:1-EN
20240131

3
ImportantSafetyInformation
WARNING
Failuretoobservethefollowinginstructionsmayresultinsevereinjuryordeath.
lInstallationmustbeperformedbyqualifiedpersonnelonly,andmustconformtoalllocalcodes.
lAnyexternalpowersupplyconnectedtothisproductmayonlybeconnectedtoanotherAvigilonproductof
thesamemodelseries.Externalpowerconnectionsmustbeproperlyinsulated.
lDonotconnectdirectlytomainspowerforanyreason.
CAUTION
Failuretoobservethefollowinginstructionsmayresultininjurytopersonsordamagetothe
device.
lDonotexposethecameradirectlytohighlevelsofx-ray,laser,orUVradiation.Directexposuremaycause
permanentdamagetotheimagesensor.
lDonotinstallnearanyheatsourcessuchasradiators,heatregisters,stoves,orothersourcesofheat.
lDonotsubjectthedevicecablestoexcessivestress,heavyloadsorpinching.
lDonotopenordisassemblethedevice.Therearenouserserviceableparts.
lReferalldeviceservicingtoqualifiedpersonnel.Servicingmayberequiredwhenthedevicehasbeen
damaged(suchasfromaliquidspillorfallenobjects),hasbeenexposedtorainormoisture,doesnot
operatenormally,orhasbeendropped.
lDonotusestrongorabrasivedetergentswhencleaningthedevicebody.
lUseonlyaccessoriesrecommendedbyAvigilon.

4
RegulatoryNotices
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)this
devicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
ThisClassBdigitalapparatuscomplieswithCanadianICES-003(B)/NMB-3(B).
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15
oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceina
residentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalled
andusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.However,
thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful
interferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuser
isencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
lReorientorrelocatethereceivingantenna.
lIncreasetheseparationbetweentheequipmentandreceiver.
lConnecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
lConsultthedealeroranexperiencedradio/TVtechnicianforhelp.
ChangesormodificationsmadetothisequipmentnotexpresslyapprovedbyAvigilonCorporationorparties
authorizedbyAvigilonCorporationcouldvoidtheuser’sauthoritytooperatethisequipment.
TomeettherequirementsoftheEN50121-4RailwayApplicationsStandard,useanexternalpowersupplyorPOE
injectorthatisalsocompliantwithEN50121-4.PleasecontactAvigilonforassistanceregardingsupporting
equipment.
TomeettherequirementsoftheEN50130-4AlarmSystemsApplicationsstandard,useanexternaluninterruptible
powersupply(UPS).
Thisequipmentcontainsacoincellbattery.Riskoffire,explosion,andburns.Donotdisassemble,crush,heat
above100°C(212°F),orincinerate.
TheuseofEMCcompliantsupportandauxiliaryequipmentwiththisdeviceisrequiredinordertofullycomplywith
theEMCregulatorystandards.
ThisproductisintendedtobesuppliedbyaULListedPowerUnitmarked“Class2”or“LPS”or“LimitedPower
Source”withoutputrated12-24VDC,13Wmin.orPoweroverEthernet(PoE),13Wmin.

5
ForKorea
DisposalandRecyclingInformation
Whenthisproducthasreachedtheendofitsusefullife,pleasedisposeofitaccordingtoyourlocalenvironmental
lawsandguidelines.
EuropeanUnion:
Thissymbolmeansthataccordingtolocallawsandregulationsyourproductshouldbedisposedofseparatelyfrom
householdwaste.Whenthisproductreachesitsendoflife,takeittoacollectionpointdesignatedbylocal
authorities.Somecollectionpointsacceptproductsforfree.Theseparatecollectionandrecyclingofyourproductat
thetimeofdisposalwillhelpconservenaturalresourcesandensurethatitisrecycledinamannerthatprotects
humanhealthandtheenvironment.

6
TableofContents
Overview 7
FrontView 7
RearView 8
InstallationSteps 9
RequiredToolsandMaterials 9
CameraPackageContents 9
InstallationSteps 9
MountingtheCamera 9
ConnectingCables 10
InitializingaCameraUsernameandPassword 10
(Optional)UsingtheUSBWi-FiAdapter 11
AssigninganIPAddress 11
AccessingtheLiveVideoStream 12
AimingandFocusingtheCamera 12
(Optional)ConfiguringmicroSDCardStorage 13
ConfiguringtheCamera 13
CableConnections 14
ConnectingExternalPower 14
SeamlessFailover 14
ConnectingtoExternalDevices 15
ConnectionStatusLEDIndicator 16
TroubleshootingNetworkConnectionsandLEDBehavior 16
ResettingtoFactoryDefaultSettings 17
SettingtheIPAddressUsingtheARP/PingMethod 18
ForMoreInformation 19
LimitedWarrantyandTechnicalSupport 20

Overview 7
Overview
FrontView
1. Cameramounts
Providesmountingpointsforthecamera.Mountsaccept1/4”-20x5/16"maxthreadUNCboltscommonly
foundontripodsandmountingbrackets.
2. iCS/CSplugport
AcceptsconnectiontoaiCSorCSlens.
3. Serialnumbertag
Deviceinformation,productserialnumberandpartnumberlabel.

Rear View 8
RearView
1. I/Oconnectorblock
Providesconnectionstoexternalinput/outputdevices.
2. Ethernetport
AcceptsanEthernetconnectiontoanetwork.Servercommunicationandimagedatatransmissionoccurs
overthisconnection.AlsoreceivespowerwhenitisconnectedtoanetworkthatprovidesPowerover
Ethernet.
3. USB-Cport
AcceptsaUSB-Cadapter.OnlyrequiredwhenusingtheUSBWi-FiAdapter.
4. LEDindicators
GreenLEDprovidesinformationaboutdeviceoperation.
AmberLEDindicatesifthereisanactiveconnectionintheEthernetport.
Formoreinformation,see ConnectionStatusLEDIndicator onpage16.
5. microSDcardslots
AcceptmicroSDcardsforonboardstorage.
6. Powerconnectorblock
AcceptsaterminalblockwitheitheranACorDCpowerconnection.DCinputcanbeeitherpolarity.Only
requiredwhenPoweroverEthernetisnotavailable.

Installation Steps 9
InstallationSteps
Completethefollowingsectionstoinstallthedevice.
RequiredToolsandMaterials
lSmallslottedscrewdriverwith5/64”or2mmbladewidth—forconnectingpowerwhennotusingPowerover
Ethernet.
lMountingbracket,enclosureortripod.
CameraPackageContents
lAvigilonH6XBoxCamera
InstallationSteps
Completethefollowingsectionstoinstallthedevice.
MountingtheCamera
Cameramountingpointsareprovidedonboththetopandbottomofthecamerabody.Usethesemountingpointsto
mountthecameraonabracket,inanenclosure,oronatripod.Themountingpointshave¼”-20UNCthreaded
holeswhichallowthemtoacceptstandardphotographicmountingbolts.
Consulttheinstallationinstructionsprovidedwiththebracket,enclosureortripodfordetailedmountinginstructions.

Connecting Cables 10
WARNING
UseonlyUL-listedmountingbracketsuitableforthemountingsurfaceandminimum0.7kg(1.6
lb)weight.
ConnectingCables
RefertothediagramsintheOverviewsectionforthelocationofthedifferentconnectors.
Toconnectthecablesrequiredforproperoperation,completethefollowing:
1. Ifexternalinputoroutputdevicesarepartoftheinstallation(forexample:doorcontacts,relays,etc.),
connectthedevicestotheI/Oconnectorblock.
2. IfusingaCSoriCSlens,confirmthatthecableisconnectedtothe5-pinconnectoronthesideofthe
camera.
3. Connectpowerusingoneofthefollowingmethods:
oPoweroverEthernet(PoE)Class3—IfPoEisavailable,theLEDswillturnon.
oExternalPower—Connectanexternal12-24VDCpowersourcetothepowerconnectorblock.
4. ConnectanetworkcabletotheEthernetport(RJ-45connector).
TheLinkLEDindicatorwillturnononceanetworklinkhasbeenestablished.
5. CheckthattheConnectionStatusLEDindicatorindicatesthecorrectstate.Formoreinformation,see
ConnectionStatusLEDIndicator.
InitializingaCameraUsernameandPassword
IMPORTANT
Youmustcreateauserwith administrator privilegesbeforethecameraisoperational.
Thefirstusercanbecreatedusinganyofthefollowingmethods:
lCamera'sWebInterface:enterthecamera'sIPaddressinawebbrowsertoaccessthewebinterface.Ifthe
cameraisinthefactorydefaultstateyouwillberedirectedtotheAddanewuserpagetocreatethefirstuser.
Formoreinformation,seethe AvigilonIPCameraWebInterfaceUserGuide.
lCameraConfigurationTool:camerasdiscoveredinthefactorydefaultstatewillbeidentifiedby .Selectthe
AdminUserstabtocreatethefirstuser.Formoreinformation,seethe AvigilonCameraConfigurationTool
UserGuide .
lAvigilonUnityVideoorAvigilonControlCentersoftwareversion7.4orlater,orversion6.14.12orlater:when
connectingadeviceinthefactorydefaultstate,theclientsoftwarewillaskyoutocreateanewuser.For
moreinformation,seethe AvigilonUnityVideoClientUserGuide orthe AvigilonControlCenterClientUser
Guide .
lAvigilonCloudServices(ACS)v3.0orlater:whenaddingacamerayouwillbeaskedtocreateanewuser
forcamerasinthefactorydefaultstate.Formoreinformation,seethe AvigilonCloudServicesUserGuide .

(Optional) Using the USB Wi-Fi Adapter 11
TIP
IfyouareconnectingyourAvigiloncameratoa3rdpartyVMS,youwillneedtosetupthefirst
userthroughthecamera'sWebInterfaceorCameraConfigurationToolbeforeyouconnecttothe
3rdpartyVMS.
(Optional)UsingtheUSBWi-FiAdapter
IfyouhaveaUSBWi-FiAdapter(USB-AC56-NA-MSI-BorUSB-AC56-EU-MSI-B),attachittothecamera'sUSB-C
porttoaccessthecamera'smobilewebinterface.
AfteryouconnecttotheWi-Fisignalbroadcastbytheadapter,youcanaccessthemobilewebinterfacefromany
mobiledeviceusingthefollowingaddress:
http://camera.lan
Formoreinformationaboutconfiguringthecamerafromthemobilewebinterfacesee USBWi-FiAdapterSystem
UserGuide .
NOTE
Thecamerawillreservethe10.11.22.32/28subnetforinternalusewhiletheUSBWi-FiAdapteris
pluggedin.
AssigninganIPAddress
ThedeviceautomaticallyobtainsanIPaddresswhenitisconnectedtoanetwork.
NOTE
IfthedevicecannotobtainanIPaddressfromaDHCPserver,itwilluseZeroConfiguration
Networking(Zeroconf)tochooseanIPaddress.WhensetusingZeroconf,theIPaddressisinthe
169.254.0.0/16subnet.
TheIPaddresssettingscanbechangedusingoneofthefollowingmethods:
lDevice'swebbrowserinterface:http://
<cameraIPaddress>/ .
lNetworkVideoManagementsoftwareapplication(forexample,theAvigilonUnityVideosoftware).
lARP/Pingmethod.Formoreinformation,see
SettingtheIPAddressUsingtheARP/PingMethod on
page18.
NOTE
Whenyouloginthefirsttime,thecamerawillbeinafactorydefaultstateandnopasswordis
required.Youmustcreateauserwith administrator privilegesbeforethedeviceisoperational.
Formoreinformation,see InitializingaCameraUsernameandPassword onthepreviouspage.

Accessing the Live VideoStream 12
AccessingtheLiveVideoStream
Livevideostreamcanbeviewedusingoneofthefollowingmethods:
lThemobilewebinterfaceusingtheUSBWiFiAdapter.Formoreinformation,see(Optional)UsingtheUSB
Wi-FiAdapter.
lWebbrowserinterface:http://
<cameraIPaddress>/ .
lNetworkVideoManagementsoftwareapplication(forexample,theAvigilonUnityVideosoftware).
NOTE
Whenyouloginthefirsttime,thecamerawillbeinafactorydefaultstateandnopasswordis
required.Youmustcreateauserwith administrator privilegesbeforethedeviceisoperational.
Formoreinformation,see InitializingaCameraUsernameandPassword onpage1.
AimingandFocusingtheCamera
UsethecamerawebbrowserinterfaceortheAvigilonControlCentersoftwaretoaimandfocusthecamera.
Consultthesoftwareuserguideformoreinformation.
ForiCSlens:
1. IntheImageandDisplaysettingsarea,usetheZoomcontrolstosetthezoompositionforthecamera.
2. Focusthecamera:
a. ClickAutoFocustofocusthelens.
b. Ifthepreferredfocuswasnotachieved,usethefocusnearandfarbuttonstoadjustthefocus.
ForCSlens:
NOTE
ThesestepsshouldbecompletedanytimeaCSlensisinstalledorreplaced.IfaCSlensisnot
firstfocusedcorrectlywithmanualfocusadjustment,AutoFocusmaynotbeabletoperform
automaticfocusing.
1. ConnecttheCSlenstothecameraandthenpowerupthecamera.Thecamerashouldautomaticallydetectit.
2. LoosenthescrewsontheCSlens.
3. Manuallyzoomandfocusthelensbyrotatingtheelements.Continuerotatinguntilthelensisfocusedand
theimageisclear.
4. TightenthescrewsontheCSlens.Ensurethatyoudonotmovethecamerainanywaythatcouldinterfere
withthemanualfocus.
5. NavigatetotheSystempageandclickReinitializeLens.Ensurethatthelensisnotcoveredandthescene
isnotpitchblack.
6. Wait20secondsforinitializationtocomplete.
7. NavigatetotheImageandDisplaysettings.
8. ClickAutoFocustofinishfocusingthelens.Ifthepreferredfocuswasnotachieved,usethefocusnearand
farbuttonstoadjustthefocus.

(Optional) Configuring microSD Card Storage 13
(Optional)ConfiguringmicroSDCardStorage
Tousethecamera’sonboardstoragefeature,youmustinsert1microSDcardintoamicroSDcardslot.Whilethere
aretwomicroSDslots,currentlythecameraonlysupportsasinglemicroSDcardineitherslotforonboardstorage.
ForthelocationofthemicroSDcardslots,see Overview onpage7.
ItisrecommendedthatthemicroSDcardhaveawritespeedofclass10orbetter.IfthemicroSDcarddoesnot
meettherecommendedwritespeed,therecordingperformancemaysufferandresultinthelossofframesor
footage.
1. InsertoneortwomicroSDcardsintotheslotsonthebackofthecamera.DonotremovemicroSDcards
whilethecameraispoweredon.
2. Accessthecamera’swebinterfacetoenabletheonboardstoragefeature.Formoreinformation,seethe
AvigilonIPCameraWebInterfaceUserGuide .
ConfiguringtheCamera
Onceinstalled,useoneofthefollowingmethodstoconfigurethecamera:
lIfyouhaveinstalledmultiplecameras,youcanusetheCameraConfigurationTooltoconfigurecommon
settings.Formoreinformation,seethe CameraConfigurationToolUserGuide .
lIfthecameraisconnectedtotheAvigilonControlCentersystem,youcanusetheclientsoftwareto
configurethecamera.Formoreinformation,seethe AvigilonControlCenterClientUserGuide.
lIfthecameraisconnectedtotheAvigilonUnityVideosystem,youcanusetheclientsoftwaretoconfigure
thecamera.Formoreinformation,seethe AvigilonUnityVideoClientUserGuide .
lIfthecameraisconnectedtoathird-partynetworkmanagementsystem,youcanconfigurethecamera's
specialtyfeaturesinthecamera'swebbrowserinterface.Formoreinformation,seethe AvigilonIPCamera
WebInterfaceUserGuide.

Cable Connections 14
CableConnections
ConnectingExternalPower
IfPoEisnotavailable,thecameraneedstobepoweredthroughtheremovablepowerconnectorblock.Refertothe
diagramsinthisguideforthelocationofthepowerconnectorblock.
Thepowerconsumptioninformationislistedintheproductspecifications.
Toconnectpowertothepowerconnectorblock,completethefollowingsteps:
1. Removethepowerconnectorblockfromthecamera.
2. Removetheinsulationfrom¼”(6mm)ofthepowerwires.Donotnickordamagethewires.
3. Insertthetwopowerwiresintothetwoterminalsonthepowerconnectorblock.Theconnectioncanbemade
witheitherpolarity.
Useasmallslotted(5/64”or2mmbladewidth)screwdrivertoloosenandtightentheterminals.
4. Attachthepowerconnectorblockbackintothecamera.
SeamlessFailover
IfthecamerahaspoweravailablefrombothanexternalAuxpowersupplyandaPoEPSE(PowerSourcing
Equipment)device,thecamerawilldrawpowerfromAux.Intheeventthatthecameralosespowerfromthe
preferredAuxpowersupplyitcantransitiontodrawingpowerfromthePoEPSEdevice.
ThiscameraiscapableofSeamlessFailover,allowingthecameratotransitionbetweenPoEandauxiliarypower
sourceswithoutanyinterruptionofcameraoperationorvideorecording.Thisismainlyusefulifyouwantredundant
powersourcessothatbackuppowerwillbeavailableifonepowersourcegoesdown.

Connecting to External Devices 15
ConnectingtoExternalDevices
ExternaldevicesareconnectedtothecamerathroughtheI/Oterminalblock.ThepinoutfortheI/Oterminalblockis
showninthefollowingdiagram:
Figure1:Exampleapplication.
1. DigitalOutput
2. Ground
3. DigitalInput
4. VoltageOutput(Max50mA)
5. AudioGround
6. AudioInput(linelevel)
7. AudioOutput(linelevel)
8. RS-485B—InvertingRS-485pinforcontrollingexternalequipment.
9. RS-485A—Non-invertingRS-485pinforcontrollingexternalequipment.
l0—ExternalDevice
l*—Relay
l**—Switch
lM—Microphone
lS—Speaker

Connection Status LED Indicator 16
ConnectionStatusLEDIndicator
Onceconnectedtothenetwork,thegreenConnectionStatusLEDindicatorwilldisplaytheprogressinconnecting
totheNetworkVideoManagementsoftware.
ThefollowingtabledescribeswhattheLEDindicatorshows:
ConnectionState ConnectionStatus
LEDIndicator
Description
Obtaining
IPAddress
Oneshortflash
everysecond
AttemptingtoobtainanIPaddress.
Discoverable Twoshortflashes
everysecond
ObtainedanIPaddressbutnotconnectedtotheNetworkVideo
Managementsoftware.
UpgradingFirmware Twoshortflashes
andonelongflash
everysecond
Updatingthefirmware.
Connected On ConnectedtotheNetworkVideoManagementsoftware,aUnity
VideoServer,oranACC™Server.Thedefaultconnectedsetting
canbechangedtoOffusingthecamera'swebuserinterface.For
moreinformationseethe AvigilonIPCameraWebInterfaceUser
Guide .
TroubleshootingNetworkConnectionsandLEDBehavior
NOTE
ForanyofthebelowLEDbehaviors,ensurethatthecameraisgettingpowerandisusingagood
networkcablebeforetryinganothersolution.
LEDBehavior SuggestedSolution
GreenLEDisoffandamberison Performafactoryresetofthecamerausingthephysicalfirmware
revertbutton.Resettingthroughthecamera'swebinterfacewillnot
producethedesiredresult.
BothLEDsareoffandthecameraisnot
connectedorstreamingvideo
ChecktheGeneralsetuppageinthecamera'swebinterfaceto
ensuretheLEDsarenotdisabled.
IftheLEDsarenotdisabled,performafactoryresetofthecamera
usingthephysicalfirmwarerevertbutton.Resettingthroughthe
camera'swebinterfacewillnotproducethedesiredresult.
BothLEDsareblinkingseveraltimesatthe
sametime,thenpauseandrepeatthe
blinking
Performafactoryresetofthecamerausingthephysicalfirmware
revertbutton.Resettingthroughthecamera'swebinterfacewillnot
producethedesiredresult.
AdifferentLEDblinkingpatternthanthose
describedabove
Performafactoryresetofthecamerausingthephysicalfirmware
revertbutton.Resettingthroughthecamera'swebinterfacewillnot
producethedesiredresult.

Resetting to Factory Default Settings 17
ResettingtoFactoryDefaultSettings
Ifthedevicenolongerfunctionsasexpected,youcanchoosetoresetthedevicetoitsfactorydefaultsettings.
Usethefirmwarerevertbuttontoresetthedevice.Thefirmwarerevertbuttonisshowninthefollowingdiagram:
ResettingthecamerawillnotaffectvideothathasbeenrecordedtothemicroSDcard.
Figure2:Thefirmwarerevertbuttonontherearofthecamera
1. Ensurethedeviceispoweredon.
2. Usingastraightenedpapercliporsimilartool,gentlypressandholdthefirmwarerevertbutton.
3. Releasethebuttonafterthreeseconds.
CAUTION
Donotapplyexcessiveforce.Insertingthetooltoofarmaydamagethecamera.

Setting the IP Address Using the ARP/Ping Method 18
SettingtheIPAddressUsingtheARP/PingMethod
NOTE
TheARP/PingMethodwillnotworkiftheDisablesettingstaticIPaddressthroughARP/Ping
methodcheckboxisselectedinthecamera'sdevice'swebbrowserinterface.Formore
information,seethe AvigilonIPCameraWebInterfaceUserGuide .
CompletethefollowingstepstoconfigurethecameratouseaspecificIPaddress:
1. LocateandmakenoteoftheMACAddress(MAC)listedontheSerialNumberTagforreference.
2. OpenaCommandPromptwindowandenterthefollowingcommands:
a. arp -s <NewCameraIPAddress><CameraMACAddress>
Forexample:arp -s 192.168.1.10 00-18-85-12-45-78
b. ping -l 123 -t <NewCameraIPAddress>
Forexample:ping -l 123 -t 192.168.1.10
3. Rebootthecamera.
4. ClosetheCommandPromptwindowwhenyouseethefollowingmessage:
Reply from <New Camera IP Address>: ...

For More Information 19
ForMoreInformation
Additionalinformationaboutsettingupandusingthedeviceisavailableinthefollowingguides:
l
AvigilonControlCenterClientUserGuide
l
AvigilonIPCameraWebInterfaceUserGuide
l
CameraConfigurationToolUserGuide
l
DesigningaSitewithAvigilonVideoAnalytics
Theseguidesareavailableonhelp.avigilon.comandontheAvigilonwebsite:avigilon.com/support.

Limited Warranty and Technical Support 20
LimitedWarrantyandTechnicalSupport
Avigilonwarrantytermsforthisproductareprovidedatavigilon.com/warranty.
WarrantyserviceandtechnicalsupportcanbeobtainedbycontactingAvigilonTechnicalSupport:
avigilon.com/contact.
