FRITZ!CARD CLASSIC connects the PC to ISDN
FRITZ!CARD CLASSIC connects the PC to isdn
CLASSIC
CLASSIC
English Edition

2
FRITZ!CARD
This manual and the software it describes are protected by copyright. The manual
and software as presented are the object of a license agreement and may be used
only in accordance with the license conditions. The licensee bears all risk in regard
to hazards and impairments of quality which may arise in connection with the use
of this product.
This manual and the software it describes may not be transmitted, reproduced or
altered in whole or in part, in any form, by any means, nor may they be translated
into any other natural or computer language. The creation of a backup copy for
personal use is excepted. The information hereby made available to the licensee
may be communicated to third parties only with the written permission of AVM Ber-
lin.
This software and documentation have been produced with all due care and checked
for correctness in accordance with the best available technology. AVM Berlin dis-
claims all liability and warranties, whether express or implied, relating to this
product’s quality, performance or suitability for any given purpose which deviates
from the performance specifications contained in the product description.
AVM will not be liable for damages arising directly or indirectly from the use of the
manual or related software, nor for incidental or consequential damages, except in
case of intent or gross negligence. AVM expressly disclaims all liability for loss of or
damage to hardware, software or data as a result of direct or indirect errors or de-
struction and for any costs, including ISDN connection charges, related to the soft-
ware and manual supplied and due to incorrect installations not performed by AVM
itself.
The information in this manual and the software it describes are subject to change
without notice for the purpose of technical improvement.
Copyright 1998 AVM Berlin. All rights reserved.
AVM Audiovisuelles Marketing AVM Computersysteme
und Computersysteme GmbH Vertriebs GmbH & Co.KG
Alt-Moabit 95 Alt-Moabit 95
D-10559 Berlin D-10559 Berlin
FRITZ!Card Support: AVM on the Internet:
Tel.: [phone] http://www.avm.de
AVM Data Call Center (ADC): ftp://ftp.avm.de
+49 30/39 98 43 00
Trademark notice: AVM and FRITZ! are registered trademarks of AVM Vertriebs KG.
Windows is a registered trademark of Microsoft Corporation. All other trademarks
are trademarks of the respective owners.

Contents
3
CONTENTS
1 Welcome to FRITZ!Card.............................................4
1.1 What was Delivered? ............................................................................... 4
1.2 Latest Drivers for FRITZ!Card.................................................................... 5
1.3 How to Contact Us .................................................................................. 5
2 All about FRITZ!Card .................................................6
2.1 What Does FRITZ!Card Require? ............................................................... 7
2.2 How Does FRITZ!Card Work? .................................................................... 8
2.3 Freedom for Your Connection .................................................................. 9
2.4 FRITZ!Card on the ISDN Connection ........................................................ 11
2.5 Mind you Install FRITZ!Card Correctly! .................................................... 13
3 How to Install FRITZ!Card .......................................14
3.1 Installation in Windows 95 .....................................................................14
3.2 Installation in Windows NT 4.0 (Workstation i386) ................................ 19
3.3 Installation in Windows 3.x ................................................................... 23
4 Onto the Internet with FRITZ!Card ........................28
4.1 Concept of the AVM System Drivers in the MS Windows System ............ 28
4.2 The AVM ISDN CAPI Port Driver .............................................................. 29
4.3 The AVM NDIS WAN CAPI Driver ............................................................. 30
4.4 Requirements for Provider or Other Party .............................................. 30
4.5 ISDN CAPI Port Driver or NDIS WAN CAPI Driver? .....................................31
5 FRITZ! Installation ...................................................32
5.1 What Can FRITZ! Do? ............................................................................. 33
5.2 Help for FRITZ! ...................................................................................... 34
6 Setting the I/O Address on FRITZ!Card ..................36

1 Welcome to FRITZ!Card
4
1WELCOME TO FRITZ!CARD
This manual is your introduction to FRITZ!Card.
1.1 What was Delivered?
After opening and unpacking the box, you should have the
following on the table in front of you:
•1 FRITZ!Card
FRITZ!Card is an AVM I DN-Controller which connects
your computer to the I DN. FRITZ!Card is installed (by
you) in your computer.
•1 ISDN cable
The supplied cable allows you to connect FRITZ!Card to
the I DN socket.
•1 FRITZ!Card CD-ROM
The CD includes an introduction which provides you with
information about the contents of the CD and assists you
with the installation of FRITZ!Card. This introduction
starts automatically under Windows 95 and Windows NT
4.0 (Workstation i386) when you insert the CD in your CD
drive. You can also start the introduction manually by
going into the File Manager or the Explorer and double-
clicking on the file INTRO.HLP in the root directory of the
CD.
The CD additionally contains the FRITZ!Card installation
programs for the Windows 95, Windows NT 4.0 (Worksta-
tion i386), Windows 3.x and DO platforms, and also the
installation programs for the FRITZ! communications soft-
ware for Windows 95 and Windows NT 4.0 (Workstation
i386) as well as for Windows 3.x, and AVM system drivers
for Windows 95 and Windows NT. And you will also find
detailed documentation for all the supplied AVM prod-
ucts on the CD.

1 Welcome to FRITZ!Card
5
If the computer on which you want to install FRITZ!Card does not
have a CD-ROM drive, you may copy the required software onto
diskettes for private purposes. AVM will not supply the FRITZ!Card
software on diskettes.
•1 FRITZ!Card manual
(you are reading it right now)
•1 FRITZ!32 manual
Manual for the FRITZ!32 communications software
•1 registration card
This card is used for registering customers in the AVM
customer database. You can only benefit from the AVM
support facilities after returning your registration card.
1.2 Latest Drivers for FRITZ!Card
AVM makes the latest drivers for FRITZ!Card available to
you free of charge. You can obtain these drivers from the AVM
Data Call Center (ADC), or from the AVM FTP server over
the Internet .
1.3 How to Contact Us
AVM Data Call Center (ADC)
+49/(0) 30/39 98 43 00 (IDtrans protocol)
AVM on the Internet
http://www.avm.de
ftp://ftp.avm.de
FRITZ!Card Support by telephone
+49/(0) 30/39 00 43 90
You can get information about AVM products on the Internet. We
recommend that you contact the ADC using ISDN when downloading
new drivers; access is faster and thus more cost-effective.

2 All about FRITZ!Card
6
Windows 95 and
NT 4.0 @ Internet
2ALL ABOUT FRITZ!CARD
With FRITZ!Card, AVM offers an integrated communications
package which makes the advantages of I DN available to you:
a high transfer rate, rapid establishment of connections, opti-
mum line quality and maximum operational reliability.
FRITZ!Card consists of several different components:
•The AVM I DN Controller FRITZ!Card with the associated
driver software. FRITZ!Card provides the connection
between the I DN and application programs on the
computer, for example FRITZ! and other CAPI applications.
You have the facility to install FRITZ!Card in Windows 95, Win-
dows NT 4.0 (Workstation i386) or Windows 3.x. For further in-
formation, please refer to the relevant sections.
•The FRITZ! Windows software, a compact and powerful I DN
communications program. The CD contains both the 16-bit
version of FRITZ! and also the 32-bit version for Windows
95 and Windows NT.
• The AVM I DN CAPI Port Driver and the AVM NDI WAN CAPI
Driver. These drivers enable the I DN integration of operating
system functions under Windows 95 and Windows NT 4.0.
They permit utilization of “Remote Access ervice” (RA ) and
allow you to connect your computer to the server of an
Internet provider by way of the TCP/IP stack and the Dial-Up
Networking application of Windows 95 and NT.
For further information about the conception, deployment op-
portunities and environment prerequisites for the AVM system
drivers, please refer to Chapter 4 “Onto the Internet with
FRITZ!Card”.

2 All about FRITZ!Card
7
2.1 What Does FRITZ!Card Require?
The following requirements must be met before you can oper-
ate the AVM I DN Controller FRITZ!Card in your computer:
• Your computer must have a free 8-bit or 16-bit plug-in slot
because FRITZ!Card is designed as a plug-in card for
computers with a PC/AT bus system. If both types of slot are
available, you should insert FRITZ!Card into the 16-bit slot.
• Find out which protocol is provided on your I DN line by the
I DN network operator. Connections employing the D 1 or
1TR6 protocol are possible. Connections installed
subsequent to 1994 are generally D 1 connections (Euro-
I DN connections).
• An IBM or 100% compatible computer with a hard disk and a
CD-ROM drive.
• Microsoft Windows 3.x for installation of the 16-bit version
of FRITZ!.
• Microsoft Windows 95 or Windows NT 4.0 (Workstation i386)
for installation of the 32-bit version of FRITZ!.
• If you intend to use the functions CAPI SoftModem V32 for
fax receiving and CAPI SoftCompression X75/V42bis (see
page 8) for data compression, we recommend a computer
with a Pentium processor and a minimum 16 MB of RAM.
If all these requirements are met, you can install FRITZ!Card.
FRITZ!Card and the software supplied with it have been developed
as a single workstation solution and are intended exclusively for the
connection of an individual PC to the ISDN.

2 All about FRITZ!Card
8
2.2 How Does FRITZ!Card Work?
FRITZ!Card simply plugs into a free slot on the PC/AT bus. It is
connected to the I DN basic connection via the 0 interface on
the FRITZ!Card. This interface is connected to the I DN con-
nection by means of the supplied cable.
The driver software associated with FRITZ!Card is loaded from
the hard disk upon starting Windows. It controls the commu-
nication and data transfer processes, for example the simul-
taneous use of the B channels.
FRITZ!Card supports Version 2.0 of the standardized interface
COMMON-I DN-API (CAPI). Programs from other manufacturers
based on CAPI 2.0 can also be used with FRITZ!Card. This CAPI
version also allows you to work with CAPI 1.1 applications.
FRITZ!Card simultaneously processes both channels of an I DN
basic connection (2 x 64000 bits/s). Its small dimensions also
make FRITZ!Card ideally suited for use in small housings.
FRITZ!Card is a PC plug-in card which uses passive technology,
i.e. there is no processor on the card. All computing operations
are performed by the processor in the PC.
Functions of the driver software
The driver software with CAPI 2.0 processes the D channel pro-
tocols of the I DN connection and makes all the requisite B chan-
nel protocols (X75, HDLC etc.) available to the applications. In
addition, CAPI 2.0 offers the oftCompression X75/V42bis,
oftModem and oftFax performance features.
The driver software for FRITZ!Card supports data compression
as per V.42bis for X.75 connections in accordance with the CAPI
standard. The connection times and costs can be considerably
reduced when using this type of data compression on account
of faster transfer rates. Data compression is activated or deac-
tivated at the request of your I DN application, e.g. by
FRITZ!data.
In addition to the digital performance features, you can utilize
analog services such as Group 3 Fax (CAPI oftFax G3) and Mo-
dem (CAPI oftModem V32) with FRITZ!Card.
SoftCompression
X75/V42bis
SoftFax

2 All about FRITZ!Card
9
The current driver software allows you to use FRITZ!Card with
all CAPI-based Windows fax applications. The controller supports
the sending and receiving of faxes at a rate of up to 14400 baud.
It behaves like a Group 3 fax machine.
FRITZ!Card additionally offers the CAPI oftModem perfor-
mance feature. On the basis of this modem emulation, it is pos-
sible to establish a connection from an I DN connection to ana-
log remote parties which are connected to the telephone net-
work via a modem.
Refer to the readme file for further details about the aforementioned
performance features CAPI SoftCompression, CAPI SoftFax and CAPI
SoftModem.
2.3 Freedom for Your Connection
FRITZ!Card enables you to establish connections with various
services and other parties. The basic principle for successful con-
nections and transfer operations is: The other party must have
a terminal device which is either of the same type or is compat-
ible.
The current standards are listed in the following:
Internet
In order to dial an Internet provider using the Dial-Up Network-
ing application of Windows 95 and Windows NT 4.0, you use
the PPP over I DN protocol (synchronous PPP) with the I DN
AVM CAPI Port Driver or the AVM NDI WAN CAPI Driver. For
further information, please refer to Chapter 4 “Onto the Internet
with FRITZ!Card”. Windows 3.x users are recommended to dial
in through a 16-bit client of an online service provider. Further
information about settings and applications can be obtained
from your service provider.
Online services
In order to dial online services you require the access software
for a service provider. Further information about installation and
SoftModem

2 All about FRITZ!Card
10
configuration of the application can be obtained from your ser-
vice provider.
ISDN file transfer
For I DN file transfer you use FRITZ!data with the IDtrans or
Eurofile transfer protocols. The use of V.42bis data compres-
sion on both sides optimizes the transfer rate.
Group 3 fax
For faxing to devices with the Group 3 fax standard, the fax emu-
lation is generated in the CAPI driver. The user-friendly and prac-
tical FRITZ! module FRITZ!fax is recommended as the fax ap-
plication.
After installation of the AVM I DN CAPI Port Driver, you can also
carry out fax operations using the virtual modem AVM ISDN FAX
(G3). Other fax applications offering CAPI 2.0 support can simi-
larly be used.
Voice
The FRITZ!vox I DN answering machine is supplied in order to
utilize the voice functions of FRITZ!Card. In addition to this, you
can use telephony software from other vendors offering CAPI
2.0 support.
ISDN BBS systems
FRITZ!com with the B channel setups for the X.75 and V.110 pro-
tocols is available to you for dialing I DN BB systems. Alter-
natively, after installation of the AVM CAPI Port Driver you can
also use the modem AVM ISDN BBS (X.75) to dial I DN BB
systems, or use terminal programs from other vendors.
Analog BBS systems
You can use FRITZ!com with the B channel setup “Modem Ana-
log” for dialing analog BB systems. Alternatively, after instal-
lation of the AVM CAPI Port Driver you can also use the modem
AVM ISDN Analog Modem (V.32) to dial analog BB systems,
or use terminal programs from other vendors.

2 All about FRITZ!Card
11
Remote Access Service, Intranet, X.31 etc.
If you wish to avail yourself of the aforementioned services, you
should contact the relevant service provider for information
about access conditions and settings.
The following diagram shows how the individual components
of FRITZ!Card work together:
Fig. 1 FRITZ!Card Functional Diagram
2.4 FRITZ!Card on the ISDN Connection
When your I DN connection is installed, your I DN network op-
erator first installs a so-called network terminator (NT). A net-
work terminator is equipped with two I DN sockets. Each of
these I DN sockets is an external 0 interface.
In most cases, an I DN PBX with analog extensions is connected
to one I DN socket of the network terminator and a digital ter-
minal device is connected to the second I DN socket. Existing
analog terminal equipment such as telephones, cordless tele-
phones, answering machines and Group 3 fax machines are con-
nected to the extensions of the PBX. The connected devices are
COMMON-ISDN-API 2.0
FRITZ!Card Classic
B channel protocols (digital):
X75, HDLC, transparent,
V110, V120, T90, ISO 8208 (X25)
AVM
NDIS
WAN
CAPI
Driver
AVM
ISDN
CAPI
Port
Driver
Applications such
as Exchange/
Explorer/
Browser/Outlook
FRITZ!data
FRITZ!fax
FRITZ!com
FRITZ!vox
Additional CAPI-based
ISDN software
On-line software
CAPI Soft-
Compression
X75/V42bis
CAPI Soft-
Modem V32
CAPI Soft-
Fax G3
C A P I

2 All about FRITZ!Card
12
addressed by way of multiple subscriber numbers (M N). Each
I DN connection has at least three M Ns. If you have connected
your PBX to one of the I DN sockets and your PC containing
FRITZ!Card to the other I DN socket, you will require additional
I DN sockets to connect other I DN terminal equipment such
as an I DN telephone (see gray area in the following Figure).
Fig. 2 Typical Configuration of an I DN Multiple Connection
However, there are also PBXs which offer digital as well as ana-
log extensions. You can connect I DN terminal devices to these
digital extensions. Digital extensions are also known as inter-
nal 0 interfaces. They are an alternative connection facility to
external 0 interfaces.
Whether you connect your FRITZ!Card to an internal or external S0
interface - the ISDN terminal device is not the FRITZ!Card but the
ISDN software on your PC, such as the FRITZ! modules FRITZ!data,
FRITZ!fax and FRITZ!vox for example.
All incoming calls from the I DN are distinguished not only by
their multiple subscriber number but also by their service indi-
cator. No such differentiation takes place for calls coming in from
the analog network: here telephone calls and faxes share the
Analog-Telefon mit
Anrufbeantworter
ISDN-Telefon
Fax
Schnurloses
Telefon
ISDN-Anlage
mit ananlogen
Nebenstellen
S
S
O
O
NT
NT
S
S
O
O
S
S
O
O
Rechner mit
FRITZ!Card

2 All about FRITZ!Card
13
service indicator “voice”. This is why it is important to specify
which call is to be accepted with which M N by which FRITZ!
module or by an I DN telephone or a PBX. Please refer to the
FRITZ! manual or the FRITZ! online help for the detailed con-
figuration instructions.
Thus, if you wish to receive faxes as well as data with
FRITZ!Card, you do not need to assign different multiple sub-
scriber numbers to these two applications because FRITZ!fax
is responsible for calls with the “voice” indicator and FRITZ!data
for calls with the “data” indicator.
FRITZ!fax and the answering machine FRITZ!vox both use the
same service indicator (“voice”), however.
If you use FRITZ!fax at the same time as FRITZ!vox, you must allo-
cate different multiple subscriber numbers to the two modules in
order that incoming calls can be assigned without ambiguity.
2.5 Mind you Install FRITZ!Card Correctly!
You should observe the following installation sequence for the
individual FRITZ!Card components:
1. Installation of FRITZ!Card and the driver software (Chapter 3
“How to Install FRITZ!Card”).
2. Installation of the FRITZ! or FRITZ!32 communications
software (Chapter 5 “FRITZ! Installation“) including the CAPI
Port Driver.
3. Installation of the AVM system drivers (Chapter 4 “Onto the
Internet with FRITZ!Card”).
4. Installation of software for online services such as AOL,
videotext services etc.
You should:
You must:
You can:

3 How to Install FRITZ!Card –Windows 95
14
3HOW TO INSTALL FRITZ!CARD
You have the facility to install FRITZ!Card in Windows 95, Win-
dows NT 4.0 (Workstation i386) or Windows 3.x. For further in-
formation, please refer to the relevant sections.
3.1 Installation in Windows 95
The FRITZ!Card CD contains an introduction which provides you
with information about the contents of the CD. You can start the
introduction by going into the Explorer and double-clicking on
the file INTRO.HLP in the root directory on the CD.
The installation of FRITZ!Card is performed in five main steps:
1. Installation of a new hardware component
2. etting the I/O area (I/O address) on FRITZ!Card
3. Installation of FRITZ!Card in the PC
4. Connection of FRITZ!Card to the I DN
5. Installation of the driver software for FRITZ!Card
With Windows 95 it is absolutely essential to observe the sequence
of the installation steps. If you fail to follow the specified sequence,
error-free operation of FRITZ!Card is not guaranteed.
1. Installing a New Hardware Component
• Insert the FRITZ!Card CD into your CD drive. tart the CD
introduction by going into the Explorer and double-clicking
on the file INTRO.HLP in the root directory on the CD.
• On the welcome page of the introduction, click on the icon
for FRITZ!Card and on the next page, click on the Windows
95 icon.
• On the following page, click on the icon ISDN-Controller
FRITZ!Card and then on the following page, click on the Start
installation icon. The Windows 95 Add New Hardware Wiz-

3 How to Install FRITZ!Card –Windows 95
15
ard is now started. This assists you in the installation of new
hardware components.
• elect the first entry “Other devices” because FRITZ!Card
has not yet been included in the list maintained by Windows
95 at this time. Then click on Next.
• Please be patient at this point. Windows 95 now searches
for all the hardware components which have already been
installed and displays them in the next window. Then click
on the Have Disk… button in this window.
• In the next window, click on the Search... button and then
specify the path for the installation files, e.g. D:\CARDWARE\
FRITZCRD\WINDOW .95. Confirm your choice twice by click-
ing on OK.
• In the next window, “AVM I DN-Controller FRITZ!Card” is rec-
ognized as a hardware component and displayed. Click on
Next.
• In the following window, the hardware wizard displays a free
I/O area (I/O address) and a free interrupt. Make a note of
the I/O area displayed. The values given cannot be changed
here. Click on Next.
We recommend that you adopt these values for FRITZ!Card and
set the jumper position accordingly on FRITZ!Card (see Chapter
6). For how to subsequently change the I/O area (I/O address)
and interrupt in the software, please refer to Sections 3.1.1, 3.2.1
and 3.3.1 “Changing the Settings in the Software”.
The hardware wizard now copies the complete contents from
the installation directory into a temporary folder. On comple-
tion of this process, a message is displayed stating that in-
stallation of the software for the hardware component is com-
plete. Click on Next.
• In the next window, a message informs you that the com-
puter must be switched off. Click on YES. It is necessary to
switch off the computer before installing FRITZ!Card in or-
der to activate all the settings you have made.
• witch off your computer and all other connected units and
pull out the power plugs.

3 How to Install FRITZ!Card –Windows 95
16
2. Setting the I/O Area (I/O Address) on FRITZ!Card
• In the second step of installation, if necessary, change the
jumper position for the I/O area (I/O address) on FRITZ!Card.
Use the value displayed in the hardware wizard. For how to
change the jumper position, see Chapter 6 “ etting the I/O
Area (I/O Address) on FRITZ!Card”.
3. Installing FRITZ!Card in the PC
• After installing the software for the hardware component and
setting the jumper position on FRITZ!Card, the third step of
installation is carried out: installing FRITZ!Card into your PC.
Loosen the screws of the PC housing and open the PC.
• elect an appropriate slot, remove the slot plate on the top
end and insert FRITZ!Card into the selected slot.
• crew FRITZ!Card tightly to the top end of the slot.
• Close the computer, tighten the screws and reconnect the
power plugs. The installation of FRITZ!Card is now com-
pleted. FRITZ!Card must now be connected to the I DN.
4. Connecting FRITZ!Card to ISDN
• For the fourth step of installation, take the cable supplied
with the card and insert the plug into the FRITZ!Card socket.
• imply insert the other end of the cable into the I DN socket.
5. Installing the FRITZ!Card Driver Software
Once FRITZ!Card has been installed in the PC and connected to
I DN, the fifth step is to install the FRITZ!Card driver software.
• witch your computer back on. When Windows 95 starts, the
welcome window of the setup program appears. Click on
Next. You can quit the installation procedure at any time by
means of the Exit button.
• In the following window, select the Installation option and
click on Next.
• In the next window, specify the folder in which you wish to
install the FRITZ!Card software. The default is C:\IDRIVER.

3 How to Install FRITZ!Card –Windows 95
17
You may also specify a different folder. If the information
you have given is correct, click on Next.
• Now in the next window, specify which D channel protocol in
used on your I DN connection (1TR6 or D 1). Click on the
desired protocol type and then on Next.
• The installation program will now copy all files to the speci-
fied folder. The driver is entered in the Registry so that
FRITZ!Card is activated automatically when Windows 95 is
started. When you exit Windows 95, FRITZ!Card is automati-
cally deactivated.
• In the last window of the installation procedure you will see
details about the I/O area (I/O address) and interrupt under
which FRITZ!Card is managed in the system and about the
D channel protocol used. Confirm these details with OK.
• After successful completion of the installation program, you
are requested to restart Windows 95. Confirm this request
by clicking on OK.
• After restarting Windows 95, the menu item “Programs” in
the tart menu contains a new folder called AVM. This con-
tains the files FRITZ!Card Readme, FRITZ!Card Setup,
FRITZ!Card Test and AVM Internet Home Page (link to the
AVM pages on the Internet, requirement: WWW browser and
Internet access).
FRITZ!Card Readme contains up-to-date information on FRITZ!Card.
You can reselect the D channel protocol afterwards using the
FRITZ!Card Setup program and activate CAPI SoftCompression X75/
V42bis. The FRITZ!Card Test program checks the functional integrity
of FRITZ!Card.
The installation of FRITZ!Card for Windows 95 is now completed.
3.1.1 Changing the Settings in the Software
hould you wish to change the value for the I/O area (I/O ad-
dress) and the interrupt for FRITZ!Card, go into the Device
Manager and enter the desired values there. More detailed
information on setting the I/O area directly on FRITZ!Card may

3 How to Install FRITZ!Card –Windows 95
18
be found in Chapter 6 “Changing the I/O Area (I/O Address)
on FRITZ!Card”.
3.1.2Uninstalling FRITZ!Card in Windows 95
To uninstall FRITZ!Card in Windows 95, open the Control Panel
of Windows 95 ( tart/ ettings) and double-click on the Add/
Remove Programs icon. “AVM I DN-Controller FRITZ!Card” is
included in the list of installed software. Mark this entry and
then click on the Add/Remove button. The uninstall program is
started. Confirm your intention to uninstall the software by click-
ing Yes. Finally you are requested to restart the computer. This
concludes the uninstallation of FRITZ!Card.

3 Installation der FRITZ!Card –Windows NT
19
3.2 Installation in Windows NT 4.0 (Workstation i386)
You have the facility to install FRITZ!Card with the aid of the
introduction contained on the CD. This introduction guides you
through the installation procedure and gives you installation
instructions.
tart the CD introduction by going into the Explorer and double-
clicking on the file INTRO.HLP in the root directory of the
FRITZ!Card CD.
To install the driver software for FRITZ!Card in Windows NT 4.0, you
must have administrator rights.
Note that before installing the FRITZ!Card driver software, it is abso-
lutely essential that you install the current Microsoft Service Pack on
your computer. You can obtain this software directly from Microsoft.
FRITZ!Card is installed on your computer by means of a detailed
installation program. Installation is performed in four main
steps:
1. etting the I/O area (I/O address) on FRITZ!Card
2. Installation of FRITZ!Card in the PC
3. Connection of FRITZ!Card to the I DN
4. Installation of the driver software for FRITZ!Card
With Windows NT it is absolutely essential to observe the sequence
of the installation steps. If you fail to follow the specified sequence,
error-free operation of FRITZ!Card is not guaranteed.
The procedure for installing FRITZ!Card is as follows:
1. Setting the I/O Area (I/O Address) on FRITZ!Card
• In the first step of installation before installing FRITZ!Card
in your computer, make sure that a free interrupt and a free
I/O area (I/O address) are available.
• FRITZ!Card is set to 5 for the interrupt and to 300 for the I/O
area. If you wish to use an I/O area for FRITZ!Card which
deviates from the preset value on the card, it is necessary to

3 Installation der FRITZ!Card –Windows NT
20
change the jumper position directly on the card. For how to
change the jumper position, see Chapter 6 “ etting the I/O
Area (I/O Address) on FRITZ!Card”.
2. Installing FRITZ!Card in the PC
• After checking and, if necessary, changing the jumper posi-
tion on FRITZ!Card, installation of FRITZ!Card is now car-
ried out. Before performing the installation, switch off the
PC and all other connected units and pull out the power
plugs.
• Loosen the screws of the PC housing and open the PC.
• elect an appropriate slot, remove the slot plate on the top
end and insert FRITZ!Card into the selected slot.
• crew FRITZ!Card tightly to the top end of the slot.
• Close the computer, tighten the screws and reconnect the
power plugs. The installation of FRITZ!Card is now com-
pleted.
3. Connecting FRITZ!Card to ISDN
•FRITZ!Card must now be connected to the I DN. Take the
cable supplied with the card and insert the plug into the
FRITZ!Card socket.
• imply insert the other end of the cable into the I DN socket.
4. Installing the FRITZ!Card Driver Software
Once FRITZ!Card has been installed in the PC and connected to
I DN, the next step is to install the FRITZ!Card driver software.
• Insert the FRITZ!Card CD into your CD drive.
• tart the introduction by double-clicking on the file
INTRO.HLP in the root directory on the CD.
• On the welcome page of the introduction, click on the icon
for FRITZ!Card and on the next page, click on the Windows
NT icon.
