Award GTSN462 S User manual

Fridge -Freezer
User Manual
GTSN462 S
GTSN462 BS

EN - 2
Thank you for choosing this fridge - freezer.
This user manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your fridge - freezer.
Please take the time to read this user manual before using your fridge - freezer and keep
this book for future reference.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of re / ammable materials
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly

EN - 3
CONTENTS
1 SAFETY INSTRUCTIONS ............................................................................... 4
1.1 General Safety Warnings ...............................................................................................4
1.2 In󰀬allation warnings .......................................................................................................8
1.3 During Usage..................................................................................................................9
2 DESCRIPTION OF THE FRIDGE-FREEZER............................................... 10
3 USING THE FRIDGE-FREEZER................................................................... 11
3.1 Information about New Generation Cooling Technology ..............................................11
3.2 Display and Control Panel............................................................................................11
3.3 Operating your Fridge Freezer .....................................................................................11
3.3.1 Freezer Temperature Settings ...................................................................................11
3.3.2 Fridge Temperature Settings .....................................................................................12
3.3.3 Super Freeze Mode...................................................................................................12
3.3.4 Door Open Alarm Function........................................................................................12
3.4 Temperature Adju󰀬ment Warnings...............................................................................12
3.5 Accessories ..................................................................................................................13
3.5.1 Ice Tray......................................................................................................................13
3.5.2 The Freezer Box........................................................................................................13
3.5.3 The Chiller Shelf........................................................................................................14
3.5.4 The Fresh Dial...........................................................................................................14
3.5.5 Maxi-fresh preserver..................................................................................................15
4 FOOD STORAGE........................................................................................... 15
4.1 Fridge Compartment.....................................................................................................15
4.2 Freezer Compartment ..................................................................................................16
5 CLEANING AND MAINTENANCE................................................................ 19
6 SHIPMENT AND REPOSITIONING.............................................................. 20
6.1 Transportation and Changing Positioning ....................................................................20
6.2 Repositioning the Door.................................................................................................20
7 BEFORE CALLING AFTER-SALES SERVICE ........................................... 21
8 TIPS FOR SAVING ENERGY........................................................................ 23

EN - 4
1 SAFETY INSTRUCTIONS
1.1 General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings, in the
fridge - freezer enclosure or in the built-in structure,
clear of obstruction.
WARNING: Do not use mechanical devices or
other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the fridge -freezer,
unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the fridge - freezer,
ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
fridge - freezer.
WARNING: In order to avoid any hazards resulting
from the instability of the fridge - freezer, it must be
xed in accordance with the instructions.
If your fridge - freezer uses R600a as a refrigerant
(this information will be provided on the label of the
fridge - freezer) you should take care during
transportation and installation to prevent the
fridge - freezer elements from being damaged. R600a

EN - 5
is an environmentally friendly and natural gas, but it is
explosive. In the event of a leak due to damage of the
fridge - freezer elements, move your fridge - freezer
away from open ames or heat sources and ventilate
the room where the fridge - freezer is located for a few
minutes.
• While carrying and positioning the fridge - freezer,
do not damage the fridge - freezer gas circuit.
• Do not store explosive substances such as
aerosol cans with a ammable propellant in this
fridge - freezer.
• This fridge - freezer is intended to be used in
household and domestic applications such as:
–sta󰀨 kitchen areas in shops, o󰀩ces and other
working environments.
–farm houses and by clients in hotels, motels and
other residential type environments.
–bed and breakfast type environments;
–catering and similar non-retail applications.
• If the socket does not match the fridge - freezer
plug, it must be replaced by the manufacturer, a
service agent or similarly qualied persons in order
to avoid a hazard.
• A specially grounded plug has been connected to
the power cable of your fridge - freezer. This plug
should be used with a specially grounded socket
of 10 amperes. If there is no such socket in your
house, please have one installed by an authorised
electrician.

EN - 6
• This fridge - freezer can be used by children aged
from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
fridge - freezer in a safe way and understand the
hazards involved. Children shall not play with the
fridge - freezer. Cleaning and user maintenance
shall not be made by children without supervision.
• Children aged from 3 to 8 years are allowed to
load and unload fridge - freezer. Children are not
expected to perform cleaning or user maintenance
of the fridge - freezer, very young children (0-3 years
old) are not expected to use fridge - freezer, young
children (3-8 years old) are not expected to use
fridge - freezer safely unless continuous supervision
is given, older children (8-14 years old) and
vulnerable people can use fridge - freezer safely
after they have been given appropriate supervision
or instruction concerning use of the fridge - freezer.
Very vulnerable people are not expected to use
fridge - freezer safely unless continuous supervision
is given.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This fridge - freezer is not intended for use at
altitudes exceeding 2000 m.

EN - 7
To avoid contamination of food, please respect the
following instructions:
• Opening the door for long periods can cause
a signicant increase of the temperature in the
compartments of the fridge - freezer.
• Clean regularly surfaces that can come in contact
with food and accessible drainage systems
• Store raw meat and sh in suitable containers in the
fridge - freezer, so that it is not in contact with or drip
onto other food.
• Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making ice cream
and making ice cubes.
• One-, two- and three-star compartments are not
suitable for the freezing of fresh food.
• If the fridge - freezer is left empty for long periods,
switch o󰀨, defrost, clean, dry, and leave the door
open to prevent mould developing within the
fridge - freezer.

EN - 8
1.2 Installation warnings
Before using your fridge freezer for the rst
time, please pay attention to the following
points:
• The operating voltage for your fridge
freezer is 220-240 V at 50Hz.
• The plug must be accessible after
installation.
• Your fridge freezer may have an odour
when it is operated for the rst time. This
is normal and the odour will fade when
your fridge freezer starts to cool.
• Before connecting your fridge freezer,
ensure that the information on the data
plate (voltage and connected load)
matches that of the mains electricity
supply. If in doubt, consult a qualied
electrician.
• Insert the plug into a socket with an
e󰀩cient ground connection. If the socket
has no ground contact or the plug does
not match, we recommend you consult a
qualied electrician for assistance.
• The fridge - freezer must be connected
with a properly installed fused socket.
The power supply (AC) and voltage at
the operating point must match with
the details on the name plate of the
fridge - freezer (the name plate is located
on the inside left of the fridge - freezer).
• We do not accept responsibility for any
damages that occur due to ungrounded
usage.
• Place your fridge freezer where it will not
be exposed to direct sunlight.
• Your fridge freezer must never be used
outdoors or exposed to rain.
• Your fridge - freezer must be at least 50
cm away from stoves, gas ovens and
heater cores, and at least 5 cm away
from electrical ovens.
• If your fridge freezer is placed next to a
deep freezer, there must be at least 2
cm between them to prevent humidity
forming on the outer surface.
• Do not cover the body or top of fridge
freezer. This will a󰀨ect the performance
of your fridge freezer.
• Clearance of at least 150 mm is required
at the top of your fridge - freezer. Do
not place anything on top of your
fridge - freezer.
• Do not place heavy items on the
fridge - freezer.
• Clean the fridge - freezer thoroughly
before use (see Cleaning and
Maintenance).
• Before using your fridge freezer, wipe all
parts with a solution of warm water and
a teaspoon of sodium bicarbonate. Then,
rinse with clean water and dry. Return all
parts to the fridge freezer after cleaning.
• Use the adjustable front legs to make
sure your fridge - freezer is level and
stable. You can adjust the legs by
turning them in either direction. This
must be done before placing food in the
fridge - freezer.
If your fridge - freezer includes a fan
condenser
-If the bottom cabinet cover is the
plastic
The condenser of your fridge - freezer
is located at the bottom of the cabinet.
As a result, the ttings which control the
distance between the fridge - freezer
and the wall behind your fridge - freezer
are located on the cover of the bottom
of the cabinet. You can move your
fridge - freezer toward the back wall
until this point.
Plastic for distance setting

EN - 9
-If the bottom cabinet cover is the
metal
The condenser of your fridge - freezer
is placed at the bottom of cabinet.
As a result of that, assemble the
spacer by xing it to holes on the
cover bottom panel and turn 90° that’s
shown below gure for arranging the
distance between the fridge - freezer
and the back wall at where you place
the fridge - freezer. You can move the
fridge - freezer towards the back wall
until that point.
Plastic for distance setting
The distance between the fridge - freezer
and back wall must be a minimum of
75 mm.
1.3 During Usage
• Do not connect your fridge freezer to
the mains electricity supply using an
extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This fridge - freezer is designed for use
by adults. Do not allow children to play
with the fridge - freezer or hang o󰀨 the
door.
• Never touch the power cord/plug with wet
hands. This may cause a short circuit or
electric shock.
• Do not place glass bottles or cans in the
ice-making compartment as they will
burst when the contents freeze.
• Do not place explosive or ammable
material in your fridge - freezer. Place
drinks with high alcohol content vertically
in the fridge compartment and make sure
their tops are tightly closed.
• When removing ice from the ice-making
compartment, do not touch it. Ice may
cause frost burns and/or cuts.
• Do not touch frozen goods with wet
hands. Do not eat ice-cream or ice cubes
immediately after they are removed from
the ice-making compartment.
• Do not re-freeze thawed frozen food. This
may cause health issues such as food
poisoning.
Old and Out-of-order Fridges or
Freezers
• If your old fridge or freezer has a
lock, break or remove the lock before
discarding it, because children may
get trapped inside it and may cause an
accident.
• Old fridges and freezers contain
isolation material and refrigerant with
CFC. Therefore, take care not to harm
environment when you are discarding
your old fridge or freezer.
CE Declaration of conformity
We declare that our products meet the
applicable European Directives, Decisions
and Regulations and the requirements
listed in the standards referenced.
Disposal of your old fridge - freezer
The symbol on the fridge - freezer
or on its packaging indicates
that this fridge - freezer may
not be treated as household
waste. Instead it shall be
handed over to the applicable collection
point for the recycling of electrical and
electronic equipment. By ensuring this
fridge - freezer is disposed of correctly,
you will help prevent potential negative
consequences for the environment and
human health, which could otherwise be
caused by inappropriate waste handling
of this fridge - freezer. For more detailed
information about recycling of this
fridge - freezer, please contact your local
city o󰀩ce, your household waste disposal

EN - 10
service or the shop where you purchased
the fridge - freezer.
Packaging and the Environment
Packaging materials protect
your machine from damage that
may occur during transportation.
The packaging materials are
environmentally friendly as they are
recyclable. The use of recycled material
reduces raw material consumption and
therefore decreases waste production.
Notes:
• Please read the instruction manual
carefully before installing and using your
fridge - freezer. We are not responsible
for the damage occurred due to misuse.
• Follow all instructions on your
fridge - freezer and instruction manual,
and keep this manual in a safe place to
resolve the problems that may occur in
the future.
• This fridge - freezer is produced to be
used in homes and it can only be used
in domestic environments and for the
specied purposes. It is not suitable
for commercial or common use. Such
use will cause the guarantee of the
fridge - freezer to be cancelled and our
company will not be responsible for the
losses that may occur.
• This fridge - freezer is produced to be
used in houses and it is only suitable for
cooling / storing foods. It is not suitable
for commercial or common use and/or for
storing substances except for food. Our
company is not responsible for the losses
that may occur in the contrary case.
2 DESCRIPTION OF THE
FRIDGE-FREEZER
A1
16
15
14
13
B
12
2
4
5
6
7
8
9
10
11
3
This presentation is only for
information about the parts of the
fridge - freezer. Parts may vary according
to the fridge - freezer model.
A) Fridge compartment
B) Freezer compartment
1) Thermostat box / Interior display
2) Turbo fan *
3) Fridge shelves
4) Wine rack *
5) Ioniser *
6) Chiller *
7) Crisper cover
8) Crisper
9) Freezer drawers
10) Adjustable stays
11) Ice box trays
12) Freezer glass shelf *
13) Bottle shelf
14) Adjustable door shelf * / door shelf
15) Door shelf
16) Egg holder
* In some models

EN - 11
3 USING THE FRIDGE-FREEZER
3.1 Information about New Generation
Cooling Technology
Fridge - freezers with new-generation
cooling technology
have a di󰀨erent
operating system to
static fridge - freezers.
Other (static)
fridge - freezers may
experience a build up of
ice in the freezer
compartment due to
door openings and
humidity in the food. In
such fridge - freezers,
regular defrosting is
required; the
fridge - freezer must be
switched o󰀨, the frozen
food moved to a
suitable container and
the ice which has
formed in the freezer
compartment removed.
In fridge - freezers with new-generation
cooling technology, a fan blows dry cold air
evenly throughout the fridge and freezer
compartments. The cold air cools your food
evenly and uniformly, preventing humidity
and ice build-up.
In the fridge compartment, air blown by
the fan, located at the top of the fridge
compartment, is cooled while passing
through the gap behind the air duct. At the
same time, the air is blown out through the
holes in the air duct, evenly spreading cool
air throughout the fridge compartment.
There is no air passage between the
freezer and fridge compartments, therefore
preventing the mixing of odours.
As a result, your fridge - freezer, with new-
generation cooling technology, provides
you with ease of use as well as a huge
volume and aesthetic appearance.
3.2 Display and Control Panel
3 5 6 7 4
1 2
Using the Control Panel
1. Enables the setting of the freezer.
2. Enables the setting of the fridge.
3. Freezer set value screen.
4. Fridge set value screen.
5. Economy mode symbol.
6. Super freeze symbol.
7. Alarm symbol.
3.3 Operating your Fridge Freezer
Lighting (If available)
When the fridge - freezer is plugged in for
the rst time, the interior lights may turn on
1 minute late due to opening tests.
Once you have plugged in the
fridge - freezer, all symbols will be
displayed for 2 seconds and the initial
values will be shown as -18 °C on the
freezer adjustment indicator, and +4 °C on
the fridge adjustment indicator.
3.3.1 Freezer Temperature Settings
• The initial temperature value for the
freezer setting indicator is -18 °C.
• Press the freezer set button once.
When you rst press the button, the
previous value will blink on the screen.
• Whenever you press the same button,
a lower temperature will be set (-16 °C,
-18 °C, -20 °C, -22 °C or -24 °C).
• If you continue to press the button, it will
restart from -16 °C.

EN - 12
NOTE: Eco mode gets activated
automatically when the temperature
of the freezer compartment is set to
-18°C.
3.3.2 Fridge Temperature Settings
• The initial temperature value for the
fridge setting indicator is +4 °C.
• Press the fridge button once.
• Whenever you press the button, a lower
temperature will be set (+8 °C, +6 °C,
+5 °C, +4 °C, or +2 °C).
• If you continue to press the button, it will
restart from +8 °C.
3.3.3 Super Freeze Mode
Purpose
• To freeze a large quantity of food that
cannot t on the fast freeze shelf.
• To freeze prepared foods.
• To freeze fresh food quickly to retain
freshness.
How to use
To enable the super freeze
mode, press and hold the freezer
temperature setting button for 3
seconds. Once the super freeze mode
has been set, the super freeze symbol on
the indicator will be lit and the machine
will beep to conrm the mode has been
switched on.
During Super Freeze Mode:
• The temperature of the fridge
compartment may be adjusted. In this
case, Super Freeze mode will continue.
• Economy mode cannot be selected.
• Super Freeze mode can be cancelled in
the same way it is selected.
Notes:
• The maximum amount of fresh food (in
kilograms) that can be frozen within 24
hours is shown on the fridge - freezer
label.
• For optimal freezer performance in
maximum freezer capacity, activate super
freeze mode 3 hours before you put fresh
food into the freezer.
Super freeze mode will automatically
cancel after 24 hours, depending on
the environmental temperature or when the
freezer sensor reaches a su󰀩ciently low
temperature.
Recommended Settings for the Freezer
and Fridge Compartment Temperature
Freezer
Compartment
Fridge
Compartment Remarks
-18 oC4 oC
For regular
use and best
performance.
-20 oC, -22 oC
or -24 oC4 oC
Recommended
when
environmental
temperature
exceeds 30 °C.
Super Freeze
mode 4 oC
Must be used
when you wish
to freeze food in
a short period of
time.
-18 oC, -20 oC,
-22 oC or
-24 oC
2 oC
These
temperature
settings must be
used when the
environmental
temperature is
high or if you think
the fridge - freezer
compartment is
not cool enough
becuse the door
is being opened
frequently.
3.3.4 Door Open Alarm Function
If a door is opened more than 2 minutes,
alarm sounds ‘beep beep’.
3.4 Temperature Adjustment Warnings
• It is not recommended that you operate
your fridge - freezer in environments
colder than 10°C in terms of its e󰀩ciency.
• Do not start another adjustment while you
are already making an adjustment.
• Temperature adjustments should be
made according to the frequency of door
openings, the quantity of food kept inside
the fridge - freezer and the ambient
temperature in the location of your
fridge - freezer.
• In order to allow your fridge - freezer to
reach the operating temperature after
being connected to mains, do not open

EN - 13
the doors frequently or place large
quantities of food in the fridge - freezer.
Please note that, depending on the
ambient temperature, it may take 24
hours for your fridge - freezer to reach
the operating temperature.
• A 5 minute delay function is applied to
prevent damage to the compressor of
your fridge - freezer when connecting
or disconnecting to mains, or when
an energy breakdown occurs. Your
fridge - freezer will begin to operate
normally after 5 minutes.
• Your fridge - freezer is designed to
operate in the ambient temperature (T/
SN = 10°C - 43°C) intervals stated in
the standards, according to the climate
class displayed on the information
label. We do not recommend operating
your fridge - freezer out of the stated
temperature limits in terms of cooling
e󰀨ectiveness.
Climate
Class Ambient Temperature oC
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
Important installation instructions
This fridge - freezer is designed to work
in di󰀩cult climate conditions and is
powered with ‘Freezer Shield’ technology
which ensures that the frozen food in the
freezer will not defrost even if the ambient
temperature falls as low as -15 °C. So you
may then install your fridge - freezer in an
unheated room without having to worry
about frozen food in the freezer being
spoilt. When the ambient temperature
returns to normal, you may continue using
the fridge - freezer as usual.
3.5 Accessories
3.5.1 Ice Tray
• Fill the ice tray with water and place in
the freezer compartment.
• After the water has completely frozen,
you can twist the tray as shown below to
remove the ice cubes.
3.5.2 The Freezer Box
The freezer box allows food to be accessed
more easily.
Freezer boxes
Ice trays
Removing the freezer box:
• Pull the box out as far as possible
• Pull the front of the box up and out
Carry out the opposite of this operation
when retting the sliding compartment.
Always keep hold of the handle of the
box while removing it.

EN - 14
3.5.3 The Chiller Shelf
Chiller shelf
Keeping food in the Chiller compartment,
instead of the freezer or fridge
compartments, allows food to retain
freshness and avour for longer, while
preserving its fresh appearance. When the
Chiller tray becomes dirty, remove it and
wash with water.
(Water freezes at 0°C, but food containing
salt or sugar freezes at temperatures lower
than this).
The Chiller compartment is usually used
for storing foods such as raw sh, lightly
pickled food, rice, and so on.
Do not put food you want to freeze
or ice trays (to make ice) in the
Chiller compartment.
To remove the Chiller Shelf:
• Pull the chiller shelf towards you by
sliding it on the rails.
• Pull the chiller shelf up from the rail and
remove it from the fridge.
3.5.4 The Fresh Dial
Fresh dial
If the crisper is full, the fresh dial located
in front of the crisper should be opened.
This allows the air in the crisper and the
humidity rate to be controlled, to increase
the life of food within.
The dial, located behind the shelf, must be
opened if any condensation is seen on the
glass shelf.

EN - 15
3.5.5 Maxi-fresh preserver
Maxi Fresh Preserver technology helps to
remove ethylene gas (a
bioproduct released naturally
from fresh foods) and
unpleasant odors from the
crisper. In this way, food stays
fresh for a longer time.
• Maxi Fresh Preserver must
be cleaned once in a year.
The lter should be heated
for 2 hours at 65°C in a
oven.
• To clean the lter, please
remove the back cover of the lter box by
pulling it in the direction of the arrow.
• The lter should not be washed with
water or any detergent.
Maxi Fresh Preserver
(In some models)
Visual and text descriptions in
the accessories section may vary
according to the model of your
fridge - freezer.
4 FOOD STORAGE
4.1 Fridge Compartment
• To reduce humidity and avoid the
consequent formation of frost, always
store liquids in sealed containers in the
fridge. Frost tends to concentrate in the
coldest parts of the evaporating liquid
and, in time, your fridge - freezer will
require more frequent defrosting.
• Never place warm food in the fridge.
Warm food should be allowed to cool
at room temperature and should be
arranged to ensure adequate air
circulation in the fridge compartment.
• Make sure no items are in direct contact
with the rear wall of the fridge - freezer
as frost will develop and packaging will
stick to it. Do not open the fridge door
frequently.
• We recommend that meat and clean sh
are loosely wrapped and stored on the
glass shelf just above the vegetable bin
where the air is cooler, as this provides
the best storage conditions.
• Store loose fruit and vegetable items in
the crisper containers.
• Store loose fruit and vegetables in the
crisper.
• Storing fruit and vegetables separately
helps prevent ethylene-sensitive
vegetables (green leaves, broccoli,
carrot, etc.) being a󰀨ected by ethylene-
releaser fruits (banana, peach, apricot,
g etc.).
• Do not put wet vegetables into the fridge.
• Storage time for all food products
depends on the initial quality of the food
and an uninterrupted refrigeration cycle
before fridge storage.
• To avoid cross-contamination do not
store meat products with fruit and
vegetables. Water leaking from meat may
contaminate other products in the fridge.
You should package meat products and
clean any leakages on the shelves.

EN - 16
• Do not put food in front of the air ow
passage.
• Consume packaged foods before the
recommended expiry date.
NOTE: Potatoes, onions and garlic
should not be stored in the fridge.
The table below is a quick guide to
show you the most e󰀩cient way to store
the major food groups in your fridge
compartment.
Food Maximum
storage time
How and where to
store
Vegetables
and fruits 1 week Vegetable bin
Meat and
sh 2 - 3 days
Wrap in plastic foil,
bags, or in a meat
container and store
on the glass shelf
Fresh
cheese 3 - 4 days On the designated door shelf
Butter and
margarine 1 week On the designated door shelf
Bottled
products
e.g. milk
and
yoghurt
Until the
expiry date
recommended
by the
producer
On the designated
door shelf
Eggs 1 month On the designated
egg shelf
Cooked
food 2 days All shelves
4.2 Freezer Compartment
• The freezer is used for storing frozen
food, freezing fresh food, and making ice
cubes.
• For freezing fresh food; wrap and seal
fresh food properly, that is the packaging
should be air tight and shouldn’t leak.
Special freezer bags, aluminum foil
polythene bags and plastic containers
are ideal.
• Do not store fresh food next to frozen
food as it can thaw the frozen food.
• Before freezing fresh food, divide it into
portions that can be consumed in one
sitting.
• Consume thawed frozen food within a
short period of time after defrosting
• Never place warm food in the freezer
compartment as it will thaw the frozen
food.
• Always follow the manufacturer's
instructions on food packaging when
storing frozen food. If no information is
provided food, should not be stored for
more than 3 months from the date of
purchase.
• When purchasing frozen food, make sure
that it has been stored under appropriate
conditions and that the packaging is not
damaged.
• Frozen food should be transported in
appropriate containers and placed in the
freezer as soon as possible.
• Do not purchase frozen food if the
packaging shows signs of humidity
and abnormal swelling. It is probable
that it has been stored at an unsuitable
temperature and that the contents have
deteriorated.
• The storage life of frozen food depends
on the room temperature, the thermostat
setting, how often the door is opened,
the type of food, and the length of time
required to transport the fridge - freezer
from the shop to your home. Always
follow the instructions printed on the
packaging and never exceed the
maximum storage life indicated.
• The maximum amount of fresh food (in
kg) that can be frozen in 24 hours is
indicated on the fridge - freezer label.
• To use the maximum capacity of the
freezer compartment, use the glass
shelves for the upper and middle section,
and use the lower basket for the bottom
section.
• Use the fast freezing shelf to freeze
home cooking (and any other food
which needs to be frozen quickly) more
quickly because of the freezing shelf’s
greater freezing power. Fast freezing
shelf is the bottom drawer of the freezer
compartment.
NOTE: If you attempt to open the freezer
door immediately after closing it, you
will nd that it will not open easily. This

EN - 17
is normal. Once equilibrium has been
reached, the door will open easily.
Important note:
• Never refreeze thawed frozen food.
• The taste of some spices found in cooked
dishes (anise, basilica, watercress,
vinegar, assorted spices, ginger, garlic,
onion, mustard, thyme, marjoram, black
pepper, etc.) changes and they assume
a strong taste when they are stored for a
long period of time. Therefore, add small
amounts of spices to food to be frozen, or
the desired spice should be added after
the food has thawed.
• The storage time of food is dependent
on the type of oil used. Suitable oils are
margarine, calf fat, olive oil and butter.
Unsuitable oils are peanut oil and pig fat.
• Food in liquid form should be frozen in
plastic cups and other food should be
frozen in plastic folios or bags.
The table below is a quick guide to
show you the most e󰀩cient way to
store the major food groups in your freezer

EN - 18
compartment.
Meat and sh Preparation Maximum storage time
(months)
Steak Wrap in foil 6 - 8
Lamb meat Wrap in foil 6 - 8
Veal roast Wrap in foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packaging without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be kept packaged even if it has a membrane
Chicken and turkey Wrap in foil 4 - 6
Goose and duck Wrap in foil 4 - 6
Deer, rabbit, wild boar In 2.5 kg portions or as llets 6 - 8
Freshwater sh
(Salmon, Carp, Crane,
Catsh)
After cleaning the bowels and scales of the sh,
wash and dry it. If necessary, remove the tail and
head.
2
Lean sh (Bass, Turbot,
Flounder) 4
Fatty shes (Tuna,
Mackerel, Bluesh,
Anchovy)
2 - 4
Shellsh Clean and in a bag 4 - 6
Caviar In its packaging, or in an aluminium or plastic
container 2 - 3
Snails In salty water, or in an aluminium or plastic container 3
NOTE: Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after defrosting, it
must not be re-frozen.
Vegetables and Fruits Preparation Maximum storage time
(months)
String beans and beans Wash, cut into small pieces and boil in water 10 - 13
Beans Hull, wash and boil in water 12
Cabbage Clean and boil in water 6 - 8
Carrot Clean, cut into slices and boil in water 12
Pepper Cut the stem, cut into two pieces, remove the core
and boil in water 8 - 10
Spinach Wash and boil in water 6 - 9
Cauliower Remove the leaves, cut the heart into pieces and
leave it in water with a little lemon juice for a while 10 - 12
Eggplant Cut into pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as sweet corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6

EN - 19
Vegetables and Fruits Preparation Maximum storage time
(months)
Strawberry and
Blackberry Wash and hull 8 - 12
Vegetables and Fruits Preparation Maximum storage time
(months)
Cooked fruits Add 10 % of sugar to the container 12
Plum, cherry, sourberry Wash and hull the stems 8 - 12
Maximum storage time
(months)
Thawing time at room
temperature (hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)
Dairy products Preparation Maximum storage time
(months) Storage conditions
Packet (Homogenized)
Milk In its own packet 2 - 3 Pure Milk – in its own packet
Cheese - excluding
white cheese In slices 6 - 8
Original packaging may be
used for short-term storage.
Keep wrapped in foil for
longer periods.
Butter, margarine In its packaging 6
5 CLEANING AND
MAINTENANCE
Disconnect the unit from the power
supply before cleaning.
Do not wash your fridge - freezer by
pouring water on it.
Do not use abrasive products,
detergents or soaps for cleaning the
fridge - freezer. After washing, rinse with
clean water and dry carefully. When you
have nished cleaning, reconnect the plug
to the mains supply with dry hands.
• Make sure that no water enters the lamp
housing and other electrical components.
• The fridge - freezer should be cleaned
regularly using a solution of bicarbonate
of soda and lukewarm water.
• Clean the accessories separately by
hand with soap and water. Do not wash
accessories in a dish washer.
• Clean the condenser with a brush at least
twice a year. This will help you to save on
energy costs and increase productivity.
The power supply must be
disconnected during cleaning.

EN - 20
Replacing LED Lighting
Location #1
LED strip light Location #2
LED strip light
Location #3
LED strip light
To replace any of the LEDs, please contact
the nearest Authorised Service Centre.
Note: The numbers and location of the LED
strips may change according to the model.
6 SHIPMENT AND
REPOSITIONING
6.1 Transportation and Changing
Positioning
• The original packaging and foam may be
kept for re-transportation (optional).
• Fasten your fridge - freezer with thick
packaging, bands or strong cords and
follow the instructions for transportation
on the packaging.
• Remove all movable parts (shelves,
accessories, vegetable bins, and so
on) or x them into the fridge - freezer
against shocks using bands when re-
positioning or transporting.
Always carry your fridge - freezer in
the upright position.
6.2 Repositioning the Door
• It is not possible to change the opening
direction of your fridge - freezer door if
door handles are installed on the front
surface of the fridge - freezer door.
• It is possible to change the opening
direction of the door on models without
handles.
• If the door-opening direction of your
fridge - freezer can be changed, contact
the nearest Authorised Service Centre to
change the opening direction.
