Bantam Stealth User manual

bantam Stealth
made in England by Temple Audio
Thank you for purchasing the Bantam Stealth Amplifier.
A high efficiency class D amplifier that is completely made in England.
The Bantam Stealth is a modern digital
power amplifier that produces excellent
sound quality with unrivalled energy
efficiency and low idle power draw.
or more detailed information on all Temple
Audio products please visit our website.
www.templeaudio.net
If you are unsure about anything, contact
Temple Audio for advice.
Safety Information:
The Bantam Stealth runs cold and can be
installed anywhere. Adequate space should
be left around the power supply and mains
cables for air to flow.
Do not allow water to enter this unit.
If the electrical cables or power supply
appear to be damaged, do not plug the unit
in to the mains. Instead contact Temple
Audio for a replacement
1

Installation:
Please ensure that the equipment you are
connecting to the Bantam Stealth meets the
specifications in the diagrams on this page.
Then connect your audio equipment as
shown.
Turn the volume down on your audio source
and press the On/Off button on the front of
the Bantam Stealth to start playing music.
The LED should now light up.
Gradually increase the volume while playing
music until you reach your desired listening
level.
Tips:
Do not connect the speaker output terminals
to each other, or to ground. This will cause
the Amplifier to go in to self protection mode.
Its not essential to put the amplifier in to
standby mode by pressing the On/Off button
when you aren't using it. The Bantam Stealth
will automatically enter a low power mode a
few moments after you have stopped playing
music.
The standby feature is useful for muting the
sound and we do recommend putting it in to
standby mode when you are connecting up
the system.
2

The Bantam Stealth comes fully set up by Temple Audio for optimal performance.
Getting the most out of the Amplifier is as simple as plugging it in and using it.
The standard gain level of the Bantam Stealth is intended to match with the
majority of audio sources and speakers. It is possible to increase or decrease the
gain by accessing the internal gain switch.
In the rare event that you need to change the gain contact Temple Audio for
advice.
Troubleshooting:
Problem Solution
No sound from unit
(power light does not illuminate when button
is pressed)
Power not connected:
Check the power supply is properly
connected to the mains outlet. Also check
that the power supply is properly connected
to the Bantam Amplifier.
No sound from unit
(power light is illuminated when button is
pressed)
Self protection mode activated:
Try disconnecting each speaker individually.
A fault on one speaker output (I shorted
cable) will cause the amplifier to mute the
sound on both channels until the fault is
removed.
Try different speaker cables or a different
pair of speakers.
Audible Background noise: Poor quality input cable or source.
Try a different input cable
Earth connection not adequate:
Try a different sound source. Preferably full
size Hi-Fi unit. xamine your system for poor
earth connections or earth loops.
As always if you have any questions problems or comments you can always
contact Temple Audio and we will be happy to help.
3

Bantam sTeAlTh
made in England by Temple Audio
Company Information:
Temple Audio LTD
23 James Street
Sale
Cheshire
M33 3GY
Company Registration Number: 06899384
A family Business. Registered in England.
[email protected]
or more information please visit our website.
www.templeaudio.net
Warranty Details:
The Bantam Stealth comes with a 1 year manufacturers warranty. Should any
defect in materials or workmanship be discovered in the 1 year period, Temple
Audio will repair or replace the unit without any charge for parts or manual
labour. The warranty does not cover damage caused by accident, abuse, misuse,
water, flood, fire, or other acts of nature or external causes. The warranty does
not cover damage caused by unauthorised servicing or modification of the unit.
