BALAY 3SC60000EE User manual

1 2 3 4 5 6
ˎddelicado
(Low Heat)
Reduced temperature for delicate fabrics ', e.g.
polyacrylics, polyamide, elastane, ace tate silk; for a longer
drying time.
ˎmenos
(Reduced Ironing)
Reduces creasing and prolongs the anti-crease phase
after the end of the programme.
depósito (container)
filtro (clean)
Lit aempty the condensation container.
Flashing aclean the fluff filter and/or air cooler.
End of the programme once the End/Anti-Crease indicator light flas hes
Adding more or removing laundry
The drying operation can be paused to add m ore laundry or remove laundry.
The programme must then be continued until it has finish ed.
The drum and the door may be hot!
1. Open door, the drying process is interrupted.
2. Load or remove laundry and close door.
3. If required, select a new program me and additional functions.
4. Press the $inicio/stop (start/stop) button.
Emptying condensation
Empty the container after every use.
1. Remove the condensation container and hold it
level.
2. Open the locking cap.
3. Pour out the condensation .
Check the valve in the condensation container for dirt:
If there are fluff deposits on t he valvearinse the valve under running water. Also pour
some tap water into the empty condensation contain er then pour it out again through
the valve. To do this, press the valve in and allow all th e water to drain out.
4. Close the locking cap.
5. Always push the tank fully back in until it locks in place.
If the depósito (container) /filtro (clean) indicator light
comes on after emptying the container asee page 1 0.
Cleaning the fluff filter
Clean the fluff filter after each drying operation.
1. Open the door, remove the fluff filter.
2. Remove the fluff (by wiping t he filter with your hand).
If the fluff filter is heavily soiled or blocked, rinse it with wa rm water,
and dry it thoroughly.
3. Re-insert the fluff filter so that you hea r it click into place.
4. Remove fluff from door/door area.
Switching off the dryer
Turn the programme selector to stop (Off).
Do not leave laundry in the d ryer.
Removing the laundry
Your dryer is equipped with an automatic a nti-crease function. The drum is moved at specific time intervals
for 30 minutes once the programme has ended. The la undry remains loose and soft (for 90 minutes if the
menos c(Reduced Ironing) additi onal function is selected, depend ing on the model).
... and adapt to individual requirements
Never start the dryer if it is damaged!
Inform your after-sales service. Inspecting the
dryer
Sorting and loading laundry
Remove all items from pockets .
Check for cigarette lighters.
The drum must be empty pri or to loading.
Your new dryer
Congratulations! - You have chos en a modern, high-quality domestic
appliance from Balay.
A distinctive feature of the dryer is its low energy consumption.
Every dryer which leaves our factory is carefully c hecked to ensure
that it functions correctly and is i n perfect condition.
Should you have any questions , our after-sales service will be pleased
to help.
Disposal in an environmentally-responsible manner
Dispose of packaging in an en vironmentally-responsible manner.
This appliance is designated according to Eur opean directive 2002/96/EC which governs waste electrical and electronic
equipment (WEEE).
The guideline provides an EU-wide f ramework for the return and
recycling of old appliances.
For further information about our pro ducts, accessories, spare parts
and services, please visit: www.balay.es
Intended use
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5
ʋMaintenance and cleaning . . . . . . . . . . . 6
ʋOverview of programmes . . . . . . . . . . . . 7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8
ʋFrost protection / Transport . . . . . . . . . . . 8
ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . . .9
ʋWhat to do if... . . . . . . . . . . . . . . . . . . . 10
ʋSafety instructions . . . . . . . . . . . . . . . . 11
Preparing for installation, see Page 8
Selecting and adjusting the programme
Drying
Condensation container
Control panel
Care and cleaning
Dryer housing, control panel, air inlet
– Wipe off with a soft, damp cloth.
– Do not use harsh cleaning agents/solvents.
– Remove detergent and cleaning agent residue immediately.
Clean air cooler 5 or 6 times a year
or if depósito (container) /filtro(clean) flashes after cleaning the fluff filter.
Air cooler
– Allow the dryer to cool.
– Residual water may leak out, so place an absorbent towel underneath
the maintenance door.
1. Unlock the maintenance door (1).
2. Open the maintenance door fully (2).
3. Turn both locking levers outwards (1).
4. Remove the front insert (2).
5. Remove the air cooler.
Do not damage the air cooler!
When cleaning, use warm water only. Do not use hard or sharp-edged objects.
6. Clean the air cooler completely. Let it drip completely dry.
Clean the seals.
7. Insert the air cooler first (handle facing down), then the front insert.
8. Turn back both locking levers.
9. Lock the maintenance door.
Select the drying programme ...
Press the  inicio/stop
(start/stop) button
1
2
3
Make sure your hands are dry.
Hold by the plug only. Connecting the
mains plug
Drying
Information on laundry ...
Labelling of fabrics
Follow the manufacturer's care inform ation.
(Drying at normal temperature.
'cDrying at a lower temperature ase lect ddelicado (Low Heat) as well.
)cDo not machine dry.
The safety information MUST be observed apage 11!
Do not tumble-dry the followi ng fabrics for example:
– Airtight fabrics (e.g. rubber -coated fabrics).
– Delicate materials (silk, cur tains made from synthetic material) athey m ay crease.
– Laundry contaminat ed with oil.
Before using the dryer for the first time
– Do not put any laundry inside the dry er. Turn the programme selector to Timed
Programmes (apage 7) and press $inici o/stop (start/stop). At the end of the
programme, turn the programme s elector to stop (Off).
Drying tips
– To ensure a consist ent result, sort the laundry by fabric t ype and drying programme.
– Always dry ver y small items (e.g. baby socks) together with larger item s (e.g. hand towels).
– Close zips, hooks an d eyelets, and button up covers. Tie cloth bel ts, bands, etc. together.
– Do not over-dr y easy-care laundry arisk of creasing!
Allow laundry to finish drying in the ai r.
– Do not iron la undry immediately after drying, fo ld items up and leave for a while a
the remaining moisture will then be distributed evenly.
– Knitted fabrics (e.g. T-sh irts, jerseys) often shrink during the ir first drying.
aDo not use the caliente 120 min (warm 120 min) programme.
– Starched laundry is not always suitable for dry ers astarch leaves behind a coating that
adversely affects the drying opera tion.
– Use the correct dosage of fabric softener as per the manufact urer's instructions when
washing the laundry to be dried.
– Use the timer programme for small loads athis im proves the drying result.
Environmental protection/energy-saving tips
– Before drying, spin the laund ry thoroughly in the washing machine athe higher the spin
speed, the shorter the drying time will be (consumes less energy), al so spin easy-care
laundry.
– Use the maximum recomme nded capacity, but do not exceed it
aProgramme overview, page 7.
– Make sure the roo m is well ventilated during drying.
– Clean the fluff f ilter after every drying operation apage 4.
– Do not obstruct or seal up the air inlet.
Only when switched off!
Drum
Only operate the dryer
with the fluff filter
inserted! Air inlet
Fluff filter
ʋfor domestic use only,
ʋonly to be used for drying fabric s that have been
washed with water.
Do not leave children unsupervised n ear the dryer.
Keep pets away from the dryer.
Detailed programme overview apage 7.
Before drying for the first time,
run the dryingoperation once with the dryerempty a page 7.
Programme selector Additional functions /
status / service
indicators
Programme table

7
Programme overview also see Page 5
After drying: laundry is to be ...
T-shirt
Shirts
Trousers
Skirts/dresses
Sportswear
Work clothing
Anoraks
Terry/
bathrobe
Underwear
Socks
Bed linen
Table linen
Terry towels
Tea towels/
towels
c
ironed

lightly ironed dry
@c
not ironed
c
passed through a mangle
resistentes/algod. (Cottons) max. 6 kg For whites and coloureds/cotton or linen.
seco (50 - 10 0 min.) (Iron Dry) cø@c è*è*è*è*è*è*è*è* seco guard ar (60 - 120 min.) (Cupboard Dry) ccccccccc@è*è*è*è*è*è*
sintéticos (Easy-Care) max. 3 kg For non-iron laundry made of synthetic fib res and blended fabric, cotton.
seco (20 - 30 min.) (Iron Dry) cø@c è*è*è*è*è*è* seco gu ardar (20 - 40 min.) (Cupboard Dry) ccccccccc@è*è**
frio D(cold) max. 3 kg For all types of fabrics. For freshening up or airing items of laundry that have been worn for a short period of time.
1010 / 9000400658 *400658* Balay Electrogeräte GmbH
CarläWery Str. 34
81739 München / G ermany
3SC60000EE
8
Installation
– Delivery specification : dryer, instructions for insta llation and use.
– Check dryer for transpo rt damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the d ryer by protruding parts (e .g. the door) - risk of breakage.
– Do not set up in a roo m that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have the a ppliance connected by an e xpert.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is instal led on a clean, level
and firm surface.
– Keep the air inlet on th e front of the dryer clear.
– Keep the area ar ound the dryer clean.
– Adjust the height of the dryer using the threaded
feet at the front.
Do not remove the threaded feet under any
circumstances.
Mains conn ection safety information apage 11.
– Connect to an AC e arthed socket. If in doubt have the socket checked by an expe rt.
– The mains volta ge and the voltage shown on the rating plate (aPage 9) must correspond.
– The connected load and necessary fuse pro tection are specified on th e rating plate.
Frost protection / Transport
Preparation
Empty the condensation con tainer apage 4.
The dryer contains residual water;
this can flow out if th e dryer is tilted.
1.
Take all accessory parts out
of the drum. The drum must
be empty.
Make sure that the air inlet
remains unobstructed
Clean and level
2.
Do not operate the dryer if there
is a danger of frost.
Do not install the dryer b ehind a door or sliding
door, as these may preve nt the dryer door from
opening.
Observing this instruction ma y stop a child from
becoming shut inside the dryer and having its life
put in danger.
9
Technical data
Dimensions (DxWxH) 60 x 60 x 85 cm
Weight approximately 35 kg
Max. capacity 6 kg
Condensation container approx. 4.2 l
Ambient temperature 5 - 35 °C
Connection voltage 220 - 240 V
Connected load 2300 W
Fuse protection 10 A
Product number aRating plate or inside of the door
Production number
You can find the rating plate on the back of the dryer.
ʠConsumption ra tes These are guide values determ ined under standard
conditions. Deviations of up to 10 % are possible.
Spin speed in rpm
(residual moisture)
Drying time** in
minutes, includ-
ing 8 minutes
cool cycle
Energy
consumption**
in kWh
resistentes/algod.
(Cottons) 6 kg
seco guardar
(Cupboard Dry)*
1400 (aprox. 50%) 100 3.20
1000 (aprox. 60%) 120 3.84
seco (Iron Dry)* 1 400 (aprox. 50%) 80 2.52
1000 (aprox. 60%) 100 3.02
800 (aprox. 70%) 120 3.53
sintéticos (Easy-Care)c3 kg
seco guardar
(Cupboard Dry)*
800 (aprox. 40%) 40 1 .20
600 (aprox. 50%) 50 1 .50
*Test program to DIN EN 6 1121.
**The values may deviate from the v alues shown here, because of over/un dervoltage, type of
fabric, composition of the laund ry to be dried, residual moisture in the material an d size of the
load.
Optional accessories (or der from the after-sales service using the o rder number)
Washer-dryer stack connec tion set
The dryer can be placed o n top of a suitable washing m achine with the same width a nd depth
to save space. This connect ion set must always be used to secure the dryer to the washing
machine. If the worktop of the washing machine is less than 544 mm deep, please consult
the after-sales service or your sp ecialist retailer.
Platform
For easier loading and unloading. The basket in the pull- out can be used for carrying the
laundry.
Installation underneath the worktop
Risk of electric shock.
Instead of the appliance covering plate, you must have a metal cover fitted by an expert.
WZ
20311
WZ
20460
WZ
20295
10
What to do if ...
Repairs must only be carried out by the a fteräsales service or an authorised expert.
Before you contact the after-sales s ervice, please make sure that you are unab le to resolve
the problem yourself. You will be charged f or advice if a tech nician is called out, eve n during
the warranty period. You can find your nearest after-sal es service in the enclosed list. When
contacting the after-sales service, pl ease quote the appliance's product number (E -Nr.) and
production number (FD) ( ao n the inside of the door).
ʠThe $inicio/stop (start/stop)
indicator light does not come on.
Mains plug plugged in?
Programme selected?
ʠThe depósito (container)
filtro (clean) indicator light comes
on.
Empty the condensation container apage 4.
ʠThe depósito (container)
filtro (clean) indicator ligh t is
flashing.
Clean the fluff filter apage 4.
Clean the air cooler if necessa ry apage 6.
ʠDryer does not start. Has the $inicio /stop (start/stop) button been p ressed?
Door closed?
Programme set?
ʠProgramme stops shortly after it
has started.
Ambient temperature greater than 5 °C?
ʠWater is leaking out. Make sure the dryer is level.
ʠThe door opens by i tself. Push the door closed u ntil you hear it enga ge.
ʠThe required degree of dryness
was not achieved or the drying
time was too long.
Clean the fluff filter apage 4.
Empty the condensation container.
Ambient temperature h igher than 35 °C aairing.
Air inlet may b e blocked akeep unobstructe d.
Was an unsuitable programme s elected? apage 7.
Has the dryer been i nstalled with sufficient spac e on all
sides? Ensure that air can ci rculate.
Mains failure aRestart the dryer.
ʠLaundry damp. Use the next drying programme up or use the timer
programme as a supplement apage 7.
Warm laundry feels dam per than it really is!
ʠThe humidity in the room
has increased significantly.
Make sure the room is sufficien tly ventilated.
Air inlet blocked? akeep unobstru cted.
Ensure that the air cooler is in use.
ʠOne or more indicator lights is/are
flashing.
Clean the air fluff filter and air cooler if necessary
apage 4/6.
Check the instal lation conditions apage 8.
Switch off, allow to cool, s witch on again and resta rt the
programme.
ʠMains failure. Remove laundry from the dryer immediately and spread
out. This allows the heat to dissipate.
ʠIf you cannot rect ify a fault yourself o r a repair is n ecessary:
– Set the programme selec tor to stop (Off).
– Remove the appliance plu g from the socket.
– Call the after-sale s service aafter-sales s ervice directory.
11
Safety instructions
Emergency – Pull the appliance plug out of the socket immedia tely or disconnect the fuse.
ONLY use the
dryer...
– In rooms inside the h ouse.
– To dry fabrics.
The dryer must
NEVER...
– Be used for other purposes than those de scribed above.
– Be modified in terms of its technology or attributes.
Dangers – The dryer must not be used by children or persons w ho have not been
instructed in its use.
– Do not l eave children unsuper vised near the drye r.
– Keep pets away f rom the dryer.
– Remove all objects f rom pockets.
Make especially sure that cigarette lighters are removed as they constitute an
aexplosion hazard.
– Do no t lean or sit on the door arisk of tipp ing.
– Open the door carefull y. Hot steam may escape.
Installation – Secure loose cables atripping hazard.
– Do not operate the dryer if there is a risk of frost.
Mains
connection
– Connect the dryer according to specific ations to an AC ear thed socket, as
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-secti on must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug a nd socket must be compatible.
– Do not u se multiple plugs/cou plings and/or extension cables.
– Do no t touch or hold the appliance plug with wet hands
arisk of electric shock.
– Never pull the appli ance plug out of the socket by its cable .
– Do no t damage the main s lead arisk of electric sho ck.
Operation – Only load the drum with laundry.
Check the contents befo re you switch the dryer on.
– Do no t use the dryer if the laundry ha s been in contact with solvents, o il, wax,
grease or paint (e.g. hair setting spr ay, nail polish remover, stain remover,
cleaning solvent, etc.) afire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a dang er:
do not use the dryer aexplosio n hazard.
– Do n ot put laundry containing foamed m aterial/rubber in the dryer aelas tic
material may be destroyed and th e dryer may be damaged due to p ossible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
– Condensation is not drinking water and may be contaminated with f luff.
Defect – Do not use the dryer if it is d efective or if you suspect it is.
Repairs must only be carrie d out by the after-sales service.
– Do not use the drye r if the mains cable is defective. T o avoid danger, only
have the defective mains cabl e replaced by the after-sales service.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Dryer: pull out the appliance plug, then cut off the mains cable from the
appliance. Dispose of the a ppliance at a municipa l waste disposal facility.
– Packaging: do not lea ve children alone with packing pa rts
arisk of suffocation.
– All materia ls are environmentally s afe and can be r eused. Dispose of all
materials in an environmen tally-responsible manner.
Instructions for
installation and use
en
Tumble dryer
Read these instructions befor e operating the dryer.
Observe the safety instructions on page 11.

1 2
ˎddelicado
(Low Heat)
Reduced temperature for delicate fabrics ', e.g.
polyacrylics, polyamide, elastane, acetate silk; for a longer
drying time.
ˎmenos
(Reduced Ironing)
Reduces creasing and prolongs the anti-crease phase
after the end of the programme.
depósito (container)
filtro (clean)
Lit aempty the condensation container.
Flashing aclean the fluff filter and/or air cooler. $aac... and adapt to individual requirements
Never start the dryer if it is damaged!
Inform your after-sales service. Inspecting the
Sorting and loading laundry
Remove all items from pockets.
Check for cigarette lighters.
The drum must be empty prior to loading.
Your new dryer
Congratulations! - You have chosen a modern, high-quality domestic
appliance from Balay.
A distinctive feature of the dryer is its low energy consumption.
Every dryer which leaves our factory is carefully checked to ensure
that it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service will be pleased
to help.
Disposal in an environmentally-responsible manner
Dispose of packaging in an environmentally-responsible manner.
This appliance is designated according to European directive 2002/96/EC which governs waste electrical and electronic
equipment (WEEE).
The guideline provides an EU-wide framework for the return and
recycling of old appliances.
For further information about our products, accessories, spare parts
and services, please visit: www.balay.es
Intended use
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5
ʋMaintenance and cleaning . . . . . . . . . . . 6
ʋOverview of programmes . . . . . . . . . . . . 7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8
ʋFrost protection / Transport . . . . . . . . . . . 8
ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . . . 9
ʋWhat to do if... . . . . . . . . . . . . . . . . . . . 10
ʋSafety instructions . . . . . . . . . . . . . . . . 11
Preparing for installation, see Page 8
Selecting and adjusting the programme

Select the drying programme ...
Press the 
(start/stop) button
Make sure your hands are dry.
Hold by the plug only. Connecting the
mains plug
('cad)caaa$aaaaaaaa
Only operate the dryer
with the fluff filter
inserted!
ʋfor domestic use only,
ʋonly to be used for drying fabrics that have been
washed with water.
Do not leave children unsupervised near the dryer.
Keep pets away from the dryer.
Detailed programme overview aBefore drying for the first time,
run the drying operation once with the dryer empty a
Programme selector Additional functions /
status / service
indicators
Programme table

3 4
ˎd'ˎaaEnd of the programme once the End/Anti-Crease indicator light flashes
Adding more or removing laundry
The drying operation can be paused to add more laundry or remove laundry.
The programme must then be continued until it has finished.
The drum and the door may be hot!
1. Open door, the drying process is interrupted.
2. Load or remove laundry and close door.
3. If required, select a new programme and additional functions.
4. Press the $inicio/stop (start/stop) button.
Emptying condensation
Empty the container after every use.
1. Remove the condensation container and hold it
level.
2. Open the locking cap.
3. Pour out the condensation.
Check the valve in the condensation container for dirt:
If there are fluff deposits on the valvearinse the valve under running water. Also pour
some tap water into the empty condensation container then pour it out again through
the valve. To do this, press the valve in and allow all the water to drain out.
4. Close the locking cap.
5. Always push the tank fully back in until it locks in place.
If the depósito (container) /filtro (clean) indicator light
comes on after emptying the container asee page 10.
Cleaning the fluff filter
Clean the fluff filter after each drying operation.
1. Open the door, remove the fluff filter.
2. Remove the fluff (by wiping the filter with your hand).
If the fluff filter is heavily soiled or blocked, rinse it with warm water,
and dry it thoroughly.
3. Re-insert the fluff filter so that you hear it click into place.
4. Remove fluff from door/door area.
Switching off the dryer
Turn the programme selector to stop (Off).
Do not leave laundry in the dryer.
Removing the laundry
Your dryer is equipped with an automatic anti-crease function. The drum is moved at specific time intervals
for 30 minutes once the programme has ended. The laundry remains loose and soft (for 90 minutes if the
menos c(Reduced Ironing) additional function is selected, depending on the model).
... and adapt to individual requirements
Inspecting the
dryer
Sorting and loading laundry
ʋʋʋʋʋʋʋʋʋʋʋʋSelecting and adjusting the programme
Drying
Condensation container
Control panel 
Select the drying programme ...
Press the  inicio/stop
(start/stop) button
1
2
3
Connecting the
mains plug
Drying
('cad)caaa$aaaaaaaa
Drum
Only operate the dryer
with the fluff filter
inserted! Air inlet
Fluff filter
ʋʋ
Detailed programme overview apage 7.
Before drying for the first time,
run the drying operation once with the dryer empty a page 7.

56
ˎd'ˎaa$aac
ʋʋʋʋʋʋʋʋʋʋʋʋCare and cleaning
Dryer housing, control panel, air inlet
– Wipe off with a soft, damp cloth.
– Do not use harsh cleaning agents/solvents.
– Remove detergent and cleaning agent residue immediately.
Clean air cooler 5 or 6 times a year
or if depósito (container) /filtro(clean) flashes after cleaning the fluff filter.
Air cooler
– Allow the dryer to cool.
– Residual water may leak out, so place an absorbent towel underneath
the maintenance door.
1. Unlock the maintenance door (1).
2. Open the maintenance door fully (2).
3. Turn both locking levers outwards (1).
4. Remove the front insert (2).
5. Remove the air cooler.
Do not damage the air cooler!
When cleaning, use warm water only. Do not use hard or sharp-edged objects.
6. Clean the air cooler completely. Let it drip completely dry.
Clean the seals.
7. Insert the air cooler first (handle facing down), then the front insert.
8. Turn back both locking levers.
9. Lock the maintenance door.

1
2
3
Information on laundry ...
Labelling of fabrics
Follow the manufacturer's care information.
(Drying at normal temperature.
'cDrying at a lower temperature aselect ddelicado (Low Heat) as well.
)cDo not machine dry.
The safety information MUST be observed apage 11!
Do not tumble-dry the following fabrics for example:
– Airtight fabrics (e.g. rubber-coated fabrics).
– Delicate materials (silk, curtains made from synthetic material) athey may crease.
– Laundry contaminated with oil.
Before using the dryer for the first time
– Do not put any laundry inside the dryer. Turn the programme selector to Timed
Programmes (apage 7) and press $inicio/stop (start/stop). At the end of the
programme, turn the programme selector to stop (Off).
Drying tips
– To ensure a consistent result, sort the laundry by fabric type and drying programme.
– Always dry very small items (e.g. baby socks) together with larger items (e.g. hand towels).
– Close zips, hooks and eyelets, and button up covers. Tie cloth belts, bands, etc. together.
– Do not over-dry easy-care laundry arisk of creasing!
Allow laundry to finish drying in the air.
– Do not iron laundry immediately after drying, fold items up and leave for a while a
the remaining moisture will then be distributed evenly.
– Knitted fabrics (e.g. T-shirts, jerseys) often shrink during their first drying.
aDo not use the caliente 120 min (warm 120 min) programme.
– Starched laundry is not always suitable for dryers astarch leaves behind a coating that
adversely affects the drying operation.
– Use the correct dosage of fabric softener as per the manufacturer's instructions when
washing the laundry to be dried.
– Use the timer programme for small loads athis improves the drying result.
Environmental protection/energy-saving tips
– Before drying, spin the laundry thoroughly in the washing machine athe higher the spin
speed, the shorter the drying time will be (consumes less energy), also spin easy-care
laundry.
– Use the maximum recommended capacity, but do not exceed it
aProgramme overview, page 7.
– Make sure the room is well ventilated during drying.
– Clean the fluff filter after every drying operation apage 4.
– Do not obstruct or seal up the air inlet.
Only when switched off!
ʋʋaa

7
Programme overview also see Page 5
After drying: laundry is to be ...
T-shirt
Shirts
Trousers
Skirts/dresses
Sportswear
Work clothing
Anoraks
Terry/
bathrobe
Underwear
Socks
Bed linen
Table linen
Terry towels
Tea towels/
towels
c
ironed

lightly ironed dry
@c
not ironed
c
passed through a mangle
resistentes/algod. (Cottons) max. 6 kg For whites and coloureds/cotton or linen.
seco (50 - 100 min.)
(Iron Dry) cø@c è*è*è*è*è*è*è*è*
seco guardar (60 - 120 min.) (Cupboard Dry) ccccccccc@è*è*è*è*è*è*
sintéticos (Easy-Care) max. 3 kg For non-iron laundry made of synthetic fibres and blended fabric, cotton.
seco (20 - 30 min.)
(Iron Dry) cø@c è*è*è*è*è*è*
seco guardar (20 - 40 min.) (Cupboard Dry) ccccccccc@è*è**
frio D(cold) max. 3 kg For all types of fabrics. For freshening up or airing items of laundry that have been worn for a short period of time.
1010 / 9000400658 *400658* Balay Electrogeräte GmbH
CarläWery Str. 34
81739 München / Germany
3SC60000EE
8
Installation
– Delivery specification: dryer, instructions for installation and use.
– Check dryer for transport damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer by protruding parts (e.g. the door) - risk of breakage.
– Do not set up in a room that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have the appliance connected by an expert.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is installed on a clean, level
and firm surface.
– Keep the air inlet on the front of the dryer clear.
– Keep the area around the dryer clean.
– Adjust the height of the dryer using the threaded
feet at the front.
Do not remove the threaded feet under any
circumstances.
Mains connection safety information apage 11.
– Connect to an AC earthed socket. If in doubt have the socket checked by an expert.
– The mains voltage and the voltage shown on the rating plate (aPage 9) must correspond.
– The connected load and necessary fuse protection are specified on the rating plate.
Frost protection / Transport
Preparation
Empty the condensation container apage 4.
The dryer contains residual water;
this can flow out if the dryer is tilted.
1.
Take all accessory parts out
of the drum. The drum must
be empty.
Make sure that the air inlet
remains unobstructed
Clean and level
2.
Do not operate the dryer if there
is a danger of frost.
Do not install the dryer behind a door or sliding
door, as these may prevent the dryer door from
opening.
Observing this instruction may stop a child from
becoming shut inside the dryer and having its life
put in danger.
aʠc
äaʠ$ʠaʠaaʠ$ʠʠʠʠaaaaaʠaʠaʠaaʠʠaaaaaaaaaa

c@c c
cø@c è*è*è*è*è*è*è*è*ccccccccc@è*è*è*è*è*è*cø@c è*è*è*è*è*è*ccccccccc@è*è**Dä
aaaTake all accessory parts out
Do not operate the dryer if there
9
Technical data
Dimensions (DxWxH) 60 x 60 x 85 cm
Weight approximately 35 kg
Max. capacity 6 kg
Condensation container approx. 4.2 l
Ambient temperature 5 - 35 °C
Connection voltage 220 - 240 V
Connected load 2300 W
Fuse protection 10 A
Product number aRating plate or inside of the door
Production number
You can find the rating plate on the back of the dryer.
ʠConsumption rates These are guide values determined under standard
conditions. Deviations of up to 10 % are possible.
Spin speed in rpm
(residual moisture)
Drying time** in
minutes, includ-
ing 8 minutes
cool cycle
Energy
consumption**
in kWh
resistentes/algod.
(Cottons) 6 kg
seco guardar
(Cupboard Dry)*
1400 (aprox. 50%) 100 3.20
1000 (aprox. 60%) 120 3.84
seco (Iron Dry)* 1400 (aprox. 50%) 80 2.52
1000 (aprox. 60%) 100 3.02
800 (aprox. 70%) 120 3.53
sintéticos (Easy-Care)c3 kg
seco guardar
(Cupboard Dry)*
800 (aprox. 40%) 40 1.20
600 (aprox. 50%) 50 1.50
*Test program to DIN EN 61121.
**The values may deviate from the values shown here, because of over/undervoltage, type of
fabric, composition of the laundry to be dried, residual moisture in the material and size of the
load.
Optional accessories (order from the after-sales service using the order number)
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space. This connection set must always be used to secure the dryer to the washing
machine. If the worktop of the washing machine is less than 544 mm deep, please consult
the after-sales service or your specialist retailer.
Platform
For easier loading and unloading. The basket in the pull-out can be used for carrying the
laundry.
Installation underneath the worktop
Risk of electric shock.
Instead of the appliance covering plate, you must have a metal cover fitted by an expert.
WZ
20311
WZ
20460
WZ
20295
10
What to do if ...
Repairs must only be carried out by the afteräsales service or an authorised expert.
Before you contact the after-sales service, please make sure that you are unable to resolve
the problem yourself. You will be charged for advice if a technician is called out, even during
the warranty period. You can find your nearest after-sales service in the enclosed list. When
contacting the after-sales service, please quote the appliance's product number (E-Nr.) and
production number (FD) ( aon the inside of the door).
ʠThe $inicio/stop (start/stop)
indicator light does not come on.
Mains plug plugged in?
Programme selected?
ʠThe depósito (container)
filtro (clean) indicator light comes
on.
Empty the condensation container apage 4.
ʠThe depósito (container)
filtro (clean) indicator light is
flashing.
Clean the fluff filter apage 4.
Clean the air cooler if necessary apage 6.
ʠDryer does not start. Has the $inicio/stop (start/stop) button been pressed?
Door closed?
Programme set?
ʠProgramme stops shortly after it
has started.
Ambient temperature greater than 5 °C?
ʠWater is leaking out. Make sure the dryer is level.
ʠThe door opens by itself. Push the door closed until you hear it engage.
ʠThe required degree of dryness
was not achieved or the drying
time was too long.
Clean the fluff filter apage 4.
Empty the condensation container.
Ambient temperature higher than 35 °C aairing.
Air inlet may be blocked akeep unobstructed.
Was an unsuitable programme selected? apage 7.
Has the dryer been installed with sufficient space on all
sides? Ensure that air can circulate.
Mains failure aRestart the dryer.
ʠLaundry damp. Use the next drying programme up or use the timer
programme as a supplement apage 7.
Warm laundry feels damper than it really is!
ʠThe humidity in the room
has increased significantly.
Make sure the room is sufficiently ventilated.
Air inlet blocked? akeep unobstructed.
Ensure that the air cooler is in use.
ʠOne or more indicator lights is/are
flashing.
Clean the air fluff filter and air cooler if necessary
apage 4/6.
Check the installation conditions apage 8.
Switch off, allow to cool, switch on again and restart the
programme.
ʠMains failure. Remove laundry from the dryer immediately and spread
out. This allows the heat to dissipate.
ʠIf you cannot rectify a fault yourself or a repair is necessary:
– Set the programme selector to stop (Off).
– Remove the appliance plug from the socket.
– Call the after-sales service aafter-sales service directory.
aaaaaaaaa

c@c c
cø@c è*è*è*è*è*è*è*è*ccccccccc@è*è*è*è*è*è*cø@c è*è*è*è*è*è*ccccccccc@è*è**Dä
aaaTake all accessory parts out
Do not operate the dryer if there
aʠcäaʠ$ʠaʠaaʠ$ʠʠʠʠaaaaaʠaʠaʠaaʠʠa
11
Safety instructions
Emergency – Pull the appliance plug out of the socket immediately or disconnect the fuse.
ONLY use the
dryer...
– In rooms inside the house.
– To dry fabrics.
The dryer must
NEVER...
– Be used for other purposes than those described above.
– Be modified in terms of its technology or attributes.
Dangers – The dryer must not be used by children or persons who have not been
instructed in its use.
– Do not leave children unsupervised near the dryer.
– Keep pets away from the dryer.
– Remove all objects from pockets.
Make especially sure that cigarette lighters are removed as they constitute an
aexplosion hazard.
– Do not lean or sit on the door arisk of tipping.
– Open the door carefully. Hot steam may escape.
Installation – Secure loose cables atripping hazard.
– Do not operate the dryer if there is a risk of frost.
Mains
connection
– Connect the dryer according to specifications to an AC earthed socket, as
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-section must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug and socket must be compatible.
– Do not use multiple plugs/couplings and/or extension cables.
– Do not touch or hold the appliance plug with wet hands
arisk of electric shock.
– Never pull the appliance plug out of the socket by its cable.
– Do not damage the mains lead arisk of electric shock.
Operation – Only load the drum with laundry.
Check the contents before you switch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair setting spray, nail polish remover, stain remover,
cleaning solvent, etc.) afire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger:
do not use the dryer aexplosion hazard.
– Do not put laundry containing foamed material/rubber in the dryer aelastic
material may be destroyed and the dryer may be damaged due to possible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
– Condensation is not drinking water and may be contaminated with fluff.
Defect – Do not use the dryer if it is defective or if you suspect it is.
Repairs must only be carried out by the after-sales service.
– Do not use the dryer if the mains cable is defective. To avoid danger, only
have the defective mains cable replaced by the after-sales service.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Dryer: pull out the appliance plug, then cut off the mains cable from the
appliance. Dispose of the appliance at a municipal waste disposal facility.
– Packaging: do not leave children alone with packing parts
arisk of suffocation.
– All materials are environmentally safe and can be reused. Dispose of all
materials in an environmentally-responsible manner.
Instructions for
installation and use
en
Tumble dryer
Read these instructions before operating the dryer.
Observe the safety instructions on page 11.
