Axnes PNG MP30 User manual

Axnes AS
PNG MP30 Transceiver
with AXS-SW-0511
and
PNG CHG30 / CHG35 Charger
Operation Manual
Document number:
AX-PNG-UMAN-1270
Revision:
Issue B
Date:
2018-Jun-21

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page ii
Revision history
Revision
Date
Description
List of effective pages
Issue A
2018 Feb 26
First release of document
Issue B
2018 Jun 21
Updated connector
references
Added Saturated message
Added Lemo variant
Minor editorial changes
Added Microphone Echo
canceller description

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page iii
Table of contents
SECTION 1: GENERAL INFORMATION.............................................................................1-1
System................................................................................................................. 1-1
Radio ................................................................................................................... 1-2
Identification of article........................................................................................... 1-2
SECTION 2: OPERATION ..................................................................................................2-1
Groups................................................................................................................. 2-1
Configurations...................................................................................................... 2-2
2.2.1 Encryption..................................................................................................... 2-2
Noise cancelling................................................................................................... 2-2
Microphone detect................................................................................................ 2-2
General UI............................................................................................................ 2-4
Power on/off......................................................................................................... 2-5
Display indications ............................................................................................... 2-6
Adjusting volume.................................................................................................. 2-8
VOX / PTT mode.................................................................................................. 2-8
VOX sensitivity..................................................................................................... 2-8
2.10.1 Configuring the VOX Min and VOX Max level ............................................... 2-9
Local mode ........................................................................................................ 2-10
Charging ............................................................................................................ 2-10
Changing configuration/channel......................................................................... 2-10
Changing direct/intercom mode.......................................................................... 2-10
Key lock ............................................................................................................. 2-11
GPS positioning ................................................................................................. 2-11
Bluetooth............................................................................................................ 2-12
Menu.................................................................................................................. 2-13

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page iv
Audio feedback .................................................................................................. 2-17
Error conditions.................................................................................................. 2-19
Trouble shooting ................................................................................................ 2-20
SECTION 3: RECOMMENDED MAINTENANCE................................................................3-1
SECTION 4: TECHNICAL DATA.........................................................................................4-1
Technical data for MP30 ...................................................................................... 4-1
4.1.1 Operation...................................................................................................... 4-1
4.1.2 Power supply ................................................................................................ 4-1
4.1.3 Headset Interface.......................................................................................... 4-1
4.1.4 MP30 mounted connectors (model dependent)............................................. 4-2
4.1.5 Radio characteristics..................................................................................... 4-2
4.1.6 GPS.............................................................................................................. 4-2
4.1.7 Dimensions................................................................................................... 4-2
4.1.8 Material......................................................................................................... 4-2
Technical data for CHG35.................................................................................... 4-3
4.2.1 Operation...................................................................................................... 4-3
4.2.2 Power supply ................................................................................................ 4-3
4.2.3 CHG35 mounted Connectors........................................................................ 4-3
4.2.4 Dimensions................................................................................................... 4-3
4.2.5 Material......................................................................................................... 4-3
Technical data for CHG30.................................................................................... 4-4
4.3.1 Power supply ................................................................................................ 4-4
4.3.2 Dimensions................................................................................................... 4-4
4.3.3 EMC and Safety of power supply .................................................................. 4-4
4.3.4 Material......................................................................................................... 4-4
MP30 Amphenol 164-series Connector pinout..................................................... 4-5

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page v
MP30 US Nato U174 compatible pinout............................................................... 4-6
MP30 14 pin Lemo pinout..................................................................................... 4-7
SECTION 5: QUALIFICATIONS..........................................................................................5-1
SECTION 6: ABBREVIATIONS...........................................................................................6-1

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page vi
Intentionally left blank

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 1-1
Section 1: General information
Axnes AS has delivered the Polycon system to the rotary wing Search and Rescue segment
for decades. The system is widely adopted in this segment. The PNG system is based on the
functionality in the previous system, but enhances the functionality and performance based
on user feedback.
The PNG system incorporates the following main features:
•Wireless extension of aircraft intercom system with significant range and robustness.
•Full duplex operation.
•Uninterrupted communication.
•Support for keying of aircraft installed radios from the handheld.
•Support for multiple communication groups.
•Support for Bluetooth communication via mobile phone.
•Automatic microphone recognition on handhelds.
•Integrated Microphone for Patient/Casualty communication in the handheld.
•Active noise reduction on microphone inputs giving excellent audio quality and VOX
performance in high/extreme noise environments.
•Adaptive NIVOX (Axnes patented VOX), monitoring ambient noise environment and
minimising the effect of false triggers, and consequently noise flooding of intercom.
•GPS homing of handheld radios in the aircraft, on control panel and possible
integration with map systems.
•Support for mute and broadcast from aircraft side.
•Intercom operation in UHF band 397-470MHz.
•Flexible intercom interface, supporting high and low impedance systems.
•All components available in NVG friendly versions.
System
The PNG system enables wireless communication inside and outside the aircraft. The
system is very capable due to its robustness, range and noise reduction capabilities, as well
as interception free communication between the entire crew.
The PNG system consists of one PNG Base Station and one or more handheld rechargeable
radios (MP30), chargers for the handhelds, as well as an optional PNG Control Panel
connected to the Base Station. The PNG Base Station and Control Panel are installed in the
aircraft and supplied with power from the aircraft system.
The MP30 implements functionality to suppress surrounding noise, and to secure optimal
voice activation performance. It implements functionality to connect to the PNG Base Station
in the helicopter (intercom mode), or handheld to other radios (direct mode).
Through the internal microphone in the MP30, it is possible to communicate with the
survivor/ground rescue party without helmet removal.
Depending on the configuration and part number, the MP30 is equipped with a GPS receiver.
The position of the MP30 may be polled by the PNG Base Station, and presented on the

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 1-2
PNG Control Panel in the aircraft. In addition, the Base Station can be connected to a
moving map system and send handheld position data at regular intervals.
The PNG Base Station is typically connected to the aircraft ICS, and may support multiple
connection points for audio. The base station is capable of delivering a PTT signal to other
systems, as well as triggering transmission based on a received PTT signal or VOX
activation.
Radio
The PNG system operates a wireless link between the base station and the MP30 in the
UHF band. Exact frequency configuration is done at production, based on customer input to
available frequencies and bandwidth in the region they are to be operated in. The PNG
system will normally be configured within a 20 MHz band in the frequency range 397 to 470
MHz. The base station will support the full 397 to 470 MHz range (depending on the antenna
installation in the aircraft), while the MP30 supports 20 MHz bands through the 397 to 470
MHz band, depending on the installed antenna. Antennas are available through the band.
The wireless link is a single frequency, duplex, interception free, digital radio link.
The MP30 operates at an output power of up to 400mW using a licence specific frequency
allocation.
The PNG system will not set any limit to the number of simultaneous receivers, but the
number of simultaneous transmitters is limited by the available bandwidth and allocated
timeslots. The PNG system allows up to three simultaneous transmitting handhelds.
Identification of article
PNG Transceivers in the MP30 series with part numbers in the AXS-HH-D02XX* series.
PNG Table Chargers in the CHG30 series with part numbers in the AXS-CHG-010X* series
PNG Aircraft Chargers in the CHG35 series with part numbers in the AXS-CHG-015X* series
*Note: XX indicates any number of characters at the end of the part number string.

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-1
Section 2: Operation
The PNG system consists of one base station and one or more handheld radios (MP30). To
make all units in the PNG system interoperable, each unit must be configured with
compatible parameters. Configuration of the PNG system will imply setting of radio
frequencies, defining groups and setting scrambling and encryption parameters.
Multiple configurations may be stored on a device to support different operational modes.
The PNG system can be preconfigured from the vendor, or the configuration may be set by
the operator’s avionics department.
Ahead of flight all units in the PNG system will be set to compatible configurations. Different
types of operation may use different configurations, due to radio frequencies, group
definitions or other parameters. During operation and in flight, the configuration on the base
station is normally not changed, but may be required in some special conditions. Such
conditions may be caused by radio interference, where alternative frequency may be
required, and an alternative configuration is selected.
The operational scenario may also require different handheld configurations to be loaded in
different phases of the operation, e.g. to change group subscriptions during the mission.
Switching between the handheld configurations is done by the handheld operator by a simple
button push.
Groups
The MP30 supports organising the communication on the wireless link into groups. Groups
are a set of audio channels on the wireless link, and a set of physical audio interfaces on the
base station. The PNG system will support 2 groups depending on the available radio
resources (channel bandwidth).
The MP30 is configured to listen (receive) to one or more groups (allowing simultaneous
listening to multiple groups). Transmit is configured to one primary group through PTT/VOX,
but it is possible to configure transmit to a secondary group through configuration and use of
the secondary PTT on the MP30.
When the PNG system is set up, one or more configurations are defined, see section 2.2
Configurations.

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-2
Configurations
Both the MP30 and the PNG Base Station use configurations to control the behaviour of the
devices. They can hold a number of configurations, with different operation parameters. A
configuration contains a minimum of the following parameters:
•Logical name of the configuration
•Radio parameters (frequency, modulation, and channel bandwidth)
•Group subscriptions for receive
•Group subscriptions for transmit
•Configuration of remote PTT control (handheld activation of PTT from the base
station to the intercom)
The different pre-programmed configurations can be selected at start or during mission from
the PNG Control Panel. Typically, there will be several configurations when different radio
channels shall be made available. There can also be different configurations for different
mission types as e.g. SAR, EMS and MEDIVAC missions.
On the MP30, the configuration is selected with the up/down arrows, and identified with a
short two letter name and a long logical name (scrolling display).
Pre-programmed configurations can either be pre-ordered from the equipment vendor, or
changed by a qualified equipment operator with a PC based programming tool.
2.2.1 Encryption
With the PNG system all user data are encrypted according to the AES-256 encryption
standard before they are transmitted over the air. When delivered from factory, the PNG
handheld uses a default encryption key called “AXNES DEFAULT”. Changing this encryption
key requires the user to acquire an encryption key programming kit. Note that the PNG Base
Station and all handhelds in a system must use the same encryption key in order to connect
and communicate with each other.
Noise cancelling
The MP30 implements active noise cancelling of the microphone signal. Noise cancelling
ensures very high performance of the VOX operation, and speech intelligibility, even in
extremely noisy environments such as directly in front of a landing helicopter or similar. The
noise cancelled signal is transmitted on the radio, and used in the side tone. When using the
MP30 in windy environments, the microphone should always have a windsock mounted. It
should be noted that in quiet environments the noise cancelling can be noticed as a light
noise in the side tone during the quiet periods, and should be expected.
Microphone detect
The MP30 implements active microphone detection when a headset is connected. The MP30
will identify the microphone type and set parameters for gain, impedance and bias

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-3
accordingly. The active microphone detect can be disabled in the menu, and microphone
type can be manually set. It is recommended to use active microphone detect.
Note: Some active headsets have AC coupling of the microphone signal, which may affect
the microphone detection. With those headsets, manual microphone selection may be
required.

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-4
General UI
The MP30 is equipped with a small dot matrix display located at the top, angled to be
readable from front and top.
All buttons on the MP30 are located in a rectangle on the front:
•Primary PTT (PTT-1) at the top
•Volume up/ON at the upper right
•Volume down/OFF at the lower right
•Secondary PTT (PTT2) at the bottom
•Configuration up and down at the upper and lower left
•MENU and OK in the centre
The two configuration buttons are used for selecting the active configuration when in
intercom mode, or the active channel when in direct mode. There are also two buttons for
menu navigation (MENU and OK). These four buttons (MENU, OK, configuration up and
configuration down) are used to implement a four-way menu navigation.
The MP30 implements vocal audio feedback on some of the user operations. The vocal
feedback helps with the navigation and alerts the operator of unintended operation of buttons
and functions.
Two-character dot matrix display
GPS antenna
Headset connector
Secondary PTT (PTT-2)
Primary PTT (PTT-1)
Configuration up/down
OK
Volume Up/On
Volume Down/Off
Microphone
Menu

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-5
The display can show two letters at a time, and implements scrolling of text to display longer
strings. Most menu entries are therefore presented with a two-letter acronym, before the full
menu name is scrolled.
Power on/off
The MP30 is turned on by pressing the volume up/ON button. The MP30 will start up in the
last used configuration/mode. At power up, the configured name of the unit is displayed. If no
specific name is configured, the MP30 displays the last four digits of the serial number.
If the MP30 is turned on in intercom mode, it will immediately start searching for the base
station.
The MP30 is turned off by holding the volume down/OFF button for 3 seconds, until a double
dash is displayed to indicate shutdown.
SR search and rescue
Initial Scroll buffer

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-6
Display indications
Searching for intercom: When the MP30 is turned on and searching for intercom, the
display will indicate active searching with two alternating blinking dots in the display. The
alternate blinking dots will stop as soon as a connection to the base station and intercom has
been established. The vertical position of the two blinking dots indicates the battery status.
Connected to intercom and battery status: When connection to the intercom has been
established, the unit will display a standby mode. The standby mode is indicated by one
blinking dot in the display, indicating that the base station and intercom are connected. The
vertical position of the dot indicates battery status.
Charging: When the MP30 is placed in a charger, the charge status is indicated with a
battery symbol and a bar indicating the charge status. The battery is animated when
charging and steady when charging is prevented (due to temperature) or battery full.
Transmit: When the MP30 is transmitting, the transmit status is indicated with a blinking
arrow pointing upwards.
Battery low
Battery full
Battery low
Battery full
Battery low
Battery full

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-7
Receive: When the MP30 is receiving, a blinking arrow pointing downwards is displayed.
The position of the arrow indicates the signal strength in three levels: Good, fair and weak.
Direct mode indication: When the MP30 is in Direct mode (UHF FM mode), a ‘D’ will be
blinking in the display in standby mode
Local mode indication: When the MP30 is in person-to-person/Local mode, ‘L’ will be
blinking in the display in standby mode.
Bluetooth indication: When the MP30 is visible for other Bluetooth devices, ‘B’ will be
flashing in the display.
Good
Fair
Weak
Battery full
Battery low

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-8
Adjusting volume
Depending on the headset/helmet connected to the MP30, the volume may be individually
set to preferred volume by using the volume up/down buttons on the side of the MP30. When
the MP30 is power off-on cycled, it will start up with a default volume setting.
VOX / PTT mode
When a headset is connected to the MP30, it will by default be set to VOX mode. It will
remain in VOX mode until PTT mode is activated by pressing the primary PTT button.
Pressing the secondary PTT button will not take the MP30 to PTT mode, but activate
transmission to the secondary group as defined by the active configuration.
When the MP30 is in PTT mode, VOX mode can be re-enabled by pressing the
Configuration Down and the primary PTT simultaneously. A power off/on will reset to VOX as
well.
VOX sensitivity
Figure 2-1 VOX trigger level functionality
The MP30 has automatic VOX sensitivity. When starting the MP30, the VOX trigger level
starts at the VOX Min level (set in the menu). If the ambient noise level rises, the VOX trigger

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-9
level may adaptively increase. The VOX trigger level will not adapt to lower ambient noise,
and user intervention may be required. The maximum possible VOX trigger level is limited by
the VOX Max level (set in the menu).
If the VOX trigger level is experienced too high by the user, it can be reset by either leaving
VOX mode, entering the VOX Min menu or by disconnecting/connecting the headset (Note:
By disconnecting the headset cable from the MP30, the water resistance is broken, thus
should NOT be done in a humid environment).
All three actions will reset the VOX trigger level to the configured VOX Min level.
The VOX trigger level can be automatically adjusted to VOX Max level by entering the VOX
Max menu.
NOTE 1: The VOX trigger level can be increased by exposing the microphone to a steady
noise, e.g. by a careful steady blow into the microphone until the sidetone disappears. The
trigger level will increase as indicated to the user by monitoring the side tone.
NOTE 2: To avoid excessive use of battery and radio capacity, it is important that the VOX
level is set to an appropriate level to avoid inadvertent transmission.
2.10.1 Configuring the VOX Min and VOX Max level
To set the correct VOX Min level, the following procedure can be followed:
•Enter the VOX Min menu.
•Tune the VOX Min level so that the VOX is triggered when your normal operational
voice level triggers a sidetone.
To set the correct VOX Max level, the following procedure can be followed:
•Enter the VOX Max menu.
•Tune the VOX Max level so that the VOX is not triggering a sidetone until you are
shouting as loud as expected in the noisiest operational condition.
•After tuning the VOX Max level, enter the VOX Min level menu to reset the trigger.
Note 1: When tuning the VOX Min or Max level, the MP50 is transmitting according to
selected configuration or chosen channel. It is therefore recommended to avoid VHF channel
16 when doing VOX testing/configuring.
Note 2: If setting the VOX Max to a level too low, the VOX will be triggered too often in a
noisy environment. The active VOX sensitivity will be hitting the VOX Max level and thus
never be able to go high enough.
Note 3: If setting the VOX Max to a level too high, a spike in the ambient noise level will raise
the VOX trigger level too much and thus no shouting will be loud enough to trigger the VOX.

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-10
Local mode
The MP30 has an internal microphone which can be used for casualty communication, by
activating Local mode. Local mode is available when a headset is connected.
In Local mode, audio picked up from the surroundings is mixed with any radio received audio
and injected into the headset, and allows communication with individuals around the operator
without removal of the helmet. The microphone signal from the headset is muted, so the
communication between the MP30 operator and the surroundings is not transmitted.
Local mode is activated by pressing the Configuration Up and the primary PTT
simultaneously.
To leave Local mode and enter VOX mode, press the Configuration Up and the primary PTT
simultaneously.
Charging
The MP30 is charged when placed in a CHG30 or CHG35 charger. Detection of the charger
will be indicated with a battery symbol, and the charge status is indicated with a gradually
filling bar as charging progresses.
If the MP30 is turned off when installed in the charger, the MP30 will indicate charging status,
but remain in radio-off mode.
If the MP30 is turned on when installed in the charger, the MP30 will indicate charging status,
and remain in active radio mode.
Charging time is expected to be around 3 hours, but depending on the surrounding
temperature, charge time may increase or be disabled. Charging is disabled below 0°C and
above 50°C. If temperature is below 10°C or above 40°C, the charge current is reduced and
additional charging time must be expected.
Changing configuration/channel
In intercom mode, different pre-configured configurations may be selected by pressing the
configuration up or down buttons. The short name of the configuration is displayed before the
long name is scrolled.
When in direct mode, the different channels are navigated in the same manner.
Changing direct/intercom mode
The MP30 has two operational modes. It can be in either intercom mode where it is
connected to the aircraft installed PNG Base Station, or it can be in direct mode where it is

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-11
communicating over analogue FM radio without encryption over the UHF band. Switching
between intercom mode and direct mode is done by pressing both configuration buttons (up
and down) simultaneously. When changing mode, the last used UHF channel or last used
intercom configuration is activated.
Key lock
The configuration and menu keys are protected with key lock to avoid inadvertent change of
operational mode.
The keys are unlocked by pressing OK and MENU simultaneously.
Key lock is reactivated after 20 seconds of inactivity.
When key lock is active, the following status information is available by pressing:
Configuration up or down: Current selected configuration/channel
OK:
•Battery status indicated as B1 to B9
•Receive signal strength R1 to R9
•GPS lock status locked/searching/off.
Even if key lock is active, it is possible to change between direct mode and intercom mode
by pressing configuration up/down simultaneously.
GPS positioning
The MP30 includes an optional GPS module to allow position reporting to the PNG Base
Station. When the positioning is enabled in the MP30 menu, the GPS module operation is
controlled by the base station, and no local control is needed. The GPS status can be
checked by pushing the OK button while key lock is active, and will give one of the following
statuses:
•‘off’ - the GPS positioning is disabled in the MP30 configuration or from the MP30
menu.
•‘searching’ - the MP30 is searching for GPS signals. If the status continues in
‘searching’ for a long time, it is recommended to move to a position with assumed
better GPS satellite coverage.
•‘locked’ - the MP30 has got a GPS lock and is able to send position reports to the
PNG Base Station.
•‘sleep’ - the MP30 has had a GPS lock, but no base station is currently polling for
position reports. The GPS module goes to sleep mode, but will be reactivated when
the base station starts polling for position reports.

Axnes AS
Document number
Revision
Date
AX-PNG-UMAN-1270
Issue B
2018-Jun-21
Page 2-12
Bluetooth
The MP30 has an optional Bluetooth audio interface. The MP30 may connect to a mobile
phone allowing the MP30 user to communicate over the phone line from the MP30
connected headset.
Bluetooth pairing: The first time a mobile phone and the MP30 shall be paired (connected),
the MP30 must be made visible for other devices. This is done in the MP30 Bluetooth menu,
setting it “VISIBLE”. This will make MP30 visible for 2 minutes and the phone should be
connected during this time. During the time the MP30 is visible on Bluetooth a “B” will be
flashing in the display. If the phone has been connected previously, the connection can be
initiated from the phone without making the MP30 visible, as long as MP30 Bluetooth is set
to “ON”. Disconnecting the Bluetooth connection is also done from the phone menu.
When the phone is not in an active call, the MP30 audio is connected as normal to the base
station. When making an outgoing call from the phone or answering an incoming call on the
phone, the MP30 audio is automatically connected to the phone. The received audio in the
MP30 may be a mix of the phone audio and the audio coming from the base station with a
lower volume setting. The microphone audio will only be sent to the phone, and nothing of
this conversation will be transmitted to the base station. Note that in a Bluetooth call, the
microphone is “hot” and audio is transmitted always. There is no VOX/PTT mode while in a
Bluetooth call.
If pressing PTT1 during an active Bluetooth call, the microphone audio is opened up to the
base station and the received audio mixing is inverted with respect to gain. This means that
the microphone audio is transmitted to both the phone and the base station. The base station
audio will be heard at full volume and the phone audio will be attenuated if this is enabled in
the configuration. When releasing PTT1 again, the normal phone call audio paths are
restored.
As soon as the call is terminated using the phone menu or by the remote party
disconnecting the call, the audio reverts to normal intercom mode.
