Award BV60BL User manual

Wine / Beverage Preservation Technology
INSTRUCTION MANUAL
BV60S
BV60BL
WCDZ60S
WCDZ60BL
WCBV60BL
WCDZ600TS
WCDZ600TBL
Thanks for buying one of our Wine or Beverage cabinets. Before use, please read and
follow all safety rules and operating instructions.

WARNING
The information in this document is subject to modification without prior notice.
Some models are available in dedicated countries only.
All warranties are void if the appliance is being used for any purpose other than that for
which it was specifically designed. Warranty applies to the wine cellar only and not to the
content of the wine cellar.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Children should be supervised to ensure that they do not play with the appliance.
Please don't put acidic items, flammable and explosive goods into wine cooler.
This appliance is intended to be used in household and similar applications such as
–Staff kitchen areas in shops, offices and other working environments;
–Farm houses and by clients in hotels, motels and other residential type environments;
–Bed and breakfast type environments;
–Catering and similar non-retail applications.
DANGER: Risk of child entrapment. Before you throw away your old wine chiller:
- Take off the doors;
- Leave the shelves in place so that children may not easily climb inside;
- When disposing of the appliance, do so only at an authorized waste disposal centre.

R600a WARNINGS
For your safety observe the following recommendations.
This appliance contains a small quantity of R600a refrigerant which is
environmentally friendly, but flammable. It does not damage the ozone layer, nor
does it increase the greenhouse effect.
During transportation and installation, ensure that the tubing of the refrigerant
circuit is not damaged.
Avoid using sharp objects near by the appliances.
Leaking refrigerant can ignite and may damage the eyes.
In the event any damage does occur, avoid exposure to open fires and any device
which creates a spark. Disconnect the appliance from the mains power.
Thoroughly ventilate the room in which the appliance is located for several
minutes.
Notify Customer Service for necessary action and advice.
The room you installing the appliance in must be at least 1 cubic metre per 8 grams
of refrigerant. The refrigerant quantity contained in this appliance is listed on the
Rating Plate of the appliance.
It is hazardous for anyone other than an Authorised Service Person to carry out
servicing or repairs to this appliance.
- WARNING: Keep ventilation openings in the appliance enclosure or in the built-in
structure clear of obstruction.
- WARNING: Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
- WARNING: Do not damage the refrigerant circuit.
- WARNING: Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the manufacturer.
- WARNING: If you are not using the appliance, please unplug the power plug from
the socket or switch off the power supply.
- WARNING: This appliance is not intended for use by persons (including children)
with reduced Physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety;
- WARNING:Children should be supervised to ensure that they do not play with the
appliance;
- WARNING: Do not use extension cords or ungrounded (two prong) adapters;
- WARNING: If the supply cord is damaged, it must be replaced by the manufacturer,
Its service agent or similar qualified person in order to avoid hazard.

Allow 24 hours before switching on the wine cellar. During this time we recommend
that you leave the door open to clear any residual odors.
BEFORE LOADING & PLUGGING IN THE WINE CELLAR
Important: All models without front venting (air opening) are strictly for free
standing only. (See technical chart)
Recommendations:
The location you have selected for your wine cellar should:
- Be unencumbered and well ventilated;
- Be well away from any heat source and direct sunlight;
- Not be too damp (laundry, pantry, bathroom etc.);
- Have a flat floor;
- Have a standard and reliable electricity supply (standard socket to country standards,
linked to the ground), it is NOT recommended to use a multi-socket or extension lead;
- Have a surge protector fitted to the electrical outlet;
- Away from the microwave oven. Certain microwave ovens do not have wave
interference shield. When placed within 1 meter vicinity of the wine cabinet, they may
affect the operation of the wine cabinet.
Wine cellar should be placed where the ambient temperature is constant (not to hot or
cold). If the temperature is too hot or cold, it will affect the performance of the cellar.
Grounding instructions:
The wine cellar must be grounded in case of power leakage. Grounding reduces the risk of
electrical shock. The wine cellar is equipped with a power cord having an earth wire and
an earthed plug. The wine cellar plug must be plugged into a grounded electrical outlet.
Note: In locations where there is frequent lightning, it is advisable to use surge protectors.
Improper use of the earthed plug can result in the risk of electric shock. Consult a qualified
electrician or service person if the grounding instructions are not completely understood.
If the supply cord is damaged, it must be replaced by a qualified person in order to avoid
electrical hazard.
INSTALLING YOUR WINE CELLAR
Unpack and remove all of the protection and adhesive strips from the packaging around
and inside the wine cellar.

The wine cellar must be positioned such that the plug is accessible. Release the power
cord. Move your wine cellar to its final location. The wine cellar should be installed in a
suitable place where the compressor will not be subject to physical contact.
Leveling your wine cellar: Wine cellar must be leveled BEFORE loading your wines.
Your wine cellar is equipped with 4 adjustable feet to facilitate easy leveling. We
recommends that you tighten the back feet to the maximum and adjust the front feet to
level the wine cellar.
INSTALLATION INSTRUCTIONS FOR BUILT IN WINE CELLARS:
(UNDERBENCH OR IN COLUMN) FRONT VENTING WINE CELLARS ONLY.
1. “Built in” wine cellars are front venting but are not designed to be fully integrated
behind a joinery door.
2. Please follow the installation diagram when installing built-in wine cellars. No less than
the minimum installation dimension, or it will affect the venting of cellar.
3. Built-in wine cellars draw air from right of ventilation frame (VI20 VI35 from the rear)
and expel through left of ventilation frame under the front door.
4. “Built in” wine cellars have a power switch located on the control panel so power point
location is not critical.
5. The wine cellar requires a standard 240 volt/10 amp power point.
6. The power cord is 2.0m in length and is fixed on the right side at the back when looking
from front of cabinet.
7. As with most appliances of today, the wine cellar has sensitive electronic components
which are susceptible to damage through lightning and electricity supply faults. It is
therefore advised to use a power surge protector to avoid problems of this nature.
8. Air vent on door must be provided for built-in wine cellars when a wood door installed.
In Hot climate zone, an air vent or grid, with a minimum ventilation size of 200mm x
40mm MUST be cut out at the rear top of the back partitioning or at the top of either side

of the partitioning, allowing cool fresh air full access to flow into the 30mm gap located at
the rear of the cabinet.
This air vent or grid must not be opened on the same side as other appliances such as
ovens or an area that is sealed and without access to fresh cool air. Failing to comply with
the above specifications will void the WARRANTY.
INSTALLATION DRAWINGS FOR BUILT IN WINE CELLARS:
(UNDERBENCH OR IN COLUMN) FRONT VENTING WINE CELLARS ONLY.
Note: The appliance must be positioned so that the plug is accessible after installed.
DIMENSIONAL DRAWINGS:
BV60BL,BV60S,WCDZ60BL,WCDZ60S,

WCDZ600TS,WCDZ600TBL
OPEN ANGLE SIZE DRAWINGS:
BV60BL,BV60S,WCDZ60BL,WCDZ60S

WCBV60BL
WCDZ600TS,WCDZ600TBL

RADIATOR SYSTEM DESCRIPTION
BV60BL,BV60S,WCDZ60BL,WCDZ60S,WCBV60BL,WCDZ600TS,WCDZ600TBL
Models use side anti-dew tube and Independent cooling system:
TURNING ON YOUR WINE CELLAR
Plug in and switch on the cellar by pressing on the power button for a few seconds.
When you use the wine cellar for the first time (or restart the wine cellar after having it
shut off for a long time), there will be a few degrees variance between the temperature you
have selected and the one indicated on the LED readout. This is normal and it is due to
the length of the activation time. Once the wine cellar is running for a few hours
everything will stabilize.
Important: If the unit is unplugged, power is lost, or turned off, wait 3 to 5 minutes
before restarting the unit. The wine cellar will not start if you attempt to restart before
this time delay.
Operating Noises
To reach the desired temperature settings, our wine cellars, like all wine cellars operating
with compressors and fans, may produce the following types of noises. These noises are
normal and may occur as follows:
- Gurgling sound - caused by the refrigerant flowing through the appliance’s coils.

- Cracking/popping sounds - resulting from the contraction and expansion of the
refrigerant gas to produce cold.
- Fan operating sound - to circulate the air within the wine cellar.
An individual’s perception of noise is directly linked to the environment in which the wine
cellar is located, as well the specific type of models. Our wine cellars are in line with
international standards for such appliance. We will always do its utmost to satisfy its
customers but will not retake possession of the goods due to complaints based on normal
operating noise occurrences.
LOADING YOUR WINE CELLAR
You may load your wine bottles in single or double rows while taking note of the
following: if you do not have enough bottles to fill your wine cellar, it is better to
distribute the load throughout the wine cellar so as to avoid “all on top” or “all below”
type loads.
- Do remove or relocate adjustable wooden shelves to accommodate larger type of bottles
or increase the capacity of the cellar by stacking the bottles up when necessary. (See
removing shelves)
- Keep small gap between the walls and the bottles to allow air circulation. Like an
underground cellar air circulation is important to prevent mould and for a better
homogeneous temperature within the cellar.
-Do not over load your wine cellar to facilitate air circulation.
- Do not stack more than 1.5 rows of standard 0.75L bottles per shelves to facilitate air
circulation
-Avoid obstructing the internal fans (located inside on the back panel of the wine cellar).
- Do not slide the shelves outwards beyond the fixed position to prevent the bottles from
falling.
- Do not pull out more than one loaded shelf at a time as this may cause the wine cellar to
tilt forward.
- Do not cover the wooden shelves with alloy foil or other materials, as it will obstruct air
circulation.
- Do not move your wine cellar while it is loaded with wines. This might distort the body
of the wine cellar and cause back injury.

TYPES OF REGULATION
Please note that depending on the loading and settings chosen it takes about 24 hours for
the wine cellar to see the temperature stabilizing.
During this time LED seems to move erratically in particular, it is normal and this process
occurs whenever the setting is modified and/or whenever a large amount of bottles are
added to the cellar.
Designed to store and mature all wines: red, white and sparkling. These wine cellars
reproduce the ideal conditions for wine storage, at a constant recommended temperature of
12ºC. They can also be set to provide ideal serving temperature for full enjoyment of the
wine’s qualities. Unless stated by the wine maker on the bottle, we recommends 7ºC for
your champagne, 12ºC for whites and 18ºC for reds. (Refer to “Wine Service
Temperature” recommendation chart)
TEMPERATURE SETTINGS
Important: The LED displays by default shows the actual internal air temperature.
In the event of loss of power the unit will return to your preset temperatures when turned
back on.
The electrical board of all models comes with memory function.
It is important to understand that there is a difference between the air temperature inside
the wine cellar and the actual temperature of the wine: You will need to wait
approximately 12 hours before noticing the effects of temperature adjustment due to the
critical mass within a full wine cellar.
Once the temperature is set, it is strongly advised not to toy with it or adjust frequently.
The thermostat will maintain the temperature inside the wine cellar within a +/- 2.5ºC
range. But the thermal inertia of the wine and the glass is such that within this temperature
range, the actual temperature of the wine will only fluctuate 0.5ºC to 1ºC.

WCBV60BL:SINGLE WINDOW DISPLAY BOARD OPERATING
INSTRUCTION:
From left to right:
①Display Window:
Display the measured temperature inside the wine cooler;
②Cycle Button：
Each time, the temperature inside will drop 1 ℃, until reduced to a minimum, and then a
return to the highest temperature.
Press for 3 seconds, the window to achieve Celsius / Fahrenheit display conversion
③Cycle Button：
In standby mode: press and hold for 3 seconds, power is turned on, the machine starts
In the boot state: short press this button, LED lights on / off switch
In the boot state: press the button for 3 seconds, the power is off, the machine is off.
BV60BL,BV60S:SNGLE TEMPERTURE DISPLAY BOARD OPERATING
INSTRUCTION:
From left to right:
①Energy Saving Mode
Press the button for 3 seconds into the energy-saving mode, press ⑥⑦ out of energy-
saving mode

②ON/OFF the power button:
In the standby mode: press 3 seconds, the power is turned on, the whole machine starts
In the power-on state: press the power button, window 4 shows the countdown 3 2 1, the
power is turned off, the machine is turned off (show 3 2 1 process, the hand cannot leave
the button)
③Lamp button:
Press the button, lights on / off switch
④Display Window:
Displays the setting temperature
⑤Window:
Displays the actual temperature
⑥Temperature setting up button :
Press one time, window ④the set value will increase 1 degree Celsius in the original
setting temperature, the setting range according to customer requirements.
⑦Temperature setting down button :
Press one time, window ④the set value will reduce 1 degree Celsius in the original setting
temperature, the setting range according to customer requirements
⑧C/F display conversion function keys:
Set the conversion degrees Celsius / Fahrenheit display, press this button, the display
window will change to degrees Celsius or Fahrenheit.
WCDZ60S WCDZ60BL WCDZ600TS WCDZ600TBL:DUAL TEMPERTURE
DISPLAY BOARD OPERATING INSTRUCTION:
From left to right:
①“ON/OFF” the power button :

Press the button 3 seconds to power off (Window ④digital countdown displays 3, 2, 1,).
Press again (without delay), the power turns on.
②Upper zone temperature setting up button:
Press one time, window ④the set value will increase 1 degree Celsius in the original
setting temperature, the setting range according to customer requirements.
③Upper zone temperature setting down button :
Press one time, window ④the set value will reduce 1 degree Celsius in the original
setting temperature, the setting range according to customer requirements.
④Window :
Display upper zone temperature.
⑤Window:
Display lower zone temperature
⑥Lower zone temperature setting up button:
Press one time, window ⑤the set value will increase 1 degree Celsius in the original
setting temperature, the setting range accordingly to customer requirements.
⑦Lower zone temperature setting down button:
Press one time, window ⑤the set value will reduce 1 degree Celsius in the original setting
temperature, the setting range accordingly to customer requirements.
⑧Lamp button:
Press the button and the lamp turns on, the lamp will turn off once press again.
⑧C/F display conversion function keys:
Set the conversion degrees Celsius / Fahrenheit display, press this button, the display
window will change to degrees Celsius or Fahrenheit

WINE SERVING TEMPERATURE CHART
All wines mature at the same temperature, which is a constant temperature set between
12ºC to 14ºC. The below chart is an indicative temperature chart to indicate the best
temperature for drinking purposes.
Champagne NV, Sparkling, Spumante 6ºC
Dry White Semillon, Sauvignon Blanc 8ºC
Champagne Vintage, 10ºC
Dry White Chardonnay 10ºC
Dry White Gewürztraminer, Riesling, Pinot grigio 10ºC
Sweet White Sauternes, Barsac, Montbazillac, Ice Wine, Late Harvest 10ºC
Beaujolais 13ºC
Sweet White Vintage: Sauternes… 14ºC
White Vintage Chardonnay 14ºC
Red Pinot Noir, 16ºC
Red Grenache, Syrah 16ºC
Red Vintage Pinot Noir 18ºC
Cabernet & Merlot 20ºC
Chilean, Italian, Spanish, Californian, Argentinean…
Vintage Bordeaux … Room temperature not exceeding 20ºC
IMPORTANT INFORMATION ABOUT TEMPERATURE
Your wine cellar has been designed to guarantee optimum conditions for storing and/or
serving your wines.
Fine wines require long and gentle developments and need specific conditions in which to
reach their full potential.
All wines mature at the same temperature, which is a constant temperature set between
12ºC to 14ºC. Only the temperature of “degustation” (wine appreciation) varies according
to the type of wines (see “Wine Serving Temperature Chart” above). This being said and
as it is for natural cellars used by wine producers for long period of storage, it is not the
exact temperature that is important, but its consistency. In other words, as long as the
temperature of your wine cellar is constant (between 12ºC to 14ºC) your wines will be
stored in perfect conditions.
Not all wines will improve over the years. Some should be consumed at an early stage (2
to 3 years) while others have tremendous ageing capability (50 and over). All wines have a
peak in maturity. Do check with your wine merchant to get the relevant information.

DEFROSTING/CONDENSATION/ HYGROMETRY/ VENTILATION
Your wine cellar is designed with “Auto-cycle” defrost system. During “Off-cycle” the
refrigerated surfaces of the wine cellar defrost automatically. Defrost water from the wine
cellar storage compartment drains automatically and part of it goes into a drainage
container, which is located at the back of the wine cellar next to the compressor. The heat
is transferred from the compressor and evaporates any condensation that has collected in
the pan. Part of the remaining water is collected within the wine cellar for humidity
purposes.
This system enables the creation of the correct humidity level inside your wine cellar
required by the natural cork to maintain a long lasting seal.
Notes: The water collected by condensation, is therefore recycled. Under extremely dry
environmental conditions, you may have to add some water into the water container
provided with your wine cellar.
All units are equipped with a double glazed glass door that has a third internal acrylic
layer to minimize condensation on the glass door.
The wine cellar is not totally sealed; fresh air admission is permitted through the
drainpipe. Air is circulated through the cellar by means of a fan/fans and the hollow
shelves.
Notes: During the refrigerating cycle, heat is given off and disperses through the external
surfaces of the wine cellar. Avoid touching the surfaces during those cycles.
ADJUSTABLE WOODEN SHELVES
Adjusting & removing the shelves
For easy access to the storage content, you must pull the shelves approximately 1/3 of its
depth out of the rail compartment. These wine cabinets, however, are designed with a
notch on each side of the shelf tracks to prevent bottles from falling.
When removing any of these shelves out of the rail compartment, tilt the shelf as per the
diagram and simply pull out, or push in the shelf until it sits on the support brackets
securely.
Shelf installation and taking instruction:
Common wooden shelf:
Shelf taking: According to below instruction drawing to press one side of shelf limit pin①,

extract and remove the shelf from the other side of support bracket②, then take off the
shelf following the arrow mark ③.
Shelf installation will be opposite with shelf taking.
1、”A” is shelf limit pin
2、”B” is shelf
Sliding wooden shelf installation and taking instruction:
Shelf taking: According to below instruction drawing to pull out the shelf to support
bracket ①, press two sides of sliding roller buckles and pull out the shelf following the
arrow mark ②.
Shelf installation: According to below instruction drawing to push in the shelf alignment
with two sides of sliding roller following the arrow mark ③.

REVERSIBILITY OF THE DOOR
REMARK:
If your wine cooler has a lock at the bottom of the door, the door is irreversible and only the door that ope
ns to the left or right can be reversed.
Warning: To avoid accidents during the process of changing the door, we recommend that
you get assistance. The glass door is heavy and may cause injury if dropped.
- Depending on to the model and the type of handle your wine cabinet is equipped with,
you may have to rotate the door through 180 degrees.
- Depending on the type of handle your wine cabinet is equipped with, the door may not
be reversible or may require that a left or right opening door be ordered to change the
opening side.
REVERSIBILITY OF THE DOOR
BV60BL,BV60S,WCDZ60BL,WCDZ60S,WCBV60BL,WCDZ600TS,WCDZ600TBL
will use same method to install the door
1. To put the cabinet on open operation place, the door opened to the maximum angle
2. Use small knife (2) to take off the decorative nail (1) on opposite side (Drawing 1);
3. Use the inner six angle screwdriver (Tool 5) to disassemble the screws(4) of drop-proof
device (3), then remove the drop-proof device .(Drawing 1)
4. Hold the door, use six angle screwdriver (Tool 5) to screw out the door shaft core(6)
from the two ends of the top of the door. Take out the door and set aside. (Drawing 2)
5. Discharge the upper and lower door hinge (7) (8) by M5 inner six angle screwdriver
(Tool 5), then to assemble the door hinge on the opposite side. (Drawing 3 and 4)
6. Rotate the door 180 degrees, then Install the door on the right side of the cabinet.
(Drawing 5)
7. Finally, install the decorative nail and drop-proof device at the opposite side. (Drawing
6)

1.Decorative nail
2. Knife
3. Drop-proof device
4. M5 six angle
5. M5 six angle screwdriver
6. Door spindle core
7. Upper door hinge
8. Lower door hinge
Handle Installation Method
1. Take out handle from cabinet, then take out 4pcs 4 * 35 screws from accessory bag
2. Pull open door seal from the side of door, then insert screws into the 2 handle holes on
side of door, then put the screws alignment the hole of handle , tighten the screws by
Phillips screwdriver，then compress the door seal

If the screws holes of the handle don't match perfectly with the holes of the door ,please
use the electric drill to drill the holes of the door a bit big ( in surface side) ,
in order to install the handle perfectly .
OPERATION ANOMALIES
Ensure that there is power to the electrical supply plug by connecting another electrical
appliance to it. Check fuse, if any. Make sure that the door is closed properly.
If your wine cellar appears to be malfunctioning, unplug it and contact your after sales
service. Any intervention on the cold circuit should be performed by a refrigeration
technician who should carry out an inspection of the circuit sealing system. Similarly, any
intervention on the electrical circuit should be performed by a qualified electrician.
Notes: Any intervention performed by a non- authorized technician will lead to the
warranty being considered as null and void.
