BakerStone Original Series User manual

Original Series
Outdoor Multi-function
Cooking Center
Product Guide
Model # BSO4501-EBK-OOO-000
Important, Retain for Future Reference: Read Carefully
WARNING: This product guide contains important information
necessary for the proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling
and using the appliance.
Follow all leak-check procedures in the Product Guide before
using the appliance.
This appliance is for outdoor use only.
If you smell gas:
Extinguish any open flame.
Open lid.
If odor continues, keep away from the appliance and
immediately call your gas supplier or your fire department.
Do not store or use gasoline or other flammable liquids or
vapors in the vicinity of this or any other appliance.
An LP cylinder not connected for use shall not be stored in the
vicinity of this or any other appliance.
Failure to follow these instructions could result in fire or explosion
which could cause property damage, personal injury or death.
DANGER
WARNING
www.bakerstonebox.com - (855) 657 OVEN (6836)

WARNINGS
Failure to follow these instructions could result in fire or explosion which could cause
property damage, personal injury or death.
The installation must conform with local codes or, in the absence of local
codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or the Natural
Gas and Propane Installation Code, CSA B149.1, or the Propane Storage and Handling
Code,CSA B149.2, or the Standard for Recreational Vehicles, ANSI A119.2/NFPA 1192, and
CSA Z240 RV Series, Recreational Vehicle Code, as applicable.
This appliance shall be used only outdoors, and shall not be used inside a building,
garage or any other enclosed area.
This appliance is not intended to be used in or on a recreational vehicle or boat.
While using this appliance maintain a minimum clearance from sides and back of at
least 36in (0.9m) between appliance and any combustible material or contruction. Do
Clean and inspect the supply hose and regulator before each use of the appliance.
If there is evidence of abrasion, wear, cuts, or leaks, the hose must be replaced prior
to using the appliance. Only the included hose or a replacement supplied by the
manufacturer shall be used with the appliance.
The appliance is only to be fueled by a LP (liquid propane) gas cylinder measuring 12”
(30.5cm) diameter and 18” (45.7cm) high with a 20lb. (9.1kg) capacity. The gas cylinder
(tank) must incorperate a Type 1 cylinder valve and an over filling protection device
(OPD).
The LP gas cylinder must be constructed and marked in accordance with the
Specifications for LP gas Cylinders of the U.S. Department of Transportation (D.O.T.) or
the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods
and Commission, CAN/CSA-B339, as applicable.
Do not unhook or replace the LP Gas Cylinder while the appliance is in use.
connections and fittings. Do not use an open flame to check for leaks.
This appliance is not intended for commercial use.
The use of alcohol, prescription or non-prescription drugs may impair the consumer’s
ability to properly assemble or safely operate the appliance.
In the event of an oil or grease fire do not attempt to extinguish with water. Immediately
call the fire department. A Type BC or ABC fire extinguisher may, in some circumstances
contain and/or extinguish the fire.
Do not leave the appliance unattended. Keep children and pets away from the
appliance at all times.
Do not move the appliance when in use.

WARNINGS - continued
This appliance is not intended for and should never be used as a heater.
Use only appropriate bake-ware or utensils while baking and cleaning the appliance.
Do not use plastic, silicone or glass.
Do not allow food other than Pizza or Bread Dough to contact the stones. Any foods
that contain fat, oil or butter (meats, items coated with olive oil, cookies, biscuits, etc.)
should not contact the stones directly. These items should be baked in a metal baking
pan, on a metal baking sheet or in a cast-iron skillet as the stones will absorb the fat, oil
and butter which can cause smoking, odors, staining, and can impart rancid flavors to
items that you bake in the future.
Stones are fragile and can break if dropped. The appliance becomes extremely hot, do
not touch the stones or any other part of the appliance while it is in use.
any remaining residue. Do not use any cleaning agents or other liquids to clean the
stones.
Do not place gasoline, alcohol, wood products, charcoal or any other combustible
material (unless BakerStone approved) in the baking chamber.
Remove any appliance cover and place at least 10 feet (3 Meters) from appliance
before use.
Do not alter or change the gas valve orifices.
This appliace requires regular cleaning of major components and more detailed
Only use the presure regulator and hose included with this appliance.
Do not alter or install as a built in appliance.
The use of alcohol, prescription, or non-prescription drugs may impair the consumer’s
ability to properly assemble or safely operate the appliance.

Figure
Figure
Figure

What’s in the package
Assembly of the Grill
LP Gas Cylinder Requirements
LP Gas Cylinder Placement
LP Gas Cylinder Connection
LP Gas Leak Test
Pre-Use Safety Checks
Lighting Instructions
How to Use The Pizza Oven Box
Routine Care & Cleaning
Periodic Care & Cleaning of Burner System
Customer Service
Customer Service Parts Identifier
Warranty
Frequently Asked Questions
4
6
16
17
18
19
19
20
24
26
27
28
30
32
Table of Contents Page
21
22
25
Assembly of the Pizza Oven Box 14

4
What’s in the package
Before assembly, ensure that all parts below are included. Please note part numbers are not listed
in numerical order. For a complete parts diagram and part list for customer service needs such as
replacement parts please go to page 28.
22 - Cabinet
Base Panel
27 - Cabinet
Middle Panel
32 - Cabinet
Front Panel
29 - Cabinet Back
Panel
50 - Griddle
54.5 - Housing 54.1 - Back Panel 54.7 - Stone Support
53 - Griddle Cover Assembly
53.1 - Griddle Cover
53.2 - Griddle Cover Handle
Firebox Assembly
18 - Wheel Axle
19 - Wheel
(x2)
20 - Wheel
Cap (x2)
21 - Stopper
26 - Side Frame
Right
23 - Caster
(x2)
15 - Griddle Storage Rack
31 - Cabinet Top Panel1 2 - Front Brace
54.4 - Side Stone
(x2)
54.8 - Base Stone54.2 - Top Stone 54.3 - Rear Stone 54.9 - Vent Catch
(x2)
54.6 - Stone Cradle
(x2)

5
Tools required for assembly, not included:
Have a question? Please Do Not Return This Product To The Store.
Contact us first! 1-855-657-6836
or email [e-mail]
11 - Drip Tray
Support
(x2)
36 - Rear Beam 30 - Firebox Support
(x2)
28 - Gas Cylinder
Hook
24 - Right Door
10 - Folding Table
(x2)
35 - Table
Support Right
(x2)
39 - Griddle
Grease Cup
37 - Grill
Grease Cup
33 - Drip Tray
6 - Control Knob
(x6)
55 - Warming Rack56 - Cooking Grate
(x3)
2 - Flame
Tamer (x4)
AA - M4x12 Pan
Head Screw
(x5)
BB - M4x20 Pan
Head Screw
(x1)
CC - M5x12 Pan
Head Screw
(x4)
DD - M6x12 Pan
Head Screw
(x46)
EE - M6x12 Flat
Head Screw
(x12)
FF - M5 Nut
(x4) GG - M10 Nut
KK- M4x8 Pan
Head Screw
(x20)
LL - M4 Flat Washer
(x12)
(x2) HH - M Nut
(x4) II - Battery JJ - M5x8mm Shoulder Screw

6
Assembly of the Grill
STEP 1. Attach the CASTERS (23) to the RIGHT SIDE
FRAME (26).
STEP 2. Attach the WHEEL (19), WHEEL AXLE (18) to the LEFT
SIDE FRAME (16) using NUTS (GG). Next place the CAPS (20)
onto the wheels.
STEP 3. Assemble the CABINET BASE PANEL (22) to the SIDE
FRAMES (16 and 26) using SCREWS (DD).
STEP 4. Attach the STOPPER (21) to the BASE PANEL (22) with
SCREW (BB).
23
16
18
22
BB
21
22
DD DD
2616
19
20
GG
26

7
STEP 5. Attach the CABINET FRONT PANEL (32) to the BASE
PANEL (22) and SIDE FRAME (26) using SCREWS (DD).
STEP 6. Attach the CABINET MIDDLE PANEL (27) to the BASE
PANEL (22) and CABINET FRONT PANEL (32) using SCREWS
(DD).
STEP 7. Attach the CABINET BACK PANEL (29) to the BASE
PANEL (22), CABINET MIDDLE PANEL (27) and SIDE FRAME (16)
using SCREWS (DD).
26 DD
32
22
32
16 DD
92 DD
22 27
DD
27
DD 22
DD

8
STEP 10. Attach the FRONT BRACE (12) to the SIDE FRAMES
(16 and 26), FRONT CABINET PANEL (32) and CABINET MIDDLE
PANEL (27) using fasteners (AA) and (DD) as shown.
AA
12
12DD
32
26
DD 27 16
16 31 DD
27
DD
STEP .
STEP .

9
STEP 11. Attach the REAR BEAM (36) using SCREWS (DD).
STEP 12. Attach the FIREBOX SUPPORTS (30) using SCREWS
(DD) to the SIDE FRAMES (16 and 26).
STEP 13. Attached the DRIP TRAY SUPPORTS (11) using
SCREWS (AA).
36
26
27
36DD
DD
AA 1111
16
30
3026
DD

10
STEP 14.
and place onto the assembled cart.
STEP 15. Attach the FIREBOX ASSEMBLY using 4 SCREWS
(DD) on each side.
STEP 16. Secure the HOSE CLIP (41.3) using SCREW ( )
WARNING: FAILURE TO ATTACH PROPERLY MAY RESULT IN A
BURNT OR MELTED HOSE, WHICH MAY RESULT IN FIRE AND/
OR INJURY.
DD
DD
41.3

11
STEP 17. Attached the GAS CYLINDER HOOK (28).
STEP 18. Attach the TABLE SUPPORT LEFT (34) and RIGHT
(35) to each side of the grill using SCREWS ( ). NOTE:
Ensure e facing upwards when
STEP 19. Hang the FOLDING TABLES (10) onto the TABLE
SUPPORTS.
28
28
34
10
10
35
34

12
STEP 21. Attached the LEFT DOOR (25) and RIGHT DOOR(24)
by aligning the bottom hinge into the hole in the BASE (22)
and then pressing down on the top hinge while aligning it
with the hole in the FRONT BRACE (12).
STEP 22. Attached the CONTROL KNOBS (6) by firmly
pushing them onto the GAS VALVES.
STEP 23. Install the BATTERY (II) by unthreading the ignitor
button and inserting the BATTERY (II) with the positive (+)
sign facing out.
12
22
6
HH
25 24
STEP 20. Attach MATCH LIGHT CHAIN (57) to RIGHT DOOR
(24) using SCREW (JJ).
24
57JJ

13
STEP 24. Insert the GRIDDLE GREASE CUP (39) into the front
side of the grill assembly.
39
STEP 25. Loosen the pre-assembled SCREWS from the
HANDLE (53.2) and then attach the HANDLE (53.2) to the
GRIDDLE COVER (53.1) using the SCREWS.
Place the GRIDDLE COVER (53) on top of the firebox when
the GRIDDLE (50) or PIZZA OVEN BOX (54) is not in use.
When using the GRIDDLE (50) or PIZZA OVEN BOX (54) hang
the GRIDDLE COVER (53) on the hook behind the firebox.
STEP 26. Insert the DRIP TRAY (33) and GRILL GREASE CUP
(37) into the back side of the grill as shown.
53.2
53.1
53.2
53
37
33

Assembly of the Pizza Oven Box
54.5
54.6
KK LL
54.2
54.4
54.3
STEP 1 - Place the STONE CRADLES (54.6) into the HOUSNIG
(54.5), and fasten with 8 SCREWS (KK) and 8 FLAT WASH-
ERS (LL).
STEP 4 - Insert the REAR STONE (54.3) into the notches of
the 2 side stones.
STEP 2 - Insert the TOP STONE (54.2) into the housing,
resting on the stone cradles.
STEP 3 - Insert the two SIDE STONES (54.4) into the housing
as shown.
14

54.8
54.1
KK
LL
STEP 5 - Insert the BASE STONE (54.8) into the notches of
the 2 side stones.
STEP 6 - Fasten the BACK PANEL (54.1) housing with 4
SCREWS (KK) and 4 FLAT WASHERS (LL).
STEP 8 - Attach the STONE SUPPORTS (54.7) with
8 SCREWS (KK) to the stone cra-dles.
STEP 7 - Locate the VENT CATCH (54.9) and place into the
vent of the oven and resting on the base stone.
15
54.9
54.7 KK

16
LP Gas Cylinder (tank) Requirements
The appliance is only to be fueled by an LP (liquid propane) gas cylinder measuring 12” (30.5cm)
diameter and 18” (45.7cm) high with a 20lb. (9.1kg) capacity. The gas cylinder (tank) must
incorperate a Type 1 cylinder valve and an over filling protection device (OPD).
The LP gas cylinder must be constructed and marked in accordance with the Specifications for
LP gas Cylinders of the U.S. Department of Transportation (D.O.T.) or the Standard for Cylinders,
Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as
applicable.
Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of
dust cap on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps
or plugs may result in leakage of propane.
The gas cylinder must have:
- A Type 1 valve that prevents gas flow until a positive seal is obtained.
- An arrangement for vapor withdrawl. The gas cylinder must be kept in the upright position at all
times.
- A safety relief device that has direct communication with the vapor space of the gas cylinder.
- A listed over filling prevention device (OPD).
This appliance is not intended to be used with natural gas.
Appliance Installation Requirements
This appliance must be installed in accordance to the following codes:
- National Fuel Gas Code ANSI Z223.1 NFPA 54
- Natural Gas and Propane Installation Code: CAN/CGA B149.1
- Propane Installation Code: CAN/CGA B149.2 (Canada)
LP Gas Cylinder (tank) Filling Requirements:
- LP gas cylinder should only be filled by a qualified licensed LP gas dealer.
- New LP gas cylinders must be purged prior to filling.
- DO NOT allow the cylinder to be filled beyond 80% capacity. Over-filled LP gas cylinders can
create a dangerous condition. Over-filled LP gas cylinders can build-up pressure and cause the
relief valve to expel propane gas vapors. The vapor is combustible and if it comes in contact with
a spark source or flame an explosion causing severe burns, bodily harm, or death could occur.
- Always use a protective cylinder cap when grill is not connected to the gas cylinder.
- Inspect the LP gas cylinder valve rubber seal for cracks, wear or deterioration prior to use. A
damaged rubber seal can cause a gas leak, possibly resulting in an explosion, fire or severe
bodily harm.
Spare LP Gas Cylinder
- Do not store a spare LP gas cylinder under or near the appliance.

17
LP Gas Cylinder Placement
Place the LP Gas Cylinder into the Base and secure with the
rim of the LP Gas Cylinder.
WARNING:
The pressure regulator and hose assembly supplied with the appliance must be used.
Replacement pressure regulators and hose assemblies shall be those specified by the
appliance manufacturer.
Storage of this appliance indoors is permissible only if the cylinder is disconnected and
removed from the appliance.
Cylinders must be stored outdoors out of the reach of children and shall not be stored in a
building, garage, or any other enclosed area.
Only use this appliance outdoors in a well ventilated area.
Never operate this appliance within 36in (0.9m) of any structure, combustible material or other
gas cylinder.
Do not use this appliance under overhead combustable construction.
Do not place or use this appliance on a combustable surface.
This appliance becomes hot, do not place on any surface which cannot withstand high
temperatures without deforming or being damaged.
This appliance is not to be installed in or on boats or recreational vehicles.
Failure to follow these instructions could result in fire, explosion or burn hazard which could

18
LP gas cylinder connection:
Step 1. Ensure the LP cylinder used conforms to the
requirements listed on the previous page. Also inspect the
LP gas cylinder valve rubber seal for deterioration such as
cracks, deformation or tears.
Step 2. Inspect the LP gas cylinder valve to ensure the
threads match that of the included hose and regulator.
Step 3. Ensure all the burner control knobs are in the OFF
position [see Figure - 1].
Step 4. Thread the included hose and regulator onto the
LP gas cylinder. Turn the coupling fastener clockwise by
hand until it stops [see Figure - 2]. WARNING: Do not use
tools to tighten the coupling fastener.
LP Gas Cylinder
Hose and Regulator
Coupling fastener
Figure - 2
Hose and regulator
attachment
Figure - 1
