Avital AVISTART 3001 User manual

FRONT COVER

IWARNING I
!Always exercise caution and common sense when operating
your AviStart system.
!This product is intended for vehicles with fuel-injection and
automatic transmissions only. NEVER attempt to remote start
a vehicle with a manual (stick shift) transmission. Serious
injury may occur with improper use.
!NEVER attempt to remote start the engine while anyone
(including pets) is in the vehicle.
!NEVER attempt to remote start the engine while the vehicle is
in an enclosed area without sufficient ventilation.
!NEVER attempt to remote start the engine while the keys are
in the ignition.
!Always be sure the gearshift selector is in "Park" and the
emergency brake is on before attempting to remote start the
vehicle.
!Keep your AviStart remote controls out of the reach of
children.
!Whenever the vehicle is being serviced or valet parked, place
the system in Protected Valet Mode to prevent accidental or
unauthorized remote starting. See "Protected Valet Mode" on
page 7.

Table of Contents
AviStart 3001 ...............................2
Lifetime Warranty............................2
Remote Controls ............................2
Stealth CodingTechnology.......................2
Electronic Scan Prevention (ESP).....................3
Instant Remote Control Code Deletion..................3
One-Step Remote Control Code Learning ................3
Valet Switch...............................3
Operating Your AviStart..........................4
Remote Engine Start - Safety and Counter-Theft.............4
Visual Fault Indication ..........................4
Remote-Controlled Door Lock/Unlock* ................. 4
Remote Engine Start - Operation .....................5
User-Programmable Temperature-Controlled Starting ..........6
Pit Stop Mode..............................6
Protected Valet Mode..........................7
User-Programmable Features.......................8
Programming Table for System Features .................9
Programming Table for Remote Controls .................9
1
AviStart 3001 Owner's Manual

AviStart 3001 Owner's Manual
AviStart 3001
Congratulations! You have just purchased the AviStart 3001, a remote engine
starter system manufactured by Avital Technologies, Inc. You are about to
experience the convenience and luxury of being able to start your vehicle
engine from the comfort of your home, office, department store or other
remote location.
To fully benefit from the capabilities of your AviStart system, we encourage
you to read the Owner"s Manual thoroughly before using the system. If you
have any problems or questions regarding your AviStart system, consult the
dealer from whom you purchased this product.
Lifetime Warranty
Avital guarantees the operation of your AviStart control unit and remote
control for as long as you own your car. (Please refer to the back of this
manual for complete terms and conditions.)
Remote Controls
Included with your AviStart system is one 4-button/9-channel remote control.
The remote control (remote) is a miniature transmitter powered by a small
+12 volt battery. The RangeMaster™ super-heterodyne receiver (installed in
your vehicle) allows your remote to command your system from up to ¼ mile
away. Obstructions, electrical or radio interference, weather conditions,
window tint or a weak battery can reduce this range. Your remote is the
key to your AviStart system and can be used to lock and unlock your doors
and start and stop your engine.
The AviStart system can accept up to four Avital remote controls. Additional
remote controls and remote control batteries can be purchased from any
authorized Avital dealer. To locate an authorized dealer, or for other product
information, visit Avital's web site atwww.avital.com.
Stealth CodingTechnology
Stealth Coding technology offers the most advanced protection available
against "code-grabbing" devices which thieves may use to record the digital
code transmitted by your remote control. When you leave the area, thieves
can then play back the code to start or stop your system. Avital"s remote
controls with Stealth Coding randomly change the code every time you use
them, and your system will not respond if any code is retransmitted. This
technology makes code-grabbing devices useless.
2

Electronic Scan Prevention (ESP)
Your AviStart system also includes ESP, which blocks electronic scanner codes
preventing unauthorized operation of your system.
Instant Remote Control Code Deletion
In the event of a lost or stolen remote control, all remote controls can be
erased from the system memory preventing unauthorized system operation.
(See the "Programming Table for Remote Controls" on page 9).
One-Step Remote Control Code Learning
The AviStart system allows you to add new remote controls in one step. (See
the "Programming Table for Remote Controls" on page 9).
Valet Switch
The valet switch is a small hidden toggle switch which allows you to control all
of the system programmable features. (See "User-Programmable Features" on
page 9). This switch can only be controlled with the use of your ignition key.
NOTE: Be sure to have your dealer show you where the valet switch is located.
3
AviStart 3001 Owner's Manual

Operating Your AviStart
Remote Engine Start - Safety and Counter-Theft
ICAUTION : Be sure to read the "WARNING" bulletin on the inside
cover of this manual before attempting to operate remote start.
Automatic Safety and Counter-Theft Features
Before remote starting your engine, the AviStart system will automatically
perform a safety check to ensure the following conditions have been met:
•Brake pedal is not depressed.
•Engine and ignition are turned "OFF."
•Hood is closed.
After remote starting your engine, the AviStart system will shut off the engine
immediately if the ignition is "OFF" and any of the following occurs:
•The hood is opened.
•The brake pedal is pressed.
•The remote control START button is pressed.
•The 20 minute run time expired.
Visual Fault Indication
When you press the remote control button to start your engine, AviStart's
built-in fault detection system will automatically scan all of the safety zones. If
a fault is detected, the system will prevent your engine from remote starting
and provides a visual indication to show where the fault has occurred. The
parking lights will flash 1 time if a hood switch fault is detected, 3 times if a
brake switch fault is detected and 4 times if the system is in "Protected Valet
Mode" (see page 7 for a description of this feature). If this occurs, you may
need to bring your vehicle to your authorized Avital dealer for service.
Remote-Controlled Door Lock/Unlock*
To Lock the Doors
Press the remote control
C button for 1-2 seconds. The doors will lock and the
parking lights will flash twice.
* If your system was installed with this door lock/unlock feature,
all other door lock/unlock related features will apply.
4
AviStart 3001 Owner's Manual

To Unlock the Doors
Press the remote control
D button for 1-2 seconds. The doors will unlock
and the parking lights will flash once.
Remote Engine Start - Operation
Your AviStart system will start your vehicle engine with a touch of a button on
your remote control. Before remote starting, ensure the vehicle is in "Park" and
the key is not in the ignition. To cool or warm the interior of your vehicle,
preset the climate control to your preference (heater, defrost or air
conditioning). Set the fan to a medium speed(not maximum).
To Remote Start the Engine
1. Press the remote control
sbutton for 1-2 seconds, 10-15 minutes before
you enter your vehicle (this will allow the climate control time to heat or
cool the interior.) The parking lights will flash 2 times, the engine will start
and the parking lights will remain on as a visual indication that the engine
is running.
If you have a diesel engine, the AviStart will be programmed to start 15
seconds after the parking lights flash 2 times or the vehicle glow plug light
turns off. This will allow time for the glow plugs to heat up.
2. If the engine does not remote start, the AviStart system will attempt to start
the engine two additional times.
3. If the vehicle is left unattended, the engine will run for 20 minutes and
then shut off automatically.
To Operate the Vehicle While Remote Started
1. Press the remote control
D button for 1-2 seconds. The doors will unlock
and the parking lights will flash once.
2. Enter the vehicle (do not touch the brake pedal), turn the ignition key to
the "ON" position and then press the brake pedal. Pressing the brake pedal
will shut off the remote start and parking lights but the engine will remain
running.
3. You can now drive the vehicle.
To Shut Off Remote Start
At any time after the engine has been remote started, you can shut off the
engine with the remote control by pressing the remote control
Lbutton for
1-2 seconds. The engine and parking lights will shut off.
5
AviStart 3001 Owner's Manual

User-Programmable Temperature-Controlled Starting
ICAUTION : Do not activate Temperature-Controlled Starting while
the vehicle is in an enclosed area.
The AviStart system can be programmed to monitor the air temperature inside
your vehicle and automatically start the vehicle engine whenever the
temperature inside reaches or drops below a preprogrammed temperature
level. There are three temperature levels to choose from. (This feature is
programmed OFF from the factory and must be programmed ON to operate.
See the "Programming Table for System Features"on page 9.)
To Activate
Press the remote control
s and C buttons at the same time for 1-2 seconds.
The parking lights will turn on for 3 seconds, turn off for 1 second, turn on for
3 seconds and then shut off. This will be your visual indication that you have
activated the Temperature-Controlled Starting feature.
The AviStart will monitor the air temperature every 2.5 hours and will only
start the engine if the temperature inside the vehicle has reached or dropped
below the preprogrammed temperature level. The parking lights will flash 2
times, the vehicle will start and the parking lights will turn on. The vehicle will
run for 10 minutes and then shut off. This will allow the engine to warm up
and charge the battery.
To Deactivate
Press the remote controls and C buttons at the same time for 1-2 seconds.
The parking lights will turn on for 3 seconds and then shut off. This will be
your visual indication that you have deactivated the Temperature- Controlled
Starting feature.
NOTE: At any time, if the ignition key is turned "ON" or the vehicle is remote
started, the Temperature-Controlled Starting feature will deactivate.
Pit Stop Mode
ICAUTION : Do not leave passengers or pets in the vehicle while the
system is in Pit Stop Mode.
The Pit Stop Mode allows you to park the vehicle for short-term stops, remove
the ignition key and leave the engine running.
6
AviStart 3001 Owner's Manual

To Activate
1. While the vehicle engine is running with the ignition key turned "ON,"
press the remote control
sbutton for 1-2 seconds. The parking lights will
flash 2 times and stay on. (Make sure the vehicle is in "Park" and the
parking brake is set.)
2. Turn the ignition key "OFF" and the engine will stay running.
3. Remove the ignition key and remote control and exit the vehicle.
Remember to keep the ignition key and remote control in your
possession.
4. Press the remote control C button for 1-2 seconds to lock the doors and
secure the vehicle.
To Deactivate
1. Press the remote controlD button for 1-2 seconds to unlock the doors.
2. Enter the vehicle (do not touch the brake pedal), turn the ignition key to
the "ON" position and then press the brake pedal. The parking lights will
shut off and you will now be able to drive the vehicle.
Protected Valet Mode
You should place your system in Protected Valet Mode whenever your vehicle
is being serviced by mechanics, car wash personnel or driven by valet parking
attendants. While in the Protected Valet Mode, all remote start functions are
bypassed to prevent unauthorized or accidental operation. If a remote start is
attempted, the parking lights will flash 4 times and the vehicle will not start.
To Turn on Protected Valet Mode
1. Turn the ignition key to the "ON" position or start the engine.
2. Flick the valet switch to the "ON" position.
3. Turn the ignition key to the "OFF" position.
To Turn off Protected Valet Mode
1. Turn the ignition key to the "ON" position or start the engine.
2. Flick the valet switch to the "OFF" position.
3. Turn the ignition key to the "OFF" position.
7
AviStart 3001 Owner's Manual

User-Programmable Features
All AviStart system and remote control programmable features are
accomplished by turning the ignition key "ON" (or starting the engine) and
flicking the valet switch on and off a preset number of times.
The AviStart also allows you to add new remote controls in one step, delete
lost or stolen remote controls or rearrange the factory preset remote control
functions.
1. Remove the system from Protected Valet Mode. Programming cannot be
accessed while the system is in Protected Valet Mode.
2. Select the feature you wish to program from the "Programming Table for
System Features" or the "Programming Table for Remote Controls" on
page 9. Note the number of beeps associated with that feature.
3. Turn the ignition key to the "ON" position.
4. Within 10 seconds, begin flicking the valet switch on and off. The piezo
beeper will beep once each time you flick the switch on then off.
5. Continue flicking the switch on and off, counting the number of beeps.
NOTE: Stop when you reach the number of beeps associated with your
chosen feature.
6. Follow the "Secondary Action." You will hear a number of beeps to
confirm that you have changed the setting of that feature.
7. Turn the ignition key to the "OFF" position.
8. Repeat steps 1-7 for any other feature you wish to program.
8
AviStart 3001 Owner's Manual

Programming Table for System Features
FeatureFactory
Setting
No. of
beeps Secondary Action
Temperature-Controlled Starting
OFF or 5 °F (-15 °C) OFF 5
Wait 3 seconds. The piezo beeper
will beep once for OFF, twice for
5°F (-15°C).
Temperature-Controlled Starting
-7°F (-20 °C) or -22°F (-30 °C) —8
Wait 3 seconds. The piezo beeper
will beep once for -7°F (-20°C),
twice for -22°F (-30 °C).
Programming Table for Remote Controls
FeatureFactory
Setting
No. of
beeps Secondary Action
Door Lock C Button 10 Press the
CButton, the piezo
beeper will beep 1 time.
Door Unlock DButton 11 Press theD Button, the piezo
beeper will beep 1 time.
Remote Engine Start sButton 12 Press the
s Button, the piezo
beeper will beep 2 times.
Remote Engine Stop LButton 13 Press theLButton, the piezo
beeper will beep 3 times.
Temperature-Controlled
Remote Engine Start C+s Buttons 14 Press the
C+sButtons, the piezo
beeper will beep 4 times.
One Step Remote Control
Code Learning C Button 15 Press the
CButton, the piezo
beeper will beep 1 time.
Instant Remote Control
Code Deletion —16
Wait 3 seconds, the piezo beeper
will beep twice. All codes are
erased out of memory.
9
AviStart 3001 Owner's Manual

ONLINE REGISTRATION: For your convenience, we now provide online
registration for your Avital purchase. Within 10 days of purchase, register at
www.clifford.com/register. By registering online, you will have access to a copy of
your Owner's Manual, as well as information on product updates or special
promotions.
Your system serial number is:
Life time Lim ited Fac tory War ranty - Terms and Con di tions
Avitalvehiclesecuritysystemsand accessoriesrequireprofes sionalinstallationby an Authorized
Avital Dealer. Un less the sys tem is sold and in stalled by an Authorized Avital Dealer, all prod uct
war ran ties are void. As the manu fac turer, Avital Technologies war rants to the origi nal con sumer
pur chaser, the sys tem con trol unit and re mote con trols to be free from de fects in ma te rial and
work man ship for as long as you own the ve hi cle in which the sys tem was origi nally in stalled. All
other parts of the sys tem and ac ces so ries to the sys tem are war ranted to be free from de fect s in
ma te rial and work man ship for one (1) year from the date of pur chase. Avital Technologies will
repair or replace, at its option and free of charge during the warranty period, any system
com po nent that proves de fec tive in ma te rial or work man ship un der nor mal installa tion,use, and
service, provided the product is returned to our factory by an Authorized Avital Dealer,
transportation charges prepaid. Products returned to our factory must be ac com pa nied by a
pho to copy of the pur chase re ceipt. In the ab sence of such pur chase re ceipt, the war ranty pe riod
shall be one (1) year from the date of manu fac ture. Any dam age to the prod uct(s) as a re sult of
misuse,abuse,neglect,accident,incorrectwiring,improperinstallation,destructionor al tera tion
of the se rial number, re pair or al tera tion out side our fac tory, or any use vio la tive of in structions
fur nished by us will void the war ranty. This war ranty is lim ited to de fec tive parts and spe c ifically
excludes any in ci den tal or con se quen tial dam ages con nected there with. This warranty is not
transferable. Avital Technologies makes no war ranty against theft. This war ranty is not to be
construed as an insurance policy against loss. Warranty on installation labor, removal and
re in stal la tion charges are not the re spon si bil ity of Avital Technologies, Inc.
Place se rial number sticker here
© 1999 Avital Technologies, Inc., A Division of Clifford Electronics
Part Number: 31-3001/AviStart3001OM/0999
