B&C Speakers Midrange 6MDN44 User manual

6MDN44 Midrange
LF Drivers LF Nd Drivers Coaxials HF Drivers Horns
300 W continuous program power capacity
44 mm (1.7 in) aluminium voice coil
150 - 6000 Hz response
96.5 dB sensitivity
Specification
Nominal Diameter 170 (6.5) mm (in)
Nominal Impedance (1) 8 Ohm
Minimum Impedence 6.5 Ohm
Nominal Power Handling (2) 150 W
Continuous Power Handling (3) 300 W
Sensitivity (1W/1m) (4) 96.5 dB
Frequency Range 150 - 6000 Hz
Voice Coil Diameter 44 (1.7) mm (in)
Winding Material Aluminium
Former Material Glass Fibre
Winding Depth 9.5 (3/8) mm (in)
Magnetic Gap Depth 6 (0.25) mm (in)
Flux Density 1.45 T
Thiele & Small Parameters
Fs 140 Hz
Re 5.4 Ohm
Qes 0.46
Qms 2.8
Qts 0.40
Vas 2.7 (0.09) dm3 (ft3)
Sd 132 (20.5) cm2 (in2)
Eta Zero 1.6 %
Xmax +/- 2.5 mm
Xvar +/- 3.0 mm
Mms 11 g
Bl 11 Txm
Le 0.47 mH
Mounting and Shipping Info
Overall Diameter 187 mm (7.4 in)
Bolt Circle Diameter 172 mm (6.7 in)
Baffle Cutout Diameter 145 mm (5.7 in)
Depth 73 mm (2.9 in)
Flange and Gasket Thickness 11 mm (0.4 in)
Net Weight 1.0 kg (2.2 lb)
Shipping Weight (4 units) 5.3 kg (11.7 lb)
Shipping Box (4 units) 405x225x210 mm
(15.9x8.8x8.3 in)
1For different impedances, please ask.
22 hours test made with continuous pink noise signal (6 dB crest factor).
Power calculated on rated minimum impedance.
3Power on Continuous Program is defined as 3 dB greater than the
Nominal rating.
4Applied RMS Voltage is set to 2.83V for 8 ohms or 2.0V for 4 ohms
Nominal Impedance
