Axis AX-1300 User manual

REV |MODEL: AX-1300
PLEASE READ DIRECTIONS COMPLETELY BEFORE USE.
AXIS SHAVERS INSTRUCTION MANUAL

AXIS/Bodyline Products International, Inc.
198 N. Brandon Drive
Glendale Heights, Illinois 60139 USA
Made in China
Congratulations!
You are now the proud owner
of an Axis battery-powered
Shaver AX-1300.
Before using your shaver, please
read the instructions in this
manual carefully for its proper use
and care. Please keep the manual
handy for ready reference.
play hard, be smooth.

Axis Rev |4| English
Axis Rev |5| English
IMPORTANT
SAFETY INSTRUCTIONS
When using an electrical appliance, basic precau-
tions should always be followed, including the
following:
Read all instructions before using your shaver.
WARNING
> Always provide close adult supervision when using
your shaver near children or the disabled.
> Follow all instructions in this manual carefully. Do
not use attachments with your shaver that have
not been specifically recommended by us.
> Do not use a unit that is not operating normally,
has been immersed in water or other liquid.
> Never operate your shaver outdoors. Avoid use in
the vicinity of aerosol products or where oxygen is
being administered.Also, keep the cord away from
heated surfaces.
> Do not insert foreign objects into any of the open-
ings in the unit.

Axis Rev |6| English
Axis Rev |7| English
headguard
inner cutter
oscillator
on/off switch
battery
compartment
body case
outer foil
frame base
release button
outer foil
frame base
outer foil frame
outer foil
outer foil
frame base
release button
PARTS OF YOUR SHAVER
> Avoid exposing the unit to direct sunlight or ambi-
ent temperatures above 140°F (60°C).
> To avoid injury to the face, do not use the unit if
the cutters or head assembly have been damaged.
> For home use only.
SAVE THESE INSTRUCTIONS

Axis Rev |8| English
Axis Rev |9| English
SHAVING TIPS
1. Keep the unit clean and dry at all times.
2. Wash and dry your skin thoroughly prior to shaving.
3. In order to achieve the closest shave and avoid
unnecessary wear on the foils, be sure that both
foils contact the skin simultaneously. Do not hold
the shaver at an angle where only one foil contacts
the skin - this will cause distortion of the foil and
may result in skin irritation.
4. Stretch your skin with your free hand while using
short, circular strokes. This will make the hairs
stand out from your face and allow the cutting
heads to reach them more easily. Shave against
the grain for optimum results.
5. To facilitate cutting and avoid foil wear, do not
apply the shaver to your skin with high pressure.
6. The normal replacement period for the foil
screens is about 6 months. In order to maintain
shaving performance and comfort, replace the
cutters at least once a year. To order replacement
parts, please refer to the “Ordering Replacement
Parts” section of this manual.

Axis Rev |10| English
Axis Rev |11| English
TO INSERT THE BATTERIES
1. Slide the On/Off Switch down to the “Off” position.
2. Remove the Battery Compartment Cover by
pulling it straight down from the shaver body.
3. Insert 2 “AA” alkaline batteries. Be sure to orient
the batteries properly to the (+) and (-) indicators.
Caution: When your device requires
new batteries, please insert only
2 new AA alkaline batteries. You
must not combine one old or used
battery with one new battery as seri-
ous leakage will occur and thus damage the unit.
*If you use your shaver daily, the alkaline batteries
will provide approximately 50 minutes of shaving
operation time. If the operating power seems low,
replace the batteries.
USING YOUR SHAVER
1. Remove the protective plastic headguard.
2. Ensure that the foil screens and inner cutters
are not damaged. Replace damaged parts before
using. To obtain replacement parts, refer to the

Axis Rev |12| English
Axis Rev |13| English
the skin upward and stroke the shaver in an easy
up and down motion. To avoid damaging the
delicate foils, do not apply high pressure.
6. A special linear cutting head, located between
the foil screens, shaving the long curly hairs.
WASHING IN WATER
1. Switch the shaver off. Depress the
outer foil base release buttons on the
side of the unit and gently lift the foil
screen assembly off.
2. Switch the shaver on and allow
“Ordering Replacement Parts” section
of this manual.
3. Slide the on/off switch up to the “on”
position.
4. Gently stretch the skin of your face
with your free hand while moving the
shaver slowly and smoothly against the
grain of your beard. Hold the shaver at
a 90° angle to your face while main-
taining contact with the foils.
5. To shave the chin area, gently pull
$PSSFDU *ODPSSFDU

Axis Rev |14| English
Axis Rev |15| English
fresh cold or lukewarm water to run over the
cutters.
3. When finished cleaning, switch the shaver off
and replace the foil screen assembly, making sure
it locks into place.
* Clean the inner blade with the brush at least once
every three (3) washings.
ClEANING WITH THE BRUSH
1. Your razor should be cleaned with the brush
provided after ever three wet cleanings.
2. Switch the shaver off. Depress the outer foil
base release buttons on the
side of the unit and gently lift
the foil screen assembly off.
3. Gently brush the hairs from
the inner cutters, the inside
surface of the foil screen as-
sembly and the shaver’s case.
To remove the inner cutters for
cleaning, gently lift straight up
from its mount.
4. To clean the delicate outer
correct incorrect

Axis Rev |16| English
Axis Rev |17| English
foil screens, gently wipe the surface of the foils with
tissue paper, being sure not to apply a great deal
of pressure.
5. When finished cleaning, reseat the inner cutters
on the mounts and replace the outer foil assembly,
making sure it locks into place.
*To ensure proper operation, the outer foil base
assembly must be properly seated. To avoid dam-
aging the delicate foils, do not remove them from
their frame. (see figure 1
*To avoid damage, be sure to thoroughly wipe pre-
shave lotion or shaver oil from the shaver body.
STORING THE SHAVER
If the shaver is to remain unused for a long period
of time, remove the batteries and store the unit in a
cool, dry place.
IMPORTANT: For best shaving performance
and results, we recommend that you replace your
shaver’s foil screens every six months and inner
cutters at least once a year.

Axis Rev |18| English
Axis Rev |19| English
TO REPlACE FOIl SCREENS
Skin irritation or a deterioration of shave quality typ-
ically indicates that your foils need to be replaced.
Replacement intervals will vary with individual use
and hair types.
1. Remove the outer foil assembly by pressing the
release buttons on both
sides of the shaver and
gently lift it off.
2. Position the replace-
ment head assembly
over the cutters. Be careful not to damage the foils.
Gently slide the head assembly down until it seats
firmly into place.
TO REPlACE THE INNER CUTTERS
NOTE: Always replace foil screens when replac-
ing the inner cutters.
1. Remove the foil screen assembly by pressing
the release buttons on both sides of the shaver
and lifting the assembly off.
2. Grasp each of the two sets of inner cutters on

Axis Rev |20| English
Axis Rev |21| English
either side and lift upwards to remove.
3. Be sure to hold the replacement cutters firmly as
you carefully insert them into the mounting assembly,
pushing down firmly until they lock into place.
4. Replace the foil screen assembly and gently
slide it down until you hear it lock into place.
Ordering replacement parts
Please contact Axis / BPI at 1-877-263-9500
to order replacement parts for your Axis shaver.
Please refer to the following part number.frame,
outer foil frame and inner blade.
PART NUMbER: AR-2
DEScRIPTION: Replacement Outer Foil
Frame and Inner Cutters for Model AX-1300
> The above parts are available at the retailer from
whom your shaver was purchased.
If your shaver requires service
Call Axis at 1-877-263-9500. To assist us in
serving you, please have the model number and
date of purchase for your shaver available.
AXIS / Bodyline Products International, Inc.

Axis Rev |22| English
Axis Rev |23| English
1-YEAR lIMITED WARRANTY
AXIS / Bodyline Products International, Inc. (BPI)
warrants that your product, except as noted below, is
on the date of purchase free from defect in material
and workmanship for a period of one year. In the
event of a defect in material or workmanship, AXIS /
BPI will repair or replace this product with new parts,
free of charge as follows:
1. The warranty is extended only to the original
purchaser. A purchase receipt or other proof of date
of the original purchase is required for service and
parts replacement under this warranty.
2. Do not return the product to the retailer from
whom this product was purchased.
3. Contact AXIS / BPI toll-free at 1-877-263-9500
to obtain authorization during the warranty period to
return the defective product by mail, postage prepaid.
lIMITATIONS AND EXClUSIONS
There are no express warranties except as listed
above.
This warranty only covers failures due to defects in
materials or workmanship that occur during normal
use. It does not cover foils, blades, cutters, or at-

Axis Rev |24| English
Axis Rev |25| English
tachments or damage that occurs in shipment, or
failures that are caused by products not supplied
by AXIS / Bodyline Products International, Inc., or
failures that result from accident, misuse, abuse,
and neglect from mishandling, misapplication, im-
proper maintenance, improper cleaning, alteration,
modification, line power surge, or commercial use
of the product, such as hotel, office or rental use of
the product, or service by anyone other than AXIS
/ Bodyline Products International, Inc., or damage
that is attributable to acts of God.
AXIS / BODYLINE PRODUCTS INTERNATIONAL,
INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTAL DAMAGES RESULTING FROM
THE USE OF THIS PRODUCT OR ARISING OUT OF
ANY BREACH OF THIS WARRANTY.
ALL EXPRESS AND IMPLIED WARRANTIES,
INCLUDING THE WARRANTIES OF MERCHANDISE
AND FITNESSS FOR A PARTICULAR PURPOSE,
ARE LIMITED TO THE APPLICABLE WARRANTY
PERIOD SET FORTH ABOVE.
Some states do not allow the exclusion or limitation
of incidental or consequential damages, or limita-
tions on how long an implied warranty lasts, so the

Axis Rev |26| English
Félicitations!
Vous êtes maintenant l’heureux
propriétaire d’un rasoir Axis AX-
1300 à batterie/pile.
Avant d’utiliser votre rasoir, veuillez
lire attentivement les instructions de
ce manuel pour une bonne utilisa-
tion et un bon entretien du rasoir.
Veuillez garder le manuel à portée
de main pour toute référence.
above exclusions and limitations may not apply to
you. This warranty gives you specific legal rights
and you may also have other rights, which vary
from state to state.
AXIS/Bodyline Products International, Inc.
198 N. Brandon Drive, Glendale Heights, Illinois
60139 USA
Made in China

Axis Rev |28| Francais
Axis Rev |29| Francais
IMPORTANTES cONSIGNES DE
SÉcURITÉ
Toujours respecter les précautions suivantes
lorsque vous utilisez un appareil électrique. Prière
de lire soigneusement toutes les instructions avant
d’utiliser votre Axis.
AVERTISSEMENT
> Une supervision adulte est obligitoire lors de
l’utilisation d’un rasoir Axis en présence d’enfants
ou de personnes handicapées.
> Respecter toutes les instructions stipuleés dans
ce guide. Ne pas utiliser avec Axis des acces-
soires qui n’auraient pas été spécifiquement
recommandés par Axis / BPI.
> Ne pas utiliser le rasoir s’il fonctionne mal, s’il
a été immergé dans l’eau ou dans un autre
liquide. Appeler le 1-877-263-9500 pour toute
réparation requise.
> Ne jamais utiliser le rasoir Axis à l’extrérieur.
Éviter de l’utiliser près de produits en aérosol ou
dans un lieu où l’on administre de l’oxygène.
> Ne pas introduire d’objets étrangers dans les

Axis Rev |30| Francais
Axis Rev |31| Francais
ouvertures du rasoir.
> Ne pas exposer le rasoir à la lumière directe du
soleil ou à des températures ambiantes supéri-
eures à 60°C (140°F).
> Pour éviter les blessures, ne pas utiliser le rasoir
si le couteau ou la tête a été endommagé.
> Ce rasoir Axis est destiné et a été conçu à des
fins d’utilisation personnelle uniquement.
> For home use only.
CONSERVER CES INSTRUCTIONS.
grille extérieure
couteau intérieur
oscillateur
bouton de
marche/arrêt
compartiment
des piles
base du
porte-grille
bouton de
dégagement de
la porte-grille
base externe
d’armature
de clinquant
armature externe
de clinquant
grille extérieure
bouton de
dégagement de
la porte-grille
LES PIÈCES DE VOTRE RASOIR

Axis Rev |32| Francais
Axis Rev |33| Francais
RECOMMANDATIONS
1Toujours maintenir le rasoir sec et propre.
2. Laver et bien sécher la peau avant le rasage.
3. Pour obtenir un rasage de près et ne pas user
inutilement les grilles, s’assurer que les deux grilles
sont simultanément en contact avec la peau. Ne
pas tenir le rasoir de façon à ce qu’une seule
grille soit en contact avec la peau. Cela risque de
déformer la grille et d’irriter la peau.
4. Étirer la peau avec la main libre tout en passant
le rasoir en petits mouvements circulaires. Les poils
se dressent mieux sur le visage et pénètrent
mieux dans les têtes de coupe.
5. Pour faciliter le rasage et ne pas user les
grilles, ne pas exercer une forte pression sur le
rasoir.
6. Remplacer les grilles environ tous les six (6)
mois. Remplacer les conteaux au moins une fois
par an pour garantir une bonne performance de
rasage et un confort inégalé. Pour les pièces de
rechange, se reporter à la section de commande
des pièces de rechange dans ce guide.

Axis Rev |34| Francais
Axis Rev |35| Francais
INSTAllATION DE PIlES
1. Faites glisser le bouton de marche/arrêt en
position d’arrêt.
2. Retirez le couvercle du compartiment des piles
en le tirant verticalement vers le bas du boîtier.
3. Insérez 2 piles alcalines “AA.” Assurez-vous de
bien les installer selon les schémas
(+) et (-).
Si vous vous rasez tous les jours, les
piles alcalines vous procureront envi-
ron 50 minutes de temps de rasage.
Si la puissance de fonctionnement semble faible,
remplacez les piles.
MODE D’EMPlOI DU RASOIR AXIS
Pour optimiser le confort du rasage, utiliser de la
mousse à raser. Ne pas utiliser de gel à raser qui
risque d’obstruer les grilles. Toujours bien nettoyer
le rasoir après chaque usage
1. Enlevez le capot protecteur en plastique de la
tête.
2. Inspectez la grille extérieure et les couteaux in-

Axis Rev |36| Francais
Axis Rev |37| Francais
térieurs pour y détecter tout dommage. Remplacez
les pièces endommagées avant d’utiliser le rasoir.
Pour les pièces de rechange, reportez-vous à la
section de commande des pièces de rechange
dans ce guide.
3. Faites glisser le bouton de marche/arrêt vers le
bas, en position de marche.
4. Étirez document la peau de votre visage avec
la main libre tout en déplaçant lentement et
soigneusement le rasoir contre le grain de votre
barbe. Maintenez le rasoir à un angle de 90° par
rapport à la peau de votre visage tout
en veillant à ce que les grilles restent en
contact avec la peau.
5. Pour le menton, étirez la peau vers
le haut et passez le rasoir de haut en
bas. N’exercez pas de pression exces-
sive sur le rasoir pour ne pas endom-
mager les grilles gui sont délicates.
6. Un couteau de précision spécial à
entrainement linéaire, situé entre les
grilles, rase le longs poils frisés.

Axis Rev |38| Francais
Axis Rev |39| Francais
NETTOYAGE à l’EAU
1. Mettez le rasoir en position d’arrêt. Appuyez sur
le bouton de dégagement de la grille extérieure
sur le côté du rasoir et soulevez doucement
l’ensemble grille.
2. Mettez le rasoir en position de marche et passez
les couteaux sous de l’eau froide ou tiède.
3. Après avoir nettoyé le rasoir,
mettez-le en position d’arrêt et et
replacez l’ensemble grille en veillant à
ce qui’il s’enclenche bien fermement.
NETTOYAGE à l’AIDE
D’UNE BROSSE
1Nous vous recommandons
de nettoyer votre rasoir avec
la brosse fournie tous les trois
nettoyages à l’eau.
2. Mettez le rasoir en posi-
tion d’arrêt. Appuyez sur le
bouton de dégagement de
l’ensemble grille sur le côté du
rasoir et soulevez doucement
l’ensemble grille.
correct incorrect
$PSSFDU *ODPSSFDU
