Badger Basket Wicker Doll Buggy 00569 User manual

1.0/0407/TG
PRODUCT MODEL
NUMBER:
00569
Visit us online at www.badgerbasket.com
Toll-Free Customer Service: 1-800-236-1310 (Monday to Thursday 7:30AM-4:30 PM CST)
Web: http://www.badgerbasket.com/parts • E-mail: [email protected]
PLANT AND GENERAL OFFICE: PO Box 227, Edgar, WI 54426-0227 • Phone: [phone] • Fax: [phone]
CORPORATE OFFICE: 111 Lions Dr., Suite 220, Barrington, IL 60010
Page 1 of 4
WICKER DOLL BUGGY
Assembly Instructions. Adult Assembly
Required. Save these instructions for future
use. This item is a toy for dolls only.
For children ages (3) years and older.
Actual product may vary slightly from shown.

1.0/0407/TGPage 2 of 4
PARTS AND HARDWARE:
BEFORE YOU BEGIN ASSEMBLY:
Check all parts and hardware listed. If anything is missing or you have
questions, please DO NOT call the store or return the product to them.
Contact us for assistance. Most problems are resolved without you
needing to leave home. When emailing or calling us, please have this
instruction manual and your product model number ready. For fastest
service, go to http://www.badgerbasket.com/parts
TOOLS NEEDED:
Philips Screwdriver
Standard Screwdriver
A power screwdriver is helpful but
be careful not to strip the screws
or damage the product.
PARTS INCLUDED:
(A) 1 - Handle
(B) 2 - Handle Frames
(C) 2 - Short Screws
(D) 1 - Wicker Body
(E) 8 - Long Bolts
(F) 8 - Washers
(G) 12 - Cap Nuts
(H) 2 - Chassis Frames
(I) 2 - Axles
(J) 4 - Short Bolts
(K) 4 - Wheels
(L) 1 - Fabric Liner
(M) 1 - Fabric Sheet
(N) 1 - Mattress Pad
Ax1
Ix2
Hx2
Bx2
Dx1
CARE INSTRUCTIONS:
Wipe clean with a damp cloth and mild soap as needed. Never immerse the
basket, chassis, or mattress pad in water. The fabric liner and sheet are
poly/cotton. For longevity of the product, we recommend spot cleaning or
gently hand washing as needed; however you can machine wash the fabric
parts in cold water, gentle cycle and air dry or tumble dry on low if desired.
Kx4
Lx1
Mx1 Nx1
Hardware not to scale.
Cx2
Ex8 Fx8 Gx12
Jx4

1.0/0407/TG
STEP1 - PICTURE 1:Attach the HANDLE (A) to the HANDLE FRAMES (B) using TWO SHORT
SCREWS (C).
!- STEP 2 - PICTURE 2: Decide if you want the handle attached in front of the carriage or behind it (it can
be removed and reattached, by an adult, in the other position at any time).
Attach the TWO HANDLE FRAMES (B) to the WICKER BODY (D) using FOUR LONG BOLTS (E), FOUR
WASHERS (F), and FOUR CAP NUTS (G). The bolts with washers go through the holes inside of the wicker
body, and then secure the parts together on the outside of the body using the cap nuts.
PICTURE 1 PICTURE 2
A
BBD
!- STEP 3 - PICTURE 3: Attach the TWO CHASSIS FRAMES (H) to the WICKER BODY (D) using
FOUR LONG BOLTS (E), FOUR WASHERS (F), and FOUR CAP NUTS (G). The bolts with washers go
through the holes inside of the wicker body, and then secure the parts together on the outside of the body using
the cap nuts.
STEP4 - PICTURE 4:Attach the TWO AXLES (I) to the underside of the CHASSIS FRAMES (H) using
FOUR SHORT BOLTS (J), and FOUR CAP NUTS (G). The bolts go through the bottom, and then secure the
parts together on the top using the cap nuts. The axles face the inside.
H
H
D
PICTURE 3 PICTURE 4
II
Page 3 of 4
NOTE: The “!” symbol indicates that this step is
easier if you have another person assist you.
AXLES FACE
THE INSIDE

1.0/0407/TG
STEP5 - PICTURE 5:Attach the FOUR WHEELS (K) to the AXLES (I). Squeeze the metal clip on the wheel
to open it, slide the wheel onto the axle, and then release the clip so that it locks over the end of the axle. Gently
tug each wheel to make sure the clip has popped into place and locked onto the axle.
PICTURE 5
KK
KK
STEP6 - PICTURE 6: Dress the FABRIC LINER (L) onto the WICKER
BODY (D). Secure it with the ribbons (slip one or both of the ribbons, as
needed, through holes in the wicker and then tie the ribbons into a bow).
Dress the FABRIC SHEET (M) onto the MATTRESS PAD (N) and place
them inside of the WICKER BODY (D). Your carriage is now assembled!
WARNING !! CHOKING
HAZARD! SMALL PARTS!
Not for children under three
(3) years of age. Please make
sure children know that this
toy is for dolls and stuffed
animals only.
It is not to be used with real
infants or with pets.
Children should NEVER
attempt to climb inside of
it, sit in it, or stand on it.
Regularly check the
hardware to ensure it
remains tight!
Page 4 of 4
PICTURE 6
Actual product may vary slightly from shown.
L
D
