Bailey infi 90 Modular Power System II User manual

®
®
Process Control and
Automation Solutions
from Elsag Bailey Group
E96-610
INFI-NET to Computer Interfaces
(INICI01/03)

WARNING notices as used in this instruction apply to hazards or unsafe practices that could result in
personal injury or death.
CAUTION notices apply to hazards or unsafe practices that could result in property damage.
NOTES highlight procedures and contain information that assists the operator in understanding the
information contained in this instruction.
WARNING
INSTRUCTION MANUALS
DO NOT INSTALL, MAINTAIN, OR OPERATE THIS EQUIPMENT WITHOUT READING, UNDERSTANDING,
AND FOLLOWING THE PROPER Elsag Bailey INSTRUCTIONS AND MANUALS; OTHERWISE, INJURY OR
DAMAGE MAY RESULT.
RADIO FREQUENCY INTERFERENCE
MOST ELECTRONIC EQUIPMENT IS INFLUENCED BY RADIO FREQUENCY INTERFERENCE (RFI). CAU-
TION SHOULD BE EXERCISED WITH REGARD TO THE USE OF PORTABLE COMMUNICATIONS EQUIP-
MENT IN THE AREA AROUND SUCH EQUIPMENT. PRUDENT PRACTICE DICTATES THAT SIGNS
SHOULD BE POSTED IN THE VICINITY OF THE EQUIPMENT CAUTIONING AGAINST THE USE OF POR-
TABLE COMMUNICATIONS EQUIPMENT.
POSSIBLE PROCESS UPSETS
MAINTENANCE MUST BE PERFORMED ONLY BY QUALIFIED PERSONNEL AND ONLY AFTER SECURING
EQUIPMENT CONTROLLED BY THIS PRODUCT. ADJUSTING OR REMOVING THIS PRODUCT WHILE IT IS
IN THE SYSTEM MAY UPSET THE PROCESS BEING CONTROLLED. SOME PROCESS UPSETS MAY
CAUSE INJURY OR DAMAGE.
AVERTISSEMENT
MANUELS D’OPÉRATION
NE PAS METTRE EN PLACE, RÉPARER OU FAIRE FONCTIONNER L’ÉQUIPEMENT SANS AVOIR LU,
COMPRIS ET SUIVI LES INSTRUCTIONS RÉGLEMENTAIRES DE Elsag Bailey. TOUTE NÉGLIGENCE À
CET ÉGARD POURRAIT ÊTRE UNE CAUSE D’ACCIDENT OU DE DÉFAILLANCE DU MATÉRIEL.
PERTURBATIONS PAR FRÉQUENCE RADIO
LA PLUPART DES ÉQUIPEMENTS ÉLECTRONIQUES SONT SENSIBLES AUX PERTURBATIONS PAR
FRÉQUENCE RADIO. DES PRÉCAUTIONS DEVRONT ÊTRE PRISES LORS DE L’UTILISATION DU MATÉ-
RIEL DE COMMUNICATION PORTATIF. LA PRUDENCE EXIGE QUE LES PRÉCAUTIONS À PRENDRE
DANS CE CAS SOIENT SIGNALÉES AUX ENDROITS VOULUS DANS VOTRE USINE.
PERTURBATIONS DU PROCÉDÉ
L’ENTRETIEN DOIT ÊTRE ASSURÉ PAR UNE PERSONNE QUALIFIÉE EN CONSIDÉRANT L’ASPECT
SÉCURITAIRE DES ÉQUIPEMENTS CONTRÔLÉS PAR CE PRODUIT. L’AJUSTEMENT ET/OU L’EXTRAC-
TION DE CE PRODUIT PEUT OCCASIONNER DES À-COUPS AU PROCÉDÉ CONTRÔLE LORSQU’IL EST
INSÉRÉ DANS UNE SYSTÈME ACTIF. CES À-COUPS PEUVENT ÉGALEMENT OCCASIONNER DES
BLESSURES OU DES DOMMAGES MATÉREILS.
NOTICE
The information contained in this document is subject to change without notice.
Elsag Bailey, its affiliates, employees, and agents, and the authors and contributors to this publication specif-
ically disclaim all liabilities and warranties, express and implied (including warranties of merchantability and
fitness for a particular purpose), for the accuracy, currency, completeness, and/or reliability of the information
contained herein and/or for the fitness for any particular use and/or for the performance of any material and/
or equipment selected in whole or part with the user of/or in reliance upon information contained herein.
Selection of materials and/or equipment is at the sole risk of the user of this publication.
This document contains proprietary information of Elsag Bailey, Elsag Bailey Process Automation, and
is issued in strict confidence. Its use, or reproduction for use, for the reverse engineering, development
or manufacture of hardware or software described herein is prohibited. No part of this document may be
photocopied or reproduced without the prior written consent of Elsag Bailey.

I-E96-610A
Preface
The INICI01 and INICI03 INFI-NET®to Computer Interfaces
provide a host computer or console with access to an INFI-NET
communication loop. State-of-the-art INFI 90®modules are
used in these interfaces.
The INNIS01 Network Interface Slave Module (NIS) is a part of
all INFI-NET to computer interfaces. It provides the intelligent
link between a node and an INFI-NET loop. One NIS module
and one INICT01 INFI-NET to Computer Transfer Module make
up an INICI01 INFI-NET to Computer Interface. One NIS mod-
ule, one INICT03 INFI-NET to Computer Transfer Module, and
one IMMPI01 Multi-Function Processor Interface Module make
up an INICI03 INFI-NET to Computer Interface.
This instruction explains INFI-NET to computer interface fea-
tures, specifications, and operation. It also includes installa-
tion and troubleshooting procedures for each module.
® INFI-NET and INFI 90 are registered trademarks of Elsag Bailey Process Automation.

I-E96-610A
®
List of Effective Pages
Total number of pages in this instruction is 94, consisting of the following:
Page No. Change Date
Preface Original
List of Effective Pages Original
iii through ix Original
1-1 through 1-8 Original
2-1 through 2-6 Original
3-1 through 3-20 Original
4-1 through 4-12 Original
5-1 through 5-6 Original
6-1 through 6-4 Original
7-1 through 7-2 Original
8-1 Original
A-1 through A-3 Original
B-1 through B-3 Original
C-1 through C-5 Original
D-1 through D-5 Original
E-1 through E-4 Original
F-1 through F-4 Original
Index-1 through Index-2 Original
When an update is received, insert the latest changed pages and dispose of the super-
seded pages.
NOTE: On an update page, the changed text or table is indicated by a vertical bar in the outer mar-
gin of the page adjacent to the changed area. A changed figure is indicated by a vertical bar in the
outer margin next to the figure caption. The date the update was prepared will appear beside the
page number.

viii I-E96-610A
Safety Summary
®
GENERAL
WARNINGS Equipment Environment
All components, whether in transportation, operation or storage,
must be in a noncorrosive environment.
Electrical Shock Hazard During Maintenance
Disconnect power or take precautions to insure that contact with
energized parts is avoided when servicing.
Special Handling
This module uses electrostatic sensitive devices (ESD).
SPECIFIC
WARNINGS Disconnect power before installing dipshunts on the module mount-
ing unit backplane. Failure to do so will result in contact with cabinet
areas that could cause severe or fatal shock. (p. 3-8, 3-12, 3-20)
Wear eye protection whenever working with cleaning solvents.
When removing solvents from printed circuit boards using com-
pressed air, injury to the eyes could result from splashing solvent as
it is blown off the printed circuit board. (p. 6-1)
SPECIFIC
CAUTIONS Never operate the ICT module with the machine fault timer circuit
disabled (jumper pins connected). Unpredictable module outputs
may result. These unpredictable module outputs may adversely
affect the entire communication system. (p. 3-16)
To avoid potential module damage, evaluate your system for com-
patibility prior to module installation. This module uses connections
to the module mounting unit backplane that served other functions
in early Network 90 systems. (p. 3-19)

I-E96-610A ix
Sommaire de Sécurité
AVERTISSEMENT
D'ORDRE
GENERAL
Environment de l'Equipement
Nes pas soumettre les composants à une atmosphère corrosive
lors du transport, de l'entreposage ou l'utilisation.
Possibilité de Chocs Électriques Durant l'Entretien
Débrancher l'alimentation ou de prende les précautions pour éviter
tout contact avec des composants sours tension durant l'entretien.
Précautions de Manutention
Ce module contient des composantes sensibles aux décharges
électrostatiques.
AVERTISSEMENT
D'ORDRE
SPECIFIQUE
Interrompez l'alimentation avant d'installer des dipshunts sur le fond
de panier du châssis de montage des modules. Sinon, tout contact
avec cette zone entraîne des risques d'électrocution sérieuse ou
fatale. (p. 3-8, 3-12, 3-20)
Portez toujours des lunettes de protection lorsque vous utilisez des
solvants de nettoyage. L'air comprimé servant à enlever le solvant
des cartes de circuits imprimés provoque des éclaboussures qui ris-
quent d'atteindre les yeux. (p. 6-1)
ATTENTION
D'ORDRE
SPECIFIQUE
Ne jamais faire fonctionner le module ICT alors que le circuit MFT
(Machine Fault Timer) est hors-circuit. Il pourrait en résulter des sor-
ties imprévisibles. Ces sorties imprévisibles pourraient affecter trés
défavorablement le systéme entier de communication. (p. 3-16)
Pour éviter d'endommager des modules, évaluez la compatibilité de
votre système avante de les y brancher. L'usage que fait ce module
de certaines connexions au fond de panier du châssis de montage
diffère de l'assignation prévue par le système Network 90 original.
(p. 3-19)

Table of Contents
Page
I-E96-610A iii
SECTION 1 - INTRODUCTION....................................................................................................1-1
OVERVIEW ..................................................................................................................1-1
INTENDED USER.........................................................................................................1-1
COMPUTER INTERFACE DESCRIPTION.......................................................................1-1
INICI01 INFI-NET to Computer Interface ................................................................1-1
INICI03 INFI-NET to Computer Interface ................................................................1-1
MODULE DESCRIPTION ..............................................................................................1-2
INNIS01 Network Interface Slave Module................................................................1-2
INICT01 INFI-NET to Computer Transfer Module ....................................................1-3
INICT03 INFI-NET to Computer Transfer Module ....................................................1-3
IMMPI01 Multi-Function Processor Interface Module..............................................1-4
FEATURES...................................................................................................................1-4
INSTRUCTION CONTENT .............................................................................................1-5
HOW TO USE THIS MANUAL .......................................................................................1-5
GLOSSARY OF TERMS AND ABBREVIATIONS .............................................................1-6
REFERENCE DOCUMENTS..........................................................................................1-6
NOMENCLATURE ........................................................................................................1-6
SPECIFICATIONS.........................................................................................................1-7
SECTION 2 - DESCRIPTION AND OPERATION........................................................................2-1
INTRODUCTION...........................................................................................................2-1
MODULE INTEGRITY ...................................................................................................2-1
INNIS01 NETWORK INTERFACE SLAVE MODULE .......................................................2-1
Exception Reports..................................................................................................2-1
Messages ...............................................................................................................2-2
Broadcast ........................................................................................................2-2
Time Synchronization ......................................................................................2-2
Multicast .........................................................................................................2-2
NIS Poll ...........................................................................................................2-2
Message Format ..............................................................................................2-2
Message Transmission.....................................................................................2-3
NIS Data Integrity ..................................................................................................2-3
Retry Logic ......................................................................................................2-3
Node Status Table............................................................................................2-3
Polling .............................................................................................................2-3
INICT01 INFI-NET TO COMPUTER TRANSFER MODULE..............................................2-4
INICT03 INFI-NET TO COMPUTER TRANSFER MODULE..............................................2-4
INFI-NET TO COMPUTER INTERFACE COMMANDS .....................................................2-5
Data Acquisition ....................................................................................................2-5
Configuration.........................................................................................................2-6
Process Control......................................................................................................2-6
System Status........................................................................................................2-6
SECTION 3 - INSTALLATION.....................................................................................................3-1
INTRODUCTION...........................................................................................................3-1
SPECIAL HANDLING ....................................................................................................3-1
UNPACKING AND INSPECTION ....................................................................................3-2
INNIS01 NETWORK INTERFACE SLAVE MODULE CONFIGURATION ...........................3-2
Dipswitch Settings .................................................................................................3-2
Dipswitch SW1 - Node Address ........................................................................3-3
Dipswitch SW2 - Loop Address ........................................................................3-3
Dipswitch SW3 - Loop Mode ............................................................................3-3
Dipswitch SW4 - I/O Module Address and Counters ........................................3-4
Jumper Settings ....................................................................................................3-6
Power System Status .............................................................................................3-7

iv I-E96-610A
Table of Contents (continued)
Page
®
SECTION 3 - INSTALLATION
(continued)
INNIS01 MODULE INSTALLATION ............................................................................... 3-7
INICT01 INFI-NET TO COMPUTER TRANSFER MODULE CONFIGURATION ................. 3-8
Dipswitch Settings................................................................................................. 3-9
Dipswitch U72 - Options ................................................................................. 3-9
Dipswitch U73 - Serial Port Communication Rate .......................................... 3-10
Dipswitch U75 - Diagnostics ......................................................................... 3-11
INICT01 MODULE INSTALLATION ............................................................................. 3-11
INICT03 INFI-NET TO COMPUTER TRANSFER MODULE CONFIGURATION ............... 3-13
Dipswitch Settings............................................................................................... 3-13
Dipswitch SW1 - Serial Port Communication Rate ......................................... 3-14
Dipswitch SW2 - Diagnostics......................................................................... 3-14
Dipswitch SW3 - SCSI Port............................................................................ 3-14
Dipswitch SW4 - Options .............................................................................. 3-15
Jumper Settings .................................................................................................. 3-16
HW SETUP Socket Jumper .................................................................................. 3-17
IMMPI01 MULTI-FUNCTION PROCESSOR INTERFACE MODULE CONFIGURATION .. 3-17
JUMPER SETTINGS................................................................................................... 3-18
INICT03 AND IMMPI01 MODULE INSTALLATION....................................................... 3-19
SECTION 4 - OPERATING PROCEDURES................................................................................4-1
INTRODUCTION .......................................................................................................... 4-1
INNIS01 NETWORK INTERFACE SLAVE MODULE START-UP PROCEDURES .............. 4-1
Event Counters ..................................................................................................... 4-1
Error Counters ...................................................................................................... 4-1
INICT01 INFI-NET TO COMPUTER TRANSFER MODULE LEDs AND CONTROLS ......... 4-1
Status LED............................................................................................................ 4-2
CPU LEDs ............................................................................................................. 4-2
Memory LEDs........................................................................................................ 4-2
Stop Switch ........................................................................................................... 4-3
Reset Switch.......................................................................................................... 4-3
INICT03 INFI-NET TO COMPUTER TRANSFER MODULE LEDS AND CONTROLS ......... 4-4
Status LED............................................................................................................ 4-4
CPU LEDs ............................................................................................................. 4-5
Stop/Reset Pushbutton ......................................................................................... 4-5
INICI01 AND INICI03 MODES OF OPERATION............................................................. 4-5
Execute Mode........................................................................................................ 4-5
Error Mode ............................................................................................................ 4-5
SECURITY FUNCTIONS ............................................................................................... 4-5
Hardware Checks .................................................................................................. 4-6
Software Checks.................................................................................................... 4-6
UTILITIES.................................................................................................................... 4-6
TALK90 Option...................................................................................................... 4-6
Configure/View Callup Password Option ............................................................... 4-9
Computer Command/Reply Sequences Option ...................................................... 4-9
Set Local Time and Date Option............................................................................. 4-9
Monitor Mode Option........................................................................................... 4-10
Real Value Conversion Option ............................................................................. 4-10
Port Address Option ............................................................................................ 4-12
Dump On Halt Option ......................................................................................... 4-12
Time Sync Accuracy Option ................................................................................. 4-12

I-E96-610A v
Table of Contents (continued)
Page
SECTION 5 - TROUBLESHOOTING...........................................................................................5-1
INTRODUCTION...........................................................................................................5-1
ERROR COUNTERS .....................................................................................................5-1
INNIS01 MODULE ERROR CODES...............................................................................5-1
INICT01 AND INICT03 MODULE ERROR CODES .........................................................5-2
SECTION 6 - MAINTENANCE.....................................................................................................6-1
INTRODUCTION...........................................................................................................6-1
PREVENTIVE MAINTENANCE SCHEDULE ...................................................................6-1
EQUIPMENT/TOOLS REQUIRED .................................................................................6-2
PREVENTIVE MAINTENANCE PROCEDURES...............................................................6-2
Printed Circuit Board Cleaning ..............................................................................6-2
General Cleaning and Washing ........................................................................6-3
Edge Connector Cleaning.................................................................................6-3
Checking Connections ...........................................................................................6-4
SECTION 7 - REPAIR/REPLACEMENT PROCEDURES...........................................................7-1
INTRODUCTION...........................................................................................................7-1
MODULE REPLACEMENT PROCEDURE ......................................................................7-1
TERMINATION UNIT OR MODULE REPLACEMENT PROCEDURES ..............................7-2
SECTION 8 - SUPPORT SERVICES...........................................................................................8-1
INTRODUCTION...........................................................................................................8-1
REPLACEMENT PARTS AND ORDERING INFORMATION ..............................................8-1
TRAINING ....................................................................................................................8-1
TECHNICAL DOCUMENTATION ...................................................................................8-1
APPENDIX A - NTCL01 TERMINATION UNIT CONFIGURATION...........................................A-1
INTRODUCTION.......................................................................................................... A-1
APPENDIX B - NICL01 TERMINATION MODULE CONFIGURATION.....................................B-1
INTRODUCTION.......................................................................................................... B-1
APPENDIX C - NTMF01 TERMINATION UNIT CONFIGURATION...........................................C-1
INTRODUCTION.......................................................................................................... C-1
APPENDIX D - NIMF01/NIMF02 TERMINATION MODULE CONFIGURATION.......................D-1
INTRODUCTION.......................................................................................................... D-1
APPENDIX E - NTMP01 TERMINATION UNIT CONFIGURATION........................................... E-1
INTRODUCTION.......................................................................................................... E-1
APPENDIX F - NIMP01/NIMP02 TERMINATION MODULE CONFIGURATION....................... F-1
INTRODUCTION...........................................................................................................F-1

vi I-E96-610A
No. Title Page
List of Figures
®
1-1. INICI01 and INICI03 INFI-NET to Computer Interfaces ........................................... 1-2
3-1. INNIS01 Module Dipswitch and Jumper Locations ................................................. 3-2
3-2. INNIS01 Module Jumper Settings .......................................................................... 3-7
3-3. INICT01 Module CPU Circuit Board Dipswitch Locations ....................................... 3-9
3-4. INICT03 Module Dipswitch and Jumper Locations ............................................... 3-13
3-5. IMMPI01 Module Jumper Locations ..................................................................... 3-18
3-6. IMMPI01 Module Jumper J1 Settings .................................................................. 3-18
3-7. IMMPI01 Module Jumper J2 Settings .................................................................. 3-19
4-1. INNIS01 Module Faceplate LEDs ........................................................................... 4-2
4-2. INICT01 Module Faceplate LEDs and Controls ....................................................... 4-3
4-3. INICT03 Module Faceplate LEDS and Controls ...................................................... 4-4
4-4. Example INICT03 Module Utilities Menu................................................................ 4-7
4-5. Example INICT01 Module Utilities Menu................................................................ 4-7
4-6. Example TALK90 Command Menu ........................................................................ 4-8
4-7. RESTART and DEMAND MODULE STATUS Commands and Replies .................... 4-10
4-8. Example Time Utilities Menu ............................................................................... 4-11
A-1. NTCL01 Connector and Jumper Locations (Revision F or Greater) ..........................A-1
A-2. NTCL01 Coaxial Cable Connections to INNIS01 Modules .......................................A-2
A-3. NTCL01 Twinaxial Cable Connections to INNIS01 Modules ....................................A-2
B-1. NICL01 Connector and Jumper Locations (Revision D or Greater) ..........................B-1
B-2. NICL01 Coaxial Cable Connections to INNIS01 Modules ........................................B-2
B-3. NICL01 Twinaxial Cable Connections to INNIS01 Modules .....................................B-2
C-1. NTMF01 Dipshunt Configuration for Direct Connection to a Host Computer ..........C-1
C-2. NTMF01 Dipshunt Configuration for Direct Connection to a Modem ......................C-2
C-3. NTMF01 Dipshunt Configuration for Direct Connection to Mainframe Computer ...C-3
C-4. NTMF01 Dipshunt Configuration for Diagnostic Terminal ......................................C-4
C-5. NTMF01 DB-25 Connector Pin Assignments and RS-232-C Signals .......................C-5
D-1. NIMF01/02 Dipshunt Configuration for Direct Connection to a Host Computer .....D-1
D-2. NIMF01/02 Dipshunt Configuration for Direct Connection to a Modem .................D-2
D-3. NIMF01/02 Dipshunt Configuration for Direct Connection
to Mainframe Computer.........................................................................................D-3
D-4. NIMF01/02 Dipshunt Configuration for Diagnostic Terminal .................................D-4
D-5. NIMF01/02 DB-25 Connector Pin Assignments and RS-232-C Signals ..................D-5
E-1. DTE Jumper Configuration for NTMP01 Termination Unit .....................................E-1
E-2. DCE Jumper Configuration for NTMP01 Termination Unit .....................................E-2
E-3. NTMP01 Nonhandshake Jumper Configuration .....................................................E-2
E-4. NTMP01 Loopback Jumper Configuration..............................................................E-3
E-5. NTMP01 Jumpers J3 through J10 Configuration ...................................................E-3
E-6. NTMP01 Jumpers J14 through J17 Configuration .................................................E-4
E-7. NTMP01 Connector Assignments and Jumper Locations........................................E-4
F-1. DTE Jumper Configuration for NIMP01 Termination Module .................................. F-1
F-2. DCE Jumper Configuration for NIMP01 Termination Module ................................. F-2
F-3. NIMP01 Nonhandshake Jumper Configuration ...................................................... F-2
F-4. NIMP01 Loopback Jumper Configuration............................................................... F-2
F-5. NIMP01 Jumpers J5 through J10 Configuration .................................................... F-3
F-6. NIMP01 Jumpers J14 through J17 Configuration .................................................. F-3
F-7. NIMP01 Connector Assignments and Jumper Locations......................................... F-4

List of Tables
No. Title Page
I-E96-610A vii
1-1. Glossary of Terms and Abbreviations .....................................................................1-6
1-2. Reference Documents ............................................................................................1-6
1-3. Nomenclature ........................................................................................................1-7
1-4. Specifications.........................................................................................................1-7
3-1. NNIS01 Module Dipswitch SW1 Settings ................................................................3-3
3-2. INNIS01 Module Dipswitch SW2 Settings ...............................................................3-3
3-3. INNIS01 Module Dipswitch SW3 Settings ...............................................................3-4
3-4. INNIS01 Module Address Settings ..........................................................................3-5
3-5. INNIS01 Module Event Counters ............................................................................3-5
3-6. INNIS01 Module Error Counters.............................................................................3-6
3-7. INICT01 Module Dipswitch U72 Settings ................................................................3-9
3-8. INICT01 Module Dipswitch U73 Settings ..............................................................3-10
3-9. INICT01 Module Dipswitch U75 Settings ..............................................................3-11
3-10. INICT03 Module Dipswitch SW1 Settings .............................................................3-14
3-11. INICT03 Module Dipswitch SW2 Settings .............................................................3-15
3-12. INICT03 Module Dipswitch SW3 Settings .............................................................3-15
3-13. INICT03 Module Dipswitch SW4 Settings .............................................................3-16
3-14. INICT03 Module Jumpers J1, J2, J4 and J5 Settings ...........................................3-17
3-15. INICT03 Module HW SETUP Socket Jumper Settings ...........................................3-17
4-1. INICT01 Module Status LED States ........................................................................4-3
4-2. INICT03 Module Status LED States ........................................................................4-4
5-1. INNIS01 Module Error Codes .................................................................................5-1
5-2. INICT01 and INICT03 Module Error Codes .............................................................5-2
5-3. INNIS01 Module Edge Connector P1 Pin Assignments ............................................5-3
5-4. INNIS01 Module Edge Connector P2 Pin Assignments ............................................5-3
5-5. INNIS01 Module Edge Connector P3 Pin Assignments ............................................5-3
5-6. INICT01 Module Edge Connector P1 Pin Assignment .............................................5-4
5-7. INICT01 Module Edge Connector P2 Pin Assignments ............................................5-4
5-8. INICT01 Module Edge Connector P3 Pin Assignments ............................................5-4
5-9. INICT03 Module Edge Connector P1 Pin Assignment ..............................................5-5
5-10. INICT03 Module Edge Connector P2 Pin Assignments ............................................5-5
5-11. INICT03 Module Edge Connector P3 Pin Assignments ............................................5-5
5-12. IMMPI01 Module Edge Connector P1 Pin Assignment .............................................5-6
5-13. IMMPI01 Module Edge Connector P3 Pin Assignments ...........................................5-6
6-1. Preventive Maintenance Schedule ..........................................................................6-2
8-1. Spare Parts List .....................................................................................................8-1
A-1. NTCL01 Jumper Settings for Revision D and E ...................................................... A-3
A-2. NTCL01 Jumper Settings for Revision F or Greater ................................................ A-3
B-1. NICL01 Jumper Settings for Revision C ................................................................. B-3
B-2. NICL01 Jumper Settngs for Revision D or Greater ................................................. B-3

OVERVIEW
I-E96-610A 1 - 1
SECTION 1 - INTRODUCTION
OVERVIEW
INFI-NET is a unidirectional, high speed serial data highway
shared by all INFI 90 nodes. INFI-NET utilizes sophisticated
computer interfaces for data exchange. These computer inter-
faces use state-of-the-art INFI 90 modules.
INTENDED USER
Personnel installing, operating, or maintaining the INFI-NET to
computer interfaces should read this manual before performing
any installation, operation, or maintenance procedures. Instal-
lation requires an engineer or technician experienced handling
electronic circuitry and familiar with communication networks.
COMPUTER INTERFACE DESCRIPTION
The computer interfaces are the INICI01 and INICI03 INFI-NET
to Computer Interfaces. The INNIS01 Network Interface Slave
Module (NIS) is a part of all INFI-NET to computer interfaces. It
is the intelligent link between a node and the INFI-NET loop.
The NIS module and other modules make up a specific com-
puter interface. Refer to Figure 1-1.
INICI01 INFI-NET to Computer Interface
The INICI01 INFI-NET to Computer Interface (ICI) is made up of
the NIS module and the INICT01 INFI-NET to Computer Trans-
fer Module (ICT). This computer interface gives a host com-
puter access to point data. Point data is available through an
RS-232-C serial link at standard rates up to 19.2 kilobaud.
The INFI-NET to computer interface is command driven
through software on the host computer. The ICI computer
interface receives a command from the host computer, exe-
cutes it and then replies to the host computer.
INICI03 INFI-NET to Computer Interface
The INICI03 INFI-NET to Computer Interface (ICI) is made up of
the NIS module, the INICT03 INFI-NET to Computer Transfer
Module (ICT), and the IMMPI01 Multi-Function Processor
Interface Module (MPI). This computer interface gives a host
computer access to point data. Point data is available through
an RS-232-C serial link at rates up to 19.2 kilobaud or through
a SCSI parallel port. The INFI-NET to computer interface is
command driven through software on the host computer. The
ICI computer interface receives a command from the host com-
puter, executes it and then replies to the host computer.

INTRODUCTION
MODULE DESCRIPTION
1 - 2 I-E96-610A
®
MODULE DESCRIPTION
A description of each module used in the INICI01 and INICI03
INFI-NET to Computer Interfaces follows.
INNIS01 Network Interface Slave Module
The NIS module is an I/O module that works in conjunction
with the other INFI-NET communication modules. This allows a
node to communicate with any other node on the INFI-NET loop.
The NIS module is a single printed circuit board that occupies
one slot in the module mounting unit. The circuit board con-
tains microprocessor based communication circuitry that
enables it to interface with other INFI-NET communication
modules. All INFI-NET to computer interfaces require a specific
communication module or modules and the NIS module.
Two latching screws on the faceplate secure the NIS module to
the module mounting unit. There are sixteen LEDs on the face-
plate that display error codes and event/error counts.
The NIS module has three card edge connectors for external sig-
nals and power (connector P1, P2 and P3). Connector P1 con-
nects to common (ground) and +5 VDC power. Connector P2
connects the NIS module to the I/O expander bus to communi-
cate with a control module within its node. Serial communication
to other nodes is through connector P3 using a cable connected
to a termination unit or termination module. Communication
between nodes is through coaxial or twinaxial cables that con-
nect the termination units or modules on each node.
Figure 1-1. INICI01 and INICI03 INFI-NET to Computer Interfaces
PCU
OIS
INFI-NET
LOOP
INICI01
INICI03
COMPUTER
COMPUTER
INNIS01 INICT01 RS-232-C
RS-232-C
T00388A
INNIS01 INICT03 IMMPI01
IEEE488
(OPTIONAL)
SCSI

INTRODUCTION
MODULE DESCRIPTION
I-E96-610A 1 - 3
INICT01 INFI-NET to Computer Transfer Module
The INICT01 INFI-NET to Computer Transfer Module (ICT) pro-
vides the electronics needed to direct the operation of the
INICI01 INFI-NET to Computer Interface. It handles all com-
munication with the host computer through RS-232-C serial
communication ports (one or both) and communicates directly
with the NIS module over the I/O expander bus.
The ICT module consists of two printed circuit boards. One cir-
cuit board is a memory board while the other is a central pro-
cessing unit. These boards contain the serial communication
circuitry necessary for the ICT module to communicate with a
computer. The ICT module occupies two mounting unit slots
adjacent to its associated NIS module.
Two latching screws on the ICT module faceplate secure the
module in the module mounting unit. The faceplate contains
eight CPU LEDs, two memory LEDs, a stop switch, and a reset
switch.
The communication path to the computer is through a cable
connection between connector P3 of the ICT module and a
NTMF01 Multi-Function Controller Termination Unit or
NIMF01 Multi-Function Controller Termination Module. Power
and I/O expander bus connections follow the same connector
assignments common to most INFI 90 modules (connector P1
for power, connector P2 for I/O expander bus).
INICT03 INFI-NET to Computer Transfer Module
The INICT03 INFI-NET to Computer Transfer Module (ICT) pro-
vides the electronics needed to direct the operation of the
INICI03 INFI-NET to Computer Interface. It handles all com-
munication with the host computer through the IMMPI01
Multi-Function Processor Interface Module (MPI), RS-232-C
(one or both) or SCSI communication ports. The ICT module
also communicates directly with the NIS module over the I/O
expander bus.
The ICT module consists of one printed circuit board. This
board contains the communication circuitry necessary for the
ICT module to communicate, through an MPI module, with a
host computer. The ICT module occupies one module mount-
ing unit slot adjacent to its associated NIS module and MPI
module.
Two latching screws on the ICT faceplate secure the module in
the module mounting unit. The faceplate contains 17 CPU
LEDs and a stop/reset switch.

INTRODUCTION
FEATURES
1 - 4 I-E96-610A
®
The host computer can be connected to the ICT module in one
of two ways. One way is to connect a SCSI communication
cable from the SCSI port on the MPI faceplate to the SCSI port
on the host computer. The other way is to connect a NKTU01,
NKTU02, NKTU11, or NKTU12 cable from the MPI module to
the NTMP01 termination unit or NIMP01 termination module
and then an RS-232-C communication cable from the termina-
tion device to the RS-232-C port on the host computer. Power
and I/O expander bus connections follow the same connector
assignments common to most INFI 90 modules (connector P1
for power, connector P2 for I/O expander bus).
IMMPI01 Multi-Function Processor Interface Module
The IMMPI01 Multi-Function Processor Interface Module (MPI)
provides the INICT03 INFI-NET to Computer Transfer Module
(ICT) with communication ports. It contains I/O ports (i.e.,
RS-232-C, SCSI) that the ICT module can use. The MPI module
is an interface device that handles I/O to and from the ICT
module. Control and data signals from the ICT module travel
through a 60-pin ribbon cable to the MPI module.
The MPI module connects to an NTMP01 Multi-Function Pro-
cessor Termination Unit or NIMP01 Multi-Function Processor
Termination Module. Input and output signals enter or leave
the MPI circuit board through a NKTU01, NKTU02, NKTU11, or
NKTU12 cable to the termination device. The SCSI connection
comes out of the faceplate for connection to a host computer.
FEATURES
The INFI-NET to computer interfaces have the following fea-
tures:
•INFI-NET, which provides a plantwide communication net-
work, is used.
•INFI-NET time synchronizes the control process plantwide.
•Each INFI-NET node can operate independently of other
INFI-NET nodes.
•Computer interface modules provide localized start-up and
shutdown on power failure without operator intervention.
•The 10-megabaud response rate gives timely information
exchange.
•The ICT modules package process information for maxi-
mum transmission efficiency.

INTRODUCTION
INSTRUCTION CONTENT
I-E96-610A 1 - 5
•The computer interface modules handle four message
types: broadcast, time synchronization, multicast and NIS
poll.
•All messages contain cyclic redundancy check codes (CRC)
and checksums to ensure data integrity.
INSTRUCTION CONTENT
This manual consists of eight sections and six appendices.
Introduction Provides an overview of the computer interfaces. It contains
module descriptions, features, and specifications.
Description and
Operation Explains module operation.
Installation Covers handling guidelines and explains how to configure the
modules before placing them into operation.
Operating Procedures Provides information about normal module operation.
Troubleshooting Explains how to troubleshoot the modules using error codes
and lists the corrective action.
Maintenance Contains a maintenance schedule for the modules.
Repair/Replacement
Procedures Explains how to replace the modules.
Support Services Explains the customer training Bailey Controls Company pro-
vides and information about ordering replacement parts.
Appendices Provides information on termination unit and module configu-
ration.
HOW TO USE THIS MANUAL
Read this manual in sequence. It is important to become famil-
iar with the entire contents of this manual before using the
modules. This manual is organized to enable quick information
retrieval.
1. Read and perform all steps in Section 3.
2. Thoroughly read Section 4 before applying power to the
computer interfaces.
3. Refer to Section 5 if a problem occurs. This section will help
to diagnose and correct a problem.
4. Refer to Section 6 for scheduled maintenance require-
ments.

INTRODUCTION
GLOSSARY OF TERMS AND ABBREVIATIONS
1 - 6 I-E96-610A
®
5. Go to Section 7 to find instructions on how to replace a
module.
6. Refer to Section 8 for a list of replacement parts and war-
ranty information.
GLOSSARY OF TERMS AND ABBREVIATIONS
Table 1-1 lists the terms and abbreviations used in this
instruction that are unique to Bailey Controls Company.
REFERENCE DOCUMENTS
Table 1-2 lists the documents that provide additional informa-
tion for related hardware/software. Refer to them as needed.
NOMENCLATURE
Table 1-3 lists the nomenclatures of the modules and associ-
ated equipment used in this instruction.
Table 1-1. Glossary of Terms and Abbreviations
Term Definition
Checksum A value computed from a data stream by treating each element as a number and
computing a sum of the elements.
Exception Report Information update generated when the status or value of a point changes by more
than a specified significant amount; abbreviated as XR.
Node A point of interconnection to a network.
NVRAM Nonvolatile random access memory. Retains stored information when power is
removed.
Termination Module Provides input/output connection between plant equipment and the INFI 90/ Net-
work 90®modules.
Termination Unit Provides input/output connection between plant equipment and the INFI 90/ Net-
work 90 modules.
Table 1-2. Reference Documents
Number Document
I-E96-200 Function Code Applications Manual
I-E96-401 NIMP01/02 Multi-Function Processor Termination Module
I-E96-408 NICL01 Communication Termination Module
I-E96-413 NIMF01/02 Multi-Function Controller Termination Module
I-E96-422 NTCL01 Communication Termination Unit
I-E96-427 NTMF01 Multi-Function Controller Termination Unit
I-E96-428 NTMP01 Multi-Function Processor Termination Unit
® Network 90 is a registered trademark of Elsag Bailey Process Automation.

INTRODUCTION
SPECIFICATIONS
I-E96-610A 1 - 7
SPECIFICATIONS
Refer to Table 1-4 for the specifications of the modules making
up the INFI-NET to Computer Interfaces.
Table 1-3. Nomenclature
Nomenclature Hardware/Description
IEMMU01/02 Module mounting unit
INICI01
INICT01
INNIS01
INFI-NET to computer interface
Requires modules:
INFI-NET to computer transfer module
Network interface slave module
INICI03
IMMPI01
INICT03
INNIS01
INFI-NET to computer interface
Requires modules:
Multi-function processor interface module
INFI-NET to computer transfer module
Network interface slave module
NFTP01 Field termination panel
NICL01 Communication termination module
NIMF01 Multi-function controller termination module
NIMF02 Redundant multi-function controller termination module
NIMP01 Multi-function processor termination module
NKLS01/11 Termination cable, INNIS01 to NTCL01
NKLS02/12 Termination cable, INNIS01 to NICL01
NKTU01/11 Termination cable, INICT01 to NTMF01 or IMMPI01 to
NTMP01
NKTU02/12 Termination cable, IMMPI01 to NIMP01
NTCL01 Communication termination unit
NTMF01 Multi-function controller termination unit
NTMP01 Multi-function processor termination unit
NTMU01/02 Termination mounting unit
Table 1-4. Specifications
Property Characteristic/Value
IMMPI01
Communication Ports Two RS-232-C and one SCSI
Power Requirements +5 VDC @ 415 mA; 2.08 W typical
Mounting Occupies one slot in a standard INFI 90 module mounting unit
INNIS01
Memory 208 kbytes RAM
64 kbytes ROM

INTRODUCTION
SPECIFICATIONS
1 - 8 I-E96-610A
®
INNIS01 (continued)
Power Requirements +5 VDC @ 900 mA; 4.50 W typical
+15 VDC @ 5 mA; 0.08 W typical
-15 VDC @ 200 mA; 3.00 W typical
System Capability 62,500 nodes in the system; 250 nodes on a loop. Any combination of
PCU, MCS, OIS, or ICI interfaces.
Communication Rates 2 Mbaud or 10 Mbaud
Mounting Occupies one slot in standard INFI 90 module mounting unit.
INICT01
Ports Two full duplex serial EIA standard RS-232-C
Memory 256 kbytes ROM
512 kbytes RAM
80 kbytes NVRAM
Power Requirements +5 VDC @ 4.2 A; 21 W typical
+15 VDC @ 40 mA; 0.6 W typical
-15 VDC @ 20 mA; 0.3 W typical
Communication Rates 50 to 19,200 baud (user-selectable)
Mounting Occupies two slots in standard INFI 90 module mounting unit
INICT03
Memory 512 kbytes ROM
2 Mbytes RAM
Power Requirements +5 VDC @ 1.958 A; 9.8 W typical
Communication Rates 50 to 19,200 baud (user-selectable) or 4 Mbytes/sec (SCSI port)
Mounting Occupies one slot in standard INFI 90 module mounting unit
All INFI-NET Communication Modules
Electromagnetic/Radio
Frequency Interference Values not available at this time. Keep cabinet doors closed. Do not use communication equipment any closer than 2 meters from the cabi-
net.
Ambient Temperature 0°to 70°C (32°to 158°F)
Relative Humidity 0% to 95% up to 55°C (131°F)(noncondensing)
0% to 45% above 55°C (131°F)(noncondensing)
Atmospheric Pressure Sea level to 3 km (1.86 mi.)
Air Quality Noncorrosive
Certification The INFI-NET to computer interface modules are CSA certified for use
as process control equipment in an ordinary (nonhazardous) environ-
ment.
The INFI-NET to computer interface modules are Factory Mutual
approved for use in Class I, Division 2, hazardous locations.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
Table 1-4. Specifications (continued)
Property Characteristic/Value

INTRODUCTION
I-E96-610A 2 - 1
SECTION 2 - DESCRIPTION AND OPERATION
INTRODUCTION
INFI-NET is a unidirectional, high-speed serial data highway
that can be used by all INFI 90 modules. The INNIS01 Network
Interface Slave Module (NIS) and the INICT01 INFI-NET to
Computer Transfer Module make up the INICI01 INFI-NET to
Computer Interface. The NIS module, INICT03 INFI-NET to
Computer Transfer Module, and the IMMPI01 Multi-Function
Processor Interface Module make up the INICI03 INFI-NET to
Computer Interface.
MODULE INTEGRITY
All INFI-NET communication modules have normal INFI 90
security functions that insure module integrity. The module
hardware checks for illegal addresses and monitors the
machine fault timer (MFT) and the I/O expander bus clock. If a
module detects an illegal address, it generates a bus error and
displays an error code on the faceplate LEDs. If the micropro-
cessor fails to reset the MFT timer, it expires. When this hap-
pens, the communication module stops and the status LED
turns red. Module hardware also monitors the I/O expander
bus clock. If there is no clock signal, the module hardware gen-
erates an interrupt.
INNIS01 NETWORK INTERFACE SLAVE MODULE
The NIS module serves as an I/O module to both the INICT01
and INICT03 modules. While each computer interface uses dif-
ferent INFI-NET communication modules, the NIS module
operates with each communication module in the same man-
ner. This section provides an overview of INFI-NET communi-
cation module operating theory.
Exception Reports
Each INFI 90 module establishes exception reporting parameters
for process inputs (points). Some examples of exception report
parameters are high and low alarm limits, minimum and maxi-
mum report time intervals, and percent of change in span limits.
When a point changes more than a given parameter, or an alarm
state changes, the module generates an exception report.
The computer transfer module polls modules (via the Control-
way or module bus) for exception reports, and packs the excep-
tion reports having a common node destination. Packing
places all exception reports for a destination (or multiple desti-
nations) into one message (of variable length). The NIS module
