Azores Networks AX1500 User manual

Azores AX1500 WiFi-6 Wireless
Router Manual
Azores Networks, LLC

Product Hardware Description
Product Backside Description：
Short press (1 second) for reset the router
Long press (5 seconds or longer) for reset to factory default settings

LED Description:
LED Behavior
Scenario
DARK
No Power
STEADY RED
Powering up
BLINKING RED
No network cable connected
BLINKING GREEN
Network connection in progress
STEADY GREEN
Function normally and can access the Internet
BLINKING BLUE
WPS or Mesh pairing in progress
STEADY BLUE
Paring successful

Product Manual
For single router：
Connect the provided network cable from the AX-1500 Router to your home Broadband Gateway (i.e. cable/DSL
modem, PON gateway). Please refer to SINGLE ROUTER SETUP STEPS for network setup.
For mesh router set:
Master AP is used as the main router, which is to be connected, via provided network cable, to your home
Broadband Gateway (i.e. cable/DSL modem, PON gateway); Slave AP is used for Wi-Fi network expansion.
Please refer to ONE ROUTER SETUP STEPS (for Master AP) & MESH SETUP STEPS (for Slave AP) for network
setup.

ONE ROUTER SETUP STEPS
The Single Router or Master AP in a Mesh Router Set can be connected according to the diagram above.
Note the DSL/PON/Cable Gateway must be connected to the Port 1 of the AP. The AP is connected to
the Internet when the LED light is steady green. If you can, try place the Single Router or Master
AP in an open area like on a table or a shelf.
Wired devices can be connected directly to ports 2, 3 or 4 for Internet access; wireless devices
can use the network name (SSID) & password (see the sticker on the bottom of the Single Router or
Master AP) to connect to Internet.
MESH SETUP STEPS
Place the Slave AP at a proper location based on your home layout. After powering on again, Slave AP
is all set when the LED is steady green. To optimize wireless performance, place the Slave AP in a location
that minimizes the barrier (such as wall, door, and floor) between the Master and the Slave AP. We recommend
one wall/door/floor between the two APs. You can connect the Slave AP to your Master AP via network cable
(preferred method) or wirelessly.
*Note:If you know there is a spot in your home, where the Wi-Fi signal is the weakest. Try place the
Slave AP midway between the Master AP and the weakest spot.
*Note:When Master AP and Slave AP paring successfully, the SSID and Password would be same, that is showing
on the bottom of Master AP.

Azores Router APP
01 Connect your Mobile device to Wi-Fi network
according to the Wi-Fi SSID and password
sticker on the bottom of the Master AP.
02 Download mobile APP software from
corresponding App Store (searching “azores
router”) or Scan the following QR code.
Scan QR code to download Azores Router APP
03 Login with Wi-Fi password on the bottom of the
Master AP.
04 Enter the “My Wi-Fi” menu to modify WiFi
configuration or perform other operations.
*Note: If you want to use the mobile device to
perform other operations on the router, follow
the instructions on the mobile APP.

MORE SETTINGS
※Refer to the following steps to change the Internet access method:
01 Wireless access terminals (such as mobile phones, PAD, laptops, etc.) or wired access terminals can
open the browser to visit http://192.168.0.1, and configure the router device.
02 Password needs to be set for the first time login, click "Next". Please remember this login password.
03 Set Internet configuration.
If the home broadband service has been opened and the home router has been deployed, you can
connect this Router device to the home router's LAN Ethernet port (or wall Ethernet port), you
can select "DHCP", then click "Next".
If the home broadband service has been activated, but dial-up is required to activate the Internet,
you can select "PPPoE", fill in the broadband account and password, and click "Next".

*Note:If you forget your broadband account password, you can inquire from the broadband operator.
*Note:"Skip" defaults to "DHCP" mode.
04 Set Wi-Fi name and password (you can modify the Wi-Fi name).
The device selects “The password is the same as the login password” by default, clicks “Next”directly,
which means that the default wireless password is the same as the login password;
If you do not check "The password is the same as the login password", you can set a new Wi-Fi
password and click "Next".
If you click "Skip", the Wi-Fi name and password will still be the information shown on the bottom
of the device.
05 Click "Complete" to complete the configuration.

Prompt "Setup Succeed", "Confirm" to jump to the login page.
After "Confirm", the wireless terminal can reconnect to the new Wi-Fi name and password.
※Refer to the following steps to switch Router to Bridge mode:
01 Log in to the http://192.168.0.1 page using the login password.
02 Change the "Uplink mode" to "Bridge Mode" on the "WAN Settings" page and click Save.
※Refer to the following steps to add a single product customized Mesh network expansion:
For duplexes, villas, and large-area residents, you can purchase multiple Azores routers of the same
model to join the Mesh network to improve WiFi network coverage.
01 (New item) Log in to the http://192.168.0.1 page with the set login password.
02 (New item) "Router Mode Settings" select "Slave AP" and click "Save", the device will restart
automatically.

03 Start networking.
If you choose wired networking, connect the new single product network port to the Master AP
network port. The wired network is successful when the new single product indicator is steady
green;
If you choose wireless networking, place the new item near the Master AP, press both device WPS
buttons for 1s, then release. The Master AP indicator will turn on in blue for 1 minute, then
restore to the original state. The wireless pairing is successful when new added product indicator
is steady green. Wait 2 minutes for information synchronization and the wireless network is
successful. You can move the new product to the network expansion location.

Frequently Asked Questions
Q1 After connecting network cable from
DSL/PON/Cable gateway to the Azores AP or
Azores Master AP in a mesh set, the AP's red
LED is keep flashing.What should I do?
Some cable carriers limit the number of home device
to one. This problem may happen if you replace your
old router with Azores AP. In this case, you need
to power down the cable gateway, leave it powered
down for 15 seconds and power back it up. Afterwards,
power down and up the Azores AP or the Master AP
in a mesh set,Then you should see the AP's LED turns
steady green pretty soon.
Q2 How to reset the device?
Answer: When the router is powered on, pushing the
“Reset” hole on the bottom of the device with a
needle. The LED starts to flash green and hold for
5 more seconds. Release when the LED turns off. The
LED will become steady red and will then start. Wait
for about 2 minutes, then the factory default reset
is completed.
Q3 Mobile phones and other devices are
connected to the router but cannot access the
Internet.
Answer: (1) Check whether the main router is
connected to your Broadband Gateway. The main
router's network port should be connected to your
Broadband gateway (i.e. DSL/Cable modem, PON
gateway) with a network cable.
(2) If PPPoE Internet access is needed, you need
to check whether the broadband account and password
are filled in correctly; otherwise, check whether
the Internet status of your Broadband Gateway is
normal.
(3) Make sure the broadband service is normal and
you have paid Internet bill.
(4) When all above are normal, try reboot the
device and then check the network once it powers
back on.
Q4 How to manage Azores router network?
Answer: Connect your device to the Router using
wireless or wired connection. Open an internet
browser and enter http://192.168.0.1. You can
modify WAN configuration, router configuration,
single SSID for 2.4 and 5G network, guest Wi-Fi
network, and retrieve your wireless network
status.
Q5 Azores Router APP cannot control Azores
routing?
Answer: Please make sure to use the Azores Router
APP to connect to the Azores router, and use the
current Wi-Fi password for login.
Q6 If I want to switch the Mesh Router Set
to wireless networking after successful
wired networking,What should I do?
Answer: Disconnect the wired connection between
the Slave AP and the Master AP, power off and
restart the Slave AP. When the indicator light
flashes green, press the WPS buttons of the Slave
AP and Master AP to pair. It will return to its
original state after the Master AP indicator is
blue for 1 minute. Pairing is successful when the
Slave AP indicator flashes steady green.
