WG400
Line Array Source
LF Drivers LF Nd Drivers Coaxials HF Drivers Horns
Line Array optimized Waveguide
Max. horizontal coverage 140°
100 W continuous program power capacity
44 mm (1.7 in) aluminium voice coil
Polyimide diaphragm
1200 – 18000 Hz response
108.5 dB sensitivity
Specifications
Horizontal Coverage 140° max
Active Radiating Factor 92.5 %
Recommended Crossover (1) 1.5 kHz
Waveguide Material Cast Aluminium
Nominal Impedance 8 ohm
Minimum Impedance 7.7 ohm
Nominal Power Handling (2) 50 W
Continuous Power Handling (3) 100 W
Sensitivity (1W/1m) (4) 108.5 dB
Frequency Range (5) 1.2 -18 kHz
Voice Coil Diameter 44 mm (1.7 in)
Winding Material Aluminium
Diaphragm Material Polyimide
Flux Density 1.8 T
Mounting and Shipping Info
Waveguide Baffle Cutout 102x25 mm (4x1 in)
Driver diameter 86 mm (3.3 in)
Dimensions 111x87x155 mm
(4.4x3.5x6.1 in)
Net Weight 1.3 kg (2.9 lb)
Shipping Weight 1.35 kg (3.0 lb)
Shipping Box 120x95x180 mm
(4.7x3.7x7.1 in)
112 dB/oct. or higher slope high-pass filter.
22 hours test made with continuous pink noise signal (6 dB crest factor).
Power calculated on rated minimum impedance.
3Power on Continuous Program is defined as 3 dB greater than the
Nominal rating.
4Applied RMS Voltage is set to 2.83V for 8 ohms Nominal Impedance.
5Waveguide mounted on 90°x10° bell horn
