Welcome to B-hyve™
Water intrusion in the home causes extensive damage unless it is caught
right away. The B-hyve™ Flood Sensor offers peace of mind and protection
by alerting your phone immediately when a leak in your home is detected.
Back
Inside B-hyve Gen 2 Hub
1) Open the B-hyve™ App
Log into your B-hyve account and tap “My B-hyve”. Go to “devices” then
“add device”. The app will walk you through the rest of the process.
For new users, search apps for “B-hyve”
and download the free Android or iOS app.
Create an account to begin setup.
2) Power and Pair Gen 2 Hub
Plug the hub into an indoor outlet, central to sensor locations, and within
range of Wi-Fi. Press button five times to reset the hub and enter
into pairing mode. Your hub will flash red, then blue to signify it is in
pairing mode.
3) Power and Pair Sensor
Remove the pull tab to activate the battery, your sensor is now
in pairing mode.
If at any time you need to re-pair, quickly press the on the back
of the sensor 5 times.
Sensors include one Lithium CR2032 battery. Annual battery
replacement is recommended for optimal performance. See the “Replacing
the Battery” section for instructions.
4) Select Sensor Location
Place the sensor in an indoor location within range of your hub. Range is
approximately 150 ft. (45m), walls and other interference can reduce this
range. Position the retrieval cord for easy extraction when placing a sensor
beneath heavy objects.
If using as a water sensor:
•Place the sensor flat on the floor in the area you wish to monitor.
•Ensure that the flood sensor is positioned with its flat surface faced down.
If using as a heat/cold sensor:
•Place in the location where you wish to detect changes
in temperatures.
•Avoid areas where inconsistent temperatures are common.
(near vents, exhausts, etc.)
The sensor communicates with the hub via Bluetooth™; the range
between the sensor and hub will vary depending on the number of
walls and types of obstacles the signal needs to travel through.
If water is detected or there is a temperature fluctuation, a beep will
play and a notification will be displayed on your phone.
Avoid areas where the signal must travel through
dirt or thick steel barriers.
5) Complete Setup
Continue to follow the instruction within the app to complete
the setup process.
Replacing the Battery
• Insert a flathead screwdriver into the open slot.
• Turn the screwdriver 90º to snap open the cover.
• To remove the battery, lift on the edge of the coin cell
battery using your fingers. DO NOT use a screwdriver
or other metal object.
• Insert a new CR2032 battery at an angle.
• Verify that the + side is up.
• Reinstall the battery cover by snapping it into place.
Always completely secure the battery compartment. If the battery
compartment does not close securely, stop using the product, remove
the batteries, and keep it away from children.
If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention. Even used
cells may cause injury.
CAUTION: Dispose of used batteries according to the battery
manufacturer’s instructions.
WARNING: Risk of Fire, Explosion, and Electric Shock. Replace
battery with CR2032 only. Use of a different battery has the potential for
a risk of fire, explosion, and electric shock.
WARNING: Do not ingest batteries. Chemical Burn Hazard.
Keep batteries away from children.
WARNING: This product contains a lithium button/coin cell battery.
WARNING: If a new or used lithium button/coin cell battery is
swallowed or enters the body, it can cause severe internal burns and can
lead to death in as little as 2 hours.
Front
LED
Status
Light
Pairing
Reset
Button
Water
Sensors
MAC ID
CR2032 Battery Location
FLOOD SENSOR
CR2032 3V
XXXXXXXXXXXX
Retrieval
Cord

Specifications
Sensor
HVIN: FS1
Part No – 71003, 71000, 04133
FCC ID:ML6FS1
IC:3330A-FS1
RATING: DC 3.3V
Battery: CR 2032 Lithium (Non-Rechargeable)
Temp Range: 32-158°F (0-70°C)
Hub
HVIN: BH1G2
Part No – 21008
FCC ID:ML6-BH1G2
IC:3330A-BH1G2
Range: 150 ft. (45m) without interference
Temperature Operating Range: 32°F-104°F (0-40°C)
Storage Temperature: -4°F to 140°F (-20 °C to 60 °C)
Humidity Operating Range: 0–90%
Input: 100-240V ~ 50/60Hz 0.2A
Output: 5V-1.0A
Limited Warranty
Limited Orbit Irrigation Products LLC., (hereinafter Orbit) warrants this product will be free
from defects in material and workmanship for a period of one year from the date of purchase.
Proof of Purchase (copy of your original receipt, purchase order or invoice), the date the product
was purchased and installation date is required. During the warranty period, Orbit, will replace, free
of charge, the part or parts found to be defective under reasonable use and service, as determined
solely by Orbit. Orbit reserves the right to inspect the defective part prior to replacement. Liability
under this warranty is limited to the replacement or repair of defective parts. This warranty is
exclusive and is in lieu of all other warranties expressed or implied, including, but not limited to
warranties for fitness, for use or merchantability.
FCC and IC Statement
This device complies with Part 15 of the FCC Rules and Industry Canada license exempt RSS
standards. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC Warning: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device meets the FCC and IC requirements for RF exposure in public or controlled
environments. The end user is advised to maintain a distance of 20 cm from the controller and
any personnel to ensure compliance with RF exposure regulations. This Class B digital apparatus
complies with Canadian ICES-003.
Déclaration de FCC et l’IC
Cet appareil est conforme à la section 15 de la Règlementation de la FCC et la norme RSS
d’Industry Canada. Son fonctionnement est soumis aux deux conditions suivantes: (1) cet appareil ne
doit pas causer d’interférences nuisibles, et (2) cet appareil doit tolérer toutes les interférences, dont
les interférences pouvant causer un fonctionnement non désiré.
Cet appareil numérique de classe B est conforme à la norme canadienne ICES-003.
Remarque: cet appareil été testé et déclaré conforme aux limites d’exposition pour les appareils
numériques de classe B, selon la section 15 de la Règlementation de la FCC. Ces limites sont
conçus pour fournir une protection raisonnable contre les interférences nuisibles dans une
installation résidentielle. Cet appareil produit, utilise et peut émettre de l’énergie radio fréquence
et, si elle n’est pas installée et utilisée conformément aux instructions, peut causer des interférences
nuisibles aux communications radio. Cependant, il n’est pas garantie que des
interférences ne se produisent pas dans une installation particulière.
Si cet appareil cause des interférences gênantes à la réception d’un signal radio ou de télévision,
ce qui peut être déterminé en allumant et en éteignant l’appareil, l’utilisateur peut corriger les
interférences en suivants une des mesures suivantes :
• Réorientez ou repositionnez l’antenne de réception.
• Augmentez la distance entre l’appareil et le récepteur.
• Branchez l’appareil dans une prise sur un circuit différent du circuit sur lequel le récepteur
est branché.
• Consulter le revendeur ou un technicien radio/TV expérimenté pour obtenir de l’aide.
Cet appareil est conforme aux exigences de la FCC et de l’IC concernant l’exposition aux ondes
dans un environnement public ou contrôlé. Il est conseillé à l’utilisateur final de maintenir une distance
de 20 cm du contrôleur pour assurer la conformité aux réglementations d’exposition RF. Information
de conformité pour le Canada.
call us
1-800-488-6156
text us
801-797-2319
Orbit®
PO Box 328
Bountiful, UT 84011-0328 USA
Need Help?
If you encounter a problem, please use the following resources before returning your
B-hyve to the store.
Scan the QR Code for access to the Orbit online help center.
or visit us at:
community.orbitonline.com
