SPECIFICATIONS SHEET
PHON SPORTS
ABT100S
Highlights
Take your music experience to the next
level during any season with this waterproof
and dustproof portable bluetooth speaker.
Unique Selling Points:
Aztech PHON SPORTS ABT100S will give you maximum performance
regardless of the speaker size, and whatever the music source.
With the IP67 rating, this speaker is meant for outdoor rugged use
withstanding the heaviest element of rain and dust - it is virtually
waterproof and dustproof allowing you to use it with no worry
whenever wherever.
AUX
Support
4400mAh Battery for
Longer Playing Time
IP67 Dustproof and
Waterproof Rating
PHON SPORTS ABT100S allows you
to connect to external media devices
through AUX support which means
more possible sources for your needs.
Up to 10 hours of continuous playing is
made possible by the 4400mAh battery
of this powerful device. The longer the
playing time the better.
PHON SPORTS is protected
from contact with harmful dust
entry such as beach sand. It is
also protected from accidental
submersion in 1M of water for up
to 30 minutes.
PHON SPORTS ABT100S

Features
Built-in MP3 Player through MicroSD Card Slot.
PHON SPORTS has a MicroSD card slot which serves as an alternate source of music. Play
tons of music that are absolutely perfect for various occasions using the built-in MP3 Player.
Powerful Bass.
Speakerphone with High Sensitivity Microphone.
With its built-in microphone, be heard clearly during phone calls. Conference call is also
possible and can be executed well. Conversations are made even better with this speaker.
This speaker will give you a unique music experience having dual high performance drivers
that’s been “hand-picked” to match the ampliers, a criterion found only on professional
grade loudspeakers. Its sonic signature combines the best objective detail of a STUDIO
monitor with the subjective “musicality” of “Audiophile-like” uidness and transparency.
Whether you are into hard rock music or classical music, this will give you the best sound
experience.
One-Tap Connectivity
Another feature of this speaker is the one-tap connectivity through NFC. Near Field
Communications provides a low-speed connection with simple setup used for better
wireless connection. With just a tap, connect your devices in an instant
Handfree Call.
Another feature of this speaker is the handfree call. Just one press on the button to answer
and end a call. The built in internal microphone allows you to talk and be heard clearly. This
also works on conference calls.
Thermal Sensors within Top Panel.
With the thermal sensors used in the speaker’s top panel, buttons are automatically
illuminated with a shallow frosted LED backlight when used at night. This makes it easier
for users to control PHON SPORTS even in the dark.
PHON SPORTS ABT100S
SPECIFICATIONS SHEET

SPECIFICATIONS SHEET
Product Specications
Technical Information
Power Bank Output: 5V, 1A
Output Power: 10W x 2
Battery Capacity: 4400mAh
Playback time: 10 Hours (Depending on music)
THD: ≤ 1.0%
SNR: ≥ 90dB
Dimensions: 200mm x 65mm x 87mm
Control Buttons
Status Indicators
Press and hold to turn on. Press again to turn off.
Press and hold for 8 seconds to reset device should
operational issues occur.
Press to switch between Bluetooth, AUX, and MicroSD
modes. If there is no AUX Cable or MicroSD card inserted,
speaker will automatically enter default Bluetooth Mode.
Press to navigate between tracks (Available in Bluetooth and
MicroSD Mode).
Use to play and pause audio.
*Note: Doubles as a Bluetooth pairing button, press and
hold to initiate Bluetooth pairing.
Press to increase/decrease the volume.
While in Bluetooth mode, press and hold to activate Siri or
S-Voice. Press again to disable. Incoming call: Press once to
answer, press again to end. Press and hold to decline call.
Flashing Red: Battery is low.
Solid Green: Device is charging
Lights indicate remaining power.
Flashing: Device is charging.
Solid: Device is fully charged.
When indicator light is on, AUX Mode is enabled
When indicator light is on, MicroSD Mode is enabled
When indicator light is on, Bluetooth Mode is enabled. When
Bluetooth is in pairing mode, indicator will ash. Once a
device has been paired, indicator will remain solid
Detects the heat of human hand and will automatically acti-
vate the device frosted LED button-backlighting
Hold your device over this area to use NFC for Bluetooth
Connection.
Remain within three feet of microphone while speaking
PHON SPORTS ABT100S

SPECIFICATIONS SHEET
Diagrams
1. Power Button
2. Mode Button
3. Previous / Next Button
4. Play / Pause Button
5. Volume Increase / Decrease Button
6. Phone Button
Deployment and Setup
7. Charging Indicator
8. Battery-Level Indicator
9. AUX Indicator
10. MicroSD Indicator
11. Bluetooth Indicator
12. Thermal Sensor
13. NFC Area
14. Microphone
15. Charging Port
16. USB Power Port
17. AUX IN Port
18. MicroSD Port
Perfect for
Your Room Any Season of the Year Your Outdoor Activities
Long press power burron for 3
seconds to turn the speaker on
Press Play / Pause button to make
the speaker discoverable. Then, the
speaker will enter the pairing mode
and the indicator light should be
ashing.
Turn on Bluetooth on your device
and connect it with the speaker.
Select your music player and play
your favorite songs.
Easy Setup
PHON SPORTS ABT100S
