Baratza Sette 270Wi User manual

2
3
8
10
9
1
5
7
6
11
4
22
15 16
14
13
17
12 1918
21
20
Rev 05/15/2018 (v2)www.baratza.com

SETTE 270WiQUICK START GUIDE
Parts Identication
1. Hopper Lid
2. Bean Hopper
3. Bean Shutoff Knob
4. Hopper Alignment Indicator
5. Control Panel
6. Grind Adjustment Assembly
7. Adjustable Portalter Hook
8. Convertible Device Arms
9. Grounds Bin
10. Power Cord Port
11. Removable Grounds Tray
12. LCD Display
13. Memory Preset Buttons
& Indicators
14. Grinding Indicator
15. Stop
16. Start/Pause
17. Grind Weight Adjustment
Buttons
18. Installation/Removal
Tab (blue)
19. Installation/Removal
Indicator
20. Macro Adjustment (black)
21. Stepless Micro Adjustment
22.Bag of Tools
This is a quick start guide only. Detailed instructions can be found in the full manual
on our website at baratza.com/documentation
INITIAL SETUP
1. Hand-wash the hopper lid (1), bean hopper (2), grounds bin (9), and removable grounds tray (11) in warm, soapy water, and dry
thoroughly. Do not wash the grind adjustment assembly (6) in water or it will rust.
2. With the bean shutoff knob (3) facing the 11 o’clock position, line up the 3 hopper tabs with the slots in the top of the grinder.
Set the hopper in place and rotate rmly clockwise until the hopper clicks into place. Install hopper lid (1) onto bean hopper (2).
• NOTE: Grinder motor will only turn on with the hopper installed and macro adjustment (18) is on a setting of 31 or smaller.
Ensure the shutoff knob (3) is in the open position.
• For the best 270Wi experience, please note: as the burrs season, grind speed will increase signicantly across the rst 10lbs ground.
When new out of the box, the grinder will need to self-calibrate for the rst 3-4 grinds before delivering an accurate dose weight.
Screen Operation: Weight Based Grinding
Press a preset button 1, 2, 3 (13) to display the corresponding pre-
programmed grind weight in grams on the screen (12). When you are
ready to grind, press the START button (16). While grinding, the screen
will count UP in grams. When the screen reaches the preset weight,
the motor will stop and the display will reset again to the programmed
weight. For manual quantities of ground coffee, press and hold the
START button until you obtain the desired amount of coffee. Release
the START button to stop the grinder. The screen will show the total
amount in grams. To get out of the manual mode, press STOP (15).
See programming info on next page.
Macro/Micro Grind Size Adjustment:
The macro adjustment (20) moves from coarse #31 to ne #1. The
micro adjustment (21) is the bottom ring, from ner “A” to coarser
“I”. For espresso: start at 9E, for manual brew: start at 20E. We
recommend you have the motor running while adjusting your grind.
Convertible Device Holder:
The black arms (8) that hold the grounds bin (9) can also be used
to hold a variety of brewing devices. To convert the arms to hold a
portalter, push in on the right arm and swing it down and to the
left. To convert the arms to hold the grounds bin or other brewing
devices, push in on the right arm and rotate to the right and up.
The left arm will automatically move into position. In the center,
above the arms, is a hook (7) for holding the lip of your portalter
to provide stability. This hook can be rotated out of the way by
pressing down on the hook and then rotating it left or right. Before
grinding into the bin or portalter, return the hook to the center
position by simply pressing down and rotating it back to center.
The Portalter Hook: Critical when grinding for espresso
When grinding directly into a portalter, you must rst convert
the arms to portalter mode and swing the hook (7) to the front.
The hook is designed to support the top lip of your portalter. It is
important that your hook is adjusted so that your portalter sits
level. To adjust the hook, loosen the 2mm hex screw (included in the
bag of tools (22)) that sits below the hook, adjust portalter hook up
or down, and tighten screw at the proper position. If your grinder is
under-dosing, most likely your hook needs further adjustment.

WARNING: The Sette grinds at a very high speed, be careful not to
overll your portalter or bin! If a mound of coffee backs up into the
chute it will clog the grinder.
Programming:
The Sette 270Wi is equipped with three programmable buttons (13).
The buttons are simply labeled 1, 2, 3. These programmable buttons
only adjust the desired grind weight, they do not adjust the grind
setting (i.e. coarse/ne). Each button comes from the factory with
the following presets: Weight: 1=18g, 2=25g, 3=35g.
You can easily program more or less grams as follows:
1. Select a preset button.
2. Press the up or down arrow buttons to adjust the weight.
3. Once you have reached the desired gram setting, press and
hold the desired preset button for 3 seconds. The screen will
blink to conrm the setting is stored.
4. To program the other buttons repeat steps 1-3. NOTE: 5g
minimum for preset mode: The software prevents users from
setting a preset below 5g. Due to the speed of the grinder, it is
unable to be accurate for weights less than 5g.
• For best dosing accuracy, we recommend assigning a particular
grind size to each preset (e.g. Preset 1 for espresso, 2 for
AeroPress®, 3 for drip) — see owner’s manual for more detail
Bag of Tools:
We have included a small bag with tools and shims (22).
• Shims used for recalibrating the machine to a ner range.
• 2mm hex key used for adjusting the portalter hook.
• 5mm hex key used for removing the cone burr from the holder
when shimming (see manual).
Need Help?
If you have any questions or concerns, please email:
[email protected] or call +1 [phone]
The full manual can be found on our website at:
baratza.com/documentation
For video instructions and troubleshooting guides:
baratza.com/troubleshooting
SAFETY INFORMATION:
!Please read the information below very carefully. It contains
important safety information for this appliance. Please keep these
instructions for future reference.
!Use only with AC current and the correct voltage. See the label on
the base of the grinder to determine the correct voltage.
!Only clean the grinder housing with a dry or slightly damp cloth.
Do not immerse the grinder, plug or cord in water or any other
liquid.
!Baratza will not accept any liability for damage, injury, or warranty
if the grinder is used other than for its intended purpose (i.e.
grinding roasted whole coffee beans) or is improperly operated
or repaired.
!Keep the appliance and its cord out of reach of children aged less
than 8 years
!Do not operate the grinder with a damaged cord or plug. If the
supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid
a hazard
!Do not leave your grinder unattended while turned ON.
!This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
!Cleaning and user maintenance shall not be made by children
without supervision.
!Always unplug the grinder from the electrical supply before
assembling, disassembling or cleaning.
!To unplug, grasp plug and remove from the outlet. Never pull on
the cord.
!CAUTION: ALWAYS unplug the electrical supply cord prior to
cleaning the grinder.
