Barco Coronis 5MP Mammo User manual

User Guide
Coronis 5MP

2Coronis 5MP

Coronis 5MP 3
Welcome!
The high-grade Coronis 5MP display system offers unsurpassed film-like
images with ultra-high resolution, luminance and contrast . The 21.3”
LCD provides unequaled image quality without pixelization, a wide
viewing angle and perfect geometry.
Building on proven technology, Coronis 5MP provides ultimate precision
and performance while maintaining the highest brightness and contrast.
The advanced 10-bit architecture ensures accurate image
representations with 1024 simultaneous shades of gray out of a palette
of 4096.
Following symbols may be used throughout this guide:
Warning: Risk of
injury to human
beings
Caution: Risk of
damage to the
product
Important notice
or remark
Note
Hint, tip Additional
information
Read all the safety information starting on page 54 before
operating your BARCO CORONIS Display.
WARNING

4Coronis 5MP

Coronis 5MP 5
Table of contents
Welcome!.........................................................................3
Table of contents.............................................................5
What's in the box.............................................................7
Parts, controls and connectors ........................................8
Front view ............................................................................................... 8
Rear view ................................................................................................ 9
Single foot ............................................................................................. 11
Dual foot ................................................................................................ 12
Display installation ........................................................13
Mounting the display ........................................................................... 13
Removing the covers ........................................................................... 19
Connecting the display......................................................................... 22
Routing the cables................................................................................ 24
First time starting up............................................................................ 26
Daily operation ..............................................................27
Recommendations for daily operation............................................... 27
Key indicator lights ............................................................................... 29
Stand-by switching............................................................................... 29
Bringing up the OSD menus ................................................................31
Navigating through the OSD menus...................................................32
Advanced operation ......................................................33
OSD menu position............................................................................... 33
OSD menu language ............................................................................ 33
OSD menu automatic close function .................................................. 34
Power status indicator light.................................................................34
Key indicator lights ............................................................................... 35
Power lock function..............................................................................35

6Coronis 5MP
Keys sound ............................................................................................ 36
Ethernet over USB................................................................................. 36
DDC HID Device.....................................................................................37
DPMS mode........................................................................................... 38
Hibernate............................................................................................... 39
Luminance target.................................................................................. 40
Viewing modes.....................................................................................41
Display functions................................................................................... 42
Ambient Light Compensation (ALC).................................................... 43
Reading rooms...................................................................................... 44
Continuous ALC...................................................................................... 45
Image scaling........................................................................................ 46
Display orientation................................................................................ 46
Video input signals ............................................................................... 47
Video encoding modes ........................................................................ 48
Grayscale conversion modes............................................................... 49
EDID timings.......................................................................................... 50
Display info............................................................................................ 51
Display status ........................................................................................ 51
Cleaning your display ....................................................52
Front glass ............................................................................................. 52
Cabinet................................................................................................... 53
Important information ..................................................54
Safety information................................................................................ 54
Environmental information.................................................................. 57
Regulatory compliance information.................................................... 60
EMC notice............................................................................................. 61
Explanation of symbols ........................................................................ 67
Legal disclaimer....................................................................................68
Technical specifications ........................................................................ 70
Open source license information ........................................................ 73

Coronis 5MP 7
What's in the box
Your BARCO CORONIS Display system comes with:
•the display
•a system tilt and swivel foot
•this BARCO CORONIS Display guide
•a system CD
•a DisplayPort cable
•a DVI cable
•a USB cable
•an AC power cord
•an external power supply
If you ordered a Barco display controller, it’s also in the box together
with its accessories. A dedicated user guide is available on the system
CD.
Keep your original packaging. It is designed for this display and
is the ideal protection during transport.

8Coronis 5MP
Parts, controls and connectors
Front view
Figure 1: Front view
Left key Right key
Menu key Power on/off key
Ambient light sensor Power LEDs
Side downstream USB 2 & 3
7
1 2 3 4 5 6
1
2
3
4
5
6
7

Coronis 5MP 9
Rear view
CONNECTOR COMPARTMENT COVER CLOSED
Figure 2: Rear view cover closed
Connector compartment
cover
Display release button for
portrait position
Mounting anchor Display release button for
landscape position
12 3
4
1
2
3
4

10 Coronis 5MP
CONNECTOR COMPARTMENT COVER OPEN
Figure 3: Rear view cover open
24 VDC Power input +5 VDC, 0.5 A power output
Display Port video input DVI video input
Ethernet connection (see
note below)
USB upstream
USB downstream 1
The Ethernet connection is used for maintenance purposes and
is not supported for user application.
5
6
7
8
9
10
11
5
6
7
8
9
10
11
