Axxion MC141 User manual

1. SPEAKERS (L&R)
2. BUTTON (ON/STANDBY)
3. MENU BUTTON
4. PROGRAM / MEMORY BUTTON
5. REMOTE SENSOR
6. ENTER / PLAY / PAUSE BUTTON
7. LCD DISPLAY
8. CD DOOR
9. NEXT /TUNE BUTTON
BACK /TUNE BUTTON
10. CD OPEN/CLOSE BUTTON
11. FUNCTION BUTTON
12. BAND / FOLDER BUTTON
13. PHONES JACK
14. PRESET EQ BUTTON
15. STEREO/MONO BUTTON
16. PLAY MODE/P BUTTON
17. RANDOM/P BUTTON
18. STOP BUTTON
19. USB PORT
20. SD/MMC PORT
21. VOLUME / BUTTON
22. FM WIRE ANTENNA
23. AUX.IN JACK
24. AC CORD
CONTROLS
MAIN UNIT
CD / MP3 / WMA / USB / SD / MMC MICRO SYSTEM
Instruction Manual
MC141
+
-
+
-
+
-
MC141USB-SD-AXXION-ENG-IM.indd 1 11/16/2009 2:44:25 PM

CLASS 1 LASER PRODUCT
This product contains a low power laser device.
CLASS 1 LASER PRODUCT
APPAREIL Á LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
CAUTION
INVISIBLE LASER RADIATION WHEN OPEN
AND INTERLOCKS DEFEATED.
AVOID EXPOSURE TO BEAM
Warning: Do not touch the lens.
DO NOT THROW BATTERIES IN FIRE !
ATTENTION : To reduce the risk of electric
shock, do not remove the cover. There are
no user serviceable parts inside the unit.
Refer all servicing to qualied personnel.
The exclamation point within the
triangle is a warning sign alerting
the user of important instructions
accompanying the product.
The lightening flash with
arrowhead symbol within the triangle
is a warning sign alerting the user of
"dangerous voltage" inside the unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
In case of malfunction due to electrostatic discharge, the apparatus has to be reset by disconnecting it from mains supply.
THE MARKING PLATE IS LOCATED ON THE BOTTOM OF ENCLOSURE OF THE APPARATUS.
PRECAUTIONS
Follow the advice below for safe and appropriate operations.
Follow the advice below for safe and appropriate operations.
ON PLACEMENT
• Do not use the unit in places which are extremely hot,
cold, dusty, or humid.
• Place the unit on a at and even surface.
• Do not restrict the air ow of the unit by placing it in a
place with poor air ow, by covering it with a cloth,
or by placing it on a carpet.
ON SAFETY
• When connecting and disconnecting the AC cord,
grip the plug and not the cord itself. Pulling the cord may
damage it and create hazard.
• When you are not going to use the unit for a long period
of time, disconnect the AC power cord.
ON AC VOLTAGE
• Before use, check that the rated voltage of your unit
matches your local voltage.
SYSTEM CONNECTIONS
1. SPEAKER CONNECTING
Connect the black wire to the (-) terminal.
The grey wire to the (+) terminal.
2. AC POWER CONNECTING
Before use, check the rated voltage (indicated at the rear
of unit) of your system to match your local voltage.
CAUTION :
• Make sure the SPEAKER PANEL are well connected
before plugging the AC power cord into an AC outlet.
• Power is fed to the unit even when it is in standby.
3. FM WIRE ANTENNA
ON CONDENSATION
• When left in a heated room where it is warm and damp,
water droplets or condensation may form inside the
CD player.
• When there is condensation inside the unit, the unit may not
function normally.
• Let it stand for 1 to 2 hours before turning the power on, or
gradually heat the room up and dry the unit before use.
* Ensure a minimum distance of 5 cm around the apparatus
for sufcient ventilation.
* Ensure that the ventilation is not impeded by covering the
ventilation openings with items, such as newspapers,
table-cloths, curtains, etc..
* Do not place naked ame sources, such as lighted candles
on the apparatus.
* Take attention to the environmental aspects of battery
disposal.
* Use the apparatus only in moderate climates (not in tropical
climates).
* Do not expose the apparatus to dripping or splashing.
* Do not place objects lled with liquids, such as vases, on the
apparatus.
• Mains plug is used as the disconnection device. It shall
remain readily operable and should not be obstructed during
intended use. To be completely disconnected the apparatus
from supply mains, the mains plug of the apparatus shall
be disconnected from the mains socket outlet completely.
Should any trouble occur, disconnect the AC power cord and
refer servicing to qualied personnel.
WARNING: TO PREVENT THE RISK OF FIRE OR ELECTRICAL SHOCK , DO NOT
EXPOSE THESE APPLIANCES TO RAIN OR OTHER MOISTURE.
EXPLANATION OF GRAPHICAL SYMBOLS:
WARNING
GB 1
MC141USB-SD-AXXION-ENG-IM.indd 2 11/16/2009 2:44:25 PM

SYSTEM CONNECTIONS
Power is fed to the unit even when it is in standby.
Ensure that the unit is switched off before you make any connections.
FITTING THE BATTERIES INTO THE REMOTE CONTROL
REMOTE CONTROL UNIT
VOLUME BUTTON VOLUME BUTTON
TUNE + NEXT BUTTON
ON / STANDBY BUTTON
FUNCTION BUTTON
BAND / FOLDER BUTTON
INTRO BUTTON
PLAY MODE / P + BUTTON
ENTER /PLAY /
PAUSE BUTTON
MENU BUTTON
STEREO / MONO BUTTON
BBS BUTTON
RANDOM / P - BUTTON
- +
TUNE - BACK BUTTON
STOP BUTTON
PROGRAM / MEMORY BUTTON
GB 2
To an AC outlet
LEFT SPEAKER
RIGHT SPEAKER FM WIRE ANTENNA
* LEFT/RIGHT
SPEAKER SOCKET
Connect the black wire to the (-) terminal.
Connect the grey wire to the (+) terminal.
SPEAKER WIRE
AC POWER CORD
SPEAKER WIRE
MUTE BUTTON PRESET EQ BUTTON
Remove the battery door. Insert the batteries (2 x AAA SIZE battery, not included) and ensure that the polarities are correct (see
illustration inside the battery compartment).
Close the battery door.
MC141USB-SD-AXXION-ENG-IM.indd 3 11/16/2009 2:44:25 PM

SLEEP / WAKE TIMERSLEEP / WAKE TIMER
GB 3
ADJUSTING THE SOUND
AUX. IN
Plug the other end into the external source
AUX. IN
VOL.
VOL.
Set the TMER ON
1. Press MENU button several times until " TIMER" is shown on the display.
2. Then press the button to enter the timer setting mode.
3. Press the MENU button to select " ON-time" (wake) and "Off-time" (sleep).
4. Then press the button to start setting the hour.
5. Press the the or button to increase/decrease the hour.
6. After setting the hour, press the button to switch to minute setting. Repeat step 5 to set the minutes.
7. Press the button again to nish setting. If you press the button during setting, you will exit the setting
without saving.
Enable/disable the TIMER
1. Press the MENU button several times until "TIMER" is shown on the display.
2. Press the button until "OK" or "DISABLE" is shown.
3. Press the MENU button to select "ENABLE" or "DISABLE".
4. Press the button to conrm the setting.
Connect an external line out to the AUX. IN SOCKET
at the back of unit using the correct type of cable.
When the unit is ON, press the FUNCTION button
several times until “AUX” appears on the display.
MENU
-
+
TURN ON / OFF THE SYSTEM
Press the ON/ STANDBY button to turn the audio on. To change
the audio mode between CD, RADIO, USB, SD/MMC and AUX.,
press FUNCTION button while the power is on. the audio mode
is displayed.
Power will be cut off automatically when CD, MP3, USB and SD/MMC
function in stop mode for 15 minutes.
In STANDBY mode
1. Press the MENU button to select the CLOCK mode, the LCD
display will show “CLOCK".
2. Press the button to enter the clock setting mode.
The hour digit will ash on the display.
3. Press the or button to adjust the hour.
4. Press the button. The minute digit will ash on the display.
5. Press the or button to adjust the minute.
6. Press the button again to conrm the setting.
CLOCK SETTING
STANDBY
FUNCTION
MENU
Press volume +/- to adjust volume level.
FOR PRIVATE LISTENING
Plug in headphones (ø3.5 mm stereo mini-plug) to the
PHONES jack.
When headphones are plugged in, the speakers are
automatically disconnected.
MC141USB-SD-AXXION-ENG-IM.indd 4 11/16/2009 2:44:26 PM

GB 4
RADIO MEMORY FUNCTION
TUNER OPERATION
FOR BETTER RECEPTION
Note: Do NOT connect the FM antenna wire to an
outside antenna!
FM AM
AM: Move the unit.
Fully unwind the wire antenna and place it in the
position that sounds best.
PRESET EQ
PRESET EQ
Preset EQ : FLAT, ROCK, JAZZ, CLASSIC, POP.
Press PRESET EQUALIZER button to select your preferred
sound, preset mode is shown on the display.
1. Tune to a desired radio station.
2. Press PROGRAM / MEMORY button ( 2 seconds ) to enter tuning saving mode.
The “MEMORY” icon will be turned on.
3. Program number “01” on the left hand side will be ashing.
4. Within 10 seconds, press PLAY MODE / P+ or RANDOM / P - button to
select the desired program number.
5. Press ENTER / PLAY/PAUSE button to conrm the Program number.
6. Press PROGRAM / MEMORY button ( 2 seconds ) to conrm the memory.
7. If there is no button pressed within 10 seconds, it will exit tuning save
mode and the “MEMORY” icon will be turned off.
Tuning a RADIO Station
1. Press FUNCTION button repeatedly until
“TUNER” is shown.
2. Press the BAND / FOLDER button to select the
desired frequency band (FM or AM).
3. Press the TUNE + / NEXT or TUNE - / BACK button
as many times as required to tune in to the desired
station.
4. Press and hold the TUNE + / NEXT or TUNE - /
BACK button for more than 1 second, scanning starts
automatically and tuner stops at the rst receivable
broadcast station.
5. To stop the auto tuning, press the TUNE + / NEXT or
TUNE - / BACK button again.
Selecting FM Stereo/Mono mode
1. To select FM stereo/mono mode, press STEREO/
MONO button.
2. “STEREO” icon will be lit on when receiving station
is broadcasted in Stereo.
3. To select mono mode, press STEREO / MONO
button again.
4. “STEREO” icon will never turn on in FM MONO
mode.
BAND/
FOLDER
NEXT
BACK
PROGAM/
MEMORY
STEREO/
MONO
OR
FUNCTION
MC141USB-SD-AXXION-ENG-IM.indd 5 11/16/2009 2:44:27 PM

TO SKIP TO THE BEGINNING OF A TRACK
• Press either one of the skip buttons according to the desired skip direction.
• Play/back resumes from the selected track.
• When the button is pressed once during play, the previous track starts again.
• When the button is pressed once during play, the next track plays.
SEARCHING FOR A PASSAGE WITHIN A TRACK
• Keep the or button pressed during playback, and release the
button as soon as you recognise the desired passage. Then normal CD
playback will resume from this point.
PLAYING TRACKS IN RANDOM ORDER
1. If the RANDOM / P -RANDOM / P - button is pressed, the tracks on the discs are not played in consecutive order but in random order. Theis pressed, the tracks on the discs are not played in consecutive order but in random order. The
word RAND appears on the display to provide a visual reminder that the RAND function has been activated.
2. Press the STOP button or RANDOM / P -RANDOM / P - button to switch off the function RAND.to switch off the function RAND.
GB 5
2. Press the CD open/close
button to open the CD door.
1. Press FUNCTION button repeatedly until “CD” is
shown on display.
4. Close the CD door, the disc will rotate.
For CD : The total tracks of the disc will show on the display.
For MP3/WMA/USB/SD : The total tracks of the disc and total
number of the folder will show on the display.
TO STOP PLAYBACK
Press the STOP button.
For CD : Total number of tracks and time will be shown.
For MP3 : Total number of tracks and folder will be shown.
For WMA : Total number of tracks and folder will be shown.
For USB : Total number of tracks and folder will be shown.
For SD : Total number of tracks and folder will be shown.
For CD : Track number "001" & "CD" will be shown,
the time of the track "00:00" in ash, during
normal compact disc playback.
For MP3 : Track number "F01" & "MP3" will be shown, the time
of the track "00:00" in ash, during MP3 playback.
For WMA : Track number "F01" & "WMA" will be shown, the time
of the track "00:00" in ash, during WMA playback.
For USB : Track number "F01" & "USB" will be shown, the time
of the track "00:00" in ash, during USB playback.
For SD: Track number "F01" & "SD" will be shown, the time
of the track "00:00" in ash, during SD playback.
TO INTERRUPT PLAYBACK
Press the ENTER / PLAY/PAUSE button. Press the button
to resume playback.
5. After disc read nished, the disc will play automatically.
In stop mode, press the ENTER / PLAY/PAUSE
button to play the track.
For CD : Track number "001" & "CD" & "00:00" will be
shown, during normal compact disc playback.
For MP3 : Track number "F01" & "MP3" & "00:00" will
be shown, during MP3 playback.
For WMA :Track number "F01" & "WMA" & "00:00" will
be shown, during WMA playback.
For USB : Track number "F01" & "USB" & "00:00" will
be shown, during USB playback.
For SD : Track number "F01" & "SD" & "00:00" will
be shown, during SD playback.
3. Insert a disc with the label side facing up.
RANDOM/P-
NEXT /TUNE+
BACK /TUNE-
CD display MP3 display
USB displayWMA display
CD display MP3 display
USB displayWMA display
COMPACT DISC PLAYBACK
STOP
FUNCTION
SD display
SD display
MC141USB-SD-AXXION-ENG-IM.indd 6 11/16/2009 2:44:29 PM

GB 6
PLAY MODE/P+
FOR NORMAL COMPACT DISC PLAYBACK
Mode sequence REPEAT >> REPEAT ALL >> CLEAR.
During Repeat 1 mode,
display shows
During Repeat 2 mode,
display shows
During Repeat 3 mode,
display shows
REPEAT , REPEAT ALL , REPEAT A B , REPEAT FOLDER PLAYBACK
MP3/WMA/USB/SD display
CD display
FOR MP3 / WMA / USB / SD PLAYBACK
Mode sequence REPEAT >> REPEAT ALL >> REPEAT
FOLDER >> CLEAR.
During Repeat 1 mode,
display shows
During Repeat 2 mode,
display shows
During Repeat 3 mode,
display shows
During Repeat 4 mode,
display shows
Press PLAY MODE button during stop mode.
FOR MP3 / WMA / USB / SD PLAYBACK
Mode sequence REPEAT >> A REPEAT >>
A-B REPEAT >> REPEAT ALL >> FOLDER.
During Repeat 1 mode,
display shows
During Repeat 2 mode,
display shows
During Repeat 3 mode,
display shows
During Repeat 4 mode,
display shows
During Repeat 5 mode,
display shows
During Repeat 6 mode,
display shows
FOR NORMAL COMPACT DISC PLAYBACK
Mode sequence REPEAT >> A REPEAT >>
A-B REPEAT >> REPEAT ALL.
During Repeat 1 mode,
display shows
During Repeat 2 mode,
display shows
During Repeat 3 mode,
display shows
During Repeat 4 mode,
display shows
During Repeat 5 mode,
display shows
Press PLAY MODE button during playback.
CD display
For CD : Total number of tracks and time will be shown.
For MP3/WMA/USB: Total number of tracks and folder will be shown.
For CD : The folder tracks number and time will be shown.
For MP3/WMA/USB: The folder tracks number and folder will be shown.
MP3/WMA/USB/SD display
PLAY MODE/P+
Note on CD-R/RW discs
- Because of non-standardized format denition/ production of CD-R/RW, playback quality and performance are not guaranteed.
- Manufacturer is not responsible for the playability of CD-R/RW due to recording conditions, such as PC performance, writing
software, media ability, etc.
- Do not attach a seal or label to either side of the CD-R/RW disc. It may cause a malfunction.
- It is recommended to record only audio les on CD-R/RW discs for easy reading.
MC141USB-SD-AXXION-ENG-IM.indd 7 11/16/2009 2:44:30 PM

1. Insert USB / SD / MMC into the USB / SD / MMC input slots of the system.
2. Press the “FUNCTION” button to select USB / SD / MMC mode.
3. The unit will start to read the media and playback will start automatically.
note: The USB connector does not support connection with a USB extension cable and
it is not designed for communication with a computer directly.
The manufacturer is not responsible for the playability of a USB / SD / MMC disk or MP3 player
due to recording conditions, capacity, interface compatibility, etc.
Due to different formats, some USB / SD / MMC disks or MP3 players may take longer time to be read.
A USB stick may be connected directly or with a cable with max. 0,5 m length.
FOR NORMAL COMPACT DISC PLAYBACK
Programmed playback enables tracks on a disc to be played in the desired order. Up to 20 tracks can be programmed.
1. Program mode works in STOP mode only.
2. Holding “PROGRAM / MEMORY” button for 2 seconds to enter program mode.
The “PROG” icon will be turned on. “000 P01” will be shown with “000” ashing. “000”
represents track number and “P01” represents program location number.
3. Press TUNE + / NEXT or TUNE - / BACK button to select the required track number.
4. Press “PROGRAM / MEMORY” button to conrm the track number. The display
will show the next program number “000 P02”. The track number will be ashing
again and waiting for track number input.
5. Repeat steps 3 and 4 until all the desired tracks has been programmed or all the
program memories have been used. It will loop back to P01 after all the program
memories have been used. Same track number can be programmed more than once.
6. Press ENTER/PLAY/PAUSE button to playback.
7. To clear the programmed tracks, rst press “PROGRAM / MEMORY” button for
2 seconds to enter program mode.
8. Press STOP button to clear all the programmed memories.
GB 7
CD display
USB display
ENTER/PLAY/PAUSE
PROGRAMMED CD OPERATION
FOR MP3/WMA/USB/SD PLAYBACK
Programmed playback enables tracks on a disc to be played in the desired order. Up to 20 tracks can be programmed.
1. Program mode works in STOP mode only.
2. Holding PROGRAM / MEMORY button for 2 seconds to enter program mode.
The “PROG” icon will be turned on. “00 000 P01” will be shown with “00” ashing.
“000” represents track number and “P:01” repre sents program location number.
3. Press the TUNE + / NEXT or TUNE - / BACK button to select the desired folder.
4. Press TUNE + / NEXT or TUNE - / BACK button to select the required track number.
5. Press PROGRAM / MEMORY button to conrm the track number. The display
will show the next program number “000 P02”. The track number will be
ashing again and waiting for track number input.
6. Repeat steps 3 and 4 until all the desired tracks has been programmed or all the
program memories have been used. It will loop back to P01 after all the program
memories have been used. Same track number can be programmed more than once.
7. Press ENTER/PLAY/PAUSE button to playback.
8. To clear the programmed tracks, rst press PROGRAM / MEMORY button
for 2 seconds to enter program mode.
9. Press STOP button to clear all the programmed memories.
MP3/WMA/USB/SD display
ENTER/PLAY/PAUSE
PROGRAMMED USB/SD OPERATION
Program mode works in Stop mode
1. Hold the PROGRAM / MEMORY button for 2 seconds. Then, the “00000P:01” will be shown on the display and the rst 2 digits
will be ashing.
2. Press TUNE + / NEXT or TUNE - / BACK button to select the desired folder. After press PROGRAM /MEMORY button to
conrm the folder, the 3rd to 5th digits will be ashing.
3. Press TUNE + / NEXT or TUNE - / BACK button to select the desired track. Then, press PROGRAM / MEMORY button to
conrm the track number.
4. Press PROGRAM / MEMORY button again to conrm the setting. The display will show next program number.
5. Repeat the sequence as indicated in 2 to 4 for next program.
6. After all the desired programs have been selected, Press ENTER/PLAY/PAUSE button for playback.
PROGRAM/MEMORY
FUNCTION
USB / SD / MMC OPERATION
MC141USB-SD-AXXION-ENG-IM.indd 8 11/16/2009 2:44:31 PM

MUTE ON/OFF
GB 8
FOLDER SELECTION
1. In STOP mode, press BAND/FOLDER button will skip to the next folder.
2. The operation valid for all media of MP3 / WMA / USB / SD operation.
INTRO
BASS BOOST
The BBS button on the remote control also enables you to switch the bass boost on or off.
ID3 Display
1. Press MENU button repeatedly unit ID3 shown on the display.
2. Press ENTER/PLAY/PAUSE button to enter ID3 setting mode.
3. Press MENU button to select " ID3 ON " or " ID3 OFF ".
4. Press ENTER/PLAY/PAUSE button to conrm.
BAND/FOLDER
MENU
The mute on/ off is changed cyclically by pushing MUTE button.
The “mute” mark is on during mute is on.
The mute on is cancelled in case as shown below.
a. The power is off/on.
b. The Volume is adjusted by the VOL +/- button.
In CD mode, press to play only the rst 10 seconds of each track on the disc.
MC141USB-SD-AXXION-ENG-IM.indd 9 11/16/2009 2:44:31 PM

GB 9
CLEANING CD
If the CD skips or will not play , the disc may need cleaning.
Before playing, wipe the disc from the centre out with a cleaning
cloth. After playing, store the disc in its case.
CLEANING THE CD LENS
If the CD lens is dusty, clean it with a brush-blower. Blow
several times on the lens and remove the dust with the brush.
Finger prints may be removed with a cotton swab moistened
with alcohol.
MAINTENANCE
CLEANING THE UNIT
Do not use volatile chemicals on this unit. Clean by lightly
wiping with a soft cloth.
IMPORTANT NOTE
If an abnormal display indication or an operating problem
occurs, disconnect the AC power cord .Wait at least 5 seconds,
then reconnect the AC power cord .
WARNING
Should the CD door be opened before the reading of the CD
completed, a jamming noise may occur. This is resolved by
closing the CD door.
CD SECTION
Channels: 2 channels
S / N ratio: 60 dB
Wow & Flutter: undetectable
Sampling frequency: 44.1 kHz 4 x over sampling
Quantization: 16 bit D/A converter
Pick up light source: Semi - conductor laser
Pick up wave length 790 nm
RADIO SECTION
Tuning ranges: FM 87.5 - 108 MHz
AM 522 - 1620 kHz
Antennas: AM Built - in ferrite bar
FM Wire antenna
GENERAL
Output power: 2 W + 2 W
Power consumption: 17 WATTS
Speaker: 3" 8 OHM
Phones jack: 3.5MM
Power source: AC : 230V ~ 50Hz
Dimensions:
Main Unit : 175 (L) x 207 (D) x 133 (H)mm
Speaker : 110 (L) x 174 (D) x 133 (H)mm
Remote control : 35 (L) x 18 (D) x 190 (H)mm
Weight : 2.63 Kgs
Due to continuing improvement, the features and the design are subject to change without notice.
SPECIFICATION
Where to place the item :
Today’s furniture is coated with a wide variety of lacquers and synthetic-coatings that are treated with an extensive range of cleaning
products. Therefore, the possibility that some of these substances contain components that react adversely to the rubber feet of the
item and soften them, cannot be completely excluded. The rubber feet of the appliance can cause discoloring to furniture surfaces. If
necessary, place the appliance on a non-slide surface.
If at any time in the future you should need to dispose of this product please note that: Waste electrical products
should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice. (Waste Electrical and Electronic Equipment Directive)
MC141USB-SD-AXXION-ENG-IM.indd 10 11/16/2009 2:44:32 PM
