Barco R9852090 User manual

EVENTS
XLD(1.45-1.8:1)LENS
R9852090
INSTALLATION MANUAL
01042004 R5976679/00

Barco nv Events
Noordlaan 5, B-8520 Kuurne
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Visit us at the web: www.barco.com
Printed in Belgium

Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or
stored in a retrieval system without the prior written consent of Barco.
Changes
Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war-
ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the
program(s) described in this publication at any time without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this
publication; these changes are incorporated in new editions of this publication.
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders.
All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for
the products or their manufactures.
Guarantee and Compensation
Barco provides a guarantee relating to perfect manufacturing as partof the legally stipulated termsof guarantee. On receipt, the purchaser
must immediately inspect all delivered goods for damage incurred during transport, as well as for material and manufacturing faults Barco
must be informed immediately in writing of any complaints.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning,
at latest 30 days after the transfer of risks. In the event of justified notice of compliant, Barco can repair the fault or provide a replacement
at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a
reduction in the purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for direct or
indirect damage, and also damage attributed to the operation of software as well as to other services provided by Barco, being a component
of the system or independent service, will be deemed invalid provided the damage is not proven to be attributed to the absence of properties
guaranteed in writing or due to the intent or gross negligence or part of Barco.
If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly,
in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to influences not
agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid. Not included in the guarantee coverage are
system failures which are attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as
well as normal maintenance are not subject to the guarantee provided by Barco either.
The environmental conditions as well as the servicing and maintenance regulations specified in the this manual must be complied with by
the customer.

Table of contents
TABLE OF CONTENTS
1. XLD(1.45-1.8:1) LensKit..........................................................................................3
1.1 ContentsoftheXLD(1.45-1.8:1)LensKit ............................................................................................ 3
1.2 LensRemoval........................................................................................................................... 3
1.3 Lensinstallation......................................................................................................................... 3
1.4 Cleaning the lens........................................................................................................................ 4
2. LensSpecifications.................................................................................................7
2.1 LensFormula............................................................................................................................ 7
2.2 ProjectorDistancedetermination....................................................................................................... 7
Index.......................................................................................................................9
R5976679 XLD(1.45 - 1.8:1) LENS 01042004 1

Table of contents
2R5976679 XLD(1.45 - 1.8:1) LENS 01042004

1. XLD(1.45 - 1.8:1) Lens Kit
1. XLD(1.45 - 1.8:1) LENS KIT
1.1 Contents of the XLD(1.45 - 1.8:1) Lens Kit
Kit contents
• XLD(1.45 - 1.8:1) Lens.
• Installation Manual.
• TorayseeTM Cloth.
1.2 Lens Removal
No lens mounted !
The projector leaves the factory with no lens mounted. To protect the engine from e.g. dust, the lens gap is sealed with a foam
cover. Remove the foam cover before lens mounting.
How to remove the mounted lens
1. Support the lens with one hand. (image 1-1)
2. Move the lens lock (A) to the left to unlock the lens securing system.
3. Carefully pull the lens backwards to disconnect the lens zoom connector (B).
4. Take the lens out the lens block.
A
to unlock to lock
B
Image 1-1
Lens removal
1.3 Lens installation
How to install a lens ?
1. Unlock the lens securing system by putting the lock handle to the left (A). (image 1-2)
2. Move the rear of the lens into the lens block, lining up the lens plug with the lens connector (B) (image 1-2).
3. Carefully push on the lens until the connector seats into the socket.
Note: On the lens block a reference pin (B) is provided to center the lens. For that reason the lens body is provided with a
notch (A) which has to match the reference pin after the lens plug connection into lens socket. (image 1-3)
4. Pull the handle (A) to the right to lock the lens securing system (image 1-2).
R5976679 XLD(1.45 - 1.8:1) LENS 01042004 3

1. XLD(1.45 - 1.8:1) Lens Kit
A
to unlock to lock
B
Image 1-2
Lens installation
AB
Image 1-3
Lens notch matching with reference pin
1.4 Cleaning the lens
To minimize the possibility of damaging the optical coating or scratching exposed lens surface, we have de-
veloped recommendations for cleaning the lens. FIRST, we recommend you try to remove any material from
the lens by blowing it off with clean, dry deionized air. DO NOT use any liquid to clean the lenses.
4R5976679 XLD(1.45 - 1.8:1) LENS 01042004

1. XLD(1.45 - 1.8:1) Lens Kit
Necessary tools
TorayseeTM cloth (delivered together with the lens kit). Order number : R379058.
Howtocleanthelens?
Proceed as follow :
1. Always wipe lenses with a CLEAN TorayseeTM cloth.
2. Always wipe lenses in a single direction.
Warning: Do not wipe back and forwards across the lens surface as this tends to grind dirt into the coating.
3. Do not leave cleaning cloth in either an open room or lab coat pocket, as doing so can contaminate the cloth.
4. If smears occur when cleaning lenses, replace the cloth. Smears are the first indication of a dirty cloth.
Do not use fabric softener when washing the cleaning cloth or softener sheets when drying the cloth.
Do not use liquid cleaners on the cloth as doing so will contaminate the cloth.
Other lenses can also be cleaned safely with this TorayseeTM cloth.
R5976679 XLD(1.45 - 1.8:1) LENS 01042004 5

1. XLD(1.45 - 1.8:1) Lens Kit
6R5976679 XLD(1.45 - 1.8:1) LENS 01042004

2. Lens Specifications
2. LENS SPECIFICATIONS
2.1 Lens Formula
Calculation of the Projector distance (PD) as function of the Screen Width (SW)
Lens Formula
XLD(1.45 - 1.8:1) PDmin=1.45 x SW
PDmax=1.80 x SW
Due to production tolerances the real distances can differ by 2% from these calculated values.
For critical situations (fixed installs that use the lens at one of its extreme zoom positions) this should be
taken into account.
2.2 Projector Distance determination
Reference for measuring the PD
PD
SW
Image 2-1
PD measuring
The projection distance is the distance between front projector and screen surface, measured perpendicular onto the screen.
R5976679 XLD(1.45 - 1.8:1) LENS 01042004 7

2. Lens Specifications
8R5976679 XLD(1.45 - 1.8:1) LENS 01042004

Index
INDEX
C
Contents 3
Lens kit 3
Contents lens kit 3
L
Lens 3–4, 7
Cleaning 4
Installation 3
Removal 3
Specifications 7
Lens formula 7
Lens installation 3
Lens kit 3
Contents 3
P
Projector distance 7
Determination 7
R
Removal 3
Lens 3
S
Specifications 7
Lens 7
R5976679 XLD(1.45 - 1.8:1) LENS 01042004 9

Index
10 R5976679 XLD(1.45 - 1.8:1) LENS 01042004
