Awind WP-920 User manual

1
Wireless Presentation Adaptor
User’s Manual
(Model Name: WP-920)
Version: 4.1
Date: Mar. 22, 2010

2
Table of Contents
1.
Overview .....................................................................................................4
2. Quick Start .................................................................................................6
3. Windows Client Utility .........................................................................10
3.1 Starting Program ...............................................................................10
3.2 Login .......................................................................................................10
3.3 Main User Interface ..........................................................................11
3.4 Screen Projection ..............................................................................11
3.5 Audio Projection ................................................................................12
3.6 Video/Music streaming Feature ..................................................13
3.7 Menu Description ..............................................................................14
3.7.1 Show Login Code ...........................................................................14
3.7.2 Open Admin Web Page ................................................................15
3.7.3 Searching Server ...........................................................................15
3.7.4 Projection Quality .........................................................................16
3.7.5 Projection Source ..........................................................................16
3.7.6 Send Audio to Display ..................................................................17
3.7.7 Auto WiFi Connect .........................................................................17
3.7.8 Auto Power Manager ...................................................................18
3.7.9 Hide UI ..............................................................................................18
3.7.10 Advanced Screen Capture ......................................................19
3.7.11 Repeat ...........................................................................................20
3.7.12 Make wePresent Token ...........................................................20
3.7.13 Copy Application to desktop .................................................21
3.7.14 About ..............................................................................................21
3.7.15 Exit ..................................................................................................22
4. Windows Mobile Utility .......................................................................23
4.1 Download from wePresent box ................. 錯誤 ! 尚未定義書籤。
4.2 Using MobiShow with a Smartphone .........................................23
5. Mac Client Utility ...................................................................................29
5.1 Launch Application ...........................................................................29
5.2 Main User Interface ..........................................................................30
5.3 Screen Projection ..............................................................................31
5.4 Video/Music streaming Feature ..................................................31
6. Web Management .................................................................................33
6.1 Home Page ...........................................................................................33
6.2 Download Software ..........................................................................33

3
6.3 Conference Control ...........................................................................34
6.4 Login Web Admin ..............................................................................36
6.4.1 System Status .................................................................................36
6.4.2 Network Setup ...............................................................................37
6.4.3 OSD Setup ........................................................................................39
6.4.4 Projection Setup ............................................................................40
6.4.5 Change Passwords ........................................................................41
6.4.6 Reset to Default .............................................................................41
6.4.7 Firmware Upgrade ........................................................................42
6.4.8 Reboot System................................................................ 43
6.4.9 Logout............................................................................. 44
7. Appendix ............................................................................... 45
Screen Image Background Maker............................................... 45
Using PtG Converter .....................................................................................50

4
1.Overview
wePresent is a must-have device for your meeting room! It turns your existing
"wired" projector into a "high-end wireless" projector. With the revolutionary
Plug-and-Show wireless projection features, wePresent makes every of your
presentation and meeting efficient and successful.
High Performance Wireless Projection & Audio Projection
With the revolutionary high performance wireless projection with audio, you
can easily share the multimedia on the big monitor with friends without cable
hassle.
Plug & Show
With the accompanied Plug & Show USB Token, wireless presentation becomes
easy! Just link your PC/Laptop to wePresent (through WLAN or Ethernet),
plug the token into a USB port, and in seconds, your screen will be wireless
projected to the connected projector!
4-to-1 Split Screen Projection
With this 4-to-1 split screen feature, up to four PC screens can be projected to
one projector in the same time. Thus you can easily do side-by-side
comparison from four PC / PDAs to increase meeting productivity!
1-to-4 Screen Projection
With 1-to-4 Screen Projection, you can projection PC content out to up to 4
screens at the same time through wePresent devices. 1-to-4 Screen Projection
feature functions both under presentation mode and video mode.
Macintosh(Mac) wireless Projection
wePresent supports Mac client connected and projected wirelessly. By
launching the Mac client software that stored in accompanied USB token,
wePresent provide the same experience to Mac user to utilize the wireless
presentation feature.

5
HD video Streaming
wePresent supports video streaming feature, you can watch the HD video on
big screen with original quality through wireless streaming.
SNMP Manager
wePresent equips the SNMP management feature to make the device
management easier. By enabling the SNMP (Simple Network Management
Protocol) protocol (Version 2c), the devices could be managed and configured
through network for each or bunch.
Changeable Splash Screen
You can use the application “Screen Image Background Maker” to change the
Splash Screen. Design the image with message you would like to present,
upload it through web control page, and you could have customized starting
page.
AP-Client Mode
You can enable the AP-Client Mode function to let wePresent join the existing
Access Point through Wi-Fi. This feature provides the flexibility of wireless
network deployment in enterprise environment.
Remote Desktop
Plug standard USB keyboard or mouse into the USB port in front panel of
wePresent device, you can control your PC remotely. You don’t have to stand
still aside of PC or wePresent device, and it makes your presentation easily and
freely.

6
Features
■ Support Windows Win7, Vista, XP, 2000 and Mobile 5/6
■ Support Macintosh(Mac) version 10.5 and above.
■ Plug and Show! No installation required … just plug in the
accompanied token to a USB port, and hassle free presentation can be
started in seconds.
■ 4-to-1 split screen projection! Turn one projector into four, increase
meeting productivity right away.
■ 1-to-4 screen projection! Project PC content to four screens, fulfill the
need of multicasting purpose
■ Smartphone wireless projection! PC-less stylish presentation becomes
possible!
■ Conference control! Allows moderators to streamline grand meetings.
■ Provide session security login, wireless WEP/WPA key and Gatekeeper
function to protect presentation contents and keep good security to
office networks.
■ Provide media playback feature, support music and video streaming.
■ High Performance screen projection with audio!
■ H.264 HD video streaming support!
■ Changeable Splash Screen image!
■ SNMP Manager! To manage the devices easily
■AP-Client Mode! Deploy wireless network in enterprise environment
easily
■Remote Desktop!
2.Quick Start
1) Connect projector VGA cable to wePresent box VGA connector and turn on
projector power.

7
2) Turn on wePresent box.
♦When Projector shows the default menu on the screen as below, it
indicates the wePresent box is ready now.
3) Make sure your PC WLAN is enabled already, and connect your PC with
wePresent box.
4) Open your browser and it will redirect to wePresent main page automatically,
or you can enter the IP address to access the WPS web home page.
♦The default IP address of wePresent is 192.168.100.10 or refers to
the IP address shown on the left corner of projector screen.

8
5) Download the client software. Please select the” Win7 / Windows Vista / XP
/ 2000” or “Mac Utility” and execute the installation program.
After installing the program, you will see the wePresent shortcut on the PC
screen.
6) Make sure your personal firewall allows wePresent software to pass
through.
7) Select devices that you would like to do projection

9
8) Enter the LOGIN CODE and You can see the login code on the projector
screen
9) Click the “Play” button to start projection!

10
3.Windows Client Utility
3.1 Starting Program
After you download wePresent Windows program via web page successfully,
then follow below steps to start.
1) Click wePresent icon to execute the program.
2) Program start to search for wePresent box automatically,
3) If wePresent box founded then “Login Code” dialog box will be pop up on
the PC screen.
Searching for wePresent box
wePresent boxes are founded and enter login code to start.
3.2 Login
1) After “Login Code” dialog box shown, enter login code to start presentation.
2) You can see the login code shown on the projector screen.

11
3.3 Main User Interface
3.4 Screen Projection
Click the “Play” button for full or split screen, you can project the main screen
on to the display immediately, click the “Pause” button, you can freeze you
projection screen, and click the “Stop” button to stop projecting your screen.
Screen
Projection Tab
Streaming
Tab
Control Area for Screen
Projection Feature
Menu Area
Control Area for Streaming
Feature
Status Indicator
Select
device

12
*. To enable the audio projection, you have to install provided audio driver
and set the projection quality to “Normal”.
Button Description
Full Screen projection
Project to Split #1
Project to Split #2
Project to Split #3
Project to Split #4
Stop projecting
Pause projecting
3.5 Audio Projection
First, before starting the Audio Projection, please install the “VAC.exe” (Virtual
Audio Control) on your computer which is Windows XP. Please find the software
in USB Token. (Windows Vista and Win7 don’t need to install VAC)
Second, it applies only under “Normal” option of the “Projection Quality”.
Make sure these two steps, and you can hear the audio from device when
projecting.

13
3.6 Video/Music streaming Feature
Click the “Video Tab” to switch to Video Mode, choose a video/audio file, then it
will stream the original file to playback on the screen.
* Supported Video/Audio Format: MPEG1/2, DivX(3.4.5), XviD(MPEG4),
H.264, WMV9, MP3, WMA
Button Description
Start Playing Video/Music
Stop Playing Video/Music
Open Video/Music File
Mute
Volume Level
Progress Bar

14
3.7 Menu Description
3.7.1 Show Login Code
Click “Show Login Code”, it will display the login code on the right-upper of
desktop and close it automatically after 10 seconds. You can also click on the
area to close this window manually.
Login Code Menu
Minimize
Exit

15
3.7.2 Open Admin Web Page
Click to open function menu and select “Web Admin” management web
page. The web page detailed functions will be described on next chapter.
3.7.3 Searching Server
Click “Search Server” to re-search the wePresent again.

16
3.7.4 Projection Quality
Click the “Projection Quality”, choose “Normal” for faster projection speed with
lower screen image quality, and “Best” for clear screen image quality but slower
projection speed.
3.7.5 Projection Source
Click the “Projection Source” then you can select to project the main screen of
desktop or the virtual extended screen.
P.S: Virtual Extended Screen option
You need to install “VDD.exe” driver first which is stored in the USB token.

17
3.7.6 Send Audio to Display
Click “Send Audio to Display” then select the function you want to start audio
projection or not.
3.7.7 Auto WiFi Connect
Click “Auto WiFi Connect” to enable the AWZC function, this function can save
the WiFi connection steps.

18
3.7.8 Auto Power Manager
To make the highest projection performance, application will turn the PC’s
windows power scheme from current settings to “highest performance”,
however, you can click the “Auto Power Manage” to enable or disable this
function and restore you power scheme immediately.
3.7.9 Hide UI
Click the “Hide UI”, you can choose to hide or display the application control
panel from projection screen.

19
3.7.10Advanced Screen Capture
Click the “Advanced Screen Capture”, you will be able to see tip windows and
other layered windows (include the main UI) on the connected display.
However, the mouse cursor may blink from time to time when you are
projecting your PC screen!
Disable “Advanced Screen Capture”.
Enable “Advanced Screen Capture”.
Tip windows is shown
in projector
Tip windows is not
shown in projector

20
3.7.11Repeat
Click the” Repeat”, you can choose to playback current video/audio file repeat
or not.
3.7.12Make wePresent Token
Click “Make wePresent Token” to make a USB wePresent Token, you can insert
a USB thumb drive and follows the wizard to make the Token.
