Avipas AV-POE4 User manual

Model: AV-POE4
4-port PoE Switch
User Guide
V1.0
Please read this user guide
thoroughly before using.
www.avipas.com

Preface
Thank you for choosing AViPAS PoE Switch AV-POE4.
This guide introduces the functions, installation process and operation of AV-POE4. Prior to
installation and usage, please read the guide thoroughly.
Precautions
▪To reduce the risk of fire, electric shock, or damage to the product, when installing, operating,
and maintaining the equipment, follow the safety precautions described in the guide. “Warnings” and
“notes” in this guide do not represent all safety precautions that should be followed.
▪When using this equipment, the user must read through all the relevant precautions and special
safety instructions provided in this guide and on www.avipas.com. The "safety warnings" listed in the guide
only reflect of some the requirements. AViPAS will not bear any responsibilities for the loss caused by
violation of general safety operation requirements.
Installation environment requirements
▪This device needs to be installed on desktop, or to be wall-mounted, or 19’’rack-mounted.
▪Temperature and humidity of the installation site must be kept within the working range.
Please refer to the data sheet for the normal working temperature range and relative humidity range of PoE
devices.
▪Grounding is essential for the installation process. Correct wiring of the grounding cable
protects the PoE device from lightning, high-voltage surge, interference, and static electricity.
Lightning protection requirements
▪Do not use outdoor overhead (open) wiring. The equipment may be damaged by lightning.
Please use buried or steel pipe wiring.
▪The fiber media converter must be grounded before being powered on to ensure that the
grounding resistance of the installation environment does not exceed 10Ω, otherwise the equipment may be
damaged.

Product Specifications
▪DC Input: DC 52V 1.25A
▪Port Max: 30W, Total: 65W
▪PoE Output: IEEE 802.3af/at
▪4x PoE+ (802.3at/af) 10/100/1000 Mbps RJ45 ports (unmanaged)
▪1x Gigabit Non-PoE Port for high-speed connections
Product installation
Installation instructions
▪Please select a suitable installation location or cabinet according to the safety recommendation.
▪When installing the PoE device, the user needs to choose matching mounting accessories.
▪Please wear protective gloves when installing.
▪Do NOT install the PoE device with its power on.
Installation tools
▪Labor protection gloves
▪Plum screwdriver
▪Flat screwdriver
Installation steps
▪Desktop installation
Step 1: Place the PoE device on an even desktop. Make sure that at least 10cm of space is reserved on
both sides of the PoE device (the vents), shown in Picture 1, so that the PoE device can be well ventilated.

Connect the devices
PoE Switch connection diagram
Caution:
▪Before installing or removing the PoE switch, power must be disconnected. Operating the PoE
switch with its power on is prohibited to prevent injury or damage to the device.
▪Make sure that the protective ground wire of each device is securely grounded. All power
cables must NOT have any open parts exposed in the air.
Checklist after installation
▪All mounting parts (hanging ears and screws) are secured.
▪Polarity of all cable connections is correct.
▪Wiring between each two devices is correct and secured. Make sure there is no short circuit.
▪Power on and see if the self-check process is performed normally.
▪Indicator lights on the PoE device are in the correct working mode.

Indicator lights and button/switch function table
Symbol
Function
State
Description
Color
PWR
Work
indicator
On
Normal
Green
Off
Switch has no power supply or initialization failure
PoE
PoE
On
Normal
Green
Blink
PD device failure or power overload
Off
No connected PD or switch has no power
Link
Network
On
Link is established and ready to use
Yellow
Blink
Link port is receiving/sending data
Off
Link failure or port failure
Function switches
E: default OFF. Can support 100m power supply and communication; when dial E is set to ON, the switch
can support 10M/250m long-distance power supply and communication, however, 4 PoE ports are isolated
from each other. There will be no communication between PoE ports.
D: default OFF. After communication between ports is interrupted, the connection won’t be reestablished
automatically. The user needs to manually enter IP addresses to connect devices again; when dial D is set to
ON, communication can be resumed automatically once the interrupted connection is reestablished.
P: default ON. PoE power indicator light will light up in different colors. Power consumption≤25% (green
block), 25%<P≤50% (yellow block), 50%<P≤75% (orange block), P>75% (red block); Port 1 has the top
priority regarding the power output.

Warranty
Thank you for your interest in the products of AVIPAS Inc.
This Limited Warranty applies to PoE devices purchased from AVIPAS Inc.
This Limited Warranty covers any defect in material and workmanship under normal use within the
Warranty Period. AVIPAS Inc. will repair or replace the qualified products at no charge.
AVIPAS Inc. provides a two (2)-year warranty (from the date of purchase) for PoE devices.
This Limited Warranty does not cover problems including but not limited to: improper handling,
malfunction or damage not resulting from defects in material.
To receive warranty service, please contact AVIPAS Inc. first. We will decide whether a repair or
replacement is needed and will advise you of the cost of such repair or replacement.
Copyright Notice
All contents of this manual, whose copyright belongs to our corporation cannot be cloned, copied or
translated without the permission of the company. Product specifications and information which were
referred to in this document are for reference only. We may alter the content at any time and without
prior notice.
VER: 2021-9-27 (EN)
