Bafo BF-H103 User manual

HD VIDEO CONVERTER
User Manual
BF-H103
VGA+Audio to
HDMI Converter
Bring High-Definition to your life!

VGA+Audio to HDMI Converter
Thank you for purchasing our product. To ensure safety and many years'
trouble-free operation of the product, please read the manual carefully
before using this product.
1.0 Introduction
BAFO
VGA+Audio to HDMI converter converts VGA input into HDMI to allow PC
users to show their image not only on the PC’s monitor, but could also on TV,
to have a large display. The conversion is along with the audio. Converter
offers solutions for digital entertainment center, HDTV retail and show site,
HDTV, STB, DVD and Projector factory, noise space and security concerns,
data center control, information distribution, conference room presentation,
school and corporate training environments.
2.0 Features
BAFO VGA+Audio to HDMI converter have many features that enable them
to perform in a superior manner. among those features you will find:
1. Conversion: It could convert PC’sVGA video and R/L audio into complete
HDMI;
2. Easy to Use: Install in seconds, no need of setting;
3. Support HDMI1.3b,HDCP1.2/1.1;
4. Support resolution:480i/p,576p,720p,1080i/p;
5. Extend the transmission distance and improve transmission signal;
6. Compatible with DVI by using HDMI to DVI adapter;
7. Metal casing design and overall shielding without signal interference.
3.0 Packaging accessories:
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the shipping carton:
1. VGA to HDMI Converter------------------------------------ 1Pcs
2. Audio Cable
----------------------------------------------------- 1Pcs
3. 5V DC Power Adaptor
--------------------------------------- 1Pcs
4 . User Manual
--------------------------------------------------- 1Pcs
4.0 Specifications
Signal Input /Output
Input Video Signal
0.5-1.0 volts p-p
Input DDC Signal
5 volts p-p (TTL)
Maximum Single Link
Range
1600X1200, 1080P
Output Video
HDMI + HDCP1.2/1.1
01

VGA+Audio to HDMI Converter
VGA
640x480 60Hz 72Hz 75Hz
800x600 60Hz 72Hz 75Hz
1024x768 60Hz 70Hz 75Hz
1280x1024 60Hz
1600x1200 60Hz
DTV/HDTV
480i/576i/480p/576p/720p/1080i/1080P
Operating Frequency
Frequency
Up to165MHz
Video Amplifier
Bandwidth
1.65Gpbs/165MHz
Resolutions(HDTV)
Interlaced(50&60Hz)
480i,576i,1080i
Progressive(50&60Hz)
480p,576p,720p,1080p
Mechanical
Size(LxWxH)
73x60.5x22.5mm
Weight(Net)
0.09Kg
Warranty
Limited Warranty
1 Year Parts and Labor
Environmental
Operating Temperature
0 to70℃
℃
℃
Operating Humidity
10% to 85 % RH (no condensation)
Storage Temperature
-
10 to 80℃
Storage Humidity
5% to 95 % RH (no condensation)
Power Requirement
External Power Supply
DC 5V 1A
Regulatory Approvals
Converter Unit
CE,FCC,ROHS
Power Supply
CE,FCC,PSE,TK,UL
Accessories Adapter
AC Power Adapter
US standard, UK standard and so on
User Manual
English Version
5.0 Panel introduction
Please study the panel drawings below and become familiar with the signal
input(s), output(s) and power requirements.
VGA
------------------------------------------------------ VGA Input
Stereo
--------------------------------------------------
--------------------------------------------------
Audio Input
DC/5V DC Power Input
02

VGA+Audio to HDMI Converter
Power --------------------------------------------- Power Indicator
HDMI------------------------------------------------- HDMI Output
6.0 Connection and operation
Before installation, please make sure all devices you wish to connect
have been turned off.
1.Connect the VGA video and Stereo audio from computer to Converter.(Input
cables are optional)
2.Connect the HDMI output from to the TV which has HDMI input.
3.Insert the DC side of 5V power supply into and then connect the AC side of
the power supply into the wall outlet.
4.Power on the computer and TV, choose the input of TV to its HDMI
channel.
5.The image does not need to be adjusted, the Converter will position it
automatically, the user may adjust the horizontal position under some
extreme condition.
Attention: Insert / Extract cable gently.
7.0 INSTALLATION AND PRECAUTIONS
To avoid electric shock,product damage and to protect your safety, please
notice the following:
1. Please slowly plug or unplug signal cables and do not often plug,unplug,
or shake them.
2. The equipment should not be placed under the sun,
rain and damp or
unventilated environment.
3. Liquid items should not be placed on the equipment.
4. Do not install the equipment near heat sources such as fire,
power
,
or
other amplifiers that produce heat.
5. Do not insert the metal or other objects to the equipment in addition to
connecting cables to ports.
6. Do not demolish the equipment by yourself
;it should be maintained by
professional maintenance staff.
03
