Bakers Pride DANTE Series User manual

DANTE SERIES
GAS CHARBROILER
GLO-STONES/RADIANT C, F, L
Installation and
Operation
Instructions
2M-Z24018 Rev. A 05/21

2
2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
TO THE PURCHASER
Post in a prominent location the instructions to be followed in
the event that an operator smells gas. Obtain this information
from your local gas supplier.
FOR YOUR PROTECTION
DO NOT store or use gasoline or other ammable vapors and
liquids in the vicinity of this or any other appliance. Do not
spray aerosols in the vicinity of this appliance when it is in
operation.
WARNING
Improper installation, adjustment, operation, alteration,
service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance
instructions thoroughly before installing, operation, servicing
this appliance.
WARNING
Installation, maintenance and repairs should be performed
by a BP Authorized Service and Parts (ASAP) company
technician or other qualied personnel. Installation,
maintenance or repairs by an unauthorized and unqualied
personnel will void the warranty.
WARNING
Installation and all connections must be made according to
local codes in force. In the absence of local codes in North
America, the installation must conform with the National
Fuel Gas Code, ANSI Z223.1/NFPA 54 or the Natural Gas
and Propane Installation Code CSA B149.1 as applicable. In
Australia, the appliance must installed in compliance with AS/
NZS 5601.
WARNING
During the warranty period if a customer elects to use a
non-original part or modies an original part purchased
from Bakers Pride and/or its Authorized Service and Parts
(ASAP) companies, this warranty will be void. In addition,
Bakers Pride and its afliates will not be liable for any claims,
damages or expenses incurred by the customer which arises
directly or indirectly, in whole or in part, due to the installation
of any modied part and/or received from an unauthorized
service center.
WARNING
Adequate means must be provided to LIMIT the movement or
this appliance without depending on the gas or electrical cord
connection. Single appliances equipped with legs must be
stabilized by installing anchor straps. All appliances equipped
with casters must be stabilized by installing restraining chains.
WARNING
An appliance equipped with casters and a exible gas line
must be connected to the gas supply with a quick disconnect
device. In North America this quick disconnect must comply
with ANSI Z24.41. In Australia, the quick disconnect must
comply with AS 4627.
WARNING
DO NOT alter or remove structural material on the appliance
to accommodate placement under a ventilation hood.
WARNING
The appliance is NOT jet stream approved. DO NOT clean
the appliance with a water jet.
WARNING
DO NOT use an open ame to check for gas leaks!
NOT sit or stand on this appliance. The appliance’s front
panel, tank, splash back, tank cover, workshelf, drain board
is not a step. Serious injury could result from slipping, falling
or contact with hot surface.
WARNING
NEVER use the appliance as a step for cleaning or accessing
the ventilation hood. Serious injury could result from slips,
trips or from contacting hot surface.
WARNING
This appliance is intended for indoor use only.
WARNING
DO NOT operate appliance unless all panels and access
covers are attached correctly.
WARNING
It is recommended that this appliance be inspected by a
qualied service technician for proper performance and
operation on a yearly basis.
WARNING
There is an open ame inside this appliance. The unit may
get hot enough to set nearby materials on re. Keep the area
around the appliance free from combustibles.
WARNING
DO NOT supply the appliance with a gas that is not indicated
on the data plate. If you need to convert the appliance to
another type of fuel, contact your dealer.
WARNING
If gas ow to appliance is interrupted, or pilots extinguish,
wait 5 minutes before attempting to relight the pilot to allow
any residual gas in appliance to dissipate.
WARNING
Ensure that the appliance can get enough air to keep the
ame burning correctly. If the ame is starved for air, it can
give off a dangerous carbon monoxide gas. Carbon monoxide
is a clear odorless gas that can cause suffocation.
WARNING
This appliance is intended for professional use only and
should be operated by fully trained and qualied personnel.
WARNING
In North America, gas appliances equipped with casters must
be installed with connectors that comply with the Standard for
Connectors for Movable Gas Appliances, ANSI Z21.69.CSA
6.16 Latest Edition. This connection should include a quick
disconnect device that complies with the Standard for Quick
Disconnect Devices for Use With Gas Fuel ANSI Z21.41.CSA
6.9 Latest Edition. In Australia, an appliance equipped with
casters and a exible gas line must be connected to the gas
supply with a quick disconnect device that complies with AS
4627 and a restraining cable. The restraining cable must not
exceed 80% of the length of the exible gas line.
WARNING
This appliance is not intended for use by person (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play
with the appliance
TO THE PURCHASER, OWNER AND STORE MANAGER
Please review these warnings prior to posting them in a prominent location for reference.

2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
3
AUSTRALIAN ADDENDUM TO L25-001 R3 . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
GAS HOOK UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
GAS SETTINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
LIGHTING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
BROILER SHUT DOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
GLO-STONES C, F, L MODELS WITHOUT SAFETY PILOT . . . . . . . . . . . . . . . . . . 8
BROILER SHUT DOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
RADIANT C, F, L MODELS WITH SAFETY PILOT . . . . . . . . . . . . . . . . . . . . . . . 9
GLO-STONES C, F, L MODELS WITH SAFETY PILOT . . . . . . . . . . . . . . . . . . . . . 9
INITIAL SET-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
RADIANT C, F, L MODELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
GLO-STONES C, F, L MODELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
DAILY CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
WEEKLY CLEANING MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
IMPORTANT OPERATION INSTRUCTIONS RECAP . . . . . . . . . . . . . . . . . . . . . 13
ANNUAL MAINTENANCE AND INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . 13
TYPICAL RADIANT C, F, L ILLUSTRATION (MODEL C-36 SHOWN) . . . . . . . . . . . . . . . . . 14
TYPICAL GLO-STONES C, F, L SERIES ILLUSTRATION (MODEL C-36 SHOWN) . . . . . . . . . . 15
ACCESSORY/ PARTS LIST FOR RADIANT/ GLO-STONES C, F, L SERIES MODELS . . . 16
WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
TABLE OF CONTENTS

4
2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
This appliance must be installed to the requirements of AS/NZS5601.1, local gas and electric
authority and any other relevant statutory regulations.
The appliances covered by this manual are for use only with the gas type displayed on the
data plate.
This appliance is for installation in non-combustible locations only.
Normal Gas Consumption of Models:
(F, C, L) 24R 66 Mj/h
(F, C, L) 36R 115.5 Mj/h
(F, C, L) 48R 165 Mj/h
(F, C, L) 60R 214.5 Mj/h
(F, C, L) 72R 264 Mj/h
Test Point Pressure:
Natural Gas 1.0 kPa
Propane 2.5 kPa
Approximate Overall Dimensions and Weights
Type Model Height with Legs
(cm) Width (cm) Depth (cm) Shipping Weight (kg)
Total Cook
Area (cm 2)
F
24R 100 61 90 99.7 3,314
36R 100 91 90 133 5,233
48R 100 122 90 192 7,145
60R 100 152 90 256 9,063
72R 100 183 90 297 11,001
C
24R 64.5 61 90 95.2 3,314
36R 64.5 91 90 159 5,233
48R 64.5 122 90 193 7,145
60R 64.5 152 90 256 9,063
72R 64.5 183 90 320 11,001
L
24R 54.1 61 90 95.2 3,314
36R 54.1 91 90 159 5,233
48R 54.1 122 90 193 7,145
60R 54.1 152 90 256 9,063
72R 54.1 183 90 320 11,001
The gas supply connection to this appliance is located in the rear of the appliance
approximately 54 cm from the base of the appliance for F models, 23 cm from the base for
C models, and 13 cm for L models.
If this appliance cannot be adjusted to perform correctly contact your local authorized service
company or call the factory at the number on the back page of this manual.
AUSTRALIAN ADDENDUM TO L25-001 R3

2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
5
Units are to be installed in non-combustible locations only to utilize a 0” (0 mm) minimum clearance to non-
combustible construction. Not approved for installations in combustible constructions. In North America this
installation must conform to local codes. In the absence of local codes, the installation must conform with
the National Fuel Gas Code, ANSI Z223.1: Natural Gas Installation Code, CAN/CGA B149.1; or Propane
Installation Code CAN/CGA B149.2 as applicable.
• The appliance and its individual shutoff valve must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in excess of 1/2 psi (3.45 kPa).
• The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff
valve during any pressure testing of the gas supply piping system at test pressures equal to or less than
1/2 psi (3.45 kPa).
• Uncrate unit and put into place. The hitch pins securing burners must be removed. This will permit the
burners to be readily removed for weekly inspection, cleaning and future service.
• FOR INSTALLATION ON LEGS: A set of 6” legs is packed in the top section of the broiler (unless unit is
specically ordered without). A threaded receptacle is located near each corner base of the machine. Each
leg has a similar mating thread. Raise unit sufciently to allow legs to be screwed tightly into receptacles.
Level the unit by adjusting bottom feet of legs. Unit must be level to perform properly. FOR INSTALLATION
WITH CASTERS: This installation shall be made with a connector that complies with the Standard for
Connectors for Movable Gas Appliances, ANSI Z21.69, or Connectors for Movable G as Appliances, CAN/
CGA-6.16 ,and with a quick-disconnect device that complies with the Standard for Quick-Disconnect
Devices for Use With Gas Fuel, ANSI Z21.41, or Quick-Disconnect Devices for Use With Gas Fuel, CAN1-
6.9 (North America).
• Provide an adequate means of restraint without depending on the gas connector, the quick- disconnect
device or its associated piping to limit the appliance movement.
• The restraint (i.e. heavy gauge chain or cable) should be 1000# (4.45 kN) test load and should be attached
to the building structure by some substantial means, such as the use of anchor bolts into concrete, or lag
screws into studs in wooden structures. The opposite end of the restraint should be afxed solidly to the
base of the unit at the back where it will not become pulled out or cause damage to the appliance.
• If disconnection of this restraint becomes necessary at any time, make sure it is reinstalled after the unit is
placed in its original position and before the unit is placed in operation.
CAUTION!
• Only two of the four casters supplied have brakes. Be sure to install the two casters with brakes at the front
of the unit. NOTE: Front brakes should be locked before unit is placed in operation.
• COUNTER MODELS: All counter equipment is to be sealed to the counter to comply with applicable
sanitation standards. A bead of silicone sealant, approximately 1/2” (13 mm) wide, is to be applied to the
bottom of the unit approximately 1/4” (6.5 mm) in from the front, back and side edges.
• We suggest a Dow Corning®, GE® or Permatex® silicone ‘RTV’ adhesive sealant or equivalent. (See NSF
Basic Criteria C-2 for details).
INSTALLATION

6
2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
An adequate gas supply is imperative Undersized lines or low-pressures will restrict the volume of gas
required for satisfactory performance. A steady supply pressure between 7’’ and 8’’ w.c. (1.75 and 2 kPa) for
natural gas or 11’’ to 12” w.c. (2.75 to 3.0 kPa) for propane gas is required. With all gas appliances operating
simultaneously, the manifold pressure on any appliance should not show any appreciable drop. Fluctuations
of more than 25% on natural and 10% on propane gas will create pilot problems, and affect burner-operating
characteristics. Contact your gas company for correct supply line sizes. After connection, all newly installed
equipment should be checked for correct gas pressure by a certied gas serviceman. The unit should be
connected ONLY to the type of gas for which it is equipped. Check the type of gas on serial plate.
A. Attach regulator supplied with machine to inlet of the gas manifold. Be sure regulator is connected so that
gas ow is in the direction of the arrow on the bottom of the regulator. Using a regulator other than the
one supplied with the unit will void the warranty.
B. The manifold pressure must be maintained at the pressure marked on the serial plate: 4” w.c. (1.0 kPa)
for natural gas and 10” w.c. (2.5 kPa) for propane gas.
C. Use pipe joint compound that is suitable for use with LP gas on all threaded connections.
D. Turn off all burner valves.
E. Turn on gas supply and check all connections for leaks using ONLY a leak checking uid or soapy water.
NEVER use an open ame to check for gas leaks.
F. Provision must be made for adequate air supply for both appliance and occupants.
G. Keep area in front of unit free from obstructions that could block ow of combustion and ventilation air.
H. Be certain that adequate clearance is maintained so that air openings in front of unit are not blocked
and any subsequent service can be performed. No such clearance is required on the sides. Sufcient
clearance at rear is required for gas connections, regulator, and any master shutoff valve(s) installed. Be
sure there is no obstruction in front.
GAS HOOK UP

2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
7
LIGHTING INSTRUCTIONS:
Regulator pressure must be measured and adjusted before the unit goes into service, following installation
and when operational performance is in question. A soft blue ame, just short of a yellow tip, gives the best
results; combustion air can be adjusted by opening or closing the air shutter slightly.
Radiant Series C, F, L Models without safety pilot
A. Turn all burners to OFF.
B. Remove the top grid(s).
C. Remove the last radiant(s) closest to
GAS SETTINGS
Regulator pressure must be measured and adjusted before the unit goes into service, following installation
and when operational performance is in question. A soft blue ame, just short of a yellow tip, gives the best
results; combustion air can be adjusted by opening or closing the air shutter slightly.
D. Turn the runner tube valve to ON.
E. Light the runner tube. (Note: If the runner tube does not light, wait a the side(s) of the unit. few seconds,
then try again.)
F. Replace the radiant(s) and top grid(s). Push and turn the burner valves to operate the individual burners
as needed.
G. If any burner fails to light from the runner tube, shut off all the burners and the runner tube. Do not attempt
to re-light for ve minutes after shutdown. Repeat steps a thru f. If unit still fails to operate properly,
contact authorized service personnel.
Broiler Shut Down
Turn all burners to OFF.
Turn the runner tube valve to OFF.

8
2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
GLO-STONES C, F, L SERIES MODELS WITHOUT SAFETY PILOT
A. Turn all burners to OFF.
B. Remove the top grid(s).
C. Turn the runner tube valve to ON.
D. Light the runner tube through the gap in the front of the coal support as shown. (Note: If the runner tube
does not light, wait a few seconds, then try again.)
E. Replace the top grid(s). Push and turn the burner valves to operate the individual burners as needed.
F. If any burner fails to light from the runner tube, shut off all the burners and the runner tube. Do not attempt
to re-light for ve minutes after shutdown. Repeat steps a thru f. If unit still fails to operate properly,
contact authorized service personnel.
Broiler Shut Down
Turn all burners to OFF.
Turn the runner tube valve to OFF.

2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
9
GLO-STONES C, F, L SERIES MODELS WITH SAFETY PILOT
A. Turn all burners to OFF.
B. Remove the top grid.
C. Remove a radiant.
D. Turn the shut off valve to ON.
E. Press and hold the reset (blue) button on the safety pilot valve. Wait 15-30 seconds. Light the runner
tube. DO NOT release the reset button. (NOTE: If the runner tube does not light, wait a few seconds,
then try again. NOTE: When lighting the runner tube for the rst time after connecting the unit to the gas
source, the light time will probably increase to 1-2 minutes.)
F. Wait an additional 15-30 seconds. Release the reset button. The runner tube should remain lit. (NOTE: If
the runner tube fails to ignite, repeat step 5. If the runner tube fails to ignite after three attempts, contact
an authorized Bakers Pride service agent.)
G. Replace the radiant and top grid.
H. Push and turn the burner valves to operate the individual burners as needed.
Broiler Shut Down
Turn all burners to OFF.
Turn the runner tube valve to OFF.
Glo-Stones C, F, L Series -S Models with safety pilot
Lighting and shut down of these models is identical to that of the RMB-S models except that there are no
radiants to be removed. Simply light the runner tube by inserting the ignition device through the gap between
the front burner support and the coal support as shown in the lighting instructions for the Glo-Stones C, F, L
Series Models without safety pilot.

10
2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
All Models
PROPER SET UP OF THE BROILER - After the installation of the broiler by a qualied technician, a thorough cleaning is
necessary. After this cleaning, be sure the broiler is set up properly.
TOP GRID - Your top cooking grid has two positions, either at or tilted. Whenever you are broiling, you must use the tilted
position. This allows grease to drain into the front trough, reducing both smoke and are-up. Simply push down on the top grid
handle and pull forward to set the tilted position.
INITIAL SET-UP

2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
11
RADIANT C, F, L SERIES MODELS
STAINLESS STEEL RADIANT - It is very important that the stainless steel radiants are placed over the burners. This will
provide radiant heat and protect the burners from dripping grease.
PREHEATING - It is necessary to preheat a cold broiler each time before cooking. The recommended time is 3-5 minutes for
radiant style charbroilers, at which time the cooking grid should be hot enough to cook on without sticking, and will produce
the proper searing effect.

12
2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
GLO-STONES C, F, L SERIES MODELS
COAL SUPPORT - The coal support must be installed so that it is pushed against the back wall of the unit. This creates an air
gap over the runner tube to allow proper ventilation.
COALS - Use only Glo-Stones supplied by Bakers Pride. Do not use lava rock or other replacement coals. They do not
perform as well or last as long as the Glo-Stones that were designed for this application. Place the coals evenly across the
surface of the coal support. Do not pile them up. This will cause excessive are up, reduce ventilation, and cause overheating
of the valves and other components.
PREHEATING - It is necessary to preheat a cold broiler each time before cooking. The recommended time is 15-20 minutes
for coal style charbroilers, at which time the cooking grid should be hot enough to cook on without sticking, and will produce
the proper searing effect.
All Models
FLARE-UP - A certain amount of are-up is desirable when you are charbroiling in order to avor your products. However,
excess are- up will burn your products and leave a bitter taste. With are-up, one simple formula holds true. The hotter the
broiler and the higher the fat content of the food, the more are-up you will have. Conversely, the lower the heat and lower the
fat content, the less are-up you will have.
FLARE-UP PROBABILITY CHART
Heat Level High Fat Content Low Fat Content
High Heat High Moderate
Low Heat Moderate Low

2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
13
CLEANING AND MAINTENANCE
DAILY CLEANING AND MAINTENANCE
TOP GRID - The top grid can be cleaned in numerous ways. The recommended procedure is to remove the grid and clean
the frame, tubes and angles on front, sides and back with steel wool. The rods need only be scraped free of all cooking
debris, especially the underside of the rods, using the Bakers Pride scraper provided. The light oily sheen will aid in cooking,
acting like a seasoned iron skillet.
OUTER SIDES AND FRONT - The outer sides and front are stainless steel. Any reputable cleaner can be used to clean
these surfaces.
INNER COOKING AREA - These surfaces are also stainless steel. A paste type oven cleaner will work best to clean them,
but be sure to remove all residues before you resume cooking operation. The grease collection pan should be emptied daily
and the grease disposed of properly.
WATER TUB - The water tub is designed to reduce air-up and to eliminate ash back, which is common on radiant style
charbroilers. Flaming grease which drips down will extinguish as soon as it hits the water. The water tub should never be
allowed to run dry and should be emptied daily and the grease disposed of properly.
Maintaining a clean, well-kept broiler will ensure long-lasting cooking performance and prolong it’s life.
WEEKLY CLEANING MAINTENANCE
Generally, with this style broiler, you can follow the directions for daily cleaning. However, your top grid can be soaked in a
detergent degreasing solution weekly or monthly. After this soaking, your grid will need to be thoroughly rinsed with fresh
water and then re-seasoned.
IMPORTANT OPERATION INSTRUCTIONS RECAP
1. Always cook in a tilted position. This will allow excess grease to drain into the front grease trough and reduce smoke and
are-up.
2. Keep the top cooking grids clean, especially the underside of the rods. This will insure that the grease will drain toward
the front grease trough.
Remember the following formula for are-up:
High Heat + High Fat Content = Maximum Flare-up
Low Heat + Low Fat Content = Minimum Flare-up
ANNUAL MAINTENANCE AND INSPECTION
Disconnect all gas sources before you perform this procedure. The
unit should be inspected annually by a qualied gas appliance service
personnel.
The main burner valves should be greased annually, or as necessary,
to maintain smooth operation and prevent gas leakage.
1. Remove the knobs from the front of the unit.
2. Remove the outer front panel.
3. Loosen the two screws securing the collar to each valve.
4. Carefully disassembly the valves. See Figure 6.
5. Clean all parts.
6. Apply high temperature valve grease to the rotor assembly.
NOTE: The valve grease must be suitable for all gas types.
Reassemble the valves and broiler.

14
2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
TYPICAL RADIANT C, F, L SERIES ILLUSTRATION
NOTE: Your unit may vary from this typical diagram.
Model C-36 Shown

2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
15
TYPICAL GLO-STONES SERIES ILLUSTRATION
NOTE: Your unit may vary from this typical diagram.
Model C-36 Shown

16
2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
ACCESSORY/ PARTS LIST FOR RADIANT / GLO-STONES C, F, L SERIES MODELS
REF NO. Description
1 Top Grid, Standard
2 Radiant
3 Burner
4 Burner retaining clip (not shown)
5 Runner tube (not shown)
6 Water Tub, Left Hand
7 Water Tub, Right Hand
8 Grease Box
9 Leg, 6" (not shown)
10 Caster, 6" (not shown)
11 Knob, main burner
12 Knob, runner tube
13 Scraper (not shown)
14 Brush (not shown)
15 Regulator
16 Utility bar
17 Service shelf
18 Service shelf support (not shown)
19 LH Frame mtg brkt (not shown)
20 RH Frame mtg brkt (not shown)
21 Grease trough
22 Outer front
23 Gas valve, main burner
REF NO. Description
24 Gas valve, runner tube (not shown)
25 Orice, main burners (not shown)
26 Orice, runner tube (not shown)
27 Manifold assembly (not shown)
28 Manifold heat shield
29 Inner heat shield (not shown)
30 Inner front (not shown)
31 Front burner support
32 Outer side
33 Inner side
34 Side bafe
35 Side bafe support (not shown)
36 Top grid center support (not shown)(48/60/72 only)
37 Outer back (not shown)
38 Inner back
39 Back stiffener (not shown)
40 Back splash liner
41 Rear burner support
42 Shelf
43 Inner bottom (F only, not shown)
44 Outer bottom (not shown)
45 Coal support (see Glo-Stones illustration)
46 Coals (see Glo-Stones illustration)
Not all parts are illustrated, nor are all parts are listed. If you need a part that is not listed here, call Bakers Pride for a quote.
Always have your model and unit serial numbers available when phoning or ordering.
THESE PARTS SOLD THRU OUR DEALER NETWORK ONLY.

2M-Z24018: Bakers Pride - Dante Series Gas Charbroiler
17
LIMITED EQUIPMENT WARRANTY
Baker's Pride warrants to the original purchaser of new Baker's Pride
products to be free from defects in material or workmanship,undernormal
and proper use and maintenance service as specified by Bakers Pride
and upon proper installation and start-up in accordance with the
instructions supplied with each Bakers Pride unit. Baker's Pride
obligation under this warranty is limited to a period of one [1] year
from the date of original installation, or eighteen [18] months from
original invoice date, whichever occurs first. Defects that occur as a
result ofnormal use,within the time period and limitations defined in
this warranty, will at Baker's Pride discretion have the parts replaced or
repaired by Baker's Pride or a Baker's Pride-authorized service agency.
THIS WARRANTY IS SUBJECT TO ALL LISTED CONDITIONS
Repairs performed under this warranty are to be performed by an
Bakers Pride authorized service agency. Baker's Pride will not be
responsible for charges incurred or service performed bynon-
authorized repair agencies. Inall cases, the nearest Baker's Pride-
authorized service agency must be used. Baker's Pride will be responsible
for normal labor charges incurred in the repair or replacement of
awarrantied product within 50miles (80.5 km) of an authorized
service agency. Time and expense charges for anything beyond that
distance will be the responsibility of the owner. All labor will need to be
performed during regular service hours. Any overtime premium will be
charged to the owner. For all shipments outside the U.S.A. and Canada,
please see the International Warranty for specific details. Itisthe
responsibility ofthe owner to inspect and report any shipping damage
claims, hidden or otherwise, promptly following delivery. No mileage or
travel charges will be honored on any equipment that is deemed portable.
In general, equipment with a cord and plug weighing less than 50 lb. (22.7
kg) is considered portable and should be taken or shipped to the closest
authorized service agency, transportation prepaid.
CONTACT
Should you require any assistance regarding the operation or maintenance
of any Baker's Pride Manufacturing; phone or email our service
department. Inall correspondence provide the model number and serial
number of the unit needing service;include the voltage or gas type.
Normal Business Hours: 8:00 a.m. to4:30 p.m. Central
Telephone: [phone] Tech Service Option 2
Email: [email protected]
www.bakerspride.com
WARRANTY EXCLUSIONS
THE FOLLOWING WILL NOT BECOVERED UNDER WARRANTY.
Baker's Pride sole obligation under this warranty is limited to either
repair or replacement parts, subject tothe additional
limitations detailed below. This warranty neither assumes nor
authorizes any person to assume obligations other than those
expressly covered bythis warranty.
• Any product which has not been used, maintained, orinstalled in
accordance with the directions published in the appropriate
installation sheet and/or owner’s manual, including incorrect gas or
electrical connection. Baker's Pride is not liable for any unitwhich
has been mishandled, abused, misapplied, subjected to harsh
chemicals, modified by unauthorized personnel, damaged by flood,
fire, or other acts of nature [or God], or which have an altered or
missing serial number.
• Installation, labor, and job checkouts, calibration of heat controls,
air and gas burner/bypass/pilot adjustments, gas or electrical system
checks, voltage and phase conversions, cleaning of equipment, or
seasoning of griddle surface.
•Replacement of fuses or resetting of circuit breakers, safety
controls, orreset buttons.
•Replacement of broken or damaged glass components, quartz
heating elements, and light bulbs.
•Labor charges for all removable and consumable parts in gas
charbroilers and hotplates, including but notlimited to burners,
grates, and radiants.
•Any labor charges incurred by delays, waiting time, or operating
restrictions that hinder a service technician’s ability to perform
service.
•Replacement of parts that fail orare damaged due to normal wear
or labor for replacement of parts that can be replaced during a daily
cleaning routine, such as but notlimited to silicone belts, PTFE non-
stick sheets, control labels, knobs, bulbs, fuses, quartz heating
elements, baskets, racks, and grease drawers.
•Any economic loss of business or profits.
•Non-OEM parts. Use of non-OEM parts without Baker's Pride
approval will void the warranty.
•Units exceeding one [1] yearfrom original installation date, or more
than eighteen [18] months from original invoice date, whichever
comes first.
ADDITIONAL WARRANTIES
• Specific/chain-specific equipment may have additional and/or
extended warranties.
The foregoing warranty is in lieu of any and all other warran�es
expressed or implied and cons�tutes the en�re warranty.

BAKERS PRIDE • www.bakerspride.com
265 Hobson St. • Smithville, TN 37166
Telephone: [phone]
Printed in the U.S.A. • 2M-Z24018 • Rev. A 05/21
Specications are subject to change without notice.
is a registered trademark of Bakers Pride®, A Middleby Company. All rights reserved.
BUILT BY CRAFTSMEN. TESTED BY TIME. ®
