Congratulations
Congratulations on the purchase of your remote start system. Reading
this Owner’s Guide prior to using your system will help maximize the
use of your system and its many features.
Government Regulations and Safety Information
Read the Government Regulations and Warning! Safety
First sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
This product is designed for fuel-injected, automatic trans-
mission vehicles only. Installing it in a standard transmis-
sion vehicle is dangerous and is contrary to its intended
use. If your vehicle is equipped with a manual transmis-
sion cease use of this product and immediately return the
vehicle to an authorized Directed dealer.

Your Warranty
Your system comes with a warranty. The warranty terms are detailed at the
end of this guide. Make sure that you receive the proof of purchase from
your dealer, indicating the product was installed by an authorized Directed
dealer. Please register online (see back cover for URL).
Replacement Remote Controls
Please see your authorized dealer to order additional remote
controls. Remote control part numbers are found on the back of the
device.

Contents
Congratulations .................................................................................................i
Important Information .........................................................................................i
Government Regulations and Safety Information ............................................i
Your Warranty..........................................................................................ii
Replacement Remote Controls.....................................................................ii
Using Your System ...........................................................................................2
Commands At a Glance ............................................................................2
Start Engine .............................................................................................2
Unlock Doors ...........................................................................................2
Stop Engine .............................................................................................2
Car Finder ...............................................................................................2
Using Remote Start ............................................................................................3
Key Takeover............................................................................................4
Safety Features.........................................................................................4
Pit Stop....................................................................................................5
Optional Rear Defogger ............................................................................5
Optional Starter Anti-Grind Circuitry ...........................................................6
Disabling the Remote Start System/Garage Mode ........................................6
Remote Start Diagnostics ...........................................................................6
Pairing a Remote Control ...................................................................................8
Programming Options........................................................................................9
Rapid Resume Logic .........................................................................................9
Battery Information..........................................................................................10
Replacing the Battery ..............................................................................10
Battery Disposal .....................................................................................10
Patent Information ...........................................................................................11
Government Regulations ..................................................................................12
Warning! Safety first .......................................................................................13
Installation .............................................................................................13
Remote Start Capable .............................................................................13
Interference............................................................................................14
Upgrades ..............................................................................................14
Water/Heat Resistance ...........................................................................14
Limited lifetime consumer warranty ....................................................................15

Using Your System
Commands At a Glance
System State Press/Release Press/Hold for 3 sec.
ENGINE OFF START ENGINE CAR FINDER
ENGINE ON UNLOCK DOORS STOP ENGINE
Start Engine
When the engine is OFF, press and release the remote control button to
start the engine.
See"Using Remote Start" on page 3 for more feature details.
Unlock Doors
When the engine is ON, press and release the remote control but-ton.
The doors unlock, the parking lights flash, the horn sounds (if con-nected) as
confirmation.
Note: Horn honk may be an optional feature that requires additional parts
and labor.
Stop Engine
When the engine is ON, press and hold the remote control button for three
seconds. The engine stops running and the parking lights turn off.
Car Finder
When the engine is OFF, press and hold the remote control button for three
seconds. The parking lights flash slowly several times allowing you to
locate your vehicle.

Using Remote Start
This feature allows you to remotely start and run your vehicle for a
programmable period of time. This makes it possible to warm up the
engine, and adjust the interior temperature of the vehicle with the cli-
mate control system. If interior heating or cooling is desired, the climate
controls must be preset, and the fan blower must be set to the desired
level prior to remote starting the vehicle.
Important! (1) Never remotely start the vehicle with the vehicle
in gear, and (2) Never remotely start the vehicle with the key
in the ignition.
Starting the Engine:
1. Make sure the parking brake is set. Press and release the remote
control button once* (or the amount of times the system has been
programmed to activate the remote start).
2. The parking lights flash to confirm that the vehicle is attempting to
start. In gasoline vehicles the engine will start approximately four
seconds after the parking lights flash, in diesel vehicles the engine
starts after the WTS (WAIT-TO-START) timer has expired.
3. Once the vehicle has started, it will run for the pre-programmed
period of time (12, 24, or 60 minutes) or until a shutdown input
is triggered.
*The factory setting is one press but this can also be programmed for
two or three presses maximum (see your authorized Directed installer
for the amount of presses programmed).
Record the number of presses to activate remote start here:

If the engine fails to start, refer to "Disabling the Remote Start System"
and "Remote Start Diagnostics" sections of this guide.
Warning! It is unsafe to operate a vehicle's motor in a
garage or other closed off area. Such operation can
create a buildup of harmful gas. Breathing the exhaust
from the vehicle is hazardous and may lead to injury
or death.
Key Takeover
When you are ready to drive the vehicle:
1.
2.
3.
Unlock the doors.
Enter the vehicle. Do not step on the foot brake.
Insert the key, turn it to the RUN (not START) position. Step on the
foot brake. The remote start is disabled and the parking lights turn
off.
4. Disengage the parking brake and begin driving.
Note If your vehicle uses a Smart Key or PTS (Push-To-Start) system,
please refer to the vehicle specific instructions included with
the owner's guide of the interface module or consult your
authorized dealer.
Safety Features
The following safety features will disable the remote start when acti-
vated or not allow the engine to start if not properly set before starting.
Brake is depressed.
is open.
• Foot
• Hood
• Garage Mode is ON (see Disabling the Remote Start System).
•The pre-programmed run time (12, 24 or 60 minutes) has elapsed.

• Pressing and holding the button on the remote for three seconds
while the remote start is active.
• Parking brake is disengaged .
• Engine over-rev protection (Tachometer mode only).
Pit Stop
This remote start can keep the engine running during short trips away
from the vehicle.
Enabling Pit Stop Mode:
1. Park in a well ventilated area and set the parking brake.
2. With the engine running, set the transmission in the park position.
3. Press and release the remote control button once (or the amount of
times the system has been programmed to activate the remote
start). The parking lights turn on to confirm.
4. Turnoff the ignition and remove the key, the engine continues
running.
5. Exit and secure the vehicle, the engine runs for the programmed
runtime.
Important: This feature will not work if the brake pedal is being pressed.
Note If your vehicle uses a Smart Key or PTS (Push-To-Start) system,
please refer to the vehicle specific instructions included with
the owner's guide of the interface module or consult your
authorized dealer.
Optional Rear Defogger
If connected, the Defogger circuit automatically activates after remote
starting the vehicle.
Note: The optional rear defogger feature can be programmed to be

on during remote start by your installer, however, you do not have the
capability to turn on and off the feature at will with the 1-button remote.
The rear defogger will always be active during the remote start runtime.
Optional Starter Anti-Grind Circuitry
This system includes an anti-grind circuit that can prevent damage to
the starter motor if the key is turned to the start position while the remote
start is ON.
Note: Anti-grind circuitry only works if an optional relay has been add-
ed and the remote start system is operating the motor.
Disabling the Remote Start System/Garage Mode
Garage Mode is a safety feature that disables the remote start system if
the vehicle is parked in a garage, being serviced, or used by someone
unfamiliar with remote start systems.
When Garage Mode is ON, any attempt to start the engine, activate
Timer Mode, or enter Pit Stop mode is denied, and remote start diag-
nostics flashes the parking lights nine times.
Turn Garage Mode ON or OFF:
1. Turn the ignition on then off.
2. Within 10 seconds, press and release the Valet button once.
3. The parking lights flash:
• Nine times quickly when turning on.
• Nine times slowly when turning off.
Remote Start Diagnostics
For user safety, the system must be properly configured or remote start
will not activate. A Remote Start Fault may be caused by any of several

configuration issues. If the remote start fails to activate, refer to the table
below for the command type and parking light flashes that will identify
the configuration issue and solution.
Light Flash Problem Solution
5 flashes Brake is on Release the foot brake
6 flashes Hood is open Close the hood
8 flashes Neutral safety is disconnected Set the parking brake or move
the shifter to the park position
9 flashes Garage Mode is ON Turn Garage Mode OFF
