BALDR B0367STHR User manual

USER MANUAL
MODEL:B0367STHR
RADIO-CONTROLLED PROJECTION
ALARM CLOCK
We hereby thank you for purchasing Baldr Radio-Controlled Projec-
tion Alarm Clock .We design and manufacture the item using inno-
vative components and techniques to enable the perfect display of
time by this device.It is also equipped with backlight & projection
functions.Please read the instructions carefully to become familiar
with the properties and functions properly before usage.
English Deutsche FrançaisItaliano Español

For the start-up of this device you require:
An AC Adaptor (Included) and 1xCR2032 Battery(Included)
English
Deutsche
Français
Italiano
Español
English -------------------------------------------03~15
Deutsche -------------------------------------------16~29
Français -------------------------------------------30~42
Italiano -------------------------------------------43~55
Español -------------------------------------------56~68
CONTENTS
For für die Inbetriebnahme dieses Geräts benötigen Sie ：
An Netzadapter (im Lieferumfang enthalten) und 1xCR2032-
Batterie (im Lieferumfang enthalten)
Pour le démarrage de cet appareil vous avez besoin ：
An Adaptateur secteur (inclus) et 1xCR2032 Batterie (incluse)
Per l'avvio di questo dispositivo è necessario ：Un adattatore
AC (in dotazione) e 1xCR2032 batteria (in dotazione)
Para la puesta en marcha de este dispositivo requiere ：
An Adaptador de CA (incluido) y 1xCR2032 Batería (incluida)

Product Overview
Front View
1. Time Zone
2. AM/PM Selectable
3. Current Time
4. RCC indicator
5. DST
6. Snooze indicator
7. Max/min recordsfor
temperature and
humidity
8. Low battery indicator
9. Indoor Temperature
10. Indoor Humidity
11. Comfort Level Indicator
12. Calendar Display / Alarm
Display
13. Alarm indicator
14.Weekday display
1
543
2
6
7
8
12
9
14
11
1013
3
EN

Product Overview
Front View
Top View
1. Focus Adjustment
2. Battery Compartment
3. Alarm On/Off
1. Focus Adjustment 2. Snooze/Dimmer
4. Projection On/Off
5. DC Hole
1
2
3
4
1
4
2
CLOSEOPEN
4
EN

Side View
1. “SET”Button
Short press to switch
between month/date
display and year display
Long press to enter into
time setting
2. “▲/C/F”Button
Short press to switch
between Celsius and
Fahrenheit
Long press to switch the
projection between Time
and Temperature
3. “▼/RCC”Button
Short press to exit the
RCC receiving
Long press to enter into
RCC receiving
4. “ ”Button
Short press to switch
between calendar display
and alarm time display
Long press to enter into
alarm setting
5. “MEM”Button
Short press to check
max/min record
Long press to clear the
max/min record
6. “ ”Button
Short press to reverse the
projection with 90 degree
Long press to adjust
brightness of projection
1
5
3
2
4
6
5
EN

Features
Note:
The default yearis2020, if the weekdaydisplay isincorrect .
Please confirm year was set correctly. (for manual setting only)
Warning:
THIS PRODUCT CONTAINS A BUTTON-CELL BATTERY. IF
SWALLOWED, IT COULD CAUSE SEVERE INJURY OR DEATH
IN JUST 2 HOURS.SEEK MEDICALATTENTION IMMEDIATELY
IF INGESTED.
The CR2032 cell battery is for memory function (included).Please
do not used as power supply. If you need to replace the cell bat-
tery, please take out the part device as shown in the figure below,
load new battery matching the polarity（+and-).
1.
2.
Time, alarm and snooze function
Projection function(Time and temperature switchable)
1.
2.
CLOSEOPEN
C
R
2
0
3
2
+
3V
6
EN

POWER SUPPLY
Connect the power adaptor with DC hole on back of the unit and
plug the adaptor to a powered outlet
Measures indoor temperature(C/F) and humidity
Package Content
Getting Started
Following contents are included in the package：
1xDigital Projection Alarm Clock
1xUser Manual
1xAc Adaptor
1xCR2032 Cell battery
3.
Projection focus adjustable4.
Projection rotate function5.
Calendar function6.
Indoor temperature range:0℃~50℃（32℉~122℉）
8.
Indoor humidity range:1%-99%RH9.
Max/min record of temperature & humidity10.
Comfort level indication(GOOD;DRY;HUMID)11.
RCC in WWVB/DCF/MSF12.
DST function13.
Orange backlight with dimmer14.
Low battery indicator (CR2032 battery memory mode)15.
Key tone ON/OFF selectable16.
Weekdays in 7 languages: GER (German), ENG (English), FRE
(French),ITA(Italian), SPA(Spanish),DUT(Dutch),DRN(Denmark)
7.
7
EN

RCC Receiving Conditions:
MAIN UNIT SETUP
SET AUTOMATIC TIME
When power on or reset, LCD will full display for 3 seconds with “BI”
sound.
The default value is :
When power on or reset, the clock will start searching radio signal
for 7 minutes with the antenna symbol “ ’’ displaying in the
screen.
1.
Weekday
Language
(WWVB/
MSF)
ENG
Weekday
Language
(DCF)
GER
Time
Display
(WWVB/
MSF)
12HR
Time
Display
(DCF)
24HR
Key tone
ON
Date
Display
2020.
01.01
Tempera-
ture Unit
(DCF/MSF)
℃
Tempera-
ture Unit
(WWVB)
℉
RCC
Function
ON
Time zone
（DCF)
0hr
Time zone
（WWVB)
-5 EST
Alarm
Time
AM7:00
(OFF)
Date
Format
(DCF/MSF)
D/M
Date
Format
(WWVB)
M/D
8
EN

9
EN
There are dailyautomaticRCC receiving at 1:00AM,2:00AM,
3:00AM, 4:00AM,5:00AM. It will first start receiving DCF/
WWVB/MSF time at 1:00AM, 2:00AM, 3:00AM each day. If DCF/
WWVB/MSF time is not received till 3:00AM, it will start
receiving again at 4:00AM and 5:00AM. If the time is not
successfully received at 5:00AM, there will be no receiving the
day, It will start searching for signal at 1:00AM the next day.
2.
On normal time mode, press “SET ’’ button to enter RCC signal
receiving.
3.
During RCC reception, press“SET ’’ button to exit RCC receiving.4.
The time will be converted to the current time of corresponding
time zone after receiving the RCC .(Except 0 time zone)
a. When receiving signal , RCC icon will be flashing by“1HZ”
It will exit RCC receiving automatically when the alarm is per-
formed during RCC reception , you can repeat step 3 to enter
RCC signal receiving after turning off the alarm.
5.
After signal received,ifthere isno need for other settings, you
can just finish reading here. If there is other setting requirements.
Please check the following steps. Or if there is no signal received,
you can follow bellow steps for manual setting.
1.
c. If no signal is received, the RCC icon will disappear.
Remark:
SET MANUAL TIME
RCC symbol display:
●
b. When signal successfully received, LCD will display complete
RCC icon and exit RCC receiving.

10
EN
Press and hold “SET ”button to enter into setting, press
“SET ’’button to skip setting stepsor go to the next setting
option,the setting data will be flashing in 1Hz.
2.
Press “ SET ’’ button toselect Weekday Language. Press the
“▲/C/F” or“▼/RCC” button to select languages: ENG、GER、ITA、
FRE、DUT、SPA、DAN optional . (English/German/Italian/-
French/Dutch/Spanish/ Danish),Default setting :GER(DCF),ENG
(WWVB/MSF)
3.
Press “ SET ’’ button to select key tone ON/OFF,Press “▲/C/F” or
“▼/RCC”button to select.Default setting : key tone ON
4.
Press “ SET ’’ button to select temperature Unit.Press “▲/C/F” or
“▼/RCC”button to select ℃or ℉.Default setting : ℃.
(DCF/MSF) ℉(WWVB)
5.
Press “ SET ’’button to select the RCC. Press “▲/C/F” or“▼/RCC”
button to select OFF or ON. Default setting : RCC ON.
6.
Press “ SET ’’button to select DST. Press “▲/C/F” or “▼/RC-
C” button to select DST mode from DST ON to DST ALWAYS to
DST OFF.
7.
Press “ SET ’’button to select Time Zone. Press “▲/C/F” or
“▼/RCC”button to select time zone from -12 H to + 12 H.Default
setting : 0 hr(DCF) -5EST(WWVB)
8.
Press “ SET ’’button to select Year. Press “▲/C/F” or“▼/RCC”but-
ton to adjust the value.
9.
Press “ SET ’’ button toselect date display mode. Press
“▲/C/F” or “▼/RCC”button toselect D/M or M/D mode .Default
setting : D/M(DCF/MSF) M/D(WWVB)
10.
Press “ SET ’’button to select Month. Press“▲/C/F” or“▼/RC-
C”button to adjust the value.
11.
Press “ SET ’’ button to select date. Press“▲/C/F” or“▼/RC-
C”button to adjust the value.
12.
Press“ SET ’’button to select time display mode. Press“▲/C/F”or
“▼/RCC”button toselect 12hr or 24hr.Default setting : 24hr
format(DCF) 12hr format(MSF/WWVB)
13.

EN
Press “ SET ’’ button to select Hours. Press “▲/C/F” or“▼/
RCC” button to adjust the value.
14.
Press “ SET ’’button to select Minutes. Press “▲/C/F”or“▼/RCC”
button to adjust the value.
15.
Press“ SET ’’button to confirm and exit.16.
During the setting,if no operation for 20 seconds, it will automati-
cally save and exit setting.
Remark: There are 7 languages selectable for weekday display:
FRE、SPA、ENG、GER、ITA、DUT、DRN
*Tips: press and hold “▲/C/F” or “▼/RCC”button will quickly
change the value by 8steps.
17.
Language
Sunday
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
German
GER ENG FRE ITA SPA DUT DRN
English French Italian Spanish Dutch Denmark
SON
MON
DIE
MIT
DON
FRE
SAM
SUN
MON
TUE
WED
THU
FRI
SAT
DIM
LUN
MAR
MER
JEU
VEN
SAM
DOM
LUN
MAR
MER
GIO
VEN
SAB
DOM
LUN
MAR
MIE
JUE
VIE
SAB
ZONSON
MRR MRN
DIN TIR
WOE ONS
DON TOR
VRI FRE
ZRT LOR
11

EN
Press and hold “ ” button to enter into alarm time setting mode.1.
ALARM FUNCTION
SNOOZE FUNCTION
When in time display mode, press “ ” button to checkbetween
alarm time and calendar.
1.
Slide the switchon the back toturn on/off alarm by the
ON/OFF of symbol .
2.
When the alarm is ringing, press any otherbutton except top
button to stop the alarm. And the alarm will restart next day.
1.
OR when alarm is ringing, press “ ” button to activate
snooze function. And the alarm will repeat in each 5 minutes. The
“”symbol will beflashing on screen toindicate the snooze
mode.Press any other button except top button to exit the snooze
mode.And the alarm will restart next day.
2.
When alarm rings, the ascending “Bibi” alarm sound will last for 2
minutes if no operation.
3.
The setting order is: Hour → Minute→Exit. 3.
During setting, touch top button to save and exit setting4.
During setting,If no operation for20 seconds, it will automatically
save and exit setting.
5.
The alarm is default ON after setting the alarm time.Alarm symbol
will display on screen.
6.
Press “▲/C/F” or “▼/RCC”button to adjust data; press and hold
“▲/C/F” or“▼/RCC”button will quickly change the data by 8 steps.
2.
SET ALARM TIME:
TURN ON/OFF ALARM:
12

EN
Slide the switch on the back of unit to turn on/off projection.
●
Press the button to reverse the projection data with 90 degree
from 0°→90°→180°→270°→0°
●
PROJECTION FUNCTION
TEMPERATURE&HUMIDITY
Press and hold the button to switch the brightness of the
projection.
●
Press and hold the “▲/C/F” button to switch the projection data
between time and temperature.
●
Slide the “focus”switch on the backof unit to adjust the focus of
projection.
●
Press “ ”button to turn on the backlight.
●
Press “ ”button to switch backlight brightness among 100%,
50% and off.
●
BACKLIGHT FUNCTION
Indoor temperature display range :0°C~50°C (32°F ~122°F).,LL.L
or HH.H will display when out of range
●
Indoor humidity range:1%-99%,1% or 99% will display when out
of range
●
Accuracy: For temperature between 0℃~50℃,the accuracy
is±1 ℃; For humidity between 40-70%RH,the accuracy
is±5%RH,if out of this range,the accuracy will be±8%RH.
Remark:The reading will be more accurate standing still for half an
hour after power on.
●
13

EN
Precautions
MAX AND MIN RECORD
COMFORT LEVEL INDICATION
Press “MEM’’ to have maximum temperature and humidity(within
24 hours), the value will display for 5 seconds.
1.
Press “MEM’’second time to have the minimum temperature and
humidity(within 24 hours), the value will display for 5 seconds.
2.
Press “MEM’’third time will return to standard mode.3.
Press and hold “MEM’’ will clear the max and min record and
reactivate the memory.
4.
Normally, the Max and Min record will update every 24 hours at
0:00.
Humidity 1-39%RH (Too Dry)
Humidity 40-75%RH(Comfortable)
5.
Humidity 76-99%RH(Too Wet)
Do not clean any part of the product with benzene, thinner or other
solvent chemicals. When necessary, clean with a soft cloth.
Do not subject the product to extreme force, shock, or fluctuations
in temperature or humidity.
Never immerse the product in water. This will damage the product.
Do not tamper with the internal components.
Do not mix new and old batteries or batteries of different types.
Do not mix alkaline, standard or rechargeable batterieswith this
product.
14

EN
Warranty
Remove the batteries if storing this product for a long period of time.
BALDR provides a 1-year limited warranty on this product against
manufacturing defects in materials and workmanship.
Warranty service can onlybe performed byour authorized service
center. The original dated bill of sale must be presented upon
request as proof of purchase to us, or our authorized service center.
The warranty covers all defects in material and workmanship with
the following specified exceptions:(1) damage caused by accident,
unreasonable use or neglect (including the lack or reasonable and
necessary maintenance); (2) damage occurring during shipment
(claims must be presented tothe carrier); (3) damage to, or deterio-
ration of anyaccessory or decorative surface;(4) damage resulting
from failure to follow instructions contained in your owner’s manual.
This warranty covers only actual defects within the product itself,
and does not cover the cost of installation or removal from a fixed
installation, normal set-up or adjustments, claims basedon misrep-
resentation bythe seller or performance variations resulting from
installation-related circumstances.
To receive warranty service, the purchaser must contact with
BALDR nominated service center for the problem determination and
service procedure.
Thank you for your choice of BALDR products!
Do not dispose of this product as unsorted municipal waste. Collec-
tion of such waste separately for special treatment is necessary.
15

Produkt-Übersicht
Vorderansicht
16
1. Zeitzone
2. AM/PM wählbar
3. Aktuelle Zeit
4. RCC-Anzeige
5. DST
6. Schlummer-Indikator
7. Max/Min-Aufzeichnungen
für Temperatur und
Luftfeuchtigkeit
1
543
2
6
7
8
12
9
14
11
1013
8. Anzeige für schwache
Batterie
9. Innentemperatur
10. Raumluftfeuchtigkeit
11. Komfortniveau-Anzeige
12. Kalenderanzeige /
Alarmanzeige
13. Alarmanzeige
14. Wochentag-Anzeige
DE

17
1. Fokus-Anpassung
2. Batteriefach
3. Alarm ein/aus
1. Projektionslinse 2.Snooze/Dimmer
Rückansicht
Ansicht von oben
1
2
1
2
3
4
4
CLOSEOPEN
4. Projektion ein/aus
5. DC-Loch
DE

18
Seitenansicht
1. "SET"-Taste
Kurz drücken, um zwischen
der Monats-/Datumsanzeige
und der Jahresanzeige
umzuschalten
Lang drücken,
um in die Zeiteinstellung zu
gelangen
4. “ "Schaltfläche
Kurz drücken, um zwischen
Kalenderanzeige und
Alarmzeitanzeige
umzuschalten
Lang drücken,
um in die Alarmeinstellung zu
gelangen
2. "Schaltfläche "▲/C/F
Kurz drücken, um zwischen
Celsius und Fahrenheit zu
wechseln
Lang drücken, um
die Projektion zwischen Zeit
und Temperatur
umzuschalten
5. "MEM"-Schaltfläche
Kurz drücken, um Max/Min-
Eintrag zu prüfen
Lang drücken, um den Max/
Min Datensatz zu löschen
6. “ "Schaltfläche
Kurzes Drücken, um die
Projektion mit 90 Grad
umzukehren
Lange drücken, um die
Helligkeit der Projektion
einzustellen
3. "▼/RCC"Schaltfläche
Kurz drücken, um den RCC-
Empfang zu verlassen
Langes Drücken, um in den
RCC-Empfang einzutreten
1
5
3
2
4
6
DE

19
Merkmale
Anmerkung:
Warnung:
DIESES PRODUKT ENTHÄLT EINE
KNOPFZELLENBATTERIE. BEI VERSCHLUCKEN KANN
ES INNERHALB VON NUR 2 STUNDEN SCHWERE
VERLETZUNGEN ODER DEN TOD VERURSACHEN.BEI
VERSCHLUCKEN SOFORT EINEN ARZT AUFSUCHEN.
1. Das Standardjahr ist 2020, wenn die Wochentagsanzeige nicht
korrekt ist. Bitte bestätigen Sie, dass das Jahr korrekt eingestellt
wurde. (nur bei manueller Einstellung)
2. Die CR2032-Zellenbatterie ist für die Speicherfunktion (im
Lieferumfang enthalten). Bitte nicht als Stromversorgung
verwenden. Wenn Sie die Zellenbatterie austauschen müssen,
nehmen Sie bitte das Teilgerät wie in der Abbildung unten
gezeigt heraus, legen Sie eine neue Batterie passend zu polarity
（+and-) ein.
1. Zeit-, Alarm- und Schlummerfunktion
2. Projektionsfunktion (Zeit und Temperatur umschaltbar)
3. Misst Raumtemperatur (C/F) und Luftfeuchtigkeit
CLOSEOPEN
C
R
2
0
3
2
+
3V
DE

20
STROMVERSORGUNG
4. Projektionsfokus einstellbar
5. Projektions-Drehfunktion
6. Kalender-Funktion
7. Wochentags in 7 Sprachen: GER (Deutsch), ENG (Englisch),
FRE (Französisch),ITA(Italienisch), SPA(Spanisch),DUT
(Niederländisch),DRN(Dänemark)
8. Innentemperaturbereich:0℃~50℃（32℉~122℉）
9. Raumluftfeuchtigkeitsbereich:1%-99%RH
10. Max/Min-Aufzeichnung von Temperatur und Feuchtigkeit
11. Komfortniveau-Anzeige(GUT;TROCKEN;FEUCHTIG)
12. RCC im WWVB/DCF/MSF
13. DST-Funktion
14. Orange Hintergrundbeleuchtung mit Dimmer
15. Anzeige für schwache Batterie (CR2032-Batterie-
Speichermodus)
16. Tastenton EIN/AUS wählbar
Inhalt des Pakets
Folgende Inhalte sind in der package enthalten：
1xDigitaler Projektionswecker
1xBenutzerhandbuch
1xAc-Adapter
1xCR2032 Zellen-Batterie
Erste Schritte
Schließen Sie das Netzteil mit dem Gleichstromloch auf der
Rückseite des Geräts an und stecken Sie das Netzteil in eine
Steckdose
DE
