The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THEABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THEAMPLIFIER BEINGADDED
WHITE = LEFTFront (+) Input
WHITE/BLACK = LEFTFront (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHT Front (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THEABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFTFront (+) Input
WHITE/BLACK = LEFTFront (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHTFront (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THEABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFTFront (+) Input
WHITE/BLACK = LEFTFront (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHTFront (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THEABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFTFront (+) Input
WHITE/BLACK = LEFTFront (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHTFront (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THEABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFTFront (+) Input
WHITE/BLACK = LEFTFront (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHTFront (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THEABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFTFront (+) Input
WHITE/BLACK = LEFTFront (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHTFront (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.

AX-ADCT2
AX-ADCT2
AX-ADCT2
AX-ADCT2
AX-ADCT2
AX-ADCT2
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
Table of contents
Other Axxess Media Converter manuals
Popular Media Converter manuals by other brands

Baumer
Baumer HUBNER BERLIN HOG 10 Mounting and operating instructions

Digital Watchdog
Digital Watchdog Compressor DW-CP16 quick start guide

Conrad
Conrad 557478 operating instructions

Fagor
Fagor SVA Series manual

Richardson Products
Richardson Products DynaVox WPAC user manual

Ross
Ross DED-8420 user manual
