Axia i-Smart 603F User manual

Induction Hob
Instruction Manual / Installation Manual
MODEL: i-Smart 603F

Content
1. Foreword..........................................................................................4
1.1 Safety Warnings .......................................................................... 4
1.2 Installation.................................................................................. 4
1.2.1 Electrical Shock Hazard................................................... 4
1.2.2 Cut Hazard.................................................................... 4
1.2.3 Important safety instructions........................................... 4
1.3 Operation and maintenance........................................................... 5
1.3.1 Electrical Shock Hazard................................................... 5
1.3.2 Health Hazard................................................................ 5
1.3.3 Hot Surface Hazard ........................................................ 5
1.3.4 Cut Hazard.................................................................... 6
1.3.5 Important safety instructions........................................... 6
2. Product Induction ............................................................................8
2.1 Top View..................................................................................... 8
2.2 Control Panel............................................................................... 8
2.3 Working Theory ........................................................................... 8
2.4 Before using your New Induction Hob ............................................. 9
2.5 Technical Specification .................................................................. 9
3. Operation of Product ........................................................................9
3.1 Touch Controls............................................................................. 9
3.2 Choosing the right Cookware ......................................................... 9
3.3 How to use................................................................................ 10
3.3.1 Start cooking............................................................... 10
3.3.2 Finish cooking.............................................................. 11
3.3.3 Using the Boost function ............................................... 12
3.3.4 Flexible Area................................................................ 12
3.3.5 Special function ........................................................... 14
3.3.6 Locking the Controls ..................................................... 14
3.3.7 Timer control............................................................... 15
3.3.8 Default working times................................................... 17
4. Cooking Guidelines.........................................................................17
4.1 Cooking Tips ............................................................................. 17
4.1.1 Simmering, cooking rice................................................ 17
4.1.2 Searing steak .............................................................. 18
4.1.3 For stir-frying .............................................................. 18
4.2 Detection of Small Articles .......................................................... 18
5. Heat Settings .................................................................................18
6. Care and Cleaning ..........................................................................19
7. Hints and Tips ................................................................................20
8. Failure Display and Inspection .......................................................21
9. Installation ....................................................................................23
9.1 Selection of installation equipment ............................................... 23
9.2 Before installing the hob, make sure that ...................................... 24
9.3 After installing the hob, make sure that ........................................ 24

9.4 Before locating the fixing brackets................................................ 24
9.5 Adjusting the bracket position...................................................... 24
9.6 Cautions ................................................................................... 25
9.7 Connecting the hob to the mains power supply .............................. 25

4
1. Foreword
1.1 Safety Warnings
Your safety is important to us. Please read this information
before using your cooktop.
1.2 Installation
1.2.1 Electrical Shock Hazard
Disconnect the appliance from the mains electricity supply
before carrying out any work or maintenance on it.
Connection to a good earth wiring system is essential and
mandatory.
Alterations to the domestic wiring system must only be
made by a qualified electrician.
Failure to follow this advice may result in electrical shock or
death.
1.2.2 Cut Hazard
Take care - panel edges are sharp.
Failure to use caution could result in injury or cuts.
1.2.3 Important safety instructions
Read these instructions carefully before installing or using
this appliance.
No combustible material or products should be placed on
this appliance at any time.
Please make this information available to the person
responsible for installing the appliance as it could reduce
your installation costs.
In order to avoid a hazard, this appliance must be installed
according to these instructions for installation.
This appliance is to be properly installed and earthed only by
a suitably qualified person.
This appliance should be connected to a circuit which

5
incorporates an isolating switch providing full disconnection
from the power supply.
Failure to install the appliance correctly could invalidate any
warranty or liability claims.
1.3 Operation and maintenance
1.3.1 Electrical Shock Hazard
Do not cook on a broken or cracked cooktop. If the cooktop
surface should break or crack,switch the appliance off
immediately at the mains power supply (wall switch) and
contact a qualified technician.
Switch the cooktop off at the wall before cleaning or
maintenance.
Failure to follow this advice may result in electrical shock or
death.
1.3.2 Health Hazard
This appliance complies with electromagnetic safety
standards.
However, persons with cardiac pacemakers or other
electrical implants (such as insulin pumps) must consult with
their doctor or implant manufacturer before using this
appliance to make sure that their implants will not be
affected by the electromagnetic field.
Failure to follow this advice may result in death.
1.3.3 Hot Surface Hazard
During use, accessible parts of this appliance will become
hot enough to cause burns.
Do not let your body, clothing or any item other than
suitable cookware contact the Induction glass until the
surface is cool.
Metallic objects such as knives, forks, spoons and lids should
not be placed on the hob surface since they can get hot
Keep children away.
Handles of saucepans may be hot to touch. Checksaucepan
handles do not overhang other cooking zones that are on.
Keep handles out of reach of children.
Failure to follow this advice could result in burns and scalds.

6
1.3.4 Cut Hazard
The razor-sharp blade of a cooktop scraper is exposed when
the safety cover is retracted.Use with extreme care and
always store safely and out of reach of children.
Failure to use caution could result in injury or cuts.
1.3.5Important safety instructions
Never leave the appliance unattended when in use. Boilover
causes smoking and greasy spillovers that may ignite.
Never use your appliance as a work or storage surface.
Never leave any objects or utensils on the appliance.
Do not place or leave any magnetisable objects (e.g. credit
cards, memory cards)or electronic devices (e.g. computers,
MP3 players) near the appliance, as they may be affected by
its electromagnetic field.
Never use your appliance for warming or heating the room.
After use, always turn off the cooking zones and the cooktop
as described in this manual (i.e. by using the touch controls).
Do not rely on the pan detection feature to turn off the
cooking zones when you remove the pans.
Do not allow children to play with the appliance or sit, stand,
or climb on it.
Do not store items of interest to children in cabinets above
the appliance. Children climbing on the cooktop could be
seriously injured.
Do not leave children alone or unattended in the area where
the appliance is in use.
Children or persons with a disability which limits their ability
to use the appliance should have a responsible and
competent person to instruct them in its use. The instructor
should be satisfied that they can use the appliance without
danger to themselves or their surroundings.
Do not repair or replace any part of the appliance unless
specifically recommended in the manual. All other servicing
should be done by a qualified technician.
Do not use a steam cleaner to clean your cooktop.
Do not place or drop heavy objects on your cooktop.
Do not stand on your cooktop.
Do not use pans with jagged edges or drag pans across the

7
Induction glass surface as this can scratch the glass.
Do not use scourers or any other harsh abrasive cleaning
agents to clean your cooktop, as these can scratch the
Induction glass.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
This appliance is intended to be used in household and
similar applications such as: -staff kitchen areas in shops,
offices and other working environments; -farm houses; -by
clients in hotels, motels and other residential type
environments; -bed and breakfast type environments.
WARNING: The appliance and its accessible parts become
hot during use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless
continuously supervised.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical,sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire.NEVER try to extinguish
a fire with water, but switch off the appliance
and then cover flame e.g. with a lid or a fire blanket.
WARNING: Danger of fire: do not store items on the cooking
surfaces.
Warning: If the surface is cracked, switch off the appliance
to avoidthe possibility of electric shock, for hob surfaces of
glass-ceramic or similar material which protect live parts
A steam cleaner is not to be used.
The appliance is not intended to be operated by means of an
external timer or separate remote-control system.

8
Congratulations on the purchase of your new Induction Hob.
We recommend that you spend some time to read this Instruction / Installation Manual inorder to fully
understand how to install correctly and operate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction / InstallationManual for
future reference.
2. Product Induction
2.1 Top View
2.2Control Panel
2.3Working Theory
Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works
byelectromagnetic vibrations generating heat directly in the pan, rather than indirectly throughheating
the glass surface. The glass becomes hot only because the pan eventually warms it up.
iron pot
magnetic circuit
ceramic glass plate
induction coil
induced currents
1.Max. 1200/1500 W zone
2.Max. 2300/2600 W zone
3.Max. 1500/1800 W zone
4. Max. 1500/1800 W zone
5.Max. 3000/3600 W zone
6. Glass plate
7. Control panel
1. Heating zone selection controls
2. Special function
3. Timer control
4.Power / Timer slider touch control
5.Boost control
6. Keylock control
7.ON/OFF control

9
2.4Before using your New Induction Hob
Read this guide, taking special note of the ‘Safety Warnings’ section.
Remove any protective film that may still be on your Induction hob.
2.5Technical Specification
Cooking Hob
i-Smart 603F
Cooking Zones
4 Zones
Supply Voltage
220-240V~
Installed Electric Power
7100W
Product Size L×W×H(mm)
590X520X60
Building-in Dimensions A×B (mm)
560X490
Weight and Dimensions are approximate. Because we continually strive to improve our products we may
change specifications and designs without prior notice.
3. Operation of Product
3.1Touch Controls
The controls respond to touch, so you don’t need to apply any pressure.
Use the ball of your finger, not its tip.
You will hear a beep each time a touch is registered.
Make sure the controls are always clean, dry, and that there is no object (e.g. a utensil or a
cloth)covering them. Even a thin film of water may make the controls difficult to operate.
3.2Choosing the right Cookware
•Only use cookware with a base suitable for induction cooking.
Look for the induction symbol on the packaging or on the bottom
ofthe pan.
•You can check whether your cookware is suitable by carrying outa magnet test.
Move a magnet towards the base of the pan. If it isattracted, the pan is suitable
for induction.
•If you do not have a magnet:
1. Put some water in the pan you want to check.

10
2. If does not flash in the display and the water is heating, the pan is suitable.
•Cookware made from the following materials is not suitable: pure stainless steel, aluminium orcopper
without a magnetic base, glass, wood, porcelain, ceramic, and earthenware.
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the
cooking zone. Use pans whose diameter is as large as the graphic of the zone selected.Using a pot a
slightly wider energy will be used at its maximum efficiency.If you usesmaller pot efficiency could be less
than expected.Pot less than 140 mm could beundetected by the hob.Always centre your pan on the
cooking zone.
Always lift pans off the Induction hob –do not slide, or they may scratch the glass.
3.3 How to use
3.3.1 Start cooking
Touch the ON/OFFcontrol for three seconds.After power on,
the buzzer beeps once, all displaysshow“–” or “––”, indicating
that the induction hobhas enteredthe state of standby mode.

11
Place a suitable pan on the cooking zone thatyou wish to use.
•Make sure the bottom of the pan and the surface ofthe
cooking zone are clean and dry.
Touching the heating zone selection control,and an indicator
next to the key will flash
Select a heat setting by touching the slider control
•If you don’t choose a heat setting within 1 minute,the
Induction hob will automatically switch off. You will need to
start again atstep 1.
•You can modify the heat setting at any time duringcooking.
If the display flashesalternately with the heat setting
This means that:
•you have not placed a pan on the correct cooking zone or,
•the pan you’re using is not suitable for induction cooking or,
•the pan is too small or not properly centered on the cooking zone.
No heating takes place unless there is a suitable pan on the cooking zone.
The display will automatically turn off after 2 minutes if no suitable pan is placed on it.
3.3.2 Finish cooking
Touching the heating zone selection control that you wish
to switch off.
Turn the cooking zone off by touching the slider
to“○”.Make sure the displayshows”0”
Turn the whole cooktop off by touchingthe ON/OFFcontrol.
Beware of hot surfaces

12
H will show which cooking zone is hot totouch. It will
disappearwhen the surface has cooled down to a safe
temperature. It can also beused as an energy saving
function if you want to heatfurther pans, usethe
hotplate that is still hot.
3.3.3 Using the Boost function
Activate the boost function
Touching the heating zone selection control.
Touching the boost control , the zone indicator show
“b”and the power reach Max.
Cancel the Boost function
Touching the heating zone selection control that you wish
to cancel the boost function.
Touching the "Boost" control to cancel the
Boostfunction, then the cooking zone will revert to its
original setting.
The function can work in any cooking zone
The cooking zone returns to its original setting after 5 minutes.
If the original heat setting equals 0, it will return to 9 after 5 minutes.
If the original heat setting equals F, it will return to 7 after 5 minutes.
The 1st heating zone can only reach the max power of 7 when the 2nd heating zone is Boost.
The 2nd heating zone can only reach the max power of 8 when the 1st heating zone is Boost.
3.3.4 Flexible Area
• This area can be used as a single zone or as two different zones, accordinglyto the cooking needs
anytime.
• Free area is made of two independent inductors that can be controlled separately.
As big zone

13
To activate the free area as a single big zone, simply
pressthededicated key.
Adjust heat setting by touching the slider control.
As a big zone, we suggest the used as the follow:
Cookware: 250mm or 280mm diameter cookware (Square or Ovalcookware are acceptable)
We don’t recommend other operations except for above mentioned threeoperations because it might
effect the heating of appliance
As two independent zones
To use the flexible area as two different zones, you can have two choices ofheating:
a) Put a pan on the right up side or the right down side of the flexible zone .
(b)Put two pans on both sides of the flexible zone.
Notice: Make sure the pan is bigger than 12cm.

14
3.3.5Special function
The are two kinds of special functions: Fry function and Keep warm function.
a) Fry function
•You can use the function to fry food.
• The function can only work in cooking zone 2# .
Touching the heating zone selection control that you wish to
use the Fry function
Touch the“Fry function”control. Theindicator will show “ F “,
then the cooking zone starts fry function.
b) Keep warm function
•You can use the function to keep the food warm.
• The function can work in any cooking zone.
Touching the heating zone selection control that you wish to use
the warm function
Touching the "Warm function” control,the indicator shows "",
then the cooking zone starts warm function.
3.3.6 Locking the Controls
You can lock the controls to prevent unintended use (for example children accidentally turning the
cooking zones on).
When the controls are locked, all the controls except the ON/OFF control are disabled.
To lock the controls
Fry Function Keep Warm Function

15
Touch the lockcontrol
The timer indicator will show “ Lo ”
To unlock the controls
Touch and hold the lock control for a while.
When the hob is in the lock mode, all the controls are disableexcept the ON/OFF , you canalways turn the
induction hob off with the ON/OFFcontrol in an emergency, but you shall unlock the hob first in the next
operation.
3.3.7Timercontrol
You can use the timer in two different ways:
You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the
set time is up.
You can set it to turn one or more cooking zones off after the set time is up.
The timer of maximum is 99min.
a) Using the Timer as a Minute Minder
If you are notselecting any cooking zone
Make sure the cooktop is turned on.
Note: you can use the minute minder evenif you’re not
selecting any cooking zone.
Touch timer control, the“10”will show in the timer displayand
the “0”flashes.
Set the time by touching the slider control. (e.g. 5)
Touch timer control again, the“1”will flash
Set the time by touching the slider control (e.g.9), now the
timer you set is 95 minutes.
When the time is set, it will begin to count downimmediately.The display will show the remainingtime
Buzzer will beep for 30 seconds and the timer
indicator shows“- -”when the setting timefinished.
b) Setting the timer to turn one or more cooking zones off
Set one zone

16
Touching the heating zone selection control that you wantto set
the timer for.
Touch timer control, the“10”will show in the timer displayand the
“0”flashes.
Set the time by touching the slider control. (e.g. 5)
Touch timer control again, the“1”will flash.
Set the time by touching the slider control (e.g.9), now the timer
you set is 95 minutes.
When the time is set, it will begin to count downimmediately. The
display will show the remainingtime.
NOTE: The red dot next to power level indicator will illuminate
indicating that zone is selected.
When cooking timer expires, the corresponding cookingzone will
be switched off automatically.
Other cooking zone will keep operating if they are turned on previously.
set more zones:
The steps for setting more zones are similar to the steps of setting one zone;
When you set the time for several cooking zonessimultaneously, decimal dots of the relevant cooking
zones are on.The minute display shows the min. timer. The dot of the corresponding zone flashes.
The shown as below:
(set to 15 minutes)
、、、
(set to 45 minutes)

17
Once the countdown timer expires, thecorresponding
zonewill switch off. Then it will showthe new min. timer
andthe dot of corresponding zone will flash.
The shown as right:
Touch the heating zone selection control, the corresponding timer will be shown in the timer indicator.
c) Cancel the timer
Touching the heating zone selection control that you
wantto cancel the timer
Touching the timer control, the indicator flash
Touch the slider control to set the timer to ”00”, the timer is cancelled
3.3.8Default working times
Auto shut down is a safety protection function for your induction hob. It shut down automatically if
everyou forget to turn off your cooking. The default working times for various power levels are shown in
thebelow table:
Power level
1
2
3
4
5
6
7
8
9
Default working timer (hour)
8
8
8
4
4
4
2
2
2
When the pot is removed, the induction hob can stop heating immediately and the hob automatically
switch off after2 minutes.
People with a heart pace maker should consult with their doctor before using this unit.
4. Cooking Guidelines
Take care when frying as the oil and fat heat up very quickly, particularly if you’re using
PowerBoost.At extremely high temperatures oil and fat will ignite spontaneously and this
presents a seriousfire risk.
4.1 Cooking Tips
When food comes to the boil, reduce the temperature setting.
Using a lid will reduce cooking times and save energy by retaining the heat.
Minimize the amount of liquid or fat to reduce cooking times.
Start cooking on a high setting and reduce the setting when the food has heated through.
4.1.1 Simmering, cooking rice
Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising occasionally

18
tothe surface of the cooking liquid. It is the key to delicious soups and tender stews because the
flavoursdevelop without overcooking the food. You should also cook egg-based and flourthickened
saucesbelow boiling point.
Some tasks, including cooking rice by the absorption method, may require a setting higher than
thelowest setting to ensure the food is cooked properly in the time recommended.
4.1.2 Searing steak
To cook juicy flavorsome steaks:
1. Stand the meat at room temperature for about 20 minutes before cooking.
2. Heat up a heavy-based frying pan.
3. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and then lower
themeat onto the hot pan.
4. Turn the steak only once during cooking. The exact cooking time will depend on the thickness of
thesteak and how cooked you want it. Times may vary from about 2 –8 minutes per side. Press the
steakto gauge how cooked it is –the firmer it feels the more ‘well done’ it will be.
5. Leave the steak to rest on a warm plate for a few minutes to allow it to relax and become tenderbefore
serving.
4.1.3For stir-frying
1. Choose an induction compatible flat-based wok or a large frying pan.
2. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large
quantities,cook the food in several smaller batches.
3. Preheat the pan briefly and add two tablespoons of oil.
4. Cook any meat first, put it aside and keep warm.
5. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower setting,return
the meat to the pan and add your sauce.
6. Stir the ingredients gently to make sure they are heated through.
7. Serve immediately.
4.2 Detection of Small Articles
When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other small item (e.g. knife,
fork,key) has been left on the hob, the hob automatically go on to standby in 1 minute. The fan will
keepcooking down the induction hob for a further 1 minute.
5. Heat Settings
The settings below are guidelines only. The exact setting will depend on several factors, including
yourcookware and the amount you are cooking. Experiment with the induction hob to find the settings
thatbest suit you.
Heat setting
Suitability
1 - 2
•delicate warming for small amounts of food
•melting chocolate, butter, and foods that burn quickly
•gentle simmering
•slow warming
3 - 4
•reheating
•rapid simmering

19
•cooking rice
5 - 6
•pancakes
7 - 8
•sautéing
•cooking pasta
9/P
•stir-frying
•searing
•bringing soup to the boil
•boiling water
6. Care and Cleaning
What?
How?
Important!
Everyday soiling on
glass (fingerprints,
marks, stains left by
food or non-sugary
spillovers on the glass)
1. Switch the power to the cooktop
off.
2. Apply a cooktop cleaner while
the glass is still warm (but not
hot!)
3. Rinse and wipe dry with a clean
cloth or paper towel.
4. Switch the power to the cooktop
back on.
•When the power to the cooktop is
switched off, there will be no ‘hot
surface’ indication but thecooking zone
may still be hot! Take extreme care.
•Heavy-duty scourers, some nylon
scourers and harsh/abrasive cleaning
agents may scratch theglass. Always
read the label to check if your cleaner or
scourer is suitable.
•Never leave cleaning residue on the
cooktop: the glass may become stained.
Boilovers, melts, and
hot sugary spills on
the glass
Remove these immediately with
afish slice, palette knife or razor
bladescraper suitable for Induction
glasscooktops, but beware of hot
cookingzone surfaces:
1. Switch the power to the
cooktopoff at the wall.
2. Hold the blade or utensil at a
30°angle and scrape the soiling
orspill to a cool area of the
cooktop.
3. Clean the soiling or spill up with
adish cloth or paper towel.
4. Follow steps 2 to 4 for
‘Everydaysoiling on glass’ above.
•Remove stains left by melts and
sugary food or spillovers as soon
as possible. If left to cool on the
glass, they may be difficult to
remove or even permanently
damage the glass surface.
•Cut hazard: when the safety cover
is retracted, the blade in a scraper
is razor-sharp. Use with extreme
care and always store safely and
out of reach of children.
Spillovers on the
touch controls
1. Switch the power to the
cooktopoff.
2. Soak up the spill
3. Wipe the touch control area
witha clean damp sponge or
cloth.
4. Wipe the area completely dry
with a paper towel.
5. Switch the power to the
cooktopback on.
•The cooktop may beep and turn
itself off, and the touch controls
may not function while there is
liquid on them. Make sure youwipe the
touch control area drybefore turning the
cooktop backon.

20
7.Hints and Tips
Problem
Possible causes
What to do
The induction hob
cannot beturned on.
No power.
Make sure the induction hob is
connected to the power supply
and that it is switched on.
Check whether there is a power
outage in your home or area. If
you’ve checkedeverything and the
problempersists, call a qualified
technician.
The touch controls are
unresponsive.
The controls are locked.
Unlock the controls. See section
‘Using your induction cooktop’for
instructions.
The touch controls are
difficult to operate.
There may be a slight film of
water over the controls or you
may be using the tip of your
finger when touching the
controls.
Make sure the touch controlarea is dry
and use the ball ofyour finger when
touching thecontrols.
The glass is being
scratched.
Rough-edged cookware.
Unsuitable, abrasive scourer or
cleaning products being used.
Use cookware with flat andsmooth
bases. See ‘Choosingthe right
cookware’.
See ‘Care and cleaning’.
Some pans make
crackling orclicking
noises.
This may be caused by the
construction of your cookware
(layers of different metals
vibrating differently).
This is normal for cookware and
does not indicate a fault.
The induction hob
makes a lowhumming
noise when used on
a high heat setting.
This is caused by the technology
of induction cooking.
This is normal, but the noiseshould
quieten down ordisappear completely
whenyou decrease the heat setting.
Fan noise coming from
theinduction hob.
A cooling fan built into your
induction hob has come on to
prevent the electronics from
overheating. It may continue to
run even after you’ve turned the
induction hob off.
This is normal and needs noaction. Do
not switch the powerto the induction hob
off atthe wall while the fan isrunning.
Pans do not become
hotand appears in the
display.
The induction hob cannot
detect the pan because it is not
suitable for induction cooking.
The induction hob cannotdetect the
pan because it is toosmall for the
cooking zone ornot properly
centred on it.
Use cookware suitable forinduction
cooking. See section‘Choosing the right
cookware’.
Centre the pan and make surethat its
base matches the size ofthe cooking
zone.
