Axis C8210 User manual

AXISC8210NetworkAudioAmplier
UserManual

AXISC8210NetworkAudioAmplifier
Solutionoverview
Solutionoverview
Towatchthisvideo,gotothewebversionofthisdocument.
www.axis.com/products/online-manual/47555
Anoverviewofhownetworkaudioworks.
2

AXISC8210NetworkAudioAmplifier
Findthedevieonthenetwork
Findthedevieonthenetwork
TondAxisdevicesonthenetworkandassignthemIPaddressesinWindows®,useAXISIPtilityorAXISDeviceManager.Both
applicationsarefreeandcanbedownloadedfromaxis.com/support.
FormoreinformationabouthowtondandassignIPaddresses,seethedocumentHowtoassignanIPaddressandaccessour
deviceonthedevicepageataxis.com.
Browsersupport
Youcanusethedevicewiththefollowingbrowsers:
ChromeTMFirefox®Edge®Safari®
Windows®recommendedxx
OSX®recommendedx
Otheroperatingsystemsxx
Ifyouneedmoreinformationaboutrecommendedbrowsers,gotoaxis.com/browser-support.
3

AXISC8210NetworkAudioAmplifier
Aessthedevie
Aessthedevie
1.OpenabrowserandentertheIPaddressorhostnameoftheAxisdevice.
IfyouhaveaMaccomputer(OSX),gotoSafari,clickBonjourandselectthedevicefromthedrop-downlist.Toadd
Bonjourasabrowserbookmark,gotoSafari>Preferences.
2.Entertheusernameandpassword.Ifyouaccessthedeviceforthersttime,youmustsettherootpassword.SeeSeta
newpasswordfortherootaccountonpage4.
Setanewpasswordfortherootaccount
Important
Thedefaultadministratorusernameisroot.Ifthepasswordforrootislost,resetthedevicetofactorydefaultsettings.
1.Typeapassword.Followtheinstructionsaboutsecurepasswords.SeeSecurepasswordsonpage4.
2.Retypethepasswordtoconrmthespelling.
3.ClickSave.Thepasswordhasnowbeencongured.
Securepasswords
Important
Axisdevicessendtheinitiallysetpasswordincleartextoverthenetwork.Toprotectyourdeviceaftertherstlogin,set
upasecureandencryptedHTTPSconnectionandthenchangethepassword.
Thedevicepasswordistheprimaryprotectionforyourdataandservices.Axisdevicesdonotimposeapasswordpolicyasthey
maybeusedinvarioustypesofinstallations.
Toprotectyourdatawestronglyrecommendthatyou:
•seapasswordwithatleast8characters,preferablycreatedbyapasswordgenerator.
•Don’texposethepassword.
•Changethepasswordatarecurringinterval,atleastonceayear.

AXISC8210NetworkAudioAmplifier
Additionalsettings
Additionalsettings
Changetherootpassword
1.Logintotheproduct’swebpageandgotoSystem>Users.
2.Fortherootuser,clickEdit.
3.Enteranewpasswordandsave.
Setupanewzone
1.Logintotheaudiodevicethatyouwanttosetastheleaderintheaudiosystem.
2.GotoAudio>Systemsettings.
3.Edittheleaderaudiodevice:
3.1Clickthepencil.
3.2Enteraudiodevicenameandenterusernameandpassword.
3.3ClickApply
Note
DonotselectEnablebroadcastofanalogaudioinputifAXISAudioPlayerisrunning.sethisapplicationtocontrolthe
analogaudioinput.
4.Ifpossible,changetoMulticast.
5.Addaudiodevicestotheaudiosystem:
5.1nderAvailableaudiodevices,clicktheplussigntoaddanaudiodevicetothezone.Ifyourdeviceisnot
listed,clickAdddevicemanuallytoaddthedevice.
5.2Foreachaudiodevice,settheaudiodevicenameandenterusernameandpasswordforthatdevice.
5.3ClickApply.
Setvolumeandgain
Volume
1.GotoAudio>Systemoverview.
2.sethesliderSystemunderVolumetosetthesystemvolume.
AxisAudioPlayer
1.GotoServicesandappsandopenAxisAudioPlayer.
2.Setthevolumelevelforsystem,announcementsandmusic.
Note
Themaximalvolumeforannouncementsandmusiccanneverbehigherthanthemaximalvolumeforthesystem.
Gain
5

AXISC8210NetworkAudioAmplifier
Additionalsettings
1.GotoAudio>Devicesettings.
2.Ontheutput,settheutputgain.
3.OntheInputtab,settheInputgain.
4.GotoAudio>Systemoverview.
5.setheslidersbesideafollowertoadjustthegainforanaudiodevice.
Prepareanaudiocliplink
Audioclipscanbesettoplaywhenaneventoccurs.
Toprepareanaudiocliplink:
1.GotoAudio>Audioclips.
2.Clickforanaudioclip.
3.Setthevolumeandnumberoftimestorepeattheclip.
4.Clickthecopyicontocopythelink.
SetupdirectSIP(P2P)
VoIP(VoiceoverIP)isagroupoftechnologiesthatenablesvoiceandmultimediacommunicationoverIPnetworks.Formore,
seeVoiceoverIP(VoIP)onpage13.
InthisproductVoIPisenabledthroughtheSIPprotocol.FormoreinformationaboutSIP,seeSessionInitiationProtocol(SIP)on
page13
TherearetwotypesofsetupsforSIP.Peer-to-peerisoneofthem.sepeer-to-peerwhenthecommunicationisbetweenafewuser
agentswithinthesameIPnetworkandthereisnoneedforextrafeaturesthataPBX-servercouldprovide.Forinformationon
howtosetitup,seePeer-to-peerSIP(P2PSIP)onpage13.
1.GotoVoIP>SIPsettingsandselectEnableSIP.
2.InCalltimeout,setthenumberofsecondsthatacallwilllastbeforeitendsifthereisnoanswer.
3.Toallowthedevicetoreceiveincomingcalls,selectAllowincomingcalls.
4.Setthenumberofsecondsbeforetimeoutforincomingcalls.
5.ClickSave.
6.InPortsettings,entertheSIPportnumberandSIPTLSportnumber.
Note
•SIPport–forSIPsessions.Signallingtrafcthroughthisportisnon-encrypted.Thedefaultportnumberis5060.
•SIPTLSport–forSIPSandTLSsecuredSIPsessions.SignallingtrafcthroughthisportisencryptedwithTransportLayer
Security(TLS).Thedefaultportnumberis5061.
•RTPstartport–EntertheportusedfortherstRTPmediastreaminaSIPcall.Thedefaultstartportformediatransportis
4000.SomerewallsmightblockRTPtrafconcertainportnumbers.Aportnumbermustbebetween1024and65535.
7.ClickSave.
8.InNATtraversal,selecttheprotocolsyouwanttoenableforNATtraversal.
6

AXISC8210NetworkAudioAmplifier
Additionalsettings
Note
seNATtraversalwhenthedeviceisconnectedtothenetworkfrombehindaNATrouterorarewall.Formoreinformation
seeNATtraversalonpage14.
SetupSIPthroughaserver(PBX)
VoIP(VoiceoverIP)isagroupoftechnologiesthatenablesvoiceandmultimediacommunicationoverIPnetworks.Formore,
seeVoiceoverIP(VoIP)onpage13.
InthisproductVoIPisenabledthroughtheSIPprotocol.FormoreinformationaboutSIP,seeSessionInitiationProtocol(SIP)on
page13
TherearetwotypesofsetupsforSIP.APBX-serverisoneofthem.seaPBX-serverwhenthecommunicationshouldbebetweenan
innitenumberofuseragentswithinandoutsidetheIPnetwork.Additionalfeaturescouldbeaddedtothesetupdependingonthe
PBX-provider.Formoreinformationsee,PrivateBranchExchange(PBX)onpage13.
1.RequestthefollowinginformationfromyourPBXprovider:
-serID
-Domain
-Password
-AuthenticationID
-CallerID
-Registrar
-RTPstartport
2.GotoVoIP>SIPaccounts>Createaccount.
3.EnteraNamefortheaccount.
4.SelectRegistrar.
5.Selectatransportmode.
6.AddtheaccountinformationfromthePBXprovider.
7.ClickSave.
8.SetuptheSIPsettingsthesamewayasforpeer-to-peer.SeeSetupdirectSIP(P2P)onpage6formoreinformation.
StopaudiowithDTMF
Thisexampleexplainshowto:
•CongureDTMFonadevice.
•SetupaneventtostoptheaudiowhenaDTMFcommandissenttothedevice.
Note
SIPmustbeactivatedbeforeyoucanusethisactionrule.
Note
FormoreinformationabouteventsseeSetuprulesandalertsonpage14.
1.GotoVoIP>DTMF.
7

AXISC8210NetworkAudioAmplifier
Additionalsettings
2.Selectpeer-to-peerorregistraraccount.
3.ClickthepencilnexttotheSIPaccount.
4.ClickAdd.
5.IntheNameeld,enter"stopaudio".
6.IntheSequenceeld,enter"1".
7.ClickApplyandthenK.
8.GotoEvents>Management>ActionrulesandclickAdd.
9.IntheNameeld,enter"DTMFstopaudio".
10.Fromthelistoftriggers,selectCall,DTMFand“stop”.
11.Fromthelistofactions,selectStopaudioclipandthenclickK.
AXISAudioPlayer
seAXISAudioPlayertoadd,manageandschedulemusicplaylists,streamsandprerecordedannouncements.Tond
AXISAudioPlayer,gotothedevicewebpageandclickverview.
Addmusicandannouncementstothelibrary
1.GotoMUSIC.
2.Drag-and-droplesorbrowselestoaddmusictothelibrary.
Note
AllaudiolesarestoredontheSDcard.
Createaplaylist
1.ClickontheplussignnexttoPlayliststoaddanewplaylist.
2.EnteranameandclickSave.
Youcannowdraganddropmusiclesandannouncementsfromthelibrarytoyourplaylist.
NO NO
NOTICE TICE TICE
Whendeletingalefromtheplaylistitwillstillbeinthelibrary,butifyoudeletealeinthelibraryitwillbedeleted
bothinthelibraryandtheplaylist.
Addstreams
1.Ifyouhaveaproxy,clickthesettingsiconinthetoprightcornerandenteryourproxyaddress.Supportedstream
formatsareMP3,M3orPLS(playlistformat).
2.SelectMUSIC.
3.ClickontheplussignnexttoStreams.
4.WritethenameofthestreamandtheRLtoyourstream.
5.ClickSave.
Createaschedule
1.GototheScheduletab.
8

AXISC8210NetworkAudioAmplifier
Additionalsettings
2.Clickanddragtocreateaboxoverthetimeslotyouwanttoplayaplaylistorstream.Thetimeanddatesettings
onthelocaldeviceareusedforallscheduledactivities.
3.InNewEvent:
-Choosetoplayeitherdirectlyfromthelibraryortoplayaplaylistorstream.
-Clickonthetimeforstartorendifyouwanttochangethetime.
4.ClickSave.
Scheduleannouncements
1.GototheScheduletab.
2.Click>.
3.Choosewhichannouncementtoplayandthetimetoplayit.
4.Theannouncementwillbemarkedintheschedulewith.
Testtheimpedance
Testtheimpedancebeforeyouusetheamplierforthersttimeorwhenyouhavechangedthespeakersetup,connectedtothe
amplier.TheSPKLEDwillashgreenwhenanimpedancetestisrequired.Performtheimpedancetestbypressingthecontrol
buttonuntilyouheartonesfromthespeaker.
9

AXISC8210NetworkAudioAmplifier
Integration
Integration
Playaudiowhenacameradetectsmotion
ThisexampleexplainshowtosetuptheaudiodevicetoplayanaudioclipwhenanAxisnetworkcameradetectsmotion.
Prerequisites
•TheAxisaudiodeviceandAxisnetworkcameraarelocatedonthesamenetwork.
•Themotiondetectionapplicationisconguredandrunninginthecamera.
Prepareanaudiocliplink:
1.GotoAudio>Audioclips.
2.Clickthelinkiconforanaudioclip.
3.Setthevolumeandnumberoftimestorepeattheclip.
4.Clickthecopyicontocopythelink.
Example
Thelinkwillhavethisformat:
http://[audiodeviceIP]/axis-cgi/playclip.cgi?location=camera_clicks.mp3&repeat=2&v-
olume=45
Createanactionrule:
1.Inthewebpageofthecamera,gotoSettings>System>Events.
2.GotoRecipientsandaddarecipient.
3.Typeanamefortherecipient,forexample“Speaker”.
4.SelectHTTPfromtheTypedrop-downlist.
5.PastetheconguredlinkfromtheaudiodeviceintheHosteld.
6.Entertheusernameandpasswordoftheaudiodevice.
7.ClickSave.
8.GotoRulesandaddarule.
9.Typeanamefortheactionrule,forexample"Playclip".
10.FromtheConditionlist,selectavideomotiondetectionalternativeunderApplications.
Note
Iftherearenooptionsforvideomotiondetection,thengotoApps,clickAXISVideoMotionDetectionandturnon
motiondetection.
11.FromtheActionlist,selectSendnoticationthroughHTTP.
12.nderRecipient,selectyourrecipient.
13.ClickSave.
10
