Awind WPS-Dongle 2 User manual

1
Wireless Presentation Adaptor
User’s Manual
(Model Name: WPS-Dongle 2)
Version: 2.0
Date: Apr. 28, 2011

2
Table of Contents
1. Overview ............................................................................................... 4
2. Quick Start............................................................................................. 6
3. Windows Client Utility ........................................................................... 9
3.1 Starting Program................................................................................ 9
3.2 Login .................................................................................................10
3.3 Main User Interface...........................................................................11
3.4 Screen Projection...............................................................................11
3.5 Menu Description ..............................................................................12
3.5.1 Show Login Code............................................................................12
3.5.2 Open Admin Web Page ..................................................................13
3.5.3 WiFi AP-Client Configuration .........................................................13
3.5.4 Searching Server............................................................................14
3.5.5 Projection Source...........................................................................14
3.5.6 Auto WiFi Connect.........................................................................15
3.5.7 Auto Power Manager.....................................................................15
3.5.8 Hide UI ..........................................................................................16
3.5.9 Advanced Screen Capture...............................................................16
3.5.10 Make WPS Token .......................................................................17
3.5.11 Copy Application to desktop .......................................................18
3.5.12 Hot Key ......................................................................................19
3.5.13 About ........................................................................................19
3.5.14 Exit ............................................................................................20
4. Mac Client Utility ..................................................................................20
4.1 Launch Application ............................................................................20
4.2 Main User Interface...........................................................................22
4.3 Screen Projection...............................................................................22
5. Web Management ................................................................................23
5.1 Home Page........................................................................................23
5.2 Download Software...........................................................................23
5.3 Login Web Admin ..............................................................................24
5.3.1 System Status ................................................................................25
5.3.2 Network Setup...............................................................................26
5.3.3 OSD Setup......................................................................................28
5.3.4 Projection Setup ............................................................................28
5.3.5 Change Passwords .........................................................................29
5.3.6 Reset to Default.............................................................................30

3
5.3.7 Firmware Upgrade.........................................................................30
5.3.8 Reboot System ...............................................................................32
5.3.9 Logout...........................................................................................32
6. Appendix ..............................................................................................33
Screen Image Background Maker..................................................................33

4
1. Overview
WPS-Dongle 2 is a must-have device for your meeting room! It turns your existing
"wired" projector into a "high-end wireless" projector. With the revolutionary
Plug-and-Show wireless projection features, WPS makes every of your presentation
and meeting efficient and successful.
High Performance Wireless Projection
With the revolutionary high performance wireless projection, you can easily share
the multimedia on the big monitor with friends without cable hassle.
High Performance Wireless Projection & Audio Projection
With the revolutionary high performance wireless projection with audio, you can
easily share the multimedia on the big monitor with friends without cable hassle.
Easy installation
Download the software from web management page directly, or make a “Plug &
Show” token to project wirelessly right away
Plug & Show
There is an easy tool to make a Plug & Show USB Token on UI menu. Just link your
PC/Laptop to WPS (through WLAN or Ethernet), plug the token into a USB port, and
in seconds, your screen will be wireless projected to the connected projector!
Macintosh(Mac) wireless Projection
WPS-Dongle 2 supports Mac client connected and projected wirelessly. By launching
the Mac client software which can be downloaded from the web management page,
WPS provide the same experience to Mac user to utilize the wireless presentation
feature.

5
4-to-1 Split Screen Projection
With this 4-to-1 split screen feature, up to four PC screens can be projected to one
projector in the same time. Thus you can easily do side-by-side comparison from
four PC / PDAs to increase meeting productivity!
Smartphone wireless projection
WPS-Dongle 2 supports MobiShow function for windows mobile 5/6 system. By
launching MobiShow utility, MobiShow brings your mobile screen to big screen and
which can play photos and PtG files stored in your mobile phone for presentation.
Change Standby Screen
You can use the application “Screen Image Background Maker” to change the Splash
Screen. Design the image with message you would like to present, upload it through
web control page, and you could have customized starting page.
AP Client Mode
You can enable the AP-Client Mode function to let WPS join the existing Access Point
through Wi-Fi. This feature provides the flexibility of wireless network deployment in
enterprise environment.
Support PoVGA
Connect WPS-Dongle 2 to a projector supporting PoVGA, the power can be supplied
directly from the VGA port without external power adapter.

6
Features
■Support Windows Win7, Vista, XP, and Mac
■Support Macintosh(Mac) version 10.5 and above.
■Plug and Show! No installation required … just plug in the accompanied
token to a USB port, and hassle free presentation can be started in seconds.
■4-to-1 split screen projection! Turn one projector into four, increase
meeting productivity right away.
■Smartphone wireless projection! PC-less stylish presentation becomes
possible!
■Provide session security login, wireless WEP/WPA key and Gatekeeper
function to protect presentation contents and keep good security to office
networks.
■Support High Performance screen projection
■Changeable Splash Screen image!
■SNMP Manager! To manage the devices easily
■AP-Client Mode! Deploy wireless network in enterprise environment easily
■Support PoVGA.
2. Quick Start
1) Please plug WPS-Dongle 2 into projector VGA port, and open projector power to
use
2) Turn on WPS Dongle 2.
♦When Projector shows the default menu on the screen as below, it

7
indicates the WPS box is ready now.
3) Make sure your PC WLAN is enabled already, and connect your PC with WPS
Dongle 2.
4) Open your browser and enter the IP address to access the WPS web home page.
♦The default IP address of WPS is 192.168.100.10 or refers to the IP address
shown on the left corner of projector screen.
5) Download the client software. Please select the” Win7 / Windows Vista / XP ”
or ”MAC” and execute the installation program.
After installing the program, you will see the WPS shortcut on the PC screen.

8
6) Make sure your personal firewall allows WPS software to pass through.
7) Select device that your want to projection
8) Enter the LOGIN CODE and You can see the login code on the projector screen

9
9) Click the “Play” button to start projection!
3. Windows Client Utility
3.1 Starting Program
After you download WPS Windows program via web page successfully, then follow
below steps to start.
1) Click WPS icon to execute the program.
2) Program start to search for WPS box automatically,
3) If WPS box founded then “Login Code” dialog box will be pop up on the PC
screen.
Searching for WPS box

10
WPS box is founded and enter login code to start.
3.2 Login
1) After “Login Code” dialog box shown, enter login code to start presentation.
2) You can see the login code shown on the projector screen.

11
3.3 Main User Interface
3.4 Screen Projection
Click the “Play” button for full or split screen, you can project the main screen on to
the display immediately, click the “Pause” button, you can freeze you projection
screen, click the “Stop” button to stop projecting your screen, by clicking speedy
mode button, the projection will enter speedy mode for faster projection.
*. 4-1 function will be disabled in speedy mode.
*. To enable audio projection, you have to install provided audio driver first.
Button Description
Full Screen projection
Project to Split #1
Project to Split #2
Control Area for Screen Projection Feature
Menu Area
Status Indicator
Speedy mode

12
Project to Split #3
Project to Split #4
Stop projecting
Pause projecting
3.5 Menu Description
3.5.1 Show Login Code
Click “Show Login Code”, it will display the login code on the right-upper of desktop
and close it automatically after 10 seconds. You can also click on the area to close this
window manually.
Login Code
Minimize
Exit
Menu

13
3.5.2 Open Admin Web Page
Click to open function menu and select “Web Admin” management web page.
The web page detailed functions will be described on next chapter.
3.5.3 WiFi AP-Client Configuration
Click “WiFi AP-Client Configuration” to set AP client mode to join others Access
Point via wireless, besides, the others user client also can login WPS for
presentation and join to others Access Point network,

14
3.5.4 Searching Server
Click “Search Server” to re-search the WPS again.
3.5.5 Projection Source
Click the “Projection Source”, you can select to project the main screen of desktop or
the virtual extended screen.
P. S : Virtual Extended Screen option
You need to install “VDD.exe” driver first which is stored in the USB token.

15
3.5.6 Auto WiFi Connect
Click “Auto WiFi Connect” to enable the auto WiFi discovery and connection
function for quick wireless set up.
3.5.7 Auto Power Manager
To make the highest projection performance, application will turn the PC’s windows
power scheme from current settings to “highest performance”, however, you can
click the “Auto Power Manage” to enable or disable this function and restore you
power scheme immediately.

16
3.5.8 Hide UI
Click the “Hide UI”, you can choose to hide or display the application control panel
from projection screen.
3.5.9 Advanced Screen Capture
Click the “Advanced Screen Capture”, you will be able to see tip windows and other
layered windows (include the main UI) on the connected display.
However, the mouse cursor may blink from time to time when you are projecting
your PC screen!
Disable “Advanced Screen Capture”.
Tip windows is not
shown in projector.

17
Enable “Advanced Screen Capture”.
3.5.10 Make WPS Token
Click “Make WPS Token” to make a USB WPS Token, you can insert a USB thumb
drive and follows the wizard to make the Token.
Tip windows is shown
in projector.

18
3.5.11 Copy Application to desktop
Click the “Copy Application to desktop”, it will copy the application to your desktop
immediately even you don’t have the system privilege

19
3.5.12 Hot Key
Click “Hot Key” to show Hot Key guide. You can use hot key to control the projection
by keyboard.
3.5.13 About
Click “About”to show system information. It includes product model name, Client
version, IP address and other information.

20
3.5.14 Exit
Click “Exit”to exit this application. It will stop current playing status and close the
application immediate.
4. Mac Client Utility
4.1 Launch Application
1) Enable your WiFi and connect to WPS device.
2) Execute WPS client software for Mac.
