Icom IC-A14 User manual

INSTRUCTION MANUAL
iA14
iA14S
VHF AIR BAND TRANSCEIVER
This device complies with Part 15 of the FCC Rules. Operation is subject to the
condition that this device does not cause harmful interference.
YIC-A14 YIC-A14S

i
PREFACE
Thank you for choosing this Icom product.
This product is designed and built with Icom’ s state of the art
technology and craftsmanship. With proper care, this prod-
uct should provide you with years of trouble-free operation.
IMPORTANT
READ ALL INSTRUCTIONS carefully and completely
before using the transceiver.
SAVE THIS INSTRUCTION MANUAL—This in-
struction manual contains important operating instructions for
the IC-A14/IC-A14S vhf air band transceiver.
EXPLICIT DEFINITIONS
WORD DEFINITION
RDANGER! Personal death, serious injury or an explosion may
occur.
RWARNING! Personal injury, fire hazard or electric shock may
occur.
CAUTION Equipment damage may occur.
NOTE If disregarded, inconvenience only. No risk of per-
sonal injury, fire or electric shock.
SUPPLIED ACCESSORIES
The following accessories are supplied with the transceiver.
Flexible antenna
Hand strap
Belt clip
Battery pack*1
Battery charger*2Power adapter*2
*1Battery case is supplied with some versions.
*2Not supplied with the battery case supplied versions.

R DANGER! NEVER short the terminals of the battery
pack. Also, current may flow into nearby metal objects, such
as keys, and so on. Therefore, be careful when carrying with,
or placing near metal objects, carrying in bags, and so on.
R DANGER! Use and charge only specified Icom battery
packs with Icom transceivers or Icom chargers. Only Icom
battery packs are tested and approved for use with Icom
transceivers or charged with Icom chargers. Using third-party
or counterfeit battery packs or chargers may cause smoke,
fire, or cause the battery to burst.
RWARNING! NEVER hold the transceiver so that the
antenna is very close to, or touching exposed parts of the
body, especially the face or eyes, while transmitting.
RWARNING! NEVER operate the transceiver with a
headset or other audio accessories at high volume levels.
Hearing experts advise against continuous high volume
operation. If you experience a ringing in your ears, reduce
the volume level or discontinue use.
RWARNING! NEVER operate the transceiver
near unshielded electrical blasting caps or in an explosive
atmosphere.
CAUTION: DO NOT use harsh solvents such as
Benzine or alcohol to clean the transceiver, because they
can damage the transceiver’s surfaces.
DO NOT place the transceiver in direct sunlight or in areas
with temperatures below –10°C (+14°F) or above +60°C
(+140°F).
KEEP the transceiver in a secure place to prevent use by
unauthorized persons.
KEEP the transceiver away from the heavy rain, and
NEVER immerse it in the water. The transceiver
construction is water resistant, not waterproof.
CLEAN and wipe dry the battery terminals after using the
transceiver in wet conditions. The terminals may rust if not
dried before using.
ii
PRECAUTIONS
Icom is not responsible for the destruction or damage to the
Icom transceiver, if the malfunction is because of:
• Force majeure, including, but not limited to, fires,
earthquakes, storms, floods, lightning, other natural disasters,
disturbances, riots, war, or radioactive contamination.
• The use of Icom transceivers with any equipment that is not
manufactured or approved by Icom.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incor-
porated (Japan) in Japan, the United States, the United Kingdom, Germany,
France, Spain, Russia, Australia, New Zealand, and/or other countries.

iiii
FCC INFORMATION
•FOR CLASS A UNINTENTIONAL RADIATORS:
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.
CAUTION: Changes or modifications to this transceiver,
not expressly approved by Icom Inc., could void your author-
ity to operate this transceiver under FCC regulations.

iv
PREFACE ……………………………………………………………… i
IMPORTANT…………………………………………………………… i
EXPLICIT DEFINITIONS …………………………………………… i
SUPPLIED ACCESSORIES ………………………………………… i
PRECAUTIONS ……………………………………………………… ii
FCC INFORMATION ………………………………………………… iii
1. PANEL DESCRIPTION ……………………………………… 1–5
■Panel description ������������������ 1
■Function display������������������� 5
2. ACCESSORY ATTACHMENT ……………………………… 6–7
3. BASIC OPERATION………………………………………… 8–11
■Setting a frequency ����������������� 8
■Setting the squelch level ��������������� 9
■Lock function �������������������� 9
■Receiving ���������������������10
■Transmitting ��������������������10
■Side tone function ������������������11
■LCD backlight��������������������11
■Low battery indicator�����������������11
4. MEMORY OPERATION …………………………………… 12–17
■Memory channel selection ��������������12
■Memory bank selection (Available with the IC-A14 only) �12
■Entering a memory channel��������������13
■Memory names �������������������15
■Copying memory contents ��������������16
■
Clearing the memory contents (Available with the IC-A14 only)
�������������������������� 17
5. SCAN OPERATION ………………………………………… 18–20
■Scan types ���������������������18
■COM band scan�������������������18
■Memory scan ��������������������19
■Weather channel scan (Available with the IC-A14 only) ��19
■“TAG” channel setting ����������������20
6. OTHER FUNCTIONS ……………………………………… 21–26
■Home function �������������������21
■Accessing the 121.5 MHz emergency frequency (Selectable
on only the IC-A14) �����������������21
■Key touch beep tone �����������������22
■ANL function ��������������������22
■Weather channel operation (Available with the IC-A14 only)
��������������������������23
■Duplex operation (Available with the IC-A14 only) ����24
■Set mode setting ������������������25
7. BATTERY PACKS AND CASE …………………………… 27–33
■Battery charging�������������������27
■Charging the battery �����������������29
■Battery case (optional for some versions) ��������31
8. CLONING …………………………………………………… 34–35
9. TROUBLESHOOTING ……………………………………………36
10. SPECIFICATIONS…………………………………………………37
11. OPTIONS …………………………………………………………38
12. OPTIONAL HEADSET CONNECTION …………………………39
13. SAFETY TRAINING INFORMATION……………………… 40–41
TABLE OF CONTENTS

■Panel description
qANTENNA CONNECTOR [ANT] (p. 6)
Connects to the supplied antenna.
wKEY LOCK SWITCH [ ](p. 9)
➥Push to turn ON the key lock function.
➥Hold down for 2 seconds to turn OFF the key lock func-
tion.
eLIGHT SWITCH [LIGHT]
Push to toggle the LCD backlight ON or OFF. (p. 11)
For the IC-A14S only
In the memory mode, hold down for 2 seconds to turn the
“TAG” setting ON or OFF. (p. 20)
rPTT SWITCH [PTT]
Hold down to transmit, release to receive.
tSQUELCH UP/DOWN KEYS [SQLY]/ [SQLZ](p. 9)
Push either key to select the squelch level.
• 10 squelch levels, 1–10, and squelch open, 0, are selectable.
yUP/DOWN KEYS [Y]/[Z]
➥Push to change or select the operating frequency,
memory channel, Set mode setting, and so on. (p. 8)
➥While scanning, push to change the scanning direction.
(pp. 18, 19)
For the IC-A14S only
Hold down for 1 second to start scanning. (pp. 18, 19)
1
1PANEL DESCRIPTION
q
w
r
e!0
Function
display (p. 5)
o
i
u
Microphone
Speaker
!1
t
y

2
uKEYPAD (Available with only the IC-A14) (pp. 3, 4)
iMEMORY MODE/MEMORY WRITE KEY [MR]/[MW]
Push to select the memory mode. (p. 12)
For the IC-A14
➥Push [FUNC], then push this key to enter the select
memory write mode. (p. 13)
➥In the memory mode, push [FUNC] then push this key
to copy the memory content to the frequency mode.
(p. 16)
For the IC-A14S
➥Hold down for 1 second to enter the select memory
write mode. (p. 14)
➥In the memory mode, hold down for 1 second to copy
the memory content to the frequency mode. (p. 16)
oCLEAR/HOME SWITCH [CLR]/[HOME]
➥Push to select the frequency mode. (p. 8)
➥Hold down for 2 seconds to reset the transceiver to the
user-default state without changing the memory con-
tents (Home function). (p. 21)
!0 EXTERNAL SPEAKER AND MICROPHONE JACKS
[MIC/SP] (p. 39)
If desired, connects the optional speaker microphone or a
headset using the optional OPC-499 HEADSET ADAPTER.
NEVER connect an optional speaker-microphone,
headset adapter, while the transceiver power is ON.
!1 VOLUME CONTROL KNOB [VOL]
Rotate to turn the transceiver power ON or OFF and ad-
just the audio level.
1
PANEL DESCRIPTION
Jack cover
NOTE: Attach the jack
cover when optional
equipment is not used.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

3
1PANEL DESCRIPTION
DKEYPAD (Available with IC-A14 only)
➥ Inputs digit “1” for frequency entry or memory
channel selection. (pp. 8, 12)
➥ Inputs “1,” “Q,” or “Z” when entering memory
names.
(p. 15)
➥ After pushing [FUNC], turns the ANL (Automatic
Noise Limiter) function ON or OFF. (p. 22)
➥
Inputs digit “2” for frequency entry or memory
channel selection. (pp. 8, 12)
➥ Inputs “2,” “A,” “B,” or “C” when entering memory
names.
(p. 15)
➥ After pushing [FUNC], the scan starts. (pp. 18,
19)
➥
Inputs digit “3” for frequency entry or memory
channel selection. (pp. 8, 12)
➥ Inputs “3,” “D,” “E,” or “F” when entering memory
names. (p. 15)
➥ After pushing [FUNC], selects memory bank
mode, in the memory mode. (p. 12)
➥
Inputs digit “4” for frequency entry or memory
channel selection. (pp. 8, 12)
➥ Inputs “4,” “G,” “H,” or “I” when entering memory
names.
(p. 15)
➥After pushing [FUNC], turns the weather alert
function ON or OFF. (p. 23)
➥
Inputs digit “5” for frequency entry or memory
channel selection. (pp. 8, 12)
➥ Inputs “5,” “J,” “K,” or “L” when entering memory
names.
(p. 15)
➥After pushing [FUNC], enters duplex transmit fre-
quency entry mode during NAVI band operation.
(p. 24)
➥
Inputs digit “6” for frequency entry or memory
channel selection. (pp. 8, 12)
➥ Inputs “6,” “M,” “N,” or “O” when entering memory
names.
(p. 15)
➥After pushing [FUNC], selects duplex operation
during NAVI band operation. (p. 24)
➥
Inputs digit “7” for frequency entry or memory
channel selection. (pp. 8, 12)
➥ Inputs “7,” “P,” “R,” or “S” when entering memory
names.
(p. 15)
➥After pushing [FUNC], selects weather channel
mode. (p. 23)
➥
Inputs digit “8” for frequency entry or memory
channel selection. (pp. 8, 12)
➥ Inputs “8,” “T,” “U,” or “V” when entering memory
names.
(p. 15)
➥ After pushing [FUNC], key touch beep output ON
or OFF. (p. 22)

4
1
PANEL DESCRIPTION
➥ Inputs digit “9” for frequency entry or memory
channel selection. (pp. 8, 12)
➥ Inputs “9,” “W,” “X,” or “Y” when entering memory
names.
(p. 15)
➥After pushing [FUNC], toggles scan tag setting
ON or OFF. (p. 20)
➥
Inputs digit “0” for frequency entry or memory
channel selection. (pp. 8, 12)
➥ Inputs “0,” “space” or “–” when entering memory
names. (p. 15)
➥After pushing [FUNC], selects the emergency fre-
quency, 121.500 MHz. (p. 21)
➥ Sets the numeral
entry for frequency or memory
channel numbers. Enters consecutive zero into
the remaining digits.
(pp. 8, 12)
➥After pushing [FUNC], hold down for 1 second to
entering into set mode.
(p. 25)
➥ Push to activate the function, then push another
key to access its secondary function. When the
function is activated, the “F” icon appears.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

5
1PANEL DESCRIPTION
■Function display
qFUNCTION ICON
Appears when [FUNC] is pushed.
wMEMORY ICON (p. 12)
Appears when memory channel mode is selected.
eTAG ICON (p. 20)
Appears when the selected memory channel is set as a
TAG channel.
rRX ICON (p. 10)
Appears while receiving a signal, or when the squelch is
open.
tTX ICON (p. 10)
Appears while transmitting.
yDUPLEX ICON (IC-A14 only) (p. 24)
➥Appears when the duplex function is activated.
➥Blinks while setting the duplex frequency.
uANL ICON (p. 22)
Appears when the ANL (Automatic Noise Limiter) func-
tion is in use.
iWEATHER ALERT ICON (IC-A14 only) (p. 23)
Appears when the weather alert function is in use.
oLOCK ICON (p. 9)
Appears when the lock function is in use.
!0 LOW BATTERY ICON (p. 11)
➥Appears when the battery is nearing exhaustion. The
attached battery pack requires recharging when this
icon appears.
➥Blinks when battery recharging/replacing is immedi-
ately needed.
!1 FREQUENCY READOUT
Displays the operating frequency, memory channel num-
ber, memory name or the Set mode item, and so on, de-
pending on the selected mode.
qwer tyuio
!1
!0

6
2
ACCESSORY ATTACHMENT
DAntenna
Insert the supplied antenna into the
antenna connector and screw down
the antenna, as shown to the right.
CAUTION!
• NEVER carry the transceiver by
holding only the antenna.
• DO NOT transmit without an
antenna. Otherwise the transceiv-
er may be damaged.
DBelt clip
Conveniently attaches to your belt.
- To attach the belt clip
qRemove the battery pack if it is attached.
wSlide the belt clip in the direction of the arrow until the belt
clip is locked and makes a ‘click’ sound.
- To detach the belt clip
qRemove the battery pack if it is attached.
wPinch the clip (q), and slide the belt clip in the direction of
the arrow (w).
q
w
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

7
DBattery pack attachment
To attach the battery pack:
Slide the battery pack in the direction of the arrow (q), then
lock it with the battery release button.
• Slide the battery pack until the battery release button makes a
‘click’ sound.
To detach the battery pack:
Slide the battery release button in the direction of the arrow
(w) as shown in the illustration to the right. The battery pack
can then be detached.
NEVER release or attach the battery pack when the trans-
ceiver is wet or soiled. This may result water or dust get-
ting into the transceiver/battery pack and may result in the
transceiver being damaged.
2ACCESSORY ATTACHMENT
q
w
Battery release button
Turn OFF the transceiver power by rotating [VOL] before at-
taching or detaching the battery pack.
For your information
If the transceiver power cannot be turned ON after replacing
the fully charged battery pack, first detach the battery pack.
Wait for approximately 10 seconds, then attach the battery
pack and turn ON the power again.

8
3
BASIC OPERATION
■Setting a frequency
DUsing the [Y]/[Z] keys
qRotate [VOL] to turn ON power, then push [CLR] to select
the frequency mode if a memory CH number or WX CH
number appears on the function display.
wPush [Y]/[Z]to set the desired frequency.
- For the IC-A14 only -
• The 1 MHz tuning step is selectable. Push [FUNC], then
push [Y]/[Z]. Push [FUNC] again to return to normal
tuning.
DUsing keypad (IC-A14 only)
qRotate [VOL] to turn ON power, then push [CLR] to select
the frequency mode if a memory CH number or WX CH
number appears on the function display.
wPush 5 appropriate digit keys to input the frequency.
• Push [1] as the 1st digit.
• When a wrong digit is input, push [CLR] to clear, then repeat
step wagain.
• Push [ENT] to enter consecutive zero digits.
• Only [2], [5], [7] or [0] can be entered as the 5th and final digit.
[EXAMPLE]
• 111.225 MHz: Push [1], [1], [1], [2], [2]
• 117.250 MHz: Push [1], [1], [7], [2], [5]
• 120.000 MHz: Push [1], [2], [ENT]
• 125.300 MHz: Push [1], [2], [5], [3], [ENT]
2
3
[VOL]
[FUNC]
[Z]
[ENT]
[CLR]
[Y]
Keypad
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

■Setting the squelch level
The transceiver has a noise squelch circuit to mute undesired
noise when no signal is received.
qPush [SQLY]or [SQLZ]to select the squelch level.
• ‘SQL--0’ is open squelch and ‘SQL--10’ is tight squelch.
• The “ ” icon appears while the squelch is open.
w Wait for 1 second to return to the previous display.
■Lock function
The lock function prevents accidental frequency changes or
accidental function activation.
qPush []to turn ON the lock function.
• The “ ” icon appears.
wTo turn OFF the function, hold down [ ] for 2 seconds.
• The “ ” icon disappears.
9
3BASIC OPERATION
[SQLY]
“SQL-- 0” (Squelch open)
[SQLZ]
[]
Appears while the key lock
function is activated.

10
3
BASIC OPERATION
3
■Receiving
q Rotate [VOL] to turn ON the power.
wPush [SQLZ]several times to open the squelch.
• Select the squelch level 0.
e Rotate [VOL] to adjust the audio level.
r Push [SQLY]several times until the noise is muted.
• The “ ” icon disappears.
t Set the desired frequency using [Y]/[Z]keys or the key-
pad keys.
y When a signal is received on the set frequency:
• The “ ” icon appears.
• Squelch opens and audio is emitted from the speaker.
When the squelch setting is too “tight” (large number setting),
squelch may not open for weak signals. To receive weaker
signals, loosen (small number setting) the squelch.
■Transmitting
q Set the desired frequency in COM band pushing [Y]/[Z]
or the keypad keys (IC-A14 only).
• COM band frequency range: 118.00–136.975 MHz
w Hold down [PTT] to transmit.
• The “ ” icon appears.
e Speak into the microphone at a normal voice level.
• DO NOT hold the transceiver too close to your mouth or speak
too loudly. This may distort the signal.
r Release [PTT] to receive.
NOTE: About Time-Out-Timer function
To prevent prolonged transmission, according to regula-
tory requirements, the IC-A14/S has a Time-Out Timer
function. This timer cuts OFF transmission after the set
time period of continuous transmission.
The Time-Out Timer is set in the Set mode. See page 26
for details.
CAUTION: Transmitting without an antenna may damage
the transceiver.
NOTE: To prevent interference, listen on the frequency
before transmitting. If the frequency is busy, wait until it is
clear.
[PTT]
Microphone
Appears while transmitting
Appears when a signal is received.
1
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

11
3BASIC OPERATION
■Side tone function
When using a headset (user supplied),the transceiver outputs
your transmitted voice to the headset for monitoring. Connect
an optional headset to use this function (The OPC-499 headset
adapter and headset are required). (p. 39)
DSetting the side tone level
qPush [PTT] to turn ON the transmit mode.
wWhile transmitting, push [Y]/[Z]to adjust the level.
• ‘ST--0’ is OFF and ‘ST--10’ is the maximum level.
WARNING! NEVER operate the transceiver with a head-
set at high volume or monitor levels for a long periods
time. If a ringing in your ears occurs, reduce the volume or
monitor level, or discontinue use.
■LCD backlight
The IC-A14/S has an LCD backlight for convenience during
night time operation.
➥Push [LIGHT] to turn the LCD
backlight ON or OFF.
IMPORTANT!
Turn OFF the LCD back-
light when no backlight is
necessary.
■Low battery icon
The low battery icon appears or blinks when the battery
power has decreased to a specified level. The attached bat-
tery pack or battery case requires recharging or the battery
case cells need replacing.
If the batteries are not charging or replaced, even when the
low battery indicator blinks, a long beep sounds and then the
transceiver will automatically turn OFF.
[PTT]
[Z]/[Y]
Side tone level is indicated
IMPORTANT!
Select ‘ST--0’ when a speaker
microphone is connected, oth-
erwise your voice will be heard
from the speaker during trans-
mit.
[LIGHT]
Appears when the battery
is nearly exhausted.
Blinks when the battery
recharging or replacing is
immediately necessary.

12
4
MEMORY OPERATION
■Memory channel selection
The IC-A14 has 200 memory channels (20 channels in 10
banks, default setting) and the IC-A14S has 100 memory chan-
nels for storing often-used frequencies.
q Push [MR] to enter the memory mode.
• The memory mode icon appears and a memory channel num-
ber is briefly displayed .
• The memory bank number is also displayed on the IC-A14.
Using [Y]/[Z]:
w Push [Y]/[Z]to select the desired memory CH number.
• The memory channel number is briefly displayed, then the
entered frequency (or memory name, if entered) is displayed.
• If no memory channel is entered, no memory channel can be
selected.
Using the Keypad— IC-A14 only:
w Push 2 appropriate digit key (00 to 99, depending on the
bank setting) to select the desired memory channel num-
ber, then push [ENT].
• The memory channel number is briefly displayed, then the
entered frequency (or memory name, if entered) is displayed.
• If no memory channel is entered in the selected BANK, no
memory channel can be selected.
■Memory bank selection
(Available with the IC-A14 only)
A total of 200 memory channels in the IC-A14, are divided
into bank (up to 10 banks are selectable, depending on the
setting) for simple memory grouping.
q Push [MR] to select the memory mode.
w Push [FUNC], and push [BANK](3) to enter the bank se-
lection mode.
ePush [Y]/[Z]or an
appropriate digit key
([0] to [9]) to select
a memory BANK
number, then push
[ENT].
rPush [Y]/[Z], or
2 appropriate digit
keys and then [ENT]
to select a memory
channel.
Appears when the
memory mode is selected.
Appears when the bank
selection mode is selected.
Keypad
[FUNC]
[Z]
[ENT]
[B
ANK](3)
[MR]
[Y]
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

■Entering a memory channel
Enter often-used frequencies using the following instructions.
DFor the IC-A14
q Push [CLR] to select the frequency mode, if necessary.
w Set the desired frequency. (p. 8)
• Push [FUNC], then push [WX](7) to select a weather channel
mode, and then select the desired weather channel using [Y]/
[Z]or keypad if desired. (p. 23)
ePush [FUNC], then push [MW](MR) to enter the select
memory write mode.
• The memory mode icon blinks.
rPush [Y]/[Z]to select a memory channel number.
• Push [FUNC], then push [BANK](3) to enter the bank selection
mode, and push [Y]/[Z]or an appropriate digit keys ([0]–[9]),
then push [ENT] to select the BANK number, if desired.
tPush [ENT] to program the entry and return to the fre-
quency mode.
13
4MEMORY OPERATION
• EXAMPLE: Entering WX-05 into memory channel 9 in
memory BANK 3.
Blinks when the select
memory write mode is
selected.
No frequency is displayed when a blank channel is
selected.
Push
Push then
Push then
Push then
Push or ,
or, push
Push or ,
or, push
Push then
*Briefly appears.
Push to complete the entry.
*Briefly appears.

14
4
MEMORY OPERATION
DFor the IC-A14S
q Push [CLR] to select the frequency mode, if necessary.
w Set the desired frequency. (p. 8)
eHold down [MR] for 1 second to enter the select memory
write mode.
• The memory mode icon blinks.
rPush [Y]/[Z]to select the desired memory channel num-
ber.
tHold down [MR] for 1 second to set the entry and return
to the frequency mode.
Blinks when the select
memory write mode is
selected.
No frequency is displayed when a blank channel is
selected.
• EXAMPLE: Entering 123.450 MHz into memory
channel 51.
Push or
Push or
*Briefly appears.
Hold down
for 1 second.
Push
Hold down
for 1 second.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

15
4MEMORY OPERATION
■Memory names
The memory channel can display an 8 character name in-
stead of the entered frequency.
DEntering memory names
q Set the desired frequency in the frequency mode. (p. 8)
wEnter the select memory write mode.
• For the IC-A14, push [FUNC] then push [MW](MR).
• For the IC-A14S, hold down [MR] for 1 second.
e Select the desired memory channel to be entered by
pushing [Y]/[Z](or on only the IC-A14, push the keys on the
keypad then [ENT]).
rPush [MR] momentarily to enter the memory name entry
mode.
• “-- -- -- -- -- -- -- --” appears and 1st digits blink.
• Available characters
For the IC-A14
t Push the appropriate digit key several times to select the
desired character, as shown to the left.
• To move the cursor forwards or backwards, use [Y]/[Z].
• The cursor automatically moves forward when a different key is
pushed.
• To erase a character, overwrite with a space (displayed as
“_”).
y Push [ENT] to enter the name and frequency at the same
time.
• Return to the frequency display.
• If no name is entered, the entered frequency is displayed.
• To clear the entered memory names, push [CLR] before push-
ing [ENT].
For the IC-A14S
t
Push [Y]/[Z]several times to select the desired character.
• To move the cursor forwards, push [MR].
• To erase a character, overwrite with a space (displayed as
“_”).
y Hold down [MR] for 1 second to enter the name and fre-
quency at the same time.
• Return to the frequency display.
• If no name is entered, the entered frequency is displayed.
• To clear the entered memory names, push [CLR] before hold-
ing down [MR] for 1 second.
KEY CHARACTER KEY CHARACTER
[1] 1, Q, Z [6] 6, M, N, O,
[2] 2, A, B, C [7] 7, P, R, S
[3] 3, D, E, F [8] 8, T, U, V
[4] 4, G, H, I [9] 9, W, X, Y
[5] 5, J, K, L [0] 0, _ (space), –
