Azores Networks AX1500 User manual

Wi-Fi 6 MESH AP
Quick Start Guide
Azores Networks, LLC

Overview
Thank you for choosing our product.
Please read this manual before use.
If you need to change Internet Access method,i.e.from router to bridge mode,or add a new
esh AP to your esh network,or need other information,please scan the QR code below or
visit https://azoresnetworks.com/pages/download-center in the browser to view the
corresponding electronic user manual for instructions.
Scan QR code to download electronic user manual
Azores Dual-band outer Model List
AX1500
AX1800
AX1800 PRO
AX3000 PRO

01 Product Hardware Description
Product Backside Description
AX1500 AX1800
AX1500/AX1800 AX1800 PRO/AX3000 PRO
The picture is for reference only, please refer to the actual product.
Button Description
Button Function
WPS Set the WPS process.
Reset
Short press (1 second) for reset the router;
Long press (5 seconds or longer) for reset to factory default settings.
ON/OFF Power on and off the router.（Model:AX1500/AX1800 PRO/AX3000 PRO）

LED ON/OFF
Turn on or off the LED.Turn off the LED indicator for a better sleep.
The LED indicator switch will not affect the operation of Azores Router.
（Model:AX1800）
LED Description
LED Behavior Scenario
Dark No Power
Steady Red Powering up
Blinking Red No network cable connected
Blinking Green Network connection in progress
Steady Green Function normally and can access the Internet
Blinking Blue WPS or esh pairing in progress
Steady Blue Pairing successful
02 Product Manual
For single router：
Connect the provided network cable from the Azores Router to your home Broadband Gateway (i.e. cable/DSL
modem, PON gateway). Please refer to SINGLE OUTE SETUP STEPS for network setup.
AX1500/AX1800 AX1800 PRO/AX3000 PRO
Single outer

For mesh router set:
ain AP has the QR code on the label, is used as the main router, which is to be connected, via provided network
cable, to your home Broadband Gateway (i.e. cable/DSL modem, PON gateway); Satellite AP is used for Wi-Fi
network expansion. Please refer to ONE OUTE SETUP STEPS (for ain AP) & MESH SETUP STEPS (for
Satellite AP) for network setup.
When Single Router and ain AP in esh Router Set have the same operation steps, they are collectively
referred to as Azores Router hereinafter.
03 ONE OUTE SETUP STEPS
The Azores Router can be connected according to the diagram above. Note the DSL/PON/Cable Gateway
AX1500/AX1800
AX1800 PRO/AX3000 PRO
Mesh outer Set

must be connected to the WAN Port of Azores Router. When it is connected to the Internet ,the LED light is
steady green. If you can, try place the Azores Router in an open area like on a table or a shelf.
Wired devices can be connected directly to LAN Port(s) for Internet access; Wireless devices can use the
network name (SSID) & password (see the sticker on the bottom(or backside) of Azores Router) to connect
to Internet.
04 MESH SETUP STEPS
Place the Satellite AP at a proper location based on your home layout. After powering on again, Satellite AP is all
set when the LED is steady green. To optimize wireless performance, place the Satellite AP in a location that
minimizes the barrier (such as wall, door, and floor) between the ain AP and Satellite AP. We recommend one
wall/door/floor between the ain AP and Satellite AP. You can connect the Satellite AP to your ain AP via
network cable (preferred method) or wirelessly.
Note:
(1) If you know there s a spot n your home, where the W -F s gnal s the weakest. Try place the Satell te AP m dway
between the Ma n AP and the weakest spot.
(2) When Ma n AP and Satell te AP pa r ng successfully, the SSID and Password would be same, that s show ng on the
bottom of Ma n AP.
05 Azores outer APP
01 Connect your obile device to Wi-Fi network according to the Wi-Fi SSID and password sticker on the label
of Azores Router.
02 Download mobile APP software by scanning the QR code below or visiting
https://azoresnetworks.com/pages/app-download in the browser.

Scan QR code to download Azores Router APP
03 Follow the APP guidance to log in.
04 Enter the “ y Wi-Fi” menu to modify WiFi configuration or perform other operations.
*Note: If you want to use the mobile device to perform other operations on the router, follow the instructions on the
mobile APP.

06 Frequently Asked Questions
Q1 I replaced my old router with Azores
outer.After connecting network cable
from DSL/PON/Cable gateway to the
Azores outer, the LED is keep flashing
red.What should I do?
Answer:For some cable carriers limit the number of
in-home device to one. This problem may happen if
you replace your old router with Azores Router.In
this case, you need to power down the cable
gateway,leave it powered down for 15 seconds and
power back it up. Afterwards, power down and on
the Azores Router,then you should see the LED
turns steady green pretty soon.
Q2 How to reset the device?
Answer: WhenAzores Router is powered on,
pushing the “Reset” hole on the bottom of the
device with a needle. The LED starts to flash green
and hold for 5 more seconds. Release when the
LED turns off. The LED will become steady red and
will then start to blink green. Wait for about 2
minutes, then the factory default reset is completed.
Q3 Mobile phones and other devices are
connected to the router but cannot
access the Internet.
Answer: (1) Check whether the Azores Router's
WAN Port is connected to your Broadband
Gateway. The Azores Router's network port should
be connected to your Broadband gateway (i.e.
DSL/Cable modem, PON gateway) with a network
cable.
(2) If PPPoE Internet access is needed, you need
to check whether the broadband account and
password are filled in correctly;Otherwise, check
whether the Internet status of your Broadband
Gateway is normal.
(3) ake sure the broadband service is normal and
you have paid Internet bill.
(4) When all above are normal, try reboot the
device and then check the network once it powers
back on.
Q4 How to manage Azores outer
network?
Answer: Connect your device to the Router using
wireless or wired connection. Open an Internet
browser and enter http://192.168.0.1(or
http://azoresrouter.com). You can modify WAN
configuration, router configuration, single SSID for
2.4G and 5G network, guest Wi-Fi network, and
retrieve your wireless network status.
Q5 Azores outer APP cannot control
Azores outer.What should I do?
Answer: Please check your phone is connected to
WiFi normally, and use the correct password for
login.
Q6 If the way that you connect to the
network is different from shown in the
figure in “ONE OUTE SETUP
STEPS”,or the IP address conflicts with
the address of the deployed home
router/gateway,how to configure Internet
access?

、
Warning:
Answer:Try put Router in bridge mode.Please scan
the QR code(on page 1) to view the electronic user
manual to switch to bridge mode.
Q7 What if I already purchased a Mesh
outer set and want to further expand the
network with additional AP(s)?
Answer:You need to purchase another or more
Azores routers(the same model) and expand the
current mesh network.Please scan the QR code to
view the electronic user manual to obtain the
customized mesh network operation method.
Q8 How to access the Satellite AP web
management page(GUI) if the mesh
pairing failed?
Answer: anually set the PC IP address to
192.168.0.X(e.g.192.168.0.100),the subnet mask is
255.255.255.0.Open the browser and enter
http://192.168.0.254.
