AC-EX100TT-UHD-T
Table Top/Under Table, Dual Input
(HDMI/VGA) Auto Sensing HDBaseT
Transmitter
1

Introduction
The AC-EX100TT-UHD-T is a 100m HDBaseT Tx with the ability to
be powered by the Rx. It features RS-232 & IR Pass-through inputs
along with its auto sensing HDMI and VGA ports.
Key benefits of using AC-EX100TT-UHD:
1) ULTRA HIGH DEFINITION: Our AC-EX100TT-UHD supports 4K up to 70M
(230FT) & HD up to 100M (330FT) with crystal clear 4K Resolution. NOTE:
High quality CAT6a shielded required for maximum performance.
2) DISTANCE: By using AC-EX100TT-UHD-T, the transmission distance for HD
1080P is up to 100 meters (330’) and with 4K it is up to 4K up to 70M (230')
3) AUTO SENSING: This Table-Top/Under Table Transmitter is designed to be
a "set it & forget it" piece of hardware. When the user plugs their devices in
(BYOD), the transmitter will automatically sense the signal and make it active.
If both inputs are in use, there is a simple button on the front to toggle inputs.
4) CONTROL: IR & RS-232 allow control of a rack or standalone projector/
display.
5) POWER: No local power is required when you use the AC-EX100-UHD-R2.
Power is provided by ultra-stable PoE technology. Optionally, you can power it
locally for use with any HDBaseT receiver.
2
AC-EX100TT-UHD-T

Applications:
This unit is designed to work flawlessly with all PC, VESA and traditional
resolutions up to and including 4K 60Hz 4:2:0 8-bit & HDR 4K 30 4:2:2 12-bit.
VGA supports DCI 2K, 1080P, 1920x1200x60. In addition to its compact and
robust design, The AC-EX100TT-UHD-T transmits digital signals up to 100
meters (328’) giving you ultimate flexibility, especially in large rooms
like libraries or auditorium style rooms/classrooms. For a complete
solution pair the table-top transmitter (AC-EX100TT-UHD-T) with
the AC-EX100-UHD-R2 HDBaseT Receiver to power the table-top
transmitter from afar using PoE, thus eliminating the need for a power
supply unit near the wall plate.
3
AC-EX100TT-UHD-T

Table-top/under-table HDBaseT Transmitter
■Features
•HDMI 2.0 & VGA Inputs
•4K 30 4:4:4, 4K60 4:2:0 HDMI Support
•HDR 4:2:2 12 Bit Support
•DCI 2K, 1080P, 1920x1080x60 VGA Support
•HDCP 2.2 & Earlier Supported
•100M (330ft) 0n 1080P, Up to 70m (230ft) on 4K (Cat6a)
•No Local Power Necessary (Powered by AC-EX100-UHD-R2)
•Rugged, long-life chassis
•Plug & Play auto input sensing
•Select-able input (If both are plugged in)
•Designed for the conference/classroom room so your customer can
focus on their meetings, not their video system.
•3.5mm Input for audio (with VGA input only)
•Single UTP/STP LAN cable (CAT-5E/6A) for all signals
•ESD protection circuitry (Inputs / Outputs) till 7KV.
•Transfer IR & RS-232 signals from Tx to Rx (From Control
Processor)
•I-Pass Feature for control system IR "pass-through"
•3-20v protection circuit built in for safe IR transport
•Compatible with HDBaseT displays, projectors, AVR's
•Supports uncompressed PCM 2- Ch., 5.1, 7.1, Dolby Digital, DTS,
Dolby TrueHD, DTS HD-Master Audio, Atmos.
•Can Cascade for ultra-long distance
4
AC-EX100TT-UHD-T

Notice
AVProConnect reserves the right to make changes to the hardware,
packaging and any accompanying documentation without prior written notice.
Warning
To reduce the risk of fire, electric shock or product damage:
Basic
6. Clean this device with
a dry cloth only.
1. Do not expose this device to
rain, moisture, dripping or
splashing and ensure that no
objects filled with liquids are
placed on or near the device.
2. Do not install or place this unit
in a bookcase, built-in cabinet or
in another confined space.
Ensure the unit is well ventilated.
3. To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
5. Do not place sources of naked
flames, such as lighted candles,
on the unit.
7. Unplug this device
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
plugs.
9. Only use attachments /
accessories specified by
the manufacturer.
10. Refer all servicing to
qualified service
personnel.
5
AC-EX100TT-UHD-T

■What’s In The Box? Two ways to purchase:
6
AC-EX100TT-UHD-T

7
AC-EX100TT-UHD-T
■Specifications

8
AC-EX100TT-UHD-T
■Powering the AC-EX100TT-UHD-T
There are 2 ways to power the unit:
1. Use a HDBaseT Receiver that provides up stream power. We recommend
using the AC-EX100-UHD-R2.
2. If you will be using the unit directly into a NON PoE provider (AVR,
projector, display, or other HDBaseT receiver), you can power it using a
48v, .5A - 2 pin type power supply.
NOTE: In these diagrams, arrows indicate the flow of POWER, not other
signals.
Tx
OPTION 1: PoE From Receiver (AC-EX100-UHD-R2)
OPTION 2: Local power to work with other HDBaseT devices
HDBaseT Compatible Projector
CAT5/6/7 for
Audio & Video
Signals
Rx

AC-EX100TT-UHD-T
■Using Bi-Directional Power w/ AC-EX100-UHD-R2
Using the bi-directional PoE feature is fairly easy to do. Even though the AC-
EX100-UHD System is designed to handle "hot" changes. We strongly
recommend you switch directional power while the units are completely
unplugged from Power, HDMI or CAT Cable.
1. PoE direction is set by the dip switch on the Tx and Rx. You are setting
the PoE behavior for the unit. You are selecting whether you want the
unit to RECEIVE PoE or SEND PoE.
2. Here are the two possible modes.
EX1. To Power from transmitter, PoE setting should be as follows: HDBT
Tx -- The PoE slide switch should be set to Tx.
HDBT Rx -- The PoE slide switch should be set to Rx.
EX2. To Power from the receiver, PoE setting should be as follows: HDBT
Tx -- The PoE slide switch should be set to Rx.
HDBT Rx -- The PoE slide switch should be set to Tx.
3. Be sure you have the power supply plugged in on the newly selected PoE
origination side.
4. Continue normal operation.
AC-EX100TT-UHD-T (Tx)
AC-EX100-UHD-R2 (Rx)
Slide Switch Location
Slide Switch Location
9

10
AC-EX100TT-UHD-T
■IR Configuration
The AC-EX100TT-UHD-T has an IR input designed to work when
connected directly to control processors, or other IR signal generators
like Global Cache, On Controls, etc... IR signals are routed through
the entire HDBaseT link to the Rx (AC-EX100-UHD-R2).
This allows you to send control signals to:
1. The "Rack" to control and amplifier, matrix, AVR or similar for more
advanced systems.
2. Control power, volume, etc... of the remote projector/display
connected to the receiver.

AC-EX100TT-UHD-T
■RS-232 Configuration
The AC-EX100TT-UHD-T has a bi-directional RS-232. RS-232 signals are routed
through the entire HDBaseT Link to the Rx (AC-EX100-UHD-R2). You must plug
into the "HDBT" RS232 port - This will pass unaltered commands to the Rx. This
is the port for pass-through:
1. The "Rack" to control an amplifier, matrix, AVR something or similar for more
advanced systems
2. Control power, volume, etc... of the projector connected to the Receiver.
NOTE: In larger systems, RS-232 is the recommended control method for
maximum performance and longevity.
Pre-made 3.5mm to DB9 cables can be purchased from AVProStore.
11
RS232 Commands for local control on next page...
■RS-232 Pass-Through
This allows you to:

AC-EX100TT-UHD-T
■RS-232 Local Control & Commands
12
Additionally, the transmitter RS-232 command bridge detects and scans
commands from both the local RS-232 port and the HDBaseT stream. As soon
as a properly formatted command is detected, the command is executed inside
of the AC-EX100TT-UHD-T. This means you can control/switch ports from a
distance or from local RS-232 with proper commands. Commands that are not
listed below, get forwarded to the RS-232 port at the remote Rx.
To control locally, Use this port:
RS232 Settings:
Baud Rate - 115200
Checksum - None
Bit Num - 8
Stop Bit - 1
RS232 Commands:
Pin Configuration:
Same for Local and HDBT
Tip - Tx (transmit data out)
Ring - Rx (receive data in)
Sleeve - GND (ground)

The RS-232 port is also connected to the HDBT extender, and available on the
remote end. We allow a control system to communicate both with the device on
the other end as well as the AC-EX100TT-UHD-T directly.
To do this, the commands above must be prefixed with either @ex100tt or
@<hostname> where <hostname> is the name configured through the web page
(See how to use WebOS below: defaults to ex100tt-XXXX).
NOTE: XXXX= Device Serial Number, the device serial number is found ..............
Response Structure:
<@hostname> <sp> <parameter> <sp>... <parameter> <sp> <end of
response>
<@hostname> = indicates the device initiating the response
<sp> = space, ASCII 0x20
<parameter> = command-specific number of parameters, each followed by a
space or 0x20 in hex <end of response> = newline char \n for ASCII and 0xA in
hex
For example:
@ex100tt insel vga
@ex100tt-0000 insel vga
AC-EX100TT-UHD-T
■RS-232 Local Control & Commands cont.
13

AC-EX100TT-UHD-T
■Using Ethernet (as a HUB):
Ethernet usage is very straight-forward. It is used for driving network communication over the HDbaseT link.
This of these ports as a "Hub", if you plug one port into a router all the other ports on both the Tx & Rx now
have access to the network.
Usage Examples:
•Supplying a hardwire Ethernet connection to video zones for on-device streaming and/or local gaming
devices and players.
•Supplying server based content from a server to a remote display.
•Supplying a zone with a hardwired Ethernet connection for a Wi-Fi access-point in remote zones.
Usage is plug-&-play - the ports are always active and as long as ONE of the FOUR combined ports between
the Tx and Rx is connected to the network the other three also have access.
Ethernet Indicator Lights:
•AMBER - This indicates an Ethernet connection is made, and the connection is stable. This should be
SOLID.
•GREEN - This indicates that there is activity on the line. This light flashes randomly as data is transmitted.
If this light is steady OFF there is no data coming through or you may need to reset the Ethernet router.
Usage Diagram:
14

AC-EX100TT-UHD-T
■Ethernet (IP/LAN) Control
The unit can be controlled with LAN and the Ethernet is extended as well so you can actually send
commands and pull up the internal WebOS page from the remote Rx and control it using IP.
IP Defaults (Static IP):
•Host IP (WebOS Access) - 192.168.1.239
•Subnet Mask - 255.255.255.000
•Gateway IP: 192.168.1.254
Using DHCP/Host Alias - The Host Alias is an alternate way to access & control the unit. It works off of DHCP
protocol, so this means you will not have to change your PC's IP no matter what network you are on, so long
as your PC is on the same network you will have access.
Default Host Alias: ex100tt-xxxx (xxxx=the serial ID, this can be found by looking at the serial
number on the bottom of the unit. Find the number as pictured below and add a ZERO to the front
of it:
Type into PC browser page: http://ex100tt-xxxx/
Type into MAC browser page: http://ex100tt-xxxx.local
To Use IP Control - you can send the commands below directly to the unit OR
To access the WebOS for
the first time you can type the static IP above or the Host Alias. The next page has an example of the
WebOS in use.
15
By default the unit is reached by using the STATIC IP above. You can toggle DHCP on/off as well by pressing
and holding the input select button for 5 SECONDS as you power up the AC-EX100TT-UHD-T.
Press and hold to toggle DHCP
In this image you can see the device serial number is
177, so the Host Alias ID is http://ex100tt-0177/

AC-EX100TT-UHD-T
■Ethernet (IP/LAN) Control cont. (Commands)
16

AC-EX100TT-UHD-T
■Ethernet (IP/LAN) WebOS Example Page
17

18
AC-EX100TT-UHD-T
Input Select Button/Indicator Light
Indicator Colors:
HDMI Active
VGA Active
■Selecting the source
The Input is automatically set based on proprietary Auto-
Sensing Technology. The source displayed will be from the LAST
device plugged in. The auto-sensing is based on the detection of +5V
present in VGA / HDMI inputs. If this signal is missing or the source is in
standby the auto-detection cannot work.
You also have the ability to select a source if VGA and HDMI are both
occupied. Selecting the source is a single press on the "Input Select"
button on the front of the AC-EX100TT-UHD-T. There are only 2
possible states:
1. When the light is ORANGE/AMBER the HDMI source is active.
2. When the light is GREEN the VGA source is active.
Continuing to press the button will toggle between both sources.

19
AC-EX100TT-UHD-T
■Mounting Options
While the AC-EX100TT-UHD-T can be mounted any way or anywhere you
see fit with the supplied mounting ears, there are three common BYOD
end user configurations:
1. In a "Table-Top" configuration: The unit is out on a top of a table
for the user to plug into.
2. In "Under-Table" configuration: The signal is coming from a
presenter location like a podium.
3. In a "Rack-Room" configuration to utilize remote control and auto
sensing"

•Use the power supplies provided. If an alternate supply is required,
check voltage, polarity and that it has sufficient power to supply the
device it is connected to.
•Do not operate these products outside the specified temperature
and humidity range given in the above specifications.
•Ensure there is adequate ventilation to allow this product to operate
efficiently.
•Repair of the equipment should only be carried out by qualified
professionals as these products contain sensitive components that
may be damaged by any mistreatment.
•Only use this product in a dry environment. Do not allow any liquids
or harmful chemicals to come into contact with these products.
•Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner
or benzene to clean this unit.
Maintenance
To ensure reliable operation of this product as well as protecting the
safety of any person using or handling this device while powered, please
observe the following instructions.
pg. 20
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
•The DC power supply cord or AC adaptor has been damaged
•Objects or liquids have gotten into the unit
•The unit has been exposed to rain
•The unit does not operate normally or exhibits a marked change in
performance
•The unit has been dropped or the housing damaged
Damage Requiring Service
The unit should be serviced by qualified service personnel if:
