Award TDHP8 User manual
TDHP8
Dryer / User Manual
EN
Thank you for choosing this dryer.
This User Manual contains important safety information and instructions on the
operation and maintenance of your dryer.
Please take the time to read this User Manual before using your dryer and keep this
book for future reference.
Icon Caption Description
WARNING Risk of serious injury or death
RISK OF ELECTRIC SHOCK Dangerous voltage
FIRE
ATTENTION Risk of injury or material damage
IMPORTANT/NOTE Information on correct operation of the system
Read the instructions.
Hot surface
EN - III
CONTENTS
1. SAFETY INSTRUCTIONS ................................................................................. 5
1.1. Electrical Safety............................................................................................... 5
1.2. Children's Safety ............................................................................................. 6
1.3. Dryer Safety..................................................................................................... 7
1.4. Correct Use ..................................................................................................... 8
1.5. Installing On Top Of a Washing Machine....................................................... 10
2. INSTALLATION................................................................................................ 11
2.1. Connection to Water Outlet (with optional drain hose) .................................. 11
2.1.1. Connecting the Water Discharge Hose ...................................................... 11
2.2. Adjusting the Feet.......................................................................................... 11
2.3. Electrical Connection..................................................................................... 11
2.4. Under Counter Installation............................................................................. 11
3. OVERVIEW ...................................................................................................... 12
4. PREPARING THE LAUNDRY.......................................................................... 13
4.1. Sorting the Laundry to be Dried..................................................................... 13
4.2. Preparing the Laundry to be Dried ................................................................ 14
4.3. Load Capacity................................................................................................ 14
5. USING THE DRYER ........................................................................................ 15
5.1. Control Panel................................................................................................. 15
5.1.1. Programme Selection Knob........................................................................ 15
5.1.2. Electronic Indicator and Additional Functions............................................. 15
5.2. Programme Selection and Consumption Table ............................................. 16
5.2.1. Auxiliary Functions...................................................................................... 17
5.2.2. Starting the Programme ............................................................................. 18
5.2.3. Programme Progress ................................................................................ 19
5.3. Drum Light Information.................................................................................. 19
6. CLEANING AND CARE................................................................................... 21
6.1. Cleaning the Lint Filters................................................................................. 21
6.2. Emptying the Water Tank............................................................................... 21
6.3. Cleaning the Heat Exchanger........................................................................ 22
6.4. Cleaning the Humidity Sensor....................................................................... 22
6.5. Cleaning the Inner Surface of the Loading Door ........................................... 23
7. TECHNICAL SPECIFICATIONS...................................................................... 24
8. TROUBLESHOOTING..................................................................................... 25
9. AUTOMATIC FAULT WARNINGS AND WHAT TO DO................................... 27
10. ENVIRONMENTAL PROTECTION AND PACKAGING INFORMATION ...... 28
10.1. Packaging Information................................................................................. 28
10.2. Energy Efficiency......................................................................................... 28
EN - 1
PRIMARY CONSIDERATIONS
• This dryer can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
dryer in a safe way and understand the hazards
involved. Children must not play with the dryer.
Cleaning and user maintenance must not be made
by children without supervision.
• This dryer is intended only for household and
indoor use. The warranty will be void in case of
commercial use.
• Use this dryer only for laundry with a label that
indicates it is suitable for drying.
• The manufacturer will not accept responsibility for
damages resulting from incorrect use or transport.
•
ventilation openings.
• Installation and repair of the dryer should only
be made by an authorised repair agent. The
manufacturer cannot be held responsible for
damages resulting from un-authorised repairs.
WARNING: Never spray or pour water onto the
dryer to wash it! There is risk of electric shock!
• Leave at least 3 cm of space between the side and
rear walls of the dryer and above if you plan on
placing your dryer under a worktop.
• Assembly / disassembly for under-counter
installation if neccessary must be done by an
authorised service agent.
• Before installation, check the dryer for visible
damage. Never install or operate a damaged dryer.
• Keep pets away from the dryer.
• Fabric softeners or similar dryer should be used in
EN - 2
accordance with the manufacturers instructions.
• Remove all objects from pockets such as lighters
and matches.
• The dryer must not be installed behind a lockable
door, a sliding door or a door with a hinge on the
opposite side to that of the dryer, if it prevents the
door from being fully opened.
WARNING: In the dryer enclosure or in the built-
in structure, keep ventilation openings clear of
obstruction.
• Before contacting the local Authorised Service
Provider for the installation of the dryer, check the
information in the user manual to make sure that
the electrical installation and water outlet is suitable.
plumber to have the necessary adjustments made.
• It is the customer’s responsibility to prepare the
dryer’s installation place, as well as the electricity
and waste water installation. Before installation,
check the dryer for damage. If damaged, do not
have it installed. Damaged dryer may endanger
your health.
•
• Run the dryer in a dust-free environment where the
air ventilation is good.
•
should not be reduced with objects such as
carpets, wood or tape.
• Do not block the ventilation grills found on the
plinth of the dryer.
• The dryer must not be installed behind a lockable
door, a sliding door or a door with a hinge on the
EN - 3
opposite side of the dryer, in such a way that blocks
the full opening of the dryer door.
• Once the dryer has been installed, the connections
must remain stable. When installing the dryer, make
sure that the rear surface is not leaning on anything
(e.g. tap, socket).
• The operating temperature of the dryer is +5°C to
+35°C. If operated out of this temperature range,
negatively and the dryer will be damaged.
• Be careful when carrying the dryer since it is heavy.
Always wear safety gloves.
• Always install the dryer against a wall.
• The rear surface of the dryer should be placed
against the wall.
• When the dryer is placed on a stable surface,
use a level to check if it is fully level/stable. If not,
adjust the feet until it becomes steady. Repeat this
process every time you relocate the dryer.
• Do not place the dryer onto the power cable.
EN - 4
Disposing the Old Dryer
This dryer complies with EU WEEE Directive
symbol for waste electrical and electronic
equipment (WEEE).
This symbol, which is found on the dryer or
information label, indicates that this dryer must not be
disposed together with other household waste at the
end of its service life. To prevent the potential harms of
uncontrolled waste disposal on the environment and
human health, please keep this dryer separate from
other types of waste, and to prevent sustainable reuse
of material resources, make sure that it is recycled
responsibly. Contact your dealer or local authorities to
get information on how and where you can take the
dryer for environmentally-safe recycling. This dryer
cannot be mixed with other commercial wastes for
recycling.
EN - 5
1. SAFETY INSTRUCTIONS
This section contains safety instructions that will help
protect you from risk of personal injury or property
damage. Failure to follow these instructions will void
any warranty.
1.1. Electrical Safety
• The dryer must not be supplied through an external
switching device, such as a timer, or connected to
utility.
• Do not touch the power plug with wet hands. Always
pull the plug to unplug the dryer, otherwise, there
will be risk of an electric shock.
• Connect the dryer to a grounded socket with fuse
protection. The earth connection must be installed
held responsible for damages/losses resulting from
using the dryer without an earth connection as
required by local regulations.
• The voltage and the allowable fuse protection are
indicated on the type plate.(For the type plate,
please see Overview)
• Voltage and frequency values indicated on the
type plate must be equal to the mains voltage and
frequency value in your house.
• Unplug the dryer when it is not used for an
extended period, and before installation,
maintenance, cleaning and repair, otherwise, the
dryer may get damaged.
• The plug socket must be freely accessible at all
times after installation.
give you an electric shock. When damaged it must
personnel.
EN - 6
use extension cords, multi sockets or adapters to
connect the dryer to mains power.
1.2. Children's Safety
• This dryer is not intended for use by people
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
dryer by a person responsible for their safety.
• This dryer can be used by children aged from
8 years and above, and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
dryer in a safe way and understand the hazards
involved. Children must not play with the dryer.
Cleaning and user maintenance must not be made
by children without supervision.
• Do not leave children unattended near the dryer.
• Children might lock themselves in the dryer
resulting in risk of death.
• Do not allow children to touch the glass door during
operation. The surface becomes extremely hot and
may cause skin damage.
• Keep packaging material away from children.
• Poisoning and irritation may occur if detergent and
cleaning materials are consumed or come into
contact with the skin and eyes.
• Keep cleaning materials out of the reach of children
Electrical dryer are dangerous for children.
• Keep children away from the dryer while it is
running.
• To prevent children from interrupting the dryer cycle,
you can use the child lock to avoid any changes in
EN - 7
the running programme.
• Do not allow children to sit/climb on or climb inside
the dryer.
1.3. Dryer Safety
Due to risk of re, the following laundry items
and dryer should NEVER be dried in the dryer:
• Do not dry unwashed items in the dryer.
• Items that have been soiled with substances such
as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax
removers should be washed in hot water with an
extra amount of detergent before being dried in the
dryer.
• Cleaning cloths and mats that have residues
patrol, stain remover, turpentine, candle, wax, wax
remover or chemicals.
• Laundry that has residues of hair sprays, nail polish
remover and similar substances.
• Laundry on which industrial chemicals have been
used for cleaning (such as chemical cleaning).
• Laundry that has any kind of foam, sponge, rubber
or rubber-like parts or accessories. These include
latex foam sponge, shower caps, waterproof
•
during the drying process.
• Operating the dryer in environments that contain
ATTENTION: Underwear that contains metal
reinforcements should not be put in the dryer. The
dryer may be damaged if metal reinforcements come
EN - 8
FIRE:R290
Risk of re and damage!
This dryer contains enviromental friendly but
sources away from the dryer.
1.4. Correct Use
ATTENTION: Never stop a dryer before the end of
the drying cycle unless all items are quickly removed
and spread out so that the heat is dissipated.
ATTENTION: Make sure that pets do not enter
the dryer. Check the inside of the dryer before
using it.
ATTENTION: Superheating of clothes inside the
dryer can occur if you cancel the programme or in the
event of a power failure whilst the dryer is running.
This concentration of heat can cause self-combustion
so always activate the Refresh programme to cool
down or quickly remove all laundry from the dryer in
order to hang them up and dissipate the heat.
• Use the dryer only for household drying and to dry
fabrics with a label that indicates they are suitable
for drying. All other uses are out of the scope of
intended use and are prohibited.
• The warranty will be void in case of any commercial
use.
• This dryer is designed to be used inside domestic
residences only, and should be placed on a straight
and stable surface.
• Do not lean against or sit on the door of the dryer.
The dryer may tip over.
EN - 9
• To maintain a temperature that will not harm the
laundry (e.g. to prevent the laundry from catching
process. After this, the programme ends. At the
end of the programme, always remove the laundry
promptly.
•
especially when exposed to heat sources such as
in a dryer. The items become warm, causing an
oxidation reaction in oil. Oxidations creates heat. If
the heat cannot escape the items can become hot
• If it is unavoidable that fabrics that contain
vegetable or cooking oil or have been contaminated
by hair care products be placed in a dryer
extradetergent - this will reduce, but not eliminate,
the hazard
ATTENTION: Never use the dryer without a lint
• after each use as
indicated in Cleaning the Lint Filter.
•
process.
• Lint accumulation must not to be allowed around
the dryer (not applicable for dryers intended to be
vented to the exterior of the building)
IMPORTANT: The clearance between the dryer
intake cannot be ensured for the dryer.
EN - 10
• Do not install the dryer in rooms where there is
risk of freezing. Freezing temperatures negatively
freezes in the pump and hose may cause damage.
1.5. Installing On Top Of a Washing Machine
ATTENTION: A washing machine cannot be placed
on the dryer. Pay attention to the warnings below
when installing the dryer on a washing machine.
ATTENTION: The dryer can only be placed on
washing machines that have a same capacity and
above.
•
part must be attached by an Authorised Service
Provider.
• When the dryer is placed on the washing machine,
the total weight of these dryer may reach almost
150 kilograms (when loaded). Place the dryer on a
Appropriate Installation Table for Washing Machine and Dryer
Dryer
(Depth)
Washing Machine
37 cm 42 cm 53 cm 56 cm 59 cm 85 cm
56 cm X X
61 cm X X X
(For the depth information, please see 7. Technical Specications)
In order to put the dryer onto the washing machine,
a special stacking kit is required as an optional extra.
Please contact customer service to acquire. The
assembly instruction will be served together with the
stacking kit.
CE Declaration of conformity
We declare that our dryer meet the applicable European Directives, Decisions and
Regulations and the requirements listed in the standards referenced.
EN - 11
2. INSTALLATION
2.1. Connection to Water Outlet (with
optional drain hose)
In dryer with a heat pump unit, water
accumulates in the water tank during
the drying process. You must empty the
accumulated water after each drying
process. Instead of periodically emptying
the water tank, you can also use the water
drain hose provided with the dryer to
directly drain the water outside.
2.1.1. Connecting the Water Discharge
Hose
1. Pull and take out the end of the hose at the
back of the dryer. Do not use any tools to
take out the hose.
2.
3.
.
ATTENTION: The hose must be
connected in a manner that it cannot be
displaced. If the hose comes out during
your house.
IMPORTANT: The water discharge
house must be installed at a height of 80
cm maximum.
IMPORTANT: The water discharge
hose must not be bent between the outlet
and the dryer, folded or stepped over.
2
1
3
2.2. Adjusting the Feet
• For the dryer to work with less noise
and vibration, it must be stable and
balanced on its feet. Adjust the feed to
ensure that the dryer is balanced.
• Rotate the feet to the right and to the
left until the dryer is even and stable.
IMPORTANT: Never remove the
adjustable feet.
2.3. Electrical Connection
ATTENTION:
electric shock.
• Your dryer is set to 220-240 V and 50
Hz.
• The mains cable of the dryer is
equipped with a special plug. This
plug must be connected to an earthed
socket protected by a fuse of 10
Amperes as indicated on the type plate.
The fuse current rating of the power
line where the outlet is connected must
electrician if you do not have such an
outlet or fuse.
• Our company cannot be held
responsible for damages resulting from
usage without earthing.
IMPORTANT: Operating your dryer at
low voltage values will shorten the service
life and decrease the performance of your
dryer.
2.4. Under Counter Installation
• Leave at least 3 cm of space between
the side and rear walls of the dryer
and the underside of the worktop when
installing your dryer under a counter.
• Assembly / disassembly under the
counter if neccessary must be done by
authorized service.
EN - 12
3. OVERVIEW
1
2
3
4
5
6
7
8
9
10
11
1. Upper tray
2. Control panel
3. Loading door
4. Plinth
5. Plinth opening slot
6. Ventilation grills
7. Adjustable feet
8. Plinth cover
9. Type plate
10.
11. Drawer Cover
EN - 13
4. PREPARING THE LAUNDRY
4.1. Sorting the Laundry to be Dried
Follow the instructions on the labels of the laundry to be dried. Only dry items that have a
statement/symbol that indicates "they can be dried in a dryer".
• Do not operate the dryer with load amounts and laundry types other than those given
in 4.3. Load Capacity.
Suitable for drying in a
dryer
Does not need ironing Sensitive/Delicate drying
Not suitable for drying in a
dryer
No drying
Do not dry-clean At any temperature At high temperatures
At medium temperatures At low temperatures Heatless Hang to dry
Spread to dry Hang wet to dry Spread in shadow to dry Suitable for dry cleaning
this reason, dry clothes together that have the same structure and fabric type. This way,
you can get an even drying result. If you think that the laundry is still wet, you can select a
time programme for additional drying.
Please dry your big (like duvets) and small sizes of laundries seperately in order to avoid
damp laundries.
EN - 14
IMPORTANT: Delicate fabrics,
embroided fabrics, woolen/silk fabrics,
clothes made of delicate and expensive
fabrics, airtight clothes and tulle curtains
are not suitable for drying in the dryer.
4.2. Preparing the Laundry to be Dried
Risk of explosion and re!
Remove all objects from pockets such as
lighters and matches.
ATTENTION: The drum of the dryer and
the fabrics may get damaged.
• The clothes may have become
entangled during the washing process.
Separate them from each other before
placing them in the dryer.
• Remove all objects in the pockets of
the clothes and apply the following:
• Tie fabric belts, apron laces etc. to each
other or use a laundry bag.
• Lock the zips, clasps and fasteners, do
up the buttons of covers.
• To get the best drying result, sort the
laundry according to the textile type
and drying programme.
• Remove clips and similar metal parts
from the clothes.
• Woven goods such as t-shirts and knit
clothes generally shrink in the rst
drying. Use a protective programme.
• Do not over-dry synthetics. This will
cause creases.
• When washing the laundry to be dried,
adjust the amount of softener according
to the data from the manufacturer of the
washing machine.
4.3. Load Capacity
Follow the instructions in the "Programme
selection and consumption table". (See: 5.2
Programme selection and consumption
table). Do not load the dryer with more
in the table.
IMPORTANT: It is not recommended
to load the dryer with more laundry than
overloaded, the drying performance of
the dryer will decrease and the dryer and
laundry might be damaged.
Laundry Dry load weight (gr)
Bedsheet (double) 725
Pillowcase 240
Bath Towel 700
Hand Towel 225
Shirt 190
Cotton Shirt 200
Jean 650
Fabric - Gabardine Trousers 400
T-shirt 120
EN - 15
5. USING THE DRYER
5.1. Control Panel
1. Programme Selection Knob
2. Electronic indicator and additional
functions
5.1.1. Programme Selection Knob
Use the programme selection knob to select
the desired drying programme
12
5.1.2. Electronic Indicator and Additional
Functions
Display symbols:
Water tank warning indicator
Heat exchanger cleaning warning
indicator
EN - 16
5.2. Programme Selection and Consumption Table
Press the Start/Pause button to start the programme. The Start/Pause LED that indicates
that the programme has started and the remaining the of the program is seen on the
display.
Programme Load (kg)
Washing
machine
spin speed
Approximate
amount of
remaining
humidity
Duration
(minutes)
Cotton Extra Dry 8 1000 60% 179
Cotton Cupboard Dry 8 1000 60% 174
Cotton Iron Dry 8 1000 60% 148
Synthetics Cupboard
Dry 4 800 40% 74
Synthetics Iron Dry 4 800 40% 64
Delicate 2 600 50% 55
Time drying - - - -
Baby Care 3 1000 60% 78
Duvet 2,5 800 60% 140
Sport 4 800 40% 103
Mix 4 1000 60% 112
Wool Refresh - - - 5
Refresh - - - 10
Express 34' 1 1200 50% 34
Shirts 20' 0.5 1200 50% 20
Energy consumption values
Programme Load (kg) Energy Consumption
Value (kWh/year) Energy Rating Star
Cotton Cupboard Dry
Drying Level 3
8 149 7
before test series.
All values in the table were determined in accordance with standard laboratory conditions.
Consumption values may vary from the values in the table depending on the fabric type,
spin speed, environment conditions and voltage values.
EN - 17
5.2.1. Auxiliary Functions
The table that summarises the options that can be selected in programmes is given below.
Option Description
Drying Level
The humidity level obtained after drying can be increased by 3 levels. This way,
level of required dryness can be selected. The levels that can be selected other
than the standard setting: 1, 2, 3. After selection, the LED of the relevant drying
level will turn on.
Anti-Crease
If you select the "Anti-Crease" option and do not open the door of the dryer at the
end of the programme, the 1-hour anti-crease phase will extend to 2 hours. After
selecting the Anti Crease option, you will hear an audible warning. You can press
the same button again to cancel the option. If you open the door or press the Start/
Pause key while the anti-crease step is in progress, the said step will be cancelled.
Delay Start
You can delay the start time of the programme by selecting the 1-hour to 23-hour
option. You can activate the desired delay time by pressing the Start/Pause button.
When the time is up, the selected programme will start automatically. During the
delay time, options compatible with the programme can be activated/deactivated.
Long pressing on Delayed Start button changes delay time continuously.
Buzzer Cancel
The dryer gives an audible warning when programme selection knob is turned,
buttons are pressed and at the end of programme. To cancel the warnings, press
and hold the "Anti-Crease Option" button for 3 seconds. When you press the
button, you will hear an audible warning that the option has been cancelled.
Time Drying
When knob is positioned to Time Drying programme, option can be selected by
pressing Time Drying option button and program starts by pressing Start/Pause
button. Long pressing on tme dyring button changes time continuously.
Child Lock
are pressed during the programme. To activate the child lock, press and hold
the "Delay Start" and "Anti-Crease" keys simultaneously for 3 seconds. When
the child lock is active, all keys will be deactivated. Child lock will be deactivated
automatically at the end of the programme. When activating/deactivating the child
active, if you turn the programme selection knob, you will hear an audible warning
the programme knob to another programme, the previous programme will continue
running. To select a new programme, you need to deactivate the child lock and
start the desired programme.
Table of contents
Other Award Dryer manuals
