Avital AviStart 6500 User manual

AviStart 6500 Owner's Manual - 110698 Rev. B

AviStart 6500 Owner's Manual - 110698 Rev. B
IWARNING I
!Always exercise caution and common sense when operating
your AviStart system.
!This product is intended for vehicles with fuel-injection and
automatic transmissions only. NEVER attempt to remote start
a vehicle with a manual (stick shift) transmission. Serious
injury may occur with improper use.
!NEVER attempt to remote start the engine while anyone
(including pets) is in the vehicle.
!NEVER attempt to remote start the engine while the vehicle is
in an enclosed area without sufficient ventilation.
!NEVER attempt to remote start the engine while the keys are
in the ignition.
!Always be sure the gearshift selector is in "Park" and the
emergency brake is on before attempting to remote start the
vehicle.
!Keep your AviStart remote controls out of the reach of
children.
!Whenever the vehicle is being serviced or valet parked, place
the system in Protected Valet Mode to prevent accidental or
unauthorized remote starting. See "Protected Valet Mode" on
page 6.

Table of Contents
AviStart 6500...............................2
Lifetime Warranty............................2
Remote Controls ............................2
Stealth CodingTechnology.......................3
Electronic Scan Prevention (ESP).....................3
Instant Remote Control Code Deletion..................3
One-Step Remote Control Code Learning................3
Valet Switch...............................3
Operating Your AviStart..........................4
To Arm The System ...........................4
Remote-Controlled Silent Arm/Disarm .................4
User-Programmable Long-Term Silent Arm/Disarm ...........4
Two-Stage Unlock Capability......................5
Remote Panic with Safety Locks....................5
Interior Light Illumination ........................5
User-Programmable Passive Door Lock .................5
User-Programmable Ignition-Controlled Door Lock/Unlock .......5
User-Programmable RPM Door Lock..................6
Protected Valet Mode ..........................6
Remote-Controlled Valet.........................6
LED System Status Indicator .......................7
Remote-Controlled Trunk Release Capability..............7
Remote-Controlled Accessory Outputs.................7
Zone
2
™Impact Sensor .........................8
Remote-Controlled Sensor Bypass ....................8
Previous Intrusion Alert .........................8
Specific Zone Intrusion Identification ..................8
User-Programmable Door Ajar Indication ................9
User-Programmable Siren Duration ...................9
Alarm State Memory ..........................9
Automatic Malfunction Override....................9
Remote Engine Start - Safety and Counter-Theft.............10
Remote Engine Start - Operation ....................11
User-Programmable Temperature-Controlled Starting..........12
Pit Stop Mode.............................13
User-Programmable Features.......................14
Programming Table for System Features................15
Programming Table for Remote Controls................16
1
AviStart 6500 Owner's Manual - 110698 Rev. B

AviStart 6500
Congratulations! You have just purchased the AviStart 6500, a remote engine
starter and security system manufactured by Avital Technologies, Inc. You are
about to experience the convenience and luxury of being able to start your
vehicle engine from the comfort of your home, office, department store or
other remote location.
To fullly benefit from the capabilities of your AviStart system, we encourage
you to read the Owner’s Manual thoroughly before using the system. If you
have any problems or questions regarding your AviStart system, consult the
dealer from whom you purchased this product. To locate an authorized Avital
dealer, contact Avital Technologies directly at 1-800-253-0334 (toll-free
within the U.S.) or 1-847-215-2233.
Lifetime Warranty
Avital guarantees the operation of your AviStart control unit and remote
controls for as long as you own your car. (Please refer to your Lifetime Limited
Warranty Card for complete information.) Make sure that you receive your
warranty card from your dealer, complete the required information and mail
the registration portion to Avital Technologies. You should retain the top
portion of the warranty card for your records.
Remote Controls
Included with your AviStart system are two AviGlo™ 4-button/9-channel
remote controls. Once exposed to light, the AviGlo remote control buttons
will glow, making the buttons visible in the dark.
The remote control (remote) is a miniature transmitter powered by a small
+12 volt battery. The RangeMaster™ super-heterodyne receiver (installed in
your vehicle) allows your remote to command your system from up to
¼ mile away. Obstructions, electrical or radio interference, weather
conditions, window tint or a weak battery can reduce this range. Your remote
is the key to your AviStart system and can be used to arm and disarm your
alarm, lock and unlock your doors, "pop" your trunk, start your engine and
control optional accessories.
The AviStart system can accept up to four Avital remote controls. Additional
remote controls and remote control batteries can be purchased from any
authorized Avital dealer, or by calling Avital Technologies toll-free at
1-800-253-0334 (within the U.S.) or 1-847-215-2233.
2
AviStart 6500 Owner's Manual - 110698 Rev. B

Stealth CodingTechnology
Stealth Coding technology offers the most advanced protection available
against "code-grabbing" devices which thieves may use to record the digital
code transmitted by your remote control. When you leave the area, thieves
can then play back the code to unlock the doors and deactivate your system.
Avital's remote controls with Stealth Coding randomly change the code every
time you use them, and your system will not respond if any code is
retransmitted. This technology makes code-grabbing devices useless.
Electronic Scan Prevention (ESP)
Your AviStart system also includes ESP, which blocks electronic scanner codes
preventing unauthorized operation of your system.
Instant Remote Control Code Deletion
In the event of a lost or stolen remote control, all remote controls can be
erased from the system's memory preventing unauthorized system operation.
(See the "Programming Table for Remote Controls" on page 16).
One-Step Remote Control Code Learning
The AviStart system allows you to add new remote controls in one step. (See
the "Programming Table for Remote Controls" on page 16).
Valet Switch
The valet switch is a small hidden toggle switch which allows you to control all
of the system's programmable features. (See "User-Programmable Features" on
page14).Thisswitchcanonlybecontrolledwiththeuseofyourignitionkey.
NOTE:Besuretohaveyourdealershowyouwherethevaletswitchislocated.
3
AviStart 6500 Owner's Manual - 110698 Rev. B

Operating Your AviStart
To Arm The System
The alarm can be programmed for active or passive arming. Active arming
means the alarm can only be armed by the remote control. Passive arming
means the alarm will automatically arm itself. See the "Programming Table for
System Features" on page 15.
Active Arming
Press the remote ARM/DISARM button for 1-2 seconds. The siren will chirp
twice, the parking lights will flash twice, the doors will lock, the LED will flash
slowly and the starter will be disabled.
Passive Arming
Turn the ignition key "OFF," exit the vehicle and close the doors. When the
interior lights turn off, the LED will begin flashing rapidly to indicate the alarm
is passive arming. After 30 seconds, the siren will chirp twice, the parking
lights will flash twice, the LED will flash slowly and the starter will be disabled
(at any time during passive arming, the alarm can be actively armed).
To Disarm the System
Press the remote ARM/DISARM button for 1-2 seconds. The siren will chirp
once, the parking lights will flash once, the doors will unlock, the interior
lights will turn on, the LED will turn off and the starter will be enabled.
Remote-Controlled Silent Arm/Disarm
Press the remote SILENT button for 1-2 seconds to arm or disarm your system
without the usual siren chirps.
Silent Arm Indications
The parking lights will flash twice, the doors will lock, the starter will be
disabled and the LED will flash slowly.
Silent Disarm Indications
The parking lights will flash once, the doors will unlock, the starter will be
enabled and the LED will turn off.
User-Programmable Long-Term Silent Arm/Disarm
This feature allows you to completely disable the arm/disarm siren chirps until
you decide to restore them. (See the "Programming Table for System Features"
on page 15.)
4
AviStart 6500 Owner's Manual - 110698 Rev. B

Two-Stage Unlock Capability
If the optional Two-Stage Unlock feature was installed, press the
ARM/DISARM or SILENT button for 1-2 seconds and only the driver door will
unlock. Within 3 seconds, press the ARM/DISARM or SILENT button again
and the passenger doors will unlock (may require an optional relay).
Remote Panic with Safety Locks
In a threatening situation, you can activate Remote Panic with Safety Locks.
When activated, the siren will sound and the parking lights will flash. If you
are inside your vehicle and the ignition key is "ON," the doors will lock. If you
are outside the vehicle with the ignition key "OFF," the doors will unlock.
To Activate
1.Press the remote control ARM/DISARM button for 3-4 seconds.
2. The siren will sound and the parking lights will flash.
3.If the ignition key is "OFF," the doors will unlock. If the ignition key is
"ON," the doors will lock.
To Deactivate
1.Press the remote control ARM/DISARM button for 1-2 seconds.
2. The siren will shut off and the parking lights will stop flashing.
Interior Light Illumination
When the alarm system is remotely disarmed, the vehicle interior light(s) will
turn on for 30 seconds or until the ignition key is turned on.
User-Programmable Passive Door Lock
The system will not automatically lock the doors when the alarm passively
arms to prevent the keys and remote from being locked in the vehicle. If you
prefer, you can easily program the alarm to automatically lock the doors every
time the alarm passively arms. (See the "Programming Table for System
Features" on page 15.)
User-Programmable Ignition-Controlled Door Lock/Unlock
For the ultimate in security and convenience, the AviStart is programmed to
automatically lock your doors when the ignition key is turned "ON" or the
engine is started, and will unlock when the ignition key is turned "OFF." This
feature can be programmed ON or OFF. (See the "Programming Table for
System Features" on page 15.)
5
AviStart 6500 Owner's Manual - 110698 Rev. B

User-Programmable RPM Door Lock
The system can be programmed to automatically lock the doors when the
engine reaches the factory preset RPM level. (See the "Programming Table for
System Features" on page 15). When you begin driving, your vehicle doors
will automatically lock. When you turn the ignition key off, the doors will
automatically unlock.
NOTE: Ignition-Controlled Door Lock feature must be programmed OFF.
Protected Valet Mode
You should place your system in Protected Valet Mode whenever your vehicle
is being serviced by mechanics, car wash personnel or driven by valet parking
attendants. While in the Protected Valet Mode, all remote starter and alarm
functions are bypassed to prevent unauthorized or accidental operation. If a
remote start is attempted, the parking lights will flash 4 times and the vehicle
will not start. Remote-controlled door lock/unlock , trunk release and all
optional accessories will still operate.
To Turn on Protected Valet Mode
1.Turn the ignition key to the "ON" position or start the engine.
2.Flick the valet switch to the "ON" position.
3. The LED will turn on solid red to indicate the system is in the Protected
Valet Mode.
4.Turn the ignition key to the "OFF" position.
To Turn off Protected Valet Mode
1.Turn the ignition key to the "ON" position or start the engine.
2.Flick the valet switch to the "OFF" position.
3. The LED will turn off to indicate the system is no longer in the Protected
Valet Mode.
4.Turn the ignition key to the "OFF" position.
Remote-Controlled Valet
For your convenience, the system can be put into Valet Mode via the remote
control. While in Remote-Controlled Valet, all alarm functions are bypassed.
Remote start, remote-controlled lock/unlock and all optional accessories will
still operate.
NOTE: The system must be disarmed in order to activate the
Remote-Controlled Valet feature.
6
AviStart 6500 Owner's Manual - 110698 Rev. B

To Activate Remote-Controlled Valet
1.Press the remote control ARM/DISARM and START buttons at the same
time for 1-2 seconds.
2. The parking lights will flash 4 times, and the LED will turn on solid red.
To Deactivate Remote-Controlled Valet
1.Press the remote control ARM/DISARM and START buttons at the same
time for 1-2 seconds.
2. The parking lights will flash 3 times and the LED will turn off.
LED System Status Indicator
The LED on your vehicle dashboard or center console will inform you of the
system status.
LEDStatus
OffSystem is disarmed
On solidIn Protected Valet Mode
Slow flashSystem is armed
Flashing in cyclesSee "Specific Zone Intrusion Identification" on page 8
Rapid flashPassive arming
Remote-Controlled Trunk Release Capability
If you had the optional Trunk Release feature installed, simply press the
remote control TRUNK button for 1-2 seconds to activate your vehicle
electronic trunk release. The trunk will "pop" open. This feature will only work
if your system is disarmed (may require an optional relay).
Remote-Controlled Accessory Outputs
These outputs allow you to add optional remote-controlled accessories to your
system such as a window roll-up, garage door opener or fuel door release. To
activate your optional accessories, see the "Programming Table for Remote
Controls" on page 16.
7
AviStart 6500 Owner's Manual - 110698 Rev. B

Zone2 ™Impact Sensor
The Zone2 Impact Sensor has two individual vibration/impact sensing zones.
Zone #1:
If a less threatening vibration or impact is detected, the siren will issue 2
warn-away chirps. A second violation will also issue 2 warn-away chirps. If
within 45 seconds a third violation is detected, the sensor will automatically
trigger the alarm. The siren will sound and the lights will flash.
Zone #2:
If a more threatening vibration or impact is detected at any time, the siren and
lights will activate instantly.
Remote-Controlled Sensor Bypass
You can bypass the system sensor(s) at any time. The alarm system will still
provide full perimeter protection.
To Bypass the Sensor(s):
1.Press remote SILENT and TRUNK buttons at the same time.
2. The siren will chirp twice...pause...chirp twice...pause...chirp twice.
3.The sensor(s) is now bypassed until you remotely disarm and then re-arm
your system.
Previous Intrusion Alert
If the vehicle had been tampered with and the alarm has been triggered, the
siren will chirp 3 times upon remote disarm instead of the usual 1 chirp.
Specific Zone Intrusion Identification
If the alarm had been triggered in your absence, the siren will chirp 3 times
upon remote disarm (Previous Intrusion Alert). When you enter the vehicle
and turn the ignition "ON," the LED will flash in cycles to specifically identify
which zone triggered the alarm.
LEDZone
1 flash...1 flash...Impact sensor / optional sensor input
2 flashes...2 flashes... Hood trigger
3 flashes...3 flashes... Door trigger
4 flashes...4 flashes... Trunk trigger
8
AviStart 6500 Owner's Manual - 110698 Rev. B
