Axminster SB-25AV User manual

Code 108659
Original Instructions
AT: 30/06/2022
BOOK VERSION: 01
SB-25AV
Floor Pillar Drill

Axminster Tool Centre Ltd
UK DECLARATION OF CONFORMITY
‘original’
Product model: SB-25AV
Name and address of the manufacturer: Axminster Tool Centre Ltd, Unit 10 Weycroft Avenue,
Axminster, Devon EX13 5PH, United Kingdom
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Object of the declaration: SB-25AV Floor Drill Machine
The object of the declaration described above is in conformity with the relevant GB legislation:
Supply of Machinery (Safety) Regulations 2008 as amended.
Electromagnetic Compatibility Regulations 2016 as amended.
References to the relevant harmonised standards used or references to the other technical
specifications in relation to which conformity is declared:
.
ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment
and risk reduction (ISO 12100:2010)
60204-1: 2006 +AC2010/ Safety of machinery - Electrical equipment of machines -
Part 1: General requirements. Industrial electrical device.
12717:2001+A1:2009 Safety of machine tools - Drilling machines
Additional information:
Name and address of person authorised to compile the technical file: Axminster Tool Centre
Ltd, Unit 10 Weycroft Avenue, Axminster, Devon EX13 5PH, United Kingdom
The machinery fulfils all relevant provisions of Supply of Machinery (Safety) Regulations 2008
as amended.
Signed for and behalf of: Axminster Tool Centre Ltd;
(place and date of issue): Axminster, Devon, United Kingdom, 29th June 2022
(name, function): Andrew Parkhouse, Supply Chain Director
Signature: ………………………………………………………………

Axminster Tool Centre Ltd
EC DECLARATION OF CONFORMITY
‘original’
Product model: SB-25AV
Name and address of the manufacturer: Axminster Tool Centre Ltd, Unit 10 Weycroft Avenue,
Axminster, Devon EX13 5PH, United Kingdom
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Object of the declaration: SB-25AV Floor Drill Machine
The object of the declaration described above is in conformity with the relevant GB legislation:
Supply of Machinery (Safety) Regulations 2008 as amended.
Electromagnetic Compatibility Regulations 2016 as amended.
References to the relevant harmonised standards used or references to the other technical
specifications in relation to which conformity is declared:
ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment
and risk reduction (ISO 12100:2010)
60204-1: 2006 +AC2010/ Safety of machinery - Electrical equipment of machines -
Part 1: General requirements. Industrial electrical device.
12717:2001+A1:2009 Safety of machine tools - Drilling machines
Additional information:
Name and address of person authorised to compile the technical file: Axminster Tool Centre
Ltd, Unit 10 Weycroft Avenue, Axminster, Devon EX13 5PH, United Kingdom
The machinery fulfils all relevant provisions of Supply of Machinery (Safety) Regulations 2008
as amended.
Signed for and behalf of: Axminster Tool Centre Ltd;
(place and date of issue): Axminster, Devon, United Kingdom Kingdom, 29th June 2022
(name, function): Andrew Parkhouse, Supply Chain Director
Signature: ………………………………………………………………

No Description
1Base
2Flange
3Spring washer (4x)
4Screw
5Column
6Rack
7Handle
8Screw
9Clamp Bolt
10 Table Bracket
11 Shaft
12 Gear
13 Worm
14 Lock Handle
15 Feed Handle (3x)
16 Knob
17 Spring Scale
18 Feed Head
19 Collar
20 Screw
21 Head
22 Belt Adjust Handle
23 Wing Bolt
24 Screw
25 Spring washer
26 Road
27 Spring washer
28 Motor Plate
29 Spring washer
30 Nut
31 Nut
32 Screw
33 Motor
34 Pin
35 Motor Pulley
36 Belt
37 C-ring
38 Bearing
39 Spacer
40 Bearing
41 Middle Pulley
42 Insert Pulley Nut
43 Spindle Pulley
44 Insert Pulley
45 Pin
46 C-ring
47 Bearing
48 Spacer
49 Screw
50 Spring
51 Middle Pulley Shall
52 Pulley cover
53 Screw
54 Washer
55 Screw
56 Switch
57 Spring Cap Base
58 Spring Cup
59 Nut
60 Table
61 Rubber Pad
62 Spindle Nut
63 Bearing
64 Quill
65 Wedge
66 Bearing Thrust
67 Bearing
68 Spindle
69 Arbor
70 Vise
71 Clamp Bolt
72 Adjust Sheet
73 Wing Bolt
74 Water Cooling Tank
75 Water Cooling Motor
SB-25-AV Parts List
