Aztech PHON STUDIO ABT100M User manual

PHON STUDIO
ABT100M
Highlights
Tuned by the experts from the studios for
your home - a high powerful bluetooth
speaker designed to match your music and
entertainment needs.
Unique Selling Points:
Get in the spirit with the unique sound quality of Aztech PHON STUDIO
ABT100M. The rechargeable, high capacity 6600mAh battery of this
device can provide up to 10 hours of continuous playing which means
better user experience for you.
AUX
Support
Tuning
at its Finest
6600mAh Battery for
Longer Playing Time
PHON STUDIO ABT100M allows you
to connect to external media devices
through AUX support which means
more possible sources for your needs.
The tuning of the PHON STUDIO is
challenging. Having an extensive wide
spectral product experience from
professional studio sound, desktop and
portable speaker systems. The voicing
“signature” is evident.
Up to 10 hours of continuous
playing is made possible by the
6600mAh battery of this powerful
device. Longer playing time means
longer time to have fun.
PHON STUDIO ABT100M
SPECIFICATIONS SHEET

SPECIFICATIONS SHEET
Features
PHON STUDIO uses the 6600mAh built-in battery - your speaker can serve as a powerbank
Charge your mobile devices at 5V, 1A. Worry no more, use your phone more.
Powerful Bass.
Enjoy full bodied and stellar sound with its powerful bass. Its bass is deep tight and smooth
and unlike many portable speakers, it has distinct sound. This bluetooth speaker will give you
one of a kind music experience.
Speakerphone with High Sensitivity Microphone.
With its built-in microphone, be heard clearly during phone calls. Conference call is also
possible and can be executed well. Conversations are made even better with this speaker.
One-Tap Connectivity.
Another feature of this speaker is the one-tap connectivity through NFC. Near Field
Communications provides a low-speed connection with simple setup used for better
wireless connection. With just a tap, connect your devices in an instant.
Photo Resistant Sensors within Top Panel.
With the photo resistant sensors used in the speaker’s top panel, buttons are automatically
illuminated with a shallow frosted LED backlight when used at night. This makes it easier
for users to control PHON STUDIO even in the dark.
Charge Your Device through Built-In Battery.
PHON STUDIO ABT100M PHON STUDIO ABT100M
SPECIFICATIONS SHEET
Handfree Call.
Another feature of this Bluetooth speaker is the handfree call. Just one press on a button
to answer and end a call. The built-in internal microphone allows you to talk and be heard
clearly. This also works on conference calls.

SPECIFICATIONS SHEET
Product Specications
SPECIFICATIONS SHEET
Technical Information
Power Bank Output: 5V, 1A
Output Power: 12.5W x 2
Battery Capacity: 6600mAh
Playback time: 10 Hours (Depending on music)
THD: ≤ 0.5%
SNR: ≥ 90dB
Item Size: 218mm x 74mm x 84.5mm
Control Buttons
Status Indicators
Long press for 2 seconds to turn the speaker on or off.
Press to select the Bluetooth source. The speaker attempts
to connect the last paired device. If there are no paired
devices, the speaker becomes discoverable.
Once Bluetooth is connected, press again to set the speaker
discoverable and allow pairing with another Bluetooth
device.
Each time you press Bluetooth, the speaker switches be-
tween connecting/connected and discoverable.
When connected via Bluetooth and no coming call, short
press to activate/cancel “Siri” or Android Voice.
Incoming call: Press once to answer. Press again to end call.
Hold to reject call.
Use this button to navigate between tracks when Bluetooth
device is connected
Playing and Pausing
Press to incrementally decrease speaker volume. Press and
hold to continuously decrease speaker volume
Press to increase speaker volume. Press and hold to contin-
uously increase speaker volume
Indicates the Bluetooth speaker state when the Bluetooth
source is selected.
Quick blinking between blue and red means it is
discoverable and ready to pair with a Bluetooth device.
Blinking blue means it is connected to paired device
AUX is the selected source. Here you can connect your
speaker to external media devices
Low battery indicator light will display blinking red, Normally,
it will display green.
Indicates the battery power level: 30%, 60%, 100%
PHON STUDIO ABT100M

SPECIFICATIONS SHEET
Diagrams
AUX Port (In / Out)
Deployment and Setup
AC Port
USB Charge Port
Reset Button
Power Button
Play/Pause Button
BluetoothButton
Call Button
Perfect for
Your Living Room Your Conference Calls Your Studio / Ofce
Previous Button
Next Button
Volume Increase /
Decrease Button
Bluetooth Status Indicator
AUX Status Indicator
Power Level Indicator
Battery Status Indicator
Easy Setup
Long press power icon for 2 sec-
onds to turn the speaker on
Press Bluetooth icon to make the
speaker discoverable. Then, the
speaker will emit a tone and is now
ready to pair
Turn on Bluetooth on your device
and connect it with the speaker.
Select your music player and play
your favorite songs.
PHON STUDIO ABT100M
SPECIFICATIONS MAY CHANGE WITHOUT PRIOR NOTICE.
