B&C IC-1355 User manual

Ironer
IC-13 Series Installation and Operation Manual
July 25, 2017
Revision 1.0

Contents
1 Important Safety Information 1
1.1 FORYOURSAFETY-CAUTION! ............................. 1
2 Important Instructions 2
2.1 BeforeAttemptingRepairs.................................. 2
2.2 PartsOrderingInformation ................................. 3
2.2.1 NameplateLocation ................................. 3
2.3 KeySymbols.......................................... 3
2.4 SafetyInformation ...................................... 3
2.5 Installation and Operational Safety Instructions . . . . . . . . . . . . . . . . . . . . . 5
3 Installation 7
3.1 InstallationNote........................................ 7
3.2 ReceivingInspection ..................................... 7
3.3 ElectricalInstallation ..................................... 8
3.4 GasConnection ........................................ 9
3.4.1 GasSupplyLine ................................... 9
3.4.2 Gas Supply Connection Requirements . . . . . . . . . . . . . . . . . . . . . . . 10
3.5 ExhaustRequirements .................................... 11
3.6 FreshAirRequirements ................................... 12
3.7 HandlingandUnpacking .................................. 13
3.8 RoomRequirements ..................................... 14
4 Operation 15
i

4.1 HeatCircuitOperationTest ................................. 15
4.2 InitialStartup ......................................... 16
4.3 UserSafety........................................... 17
4.4 HeatingSystemSafety .................................... 17
4.5 WorkingPrinciple....................................... 17
5 User Instructions 18
5.1 DailyUse............................................ 18
6 Easy Control 20
6.1 Introduction .......................................... 20
6.2 UserInterface ......................................... 20
6.3 MachineUse.......................................... 21
6.3.1 StartingtheMachine................................. 21
6.3.2 ShutDownProcedure ................................ 21
6.4 IroningSpeedControl .................................... 22
6.5 Heating............................................. 22
6.5.1 Electrical Heating Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.5.2 GasHeating...................................... 23
6.5.3 Progamming the Working Temperature . . . . . . . . . . . . . . . . . . . . . . 23
6.6 AlarmMessages........................................ 24
6.6.1 AL1 - Insufficient Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.6.2 AL4-FanThermalRelay .............................. 24
6.6.3 AL5-InverterFault ................................. 25
6.6.4 AL6-FlameFailure ................................. 25
6.6.5 AL7 - Overheat / Temperature Probe Fault . . . . . . . . . . . . . . . . . . . . 26
6.7 ProgrammingParameters .................................. 26
6.7.1 Temperature Measurement Unit . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.7.2 MaximumTemperature ............................... 28
6.7.3 OperatingTemperature ............................... 28
6.7.4 TemperatureRegulation............................... 28
ii

6.7.5 StopTemperature................................... 29
6.7.6 HeatingType ..................................... 29
6.7.7 Number of Resistor Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7 Maintenance 31
7.1 Warranty............................................ 31
7.2 RoutineMaintenance..................................... 32
7.2.1 Cleaning........................................ 32
7.2.2 MaintenanceIntervals ................................ 32
7.3 Service&Parts ........................................ 35
7.3.1 Service......................................... 35
7.3.2 Parts .......................................... 36
8 Maintenance Instructions 37
8.1 ReplacingInfeedBelts .................................... 37
8.2 ReplacingIroningBelts.................................... 38
8.3 Replacing the Support Rollers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8.4 ReplacingtheSideRollers .................................. 39
9 Basic Troubleshooting 41
9.1 Power Failure During Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
9.2 OtherFaults .......................................... 41
9.3 Lengthy Out of Service Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
10 Decommisioning 43
A Gas Conversion Technique 44
iii

Chapter 1
Important Safety Information
1.1 FOR YOUR SAFETY - CAUTION!
WARNING: For your safety the information in this manual must be followed to minimize the
risk of fire or explosion or to prevent property damage, personal injury, or death.
•Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
•WHAT TO DO IF YOU SMELL GAS:
–Do not try to light any appliance
–Do not touch any electrical switch; do not use any phone in your building.
–Clear the room, building or area of all occupants.
–Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
–If you cannot reach your gas supplier, call the fire department.
•Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
Contact your local gas supplier to obtain particular instructions in the event that a user smells
gas. Place this sheet and any other instructions obtained from your gas supplier in a prominent
location.
1

Chapter 2
Important Instructions
2.1 Before Attempting Repairs
Moving parts can cause serious injury or death. Before attempting repairs, follow proper shut-
down procedures, remove power, and allow the machine to fully cool before commencement of
service.
Safety is of primary concern with any maintenance or repair operation. If you are in any way
unsure of how to proceed with a repair or adjustment, consult this manual, a qualified mainte-
nance technician, your local distributor, or the B&C Technologies Technical Service Department at
850-249-2222.
Only trained and experienced personnel should attempt maintenance or repair work on this equip-
ment. Follow all safety procedures including lock-out/tag-out procedures carefully. Ensure that
any loose fitting clothing or jewelry is tucked in or not worn to avoid being pulled into the ma-
chine. Remember, the machine has no brain - you must use your own.
Before attempting repairs, follow proper shutdown procedures, remove power, and allow the ma-
chine to fully cool before beginning service.
Never attempt to clean or service any area of the machine without removing power at the main
disconnect and allowing time for the machine to cool completely.
2

Read, follow, and obey these safety rules! The B&C Technologies Technical Service Department
is available to answer any questions you may have about the operation and servicing of your
machine. Please call with any questions or concerns about the operation of your machine.
2.2 Parts Ordering Information
If you require literature or spare parts, please contact your local distributor. If a local distributor
is unavailable, you may contact B&C Technologies directly at [phone] for the name of your
nearest parts dealer.
For technical assistance in the United States, contact B&C Technologies:
[phone] Phone
[phone] FAX
[email protected]
www.bandctech.com
2.2.1 Nameplate Location
When contacting B&C Technologies about your equipment, please make note of the model and
serial number, located on the nameplate on the rear of the machine.
2.3 Key Symbols
Anyone operating or servicing this machine must follow the safety rules in this manual. Partic-
ular attention must be paid to the DANGER, WARNING, and CAUTION blocks which appear
throughout the manual and shown in figures 2.1 on page 4 and 2.2 on page 4.
2.4 Safety Information
Installation Notice: For personal safety and for proper operation, the machine must be grounded
in accordance with state and local codes and in the USA in accordance with the National Electric
Code, article 250-96. Elsewhere, the equipment should be grounded in accordance with ANSI/NFPA
70, or the Canadian Electrical Code, CSA C22.1. The ground connection must be to a proven earth
ground, not to conduit or water pipes.
3

Figure 2.1: Key Symbols
Figure 2.2: Key Symbols
4

Natural Gas or Liquid Propane Gas (LP Gas) heated equipment installation must comply with
state and local codes, and in the USA, in accordance with the National Fuel Gas Code. Elsewhere,
the equipment should comply with ANSI Z22.1 or CSA B149.
Provisions must be made for adequate make-up air and ventilation, and access for equipment
service and installation.
2.5 Installation and Operational Safety Instructions
1. Read all instructions prior to operating this equipment.
2. Ensure that the equipment is properly grounded before applying power and operation be-
gins.
3. Do not process goods that have been previously cleaned in, soaked in, or exposed to gasoline,
dry cleaning chemicals, or any other flammable or explosive materials, as they could catch
fire or explode without warning, even after being washed.
4. Do not allow children to play in or around or operate this equipment.
5. Check the operation of all safety interlocks at the start of every shift. If the interlocks do not
stop the equipment immediately, the machine must be removed from service. Notify your
immediate supervisor, and do not operate the machine.
6. Never attempt to service the machine while it is running. Never reach over, under, around, or
behind any safety device, or into any area near moving parts or hot surfaces without shutting
off power and allowing the machine to adequately cool.
7. Read, understand, and follow all safety instructions. Do not come close to moving parts and
hot surfaces. Do not wear loose clothing, jewelry, neckties, or any other garment that could
become caught in the machine while operating or near the machine.
8. Only a qualified technician should attempt to service or repair the ironer.
9. Do not install the machine in an area where it could be exposed to water or weather.
10. Do not alter or tamper with the control system.
11. To reduce the risk of fire, do not process plastics or articles containing foam rubber or simi-
larly textured rubber-like materials.
12. Keep the area near the exhaust ducting clean and free of lint, dust, dirt or debris.
13. Keep the interior and exterior of the machine clean of lint, dirt, dust and debris. The inte-
rior of the machine, along with the exhaust ductwork should be periodically inspected and
cleaned to avoid potential fires (lint is highly flammable).
14. Improper installation, operation and maintenance of this machine can cause exposure to sub-
stances in the fuel or from combustion that can cause serious illness or death. The machine
must be exhausted to the outside.
5

15. Always disconnect the electrical service from the machine and allow it to cool before per-
forming service.
16. This machine must be installed according to the installation instructions. All exhaust, elec-
trical connections, and gas or steam connections must comply with state and local codes and
must be made by a licensed installer where required.
6

Chapter 3
Installation
3.1 Installation Note
Caution: this machine may only be installed, adjusted, updated, and started up by authorized
technicians or resellers.
The machine must be installed in accordance with current standards and regulations, in a room
with sufficient make-up air and exhaust.
3.2 Receiving Inspection
Upon receipt of the equipment visually inspect for shipping damage and note any damage with
the carrier before signing the shipping receipt, or advise the carrier of the damage as soon as it is
noted.
If damage is discovered, a written claim must be filed with the carrier as soon as possible.
Note: Warranty is void if the equipment is not installed according to instructions. The installation
must comply with the minimum requirements listed in this manual. All national, state, and local
codes must be followed including but not limited to gas, electrical, plumbing, and HVAC. Due to
various requirements, statutory codes should be well understood before installation.
Important: The ironer should be transported and handled in an upright position.
7

Table 3.1: IC-13 General Specifications
Model Metric US IC-1355 IC-1363 IC-1379
Number of Rolls # 1 1 1
Roll Diameter mm inch 325 13 325 13 325 13
Working Width mm inch 1400 55 1600 63 2000 79
Speed Range m/min ft/min 1-6.5 3.3-21.5 1-6.5 3.3-21.5 1-6.5 3.3-21.5
Sound Level dB 60 60 63
Dimensions
A - Width mm inch 1960 77.2 2210 87.0 2630 103.5
B - Depth mm inch 644 25.4 644 25.4 644 25.4
C - Height mm inch 1107 43.6 1107 43.6 1107 43.6
Exhaust System
Air Flow, Primary cmm cfm 2 x 8 2 x 295 2 x 8 2 x 295 2 x 8 2 x 295
Exhaust Duct mm inch 2 x 98 2 x 3.85 2 x 98 2 x 3.85 2 x 98 2 x 3.85
Electric Heat
Consumption kW 12 16 21
Roll Motor kW HP 1/4 1/3 1/4 1/3 1/4 1/3
Fan Motor kW HP 1/8 1/6 1/8 1/6 1/8 x2 1/6 x2
208-240VAC, 50/60Hz, 3PH Amps Breaker 32 40 49 50 63 80
380-480VAC, 50/60Hz, 3PH Amps Breaker 16 20 25 30 32 40
Gas Heat
Heat Input BTU 48,000 77,000 102,000
Roll Motor kW HP 1/4 1/3 1/4 1/3 1/4 1/3
Fan Motor kW HP 1/8 x2 1/6 x2 1/8 x2 1/6 x2 1/8 x2 1/6 x2
120VAC, 50/60Hz, 1PH Amps Breaker 8 15 8 15 8 15
208-240VAC, 50/60Hz, 1PH Amps Breaker 4 15 4 15 4 15
208-240VAC, 50/60Hz, 3PH Amps Breaker 2 15 2 15 2 15
380-480VAC, 50/60Hz, 3PH Amps Breaker 2 15 2 15 2 15
Weight & Shipping
Net Weight kg lbs 300 660 355 781 405 891
Shipping Weight kg lbs 335 737 375 825 428 942
3.3 Electrical Installation
Refer to Table 3.2 on page 9 for full details on the electrical requirement for your specific model
prior to installation.
Electrical connections should be made by a qualified electrician in accordance with all applicable
codes or requirements. Use a separate branch circuit to power each machine. Do not share circuits
with lighting or any other equipment.
Because this is a vibrating machine, use SO cable (or similar) with a twist-lock plug to connect
the machine to main power. A shielded liquid tight or approved flexible conduit with proper
conductor of correct size installed in accordance with National Electric Code (USA) or other appli-
cable codes is required. The connection must be made by a qualified electrician using the wiring
diagram provided with the machine.
For personal safety and for proper operation the machine must be grounded in accordance with
state and local codes and in the USA in accordance with the National Electric Code, article 250-96.
The ground connection must be to a proven earth ground, not to conduit or water pipes.
8

Do not connect the ground to the neutral (N) leg at the terminal strip (if so equipped).
If a DELTA supply system is used, the high leg should be connected to L3, since control voltage is
derived from L1 and L2.
Note:
Ensure that all power connections are tight. Loose connections will
cause burned wires and contactors on electrically heated machines.
Check the electrical connections at the incoming power terminal block,
contactors, and heating elements at installation, after the first week of
operation, and quarterly thereafter. Failure of switchgear due to negli-
gence in this area is not covered under any warranty!
Table 3.2: Electrical Requirements
Electrical Requirement - Electrical Heating
Model IC-1355 IC-1363 IC-1379
Motor Power (kW / HP) 0.37 / 0.5 0.37 / 0.5 0.49 / 0.75
Heating Power (kW) 12 16 21
Max kVA 15.5 20.5 27
Breaker Size 380-460V 20 30 40
208-230V 40 50 80
Cable Size (mm2/ AWG) 380-460V 4 / 10 4 / 10 16 / 5
208-230V 6 / 9 10 / 7 35 / 2
Electrical Requirements - Gas Heating
Model IC-1355 IC-1363 IC-1379
Motor Power (kW / HP) 0.37 / 0.5 0.37 / 0.5 0.49 / 0.75
Max kVA 1 1 1
Breaker Size
380-460V 10 10 10
208-230V 10 10 10
120V 15 15 15
Cable Size (mm2/ AWG)
380-460V 2.5 / 14 2.5 / 14 2.5 / 14
208-230V 2.5 / 14 2.5 / 14 2.5 / 14
120V 2.5 / 14 2.5 / 14 2.5 / 14
3.4 Gas Connection
3.4.1 Gas Supply Line
•1” IPS pipe is recommended.
9

Figure 3.1: Gas Plumbing Detail
•1” approved tubing is acceptable for lengths under 25 ft (6.1 m) if local codes and gas supplier
permit.
•Must include 1/8” NPT minimum plugged tapping accessible for test gauge connection,
immediately upstream of the gas connection to the ironer (see figure 3.1 on page 10).
•Must include a shutoff valve:
An individual manual shutoff valve must be installed within 6 feet (1.8m) of the equip-
ment in accordance with the National Fuel Gas Code, ANSI Z223.1. The location should
be easy to reach for opening and closing.
3.4.2 Gas Supply Connection Requirements
There are many methods by which the IC series ironer can be connected to the gas supply. Follow-
ing are some guidelines for methods of connection.
Option 1:
Flexible stainless steel gas connector:
If local codes permit use a new flexible stainless steel connector (design certified by the American
Gas Association or CSA International) to connect between the ironer and the gas supply line. Use
an elbow and a 1”’ flare x 1”’ NPT adapter fitting between the stainless steel gas connector and the
gas inlet of the machine as needed to prevent kinking.
Option 2:
Other approved piping:
Lengths under 25 feet (6.1m) use 1”’ approved tubing.
10

Lengths over 25 feet (6.1m) should use larger piping.
Pipe joint compounds that resist the action of gas must be used. DO NOT USE TEFLON R /PTFE
TAPE.
IMPORTANT: Be certain the ironer is configured for the type of gas being used. The gas type is
shown on the serial sticker on the electrical panel of the unit.
Inlet Pressure
Use a manometer to verify that the inlet pressure meets the following requirements:
Natural Gas service must be supplied at 8-14 inches of water column pressure.
LP Gas service must be supplied at 11-14 inches of water column pressure.
If the incoming gas pressure exceeds the above, install a locally obtained gas regulator that has
sufficient BTU capacity to supply the machine (Maxitrol 325-5AL for up to 300,000 BTU, 327-7L
for up to 900,000 BTU or equivalent). A chattering gas valve indicates improper line pressure, not
a faulty gas valve.
Manifold Pressure (Secondary)
Be sure to check the manifold pressure. Use a manometer to verify that the manifold pressure
matches the information on the serial sticker and the type of gas being used. A separate gas
regulator (locally obtained) must be installed if the incoming line pressure is greater than 14 inches
water column pressure.
1. Connect the manometer to the pressure connection on the gas valve (disconnect gas service).
2. Restore gas service and determine the pressure while the burner is ignited. The pressure
must match the indicated manifold pressure on the serial sticker.
Gas Conversion Notice: Do not connect a machine configured for Natural Gas to LP Gas service or
vice-versa without a qualified service technician doing a proper conversion. After the reconfigura-
tion is complete, the manifold pressure must be verified. See Section A on page 44 for conversion
details.
3.5 Exhaust Requirements
For best results, install the machine near an outside wall in order to keep the exhaust duct length
as short as possible, and to provide a source of make-up air. The rear of the ironer should not
be blocked. Blocking the air inlets prevents proper combustion, and will yield poor results, and
possibly harmful combustion byproducts. See recommended exhaust style in Figure 3.3 on page
13.
Important: Do not interrupt the flow of make-up air or the exhaust!
11

Figure 3.2: IC Series - Proper Exhaust is critical for safety!
For maximum efficiency and minimum lint accumulation the ironer must be exhausted to the
outdoors by the shortest possible route. Properly sized exhaust ducts are essential for proper
operation. Any 90-degree elbows used should be sweep type, however, 45-degree elbows are
preferable as they don’t create as much back pressure. Exhaust ducts must be assembled such that
all interior surfaces are smooth so the joints do not permit the accumulation of lint. Do not use
plastic or thin foil ducts — rigid metal ducts are recommended. Use exhaust ducts made of sheet
metal or other noncombustible material. Do not use sheet metal screws or fasteners on exhaust
pipe joints which extend into the duct and catch lint. Use duct tape or pop-rivets on all seams and
joints. The maximum allowable back pressure is 0.3 inches water column. Don’t guess, measure!
Note: Check for proper exhaust fan rotation direction before placing the equipment into ser-
vice. If the rotation is incorrect, remove power from the machine and exchange any two incom-
ing power leads. (3 phase machines only)
Note: Avoid locating the exhaust next to the fresh air supply intake.
Note: Avoid the use of ”booster fans”.
3.6 Fresh Air Requirements
When the ironer is operating, it draws in room air to carry heat and moisture from the ironed
goods and exhausts it out of the building. Therefore, the room air must be continually replenished
from outside the building.
If the make-up air is inadequate, efficiency will be adversely affected. Ignition problems and air
flow alarms may result.
Air supply (make-up air) must be given careful consideration to assure proper performance of each
ironer. An unrestricted source of air is necessary for each ironer. As a general rule, an unrestricted
12

Figure 3.3: IC Series - Exhaust Detail
air entrance from the outdoors (atmosphere) of a minimum of 1 sq ft is required for each ironer. If
registers or louvers are installed over the openings, then the area must be increased by at least one
third.
Allowances must be made for remote or constricting passageways or where ironers are located at
excessive altitudes or predominantly low-pressure areas.
Note: Avoid locating the exhaust next to the fresh air supply intake.
The flow of fresh air required make-up air is as follows:
Table 3.3: IC-13 Make-up Air Requirements
Model Metric US IC-1355 IC-1363 IC-1379
Air Flow cm/hr cf/hr 28 1000 45 1600 60 2200
3.7 Handling and Unpacking
Upon delivery, the ironer must be in perfect condition and the packing material must not be incom-
plete or damaged. Pay attention to the markings on the packaging (e.g. FRAGILE, UP/DOWN,
PROTECT FROM RAIN, etc).
Provide for adequate lifting and handling devices in order to proceed safely.
The ironer must be handled using a lift-truck of sufficient capacity and the truck forks must be
opened as much as possible to avoid toppling the ironer.
13

The ironer must be lifted at its center (center of gravity on the axis).
Do not drop or turn the ironer over, e.g. when unloading.
Note: lifting with slings or straps is not recommended, as there is a imminent risk of damaging
the ironer.
Table 3.4: IC-13 Packaged and Unpackaged Dimensions
Packaged Dimensions
Model Metric US IC-1355 IC-1363 IC-1379
Width mm in 2340 92.1 2340 92.1 2780 109.4
Depth mm in 770 30.3 770 30.3 770 30.3
Height mm in 1400 55.1 1400 55.1 1400 43.6
Weight kg lbs 335 737 375 825 435 957
Volume cu m cu ft 2.52 89.0 2.52 89.0 3 105.9
Ironer Dimensions
Model Metric US IC-1355 IC-1363 IC-1379
Width mm in 1960 77.2 2210 87.0 2630 103.5
Depth mm in 644 25.4 644 25.4 644 25.4
Height mm in 1107 43.6 1107 43.6 1107 55.1
Weight kg lbs 300 660 355 781 428 942
Volume cu m cu ft 1.4 49.4 1.58 55.8 1.83 64.6
3.8 Room Requirements
The ironer must be installed in a well-ventilated room (particularly when using gas heating) with
correct lighting and an ambient temperature not exceeding +10◦C to +40◦C / 50◦F to 105◦F
(temperature limits for the AC drive for the main motor). Below +10◦C/50◦F, the temperature
sensor will not work and the control panel will display an alarm (AL7).
Sufficient space must be provided around the ironer to allow for correct operation:
1. 5-10cm (10-12in) minimum at the back to allow for ventilation.
2. 60-80cm (24-32in) on each side to allow for servicing and maintenance.
3. Sufficient space must be provided at the front of the ironer to allow the operator to work
correctly and safely.
Leveling should be carried out on a hard and stable floor that can support the significant weight
of the ironer (400 to 500kg on 1.6 to 2 m2or 880-1100 lbs on 18-22 ft2).
The installation of this ironer requires a floor that can support a minimum of 500kg per m2or 50
lbs per ft2.
14

Chapter 4
Operation
The following items should be checked before attempting to operate the ironer:
1. Read and follow caution, warning and direction labels attached to the ironer.
2. Check incoming supply voltage to be sure that it is the same as indicated on the serial decal.
3. GAS MODELS – check to assure that the ironer is connected to the type of gas indicated on
the serial decal.
4. GAS MODELS – be sure that ALL gas shut-off valves are in the open position.
5. Be sure ALL back panels (guards) and electric box covers have been replaced.
6. Check ALL service doors to assure that they are closed and secured in place.
ALL ironers are thoroughly tested and inspected before leaving the factory. However, a pre-
operational test should be performed before the ironer is placed into service. It is possible that
adjustments have changed in transit or due to marginal location (installation) conditions.
4.1 Heat Circuit Operation Test
1. Gas Models
(a) When the ironer is first started (during initial start-up), the burner has a tendency not
to ignite on the first attempt. This is because the gas supply piping is filled with air, so
it may take a few minutes for this air to be purged from the lines.
(b) If a gas system fault occurs, the gas supply to the machine is shut off and AL6 (gas
alarm) appears on the display.
(c) After the beep ends, reset the gas system by pressing the + and - buttons simultane-
ously (see alarm chapter). If the fault persists, this could be due to one of the following
problems:
15

i. The gas supply may be shut off: check that the gas supply valve is open.
ii. Faulty ignition spark plug: replace.
iii. Exhaust tubes are blocked: check airflow.
NOTE: During the purging period check to be sure that ALL gas shut-off valves are
open.
(d) Once ignition is established, a gas pressure test should be taken at the gas valve pressure
tap to assure that the water column pressure is correct and consistent.
NOTE: Water column pressure requirements (measured at the gas valve pressure tap):
Natural gas: 3.5 to 4.0”’ water column.
L.P. Gas: 10.5 to 11.0”’ water column.
2. Electric Models
(a) Check the contactor(s) to insure that the electric heating is cycling properly.
(b) Ensure all contactor(s) and input power terminals are TIGHT! Loose connections will
cause premature failure of switchgear components. Check these connections regularly
after the machine is placed in operation.
Make a complete operational check of ALL safety-related circuits (i.e., finger safety switch and
emergency stop button).
IMPORTANT: The ironing cylinder is treated with a protective coating. Iron old materials prior to
beginning production.
4.2 Initial Startup
Prior to initial startup, check:
•Ensure that the machine is stable and level.
•Check that all utility connections are made correctly.
•Check the machine is grounded properly.
•Check that the temperature sensor is in its normal position (curved face in contact with the
ironing cylinder)
•Turn the main power switch to the ON position (labeled as 1 on the switch itself).
•Press the START button.
•Check that the fan motors rotate and are rotating in the correct direction (see arrow on the
motor). The fan motors are located on the left and right sides of the machine enclosure (on
the right side only for IC-1355 and IC-1363)
16
