Avol ALT4620M User manual

OPERATION MANUAL
ALT4620M
Read this manual carefully before operation.
* Attention
suitable TV broadcasting system as per your living area when you use this unit firstly. TV color
system is automatically searched regardless of your living area.
46'' Full HD Multi System LCD TV
Please kindly refer to "TV Broadcasting system" (page12 of user's manual) for choosing

INSTRUCTION MANUAL
DEAR CUSTOMER:
Congratulations on your purchase of the LCD color television! This manual will help you use the many
exciting and useful features to make your LCD TV viewing more enjoyable than ever before. Before
operating, please read all these safety and operating instructions completely and then retain this manual
for future reference.
IMPORTANT SAFETY AND MAINTENANCE INSTRUCTIONS
WARNING
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
Caution: To reduce the risk of
electric shock, do not remove
cover (or back). No user
serviceable parts inside. Refer
servicing to qualified service personnel.
This symbol indicates
“dangerous voltage”
inside the product that
presents a risk of electric
shock or personal injury.
This symbol
indicates important
instructions
accompanying product.
To reduce the risk of fire or
electric shock, do not expose
this product to rain or
moisture.
Apparatus shall not be
exposed to dripping or
splashing and no objects
filled with liquids, such as
vases, shall be placed on the
apparatus.
Electrical energy can perform many useful functions, but it can also cause personal injuries and property
damage if improperly handled. This product has been engineered and manufactured with the highest
priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE
HAZARD. In order to prevent potential danger, please observe the following instructions when installing,
operating and cleaning the product. To ensure your safety and prolong the service life of your LCD TV
product, please read the following precautions carefully before using the product.
1. Read these instructions---All operating instructions must be read and understood before the
product is operated.
2. Keep these instructions --- These safety and operating instructions must be kept in a safe place for
future reference.
3. Heed all warnings --- All warnings on the product and in the instructions must be observed closely.
4. Follow all instructions --- All operating instructions must be followed.
5. Attachments --- Only use attachments/accessories specified by the manufacturer. Do not use
attachments not recommended by the manufacturer. Use of improper attachments can result in
accidents.
6. Power source --- This product is intended to be supplied by a listed power supply indicated on the
marking label. If you are not sure of the type of power supply to your home, consult with your product
dealer or local power company. For added protection for this product during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from the wall outlet and
disconnect the cable system.
7. Power cable protection --- Protect the power cable from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the apparatus.
8. Power plug --- Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or third prong is provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for replacement of the obsolete outlet. Refer to the
identification/rating label located on the back panel of your product for its proper operating voltage.
To prevent electric shock, match wide blade of plug to wide slot, fully insert.
9. The MAINS plug is used as the disconnect device, and the disconnect device shall remain readily
operable.
10. Overloading --- Do not overload wall outlets, extension cables, or convenience receptacles on other
equipment as this can result in a risk of fire or electric shock.
1

11. Entering of objects and liquids --- Never insert an object into the product through vents or
openings. High voltage flows in the product, and inserting an object can cause electric shock and/or
short internal parts. For the same reason, do not spill water or liquid on the product.
12. Damage requiring service --- Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
a. When the power cable or plug is damaged.
b. When a liquid is spilled on the product or when objects have fallen into the
product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating
instructions.
Do not touch the controls other than those described in the operating
instructions. Improper adjustment of controls not described in the
instructions can cause damage, which often requires extensive
adjustment work by a qualified technician.
e. If the product has been dropped or the cabinet has been damaged in any way.
f. When the product displays an abnormal condition or exhibits a distinct change in performance. Any
noticeable abnormality in the product indicates that the product needs servicing.
This unit should only be serviced by an authorized and properly trained
technician.Opening the cover or other attempts by the user to service this unit
may result in serious injury or death from electrical shock, and may increase the
risk of fire.
13. Replacement parts --- In case the product needs replacement parts, make sure that the service
person uses replacement parts specified by the manufacturer, or those with the same characteristics
and performance as the original parts. Use of unauthorized parts can result in fire, electric shock
and/or other danger.
14. Safety checks --- Upon completion of service or repair work, request the service technician to
perform safety checks to ensure that the product is in proper operating condition.
15. Wall mounting --- When mounting the product on a wall, be sure to install the product according to
the method recommended by the manufacturer. This is a safety
feature.
ipod16. Stand --- Do not place the product on an unstable trolley, stand, tr
or table. Placing the product on an unstable base can cause the
product to fall, resulting in serious personal injuries as well as damage
to the product. When mounting the product on a wall, be sure to follow
the manufacturer’s instructions. Use only the mounting hardware
recommended by the manufacturer.
17. Careful move --- Use only the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus. When a cart
is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over. Sudden stops, excessive force and uneven floor
surfaces can cause the product to fall from the trolley.
18. Lightning --- Unplug this apparatus during lightning storms or when unused
for long periods of time.
For added protection for this television equipment during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna. This will prevent damage
to the equipment due to lightning and power-line surges.
19. Do not use this apparatus near water --- for example, near a bathtub,
washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming
pool, and the like.
Do not use immediately after moving from a low temperature to high
temperature environment, as this causes condensation, which may result in fire,
electric shock, or other hazards.
2

20. Do not place heavy foreign objects, liquid container on the product. Do not place naked flame
sources, such as lighted candles, should be placed on the apparatus, or else it may cause fire hazard
or electric shock.
21. Clean only with dry cloth --- Unplug this product from the wall outlet
before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
22. Ventilation --- Do not block any ventilation openings. Install in
accordance with the manufacturer instructions. The vents and other
openings in the cabinet are designed for ventilation. Do not cover or block
these vents and openings since insufficient ventilation can cause
overheating and/or shorten the life of the product. Do not place the product
on a bed, sofa, rug or other similar surface, since they can block ventilation
openings. This product is not designed for built-in installation; do not place the
product in an enclosed place such as a bookcase or rack, unless proper
ventilation is provided or the manufacturer’s instructions are followed.
23. Heat sources --- Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that produce heat.
24.Using video games or any external accessory with fixed images for 10
minutes can cause them to be permanently imprinted on the SCREEN.
ALSO, some network/program logos, phone numbers, teletext and images
in 4:3 form-at etc. may cause similar damage. This damage is not covered
by your warranty.
25. Panel protection --- The LCD panel used in this product is made of glass. Therefore, it can break
when the product is dropped or impacted upon by other objects. Be careful not to be injured by
broken glass pieces in case the LCD panel breaks.
26. Pixel defect --- The LCD panel is a very high technology product, giving you finely detailed pictures.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red.
Please note that this does not affect the performance of your product.
27. Working condition of the product: Temperature: 0℃~40℃
Placing condition of the product: Temperature: -20℃~50℃
28. To prevent the spread of fire, keep candles or other open flames away from this product at all times.
29. Earthing connection --- The apparatus shall be connected to a MAINS socket outlet
with a protective earthing connection.
NOTE:
Figures and illustrations in this User Manual are provided for reference only and may differ from
actual product appearance. Product design and specifications may be changed without notice.
3

USING THE REMOTE CONTROL
Use the remote control by pointing it towards the remote sensor window of the set.
Objects between the remote control and sensor window may prevent proper
operation.
NOTE: The illustration is for your reference
only, the remote sensor may
locate differently with different model.
Cautions regarding use of remote control
●Do not expose the remote control to shock. In addition, do not expose the remote
control to liquids, and do not place in an area with high humidity.
●Do not install or place the remote control under direct sunlight. The heat may cause deformation of the
unit.
●The remote control may not work properly if the remote sensor window of the main unit is under direct
sunlight or strong lighting. In such a case, change the angle of the lighting or LCD TV set, or operate
the remote control closer to the remote sensor window.
BATTERIES FOR REMOTE CONTROL
If the remote control fails to operate the LCD TV functions, replace the batteries in the remote control.
1.Open the battery cover. 2.Insert two size-AAA batteries. 3.Replace the cover until the lock snaps.
●Place the batteries with their terminals
corresponding to the (+) and (-)
indications in the battery compartment.
Precaution on battery use
Improper use of batteries can result in a leakage of chemicals and/or explosion. Be sure to follow the
instructions below.
●Place batteries with their terminals corresponding to the (+) and (–) indications.
●Different types of batteries have different characteristics. Do not mix batteries of different types.
●Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries
and/or cause old batteries to leak chemicals.
●Remove batteries as soon as they are non-operable. Chemicals that leak from batteries can cause a
rash. If chemical leakage is found, wipe with a cloth.
●The batteries supplied with the product may have a shorter life expectancy due to storage conditions. If
the remote control is not used for an extended period of time, remove the batteries from the remote
control.
●The batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as
sunshine, fire or the like.
AUDIO
i
?
0
I/II
-ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
*
INFO
SOURCE
4

CABLE INSTALLATION
Before the installation and use, please read carefully the relevant content in “Notice for Maintenance and
Safety”.
1. Take the LCD TV from the wrapping package and put it in a drafty and flat place.
NOTE: When you plug or unplug the LCD TV, computer or other equipments, you must make
sure that the AC power has been already shut down;
When unplugging the power cable or signal cable, please hold the plug (the insulated
part), do not draw the body of the cable.
2. The RF output terminal can be connected with the RF input port of the TV.
3. The output AV/ S-VIDEO terminal of DVD can be connected with the AV/ S-VIDEO input port of the
TV through AV/ S-VIDEO cable.
NOTE: S-VIDEO and AV1 can not be used at same time for they share of one audio channel.
4. The output COMPONENT(YPbPr) terminal of DVD can be connected with the COMPONENT(YPbPr)
input port of the TV through AV cable.
5. Connect one end of the VGA cable with the VGA port on computer, connect the other end of the VGA
cable with the VGA port on the TV, and tighten the bolts clockwise on the each end of VGA cable.
NOTE: While connecting the 15-pin VGA, please do not insert the plug overexertedly, for fear
the pin might be broken.
6. Connect one end of the HDMI cable with HDMI output port, connect the other end of the HDMI cable
with the HDMI port on the TV.
NOTE: While connecting the HDMI, please aim at carefully, do not insert overexertedly, for
fear the pin might be broken.
7. The AV output of the TV can be connected with the input port of other AV equipment through AV cable.
NOTE: AV OUT can output only TV channels' audio/video signal.
DIGITAL AUDIO OUT can output TV, AV, S-VIDEO, YPBPR and MEDIA channels' audio
signal.
8. Check and make sure that all AV cables are connected with the corresponding ports correctly.
9. Connect the AC power cable with 100-240V AC power supply.
10. Connect the other end of the AC power cable with the AC power port on the TV.
NOTE：
The range of power input for the LCD TV is 100-240V/50Hz, 60Hz, do not connect the
TV power input port with the AC power out of the above range.
Please hold the insulated part of the plug when you are unplugging the power cable,
do not touch directly the metallic part of the cable.
YPBPR2 and AV3 can not be used at same time for they share of one audio channel.
5

NAME OF COMPONENTS
Name Function Description
〖 〗 Enter or leave the standby mode, same as on the remote control.
〖CH-〗1. In TV mode, decrease channel number; 2. To select functions in menu operation.
〖CH+〗1. In TV mode, increase channel number; 2. To select functions in menu operation.
〖VOL-〗To decrease the sound volume. Adjust functions in menu operation.
〖VOL+〗To increase the sound volume. Adjust functions in menu operation.
〖TV/AV〗To switch among the signal source.
〖MENU〗Open or close the menu.
〖 〗
Definition and function presentation of LCD TV
The definition and function presentation of the buttons of the product:
6
Main power switch

QUICK START GUIDE
Connection
zTurn off and unplug all components before making connections.
zDo not turn on the TV until connection setup is completed.
Input
Connector Video Connection Audio Connection High or Standard Definition Quality
AV
Composite video connector
Audio L/R
S-VIDEO
Use this connector in place of
composite video connector
Audio L/R
480P
YPBPR
Component connection
Audio L/R
1080p, 1080i, 720p, 480p, 480i
HDMI
HDMI connection
HDMI cable carries both video and audio
signals. Separate audio cable is not
needed. (When HDMI is connected to DVI
with an adapter, a separate audio L/R is
necessary)
1080p, 1080i, 720p, 480p, 480i, PC
VGA
VGA/PC connection
VGA/PC audio
1024×768(60Hz)
Connection
USB USB connection USB2.0
RF RF connection 75Ω
Turn on the TV
1. Connect the AC input cable then turn on the AC switch of the TV.At this time the TV will enter
standby mode.
2. Switch on the TV by pressing .
Scanning channels
1. Press SOURCE button, you will see the signal source menu.
2. Press ▲/▼button to highlight TV then press ENTER.
3. Press the MENU button to bring the OSD menu up.
4. Press ▲/▼button to select SETUP menu, press ► button to enter.
5. Press ▲/▼button to highlight Auto Search, press ► button to perform the automatic channel
searching.
6. Then, the Auto Search Frame comes out and the system begins to seach channels, the searched
channels can be saved automatically.
7
NOTE: "Refer to page 16 for detail" under USB information.

REMOTE CONTROL
The buttons of the original remote control are as following:
Definition of the buttons on remote control:
1. POWER: Enter or quit the standby mode.
2. INFO: Show info of current program.
:Requests index page when index link is valid.
3. :Mute or restore sound.
4. NUMBER BUTTONS: Use to choose channels.
5. SOURCE: Select signal source.
:Reveal, displaying the hidden information in the
Picture/Text.
6. ∞I/II:The button can be used to switch among
Mono/Dual1/Dual2.
7. ZOOM : Adjust displayable aspect ratio.
SIZE : Switch between zooming to the upper
half, lower half and in full.
8. RECALL : Return to last viewed program/signal
source.
9. MENU: Press to display/disappear the on screen
menus or to quit some operations.
10. EXIT: Quit the current interface.
11. ENTER: Select or confirm menu item.
12. △/▽/◁/▷: Select direction.
13. VOL+/VOL-: Increase/Decrease audio volume.
14. CH+/CH-: Scroll to next/previous channel.
15. SLEEP: Set the sleep timer.
16. REPEAT: Press to select the repeat play mode. (in
MEDIA mode)
mode.(You should setup your favourite channels in
Program Edit menu)
navigation link.
:Fast reverse (in MEDIA mode)
:Fast forward (in MEDIA mode)
: Previous (in MEDIA mode)
: Next (in MEDIA mode)
:Stop (in MEDIA mode)
:Hold, holding the content of the Picture/Text.
:Play / Pause (in MEDIA mode)
: Text, Switch between teletext on, mix and
teletext off.
:Sub-code, sub-page of the Picture/Text.
: Enter or quit the PIP function.(in HDMI mode)
:Cancel, displays TV picture while maintaining
TEXT mode active.
MEDIA signal source, press this button can only
select the picture mode.
NOTE:
All pictures in this manual are
examples, only for reference,
actual product may differ from the
pictures.
The buttons not mentioned
here are not used.
1
2
3
4
56
78
910
11 12
13 14
15
16 17
18
19
20 21
22
23 24
17. ♥:Press to display the Favourites program in TV
18. COLOR BUTTONS: Red/green/yellow/blue key
19. STILL: Freeze or activate the current picture.
20.
21.
22. E/W: Switch between different languages.
23.
24. TOOLS: Press to select the picture/sound mode. In
8

TV OPERATION
Turning on and off the TV
1. Turning on
1. Connect the AC input cable then turn on the AC switch of the TV. At this time the TV will enter standby
mode.
2. In standby mode, press the button on remote control to turn on the TV.
2. Turning off
1. When the temporary turning off is required, please press the button on remote control.
2. When a complete turning off is required, please turn off the AC switch on the TV and unplug the power
cable from the power socket.
NOTE:
If there is an accident power off, the TV will be in standby mode automatically after re-supply
the power. To ensure the normal use of the TV, the frequent turning on and off is forbidden,
when there is an accident power off, it is recommended to unplug the power cable from the
power socket.
3. Automatic turning off for no TV signal input
When the TV working in RF receiving mode, the TV will enter standby mode automatically 5 minutes
after there is no any signal (such as the programs are stopped by TV station)
Press SOURCE button on the remote control to enter the menu, and then select the signal sources
among TV, AV1, AV2, AV3, S-VIDEO, YPBPR1, YPBPR2, HDMI1, HDMI2, HDMI3, PC, MEDIA1 and
MEDIA2 by pressing ▲/▼ on the remote control. Press ENTER button to access the selected mode.
The volume can be adjusted continuously by pressing VOL+/VOL- on the remote control.
Press button on the remote control to mute the sound.
The icon displayed on the lower left position is as the following picture:
You can release mute by pressing or VOL+.
Switching the Signal Source
Adjusting Volume
Mute and Relevant Functions
9

Channel Selection
Press CH+/CH- on the remote control to increase or decrease the channel numbers. Also, the channel
can be selected by pressing the number buttons.
Additionally, when TV is in AV, S-VIDEO, YPBPR, HDMI or PC mode, the TV will work in TV mode and
play the corresponding channel if any number button is pressed.
Basic Function of the TV
Many function settings and adjustments of the TV will begin from the menu choosing. All operation can
be followed as help bar shows. Press MENU button to display the main menu. Press ▲/▼button to
cycle through the main menu. Press ►enter into sub-menu. Press ▲/▼button to highlight the item to
be adjusted. Press ◄/►button to set the selected item. Press ►button to enter into sub-menu. After
setting is done, press MENU to go back to the previous menu. Press EXIT to quit the setting menu.
zIn this manual, the icon with “〖〗” means the button on the TV.
zButtons on the TV have the same function as corresponding buttons on the remote control. If
your remote control is lost or couldn’t work, you may use the buttons on the TV to select
menus. This manual focuses on operation of the remote control.
zSome items in the menus may be hidden depending on modes or signal sources used.
zWhen an item in MENU is displayed gray, it means that the item is not available or cannot be
adjusted.
Picture Menu
Press MENU button on the remote control to select the PICTURE menu. Shown as below:
Picture Mode
To select the picture mode.
Brightness
To adjust the picture’s brightness.
Contrast
To adjust the picture’s contrast.
Color
Adjusts intensity of all colours.
Sharpness
To adjust the picture’s sharpness.
Tint (Only in the NTSC mode)
To adjust the tint of the picture.
Color Temp
Normal, Cool and Warm, three modes of color
temperature are provided.
10

Advanced
DNR
Provide the picture with dynamic noise reduction
treatment, checking the high frequency noise of
the picture, there are Off, Low, Mid and High, four
modes of noise reduction. “Off ” means to close
the noise reduction.
DCC
Adjusts the contrast to keep it at the best level
according to the brightness of the screen.
Backlight
To control the brightness of the screen, adjust the
brightness of LCD panel.
Sound Menu
Press MENU button on the remote control to select the SOUND menu. Shown as below:
Sound Mode
To select the sound mode.
AVL
AVL (Automatic Volume Leveler) is used to
control the volume automatically.
Surround
To switch the surround sound.
Equalizer
Press ►button to enter into Equalizer item, you
can strengthen or weaken some audio effect as
you favor. When changing the sound parameters
to change the sound mode.
11

Setup Menu
zIn TV mode
Press MENU button on the remote control to select the SETUP menu. Shown as below:
Channel
Display the current channel number, you can
switch between the channels through the button
◄/►
.
Color System
To select the Colour System.
Sound System
To select the Sound System.
Auto Search
In TV mode, select Auto Search, and then press ►to perform the automatic channel searching as
described in the following picture：
During searching, press MENU to quit the automatic search and go back to the previous menu.
After automatic search has been compete, or the capacity of storing 235 channels has been used up,
or the EXIT is pressed during searching, the system will quit from automatic searching mode and
switch to channel 1 automatically.
Manual Search
Manual Search lets you manually tune and arrange the stations in whatever order you desire.
Country Color System Sound System
AZORES(PORTUGAL) PAL B/G
BALKANS(KOSOVO, BOSNIA) PAL B/G
BELGIUM/GERMANY/ITALY PAL B/G
IRAQ SECAM B
AFGHANISTAN PAL B
NETHERLANDS/NORWAY PAL B/G
SECAM B
PAL B
KUWAIT/TURKEY/JORDAN PAL B/G
UNITED KINGDOM PAL I
CZECH/HUNGARY/POLAND PAL D/K
RUSSIA SECAM D/K
U.S.A./JAPAN/KOREA/GUAM M
COLOR TV BROADCASTING SYSTEM
SAUDI ARABIA
NTSC
12
TV broadcasting system:

Program Edit
1. Use the ▲/▼button to select a channel.
2. Press the RED / GREEN / YELLOW / BLUE button to edit the channel.
Fav.
Press the RED button to set or cancel the
selected channel as one of the favourite
programmes.
Press the button to display the Favourites
program.
Swap
Use the ▲/▼button to select a channel that you
wish to move and then press the GREEN button.
Press the ▲/▼button to select the channel is to
be moved, and press the GREEN again. The first
selected channel is exchanged with the second
selected channel.
Skip
Press the YELLOW button to skip or not skip the selected channel. When setting the program skip as
on, CH+/CH- button cannot select it. But you can select the skipped program by pressing the number
buttons directly.
Edit
Press the BLUE button to rename the selected channel. Use the ▲/▼button to select the characters
to represent the station name, use the ◄/►button to move the next position of character, press the
ENTER button to confirm.
PC Menu
zIn PC mode
Press MENU button on the remote control to select the PC menu. Shown as below:
H-Position
Moving the picture horizontally through ◄/►.
V-Position
Moving the picture vertically through ◄/►.
Phase
Phase adjustment of the picture: in PC mode, this
function can be worked when there is any
abnormality of pictures.
Clock
Press ◄/►button to adjust it.
Auto Adjust
Automatic position & effect adjustment of the
pictrue. If the picture position is not so good, you
can select this function.
Frequency
Display the current channel frequency.
AFT
Press ◄/►to setup the automatic frequency tracking.
13

Timer Menu
Press MENU button on the remote control to select the TIMER menu. Shown as below:
Current Time ( hour:minute )
/►
y
( hour:minute ) the TV by pressing ◄/►
tly

annel for turning on the TV through ◄/►to change the channel number (1~235).
Pre trol to select the FUNCTION menu. Shown as below:
Language
OSD language selection.
on.
Blue Screen
The on and off modes of Blue Screen are as following
When there is no other signals
Set the current time by pressing ◄/►to change
the time parameter, or you can directly input the
time through the number buttons.
Off Time ( hour:minute )
Set the time to turning off the TV by pressing ◄
to change the time parameter, or you can directl
input the time through the number buttons.
On Time
Set the time to turning on
to change the time parameter, or you can direc
input the time through the number buttons.
On Channel
Set the ch
Timer Mode
Set the timer mode, there are modes of Off, Once and Daily.
Sleep
To select the Sleep Time you want.
Function Menu
ss MENU button on the remote con

Zoom
Picture zoom mode selecti

:
When there is no TV signal
On Blue Screen Blue Screen
Off Black ScreenPicture is spotted with snowflake
14

Transparency
Select menu transparency according to different background pictures.
ked and lose their function ( to
l Lock, please press〖CH+〗or〖CH-〗button for more than 5 seconds), when you select


zIn HDMI mode select the FUNCTION menu.
N setting menu, through ▲/▼to select the items, and press ►to enter into PIP
st the PIP
Position yourself by selecting "On"
t the PIP Source. The PIP source you can
/S-VIDEO.
ct the PIP window

item, and restore to the original setting
s ►, after this operation, all of the settings

Panel Lock
When the Panel Lock is set as "On", all of the buttons on the TV are loc
release Pane
this item as "Off ", the buttons on the TV are in normal mode.
Power Manage
PIP Setting
Press MENU button on the remote control to
In the FUNCTIO
Setting menu. Shown as below :
PIP On/Off
To switch the PIP mode. You can adju
Source / PIP
mode.
PIP Source
To selec
select TV/AV
PIP Position
Press ◄/►button to sele
position.
Reset
Select this
by pres
made by user will be replaced by original setting
parameters.
, 3 Hours and 4 Hours by pressing ◄/►,
ans if there is no any operation to the TV in 1 (or 2 or 3 or 4) hours, the TV will enter
Power Management Mode, you can select Off, 1 hour, 2 Hours
this operation me
into the standby mode automatically.
15

o Access/Quit USB Mode
button to call up the signal source selection menu. Use the ▲/▼to highlight
TER button to access the MEDIA mode. You may also use the signal
ff the TV. Connect the USB device after the
ing on.
B interface for additional instructions.
M
Us O or TEXT, the files saved in the USB device connected to the
to return to the previous folder.
MEDIA Operation
T
Press the SOURCE
MEDIA1/MEDIA2, and the EN
source selection menu to exit from the MEDIA mode.
NOTE:
Please unplug the USB device when turning on/o
TV turn
Special USB device may be not or well supported.
Insert a USB device with a standard USB interface correctly. Please read operation manuals
of your USB device that will be connected to the US
Consequence due to misuse is not within the range covered by our warranty.
It's recommended to connect external USB devices to the interfaces directly to ensure the
line when in use can drive the connected USB device. A non-standard extended line may
cause abnormal operation to the USB device, which is not resulted from the TV.
ain Operating Interface
e the ◄/►to select MOVIE, MUSIC, PHOTO or TEXT.
After selecting MOVIE, MUSIC, PHOT
USB interface will be displayed on the screen.
Press the ▲/▼to select a folder or file.
Press ENTER to open the folder or play the file.
ENTERHighlight Up Folder in the menu and press
The formats supported
The TV supports the following files including movie, music, photo and text.
PEG-1/MPEG-2/MPEG-4, RM, RMVB file format.
upported by the USB.
For MOVIE, it supports M
For MUSIC, it supports MP3 file format.
For PHOTO, it supports file formats among JPEG, BMP.
For TEXT, it supports TXT.
NOTE: Special algorithm documents may not be or well s
high-speed data line interfaces' stable and reliable operation. Make sure that a USB extended
The USB supports the format mentioned above, if the file format is not supported, change
it to the given format.
16

File Playback
1. Play/ Pause
selected file of a folder or pause.
re 2/4/8/16 levels of rewind speed.
fast forward speed.
the repeat play mode.
ss ◄/►to change pages up and down. Press ▲/▼to change lines up
ay use the◄/►/▲/▼to move the photo.

Start playing the
S2. top
Stop the playing files.
3. / Fast Reverse/Fast Forward
Fast Reverse: There a
Fast Forward: There are 2/4/8/16 levels of
4. / Previous/Next
You can select the desired files manually in normal condition.
5. REPEAT
When play MOVIE and MUSIC files, you can press this button to select
Circulating play for single file.1:
A: Circulating play for all file.
X:
6. ◄/►/▲/▼
No circulating play.
When view the TEXT files, pre
and down.
7. ZOOM
Press button to zoom Photo/Movie Picture. If size of the zoomed photo exceeds the display
m
range, you
8. INFO
When play Photo and Movie files, you can press INFO button to display the current file information.
17

When you meet the following common problems, you might diagnose and get the solutions without
Possible Reason Solutions
TROUBLE SHOOTING
contacting with the technicians.
Symptoms
No picture d no 1.The po ged in 1.Plug the pwer cord is not plug ower cord in
2.Turn the power on
, no sound, an
indicator light on 2.The power is off
Picture and sound with 1.Contrast, sharpness, and color
2. properly
ontrast,
2. the rd
3.
are set improperly
Color system is set im
3.Sound system is set improperly
1.Adjust the value of C
sharpness, and color
Set the Color system to
country broadcasting standa
Set the Sound system to the
country broadcasting standard
abnormity
Picture is spotted or with snow Signal source is low-grade or the Use the qualified signal cord
signal cord is in a lower quality
Contrast, brightness, color and Adjust the value of contrast,
volume are all in the minimum
value or TV is in mute mode. brightness, color and volume
No picture, no sound and ly Connect the signal cable correctly
indicator light is on The signal cable is not correct
connected.
Blue screen, AV or S-VIDEO is ignal input or the video Connect the video cable correctly
There is no s
cable is not connected or
incorrectly connected
displayed
Picture is unclear or shaking or
with black horizontal strips (in
PC mode)
PC picture is not centered
PC picture is not correctly adjusted.
Enter into “PC” menu, select “Auto
Adjust” item to perform automatic
calibration and adjust “Phase” to
solve the problem
No sound There is no audio signal input or Connect the audio cable correctly
audio cable is not connected
correctly
PC picture display with improper temp is adjusted Readjust the color temp, or selectThe color
color incorrectly by user the original color setting
HDMI source, with snow pixel of is not
full screen The source generate Plug the HDMI cable again standard
The remote control does not Batteries are improperly installed or
d the
2.
3.Replace the batteries
1.Make sure the positive an
negative polarities are correct.
Check if there is a loose contact
between the batteries and the
springs
work exhausted
NOTE: the product of advanced technology, it is consisted of more than 3,932,160 film transistors, l
consideration
LCD TV is
and it can bring you with the perfect and vivid picture, but in a very rare condition, there might be severa
inactivated displayed on the screen fixedly as blue spot, green spot, red spot or black spot and white
spot, please notice, this phenomenon does not affect the any performance of the product.
The PC display mode is designed delicately according to the standard model, also with the
of the adapter in poor quality in the market, but the display quality might be affected by using such
adapter in poor quality.
18
