Barco MDSC-8532 User manual

ENABLING BRIGHT OUTCOMES
MDSC-8532 SSTP
MDSC-8532 12GP
User Guide
32”4K UHD surgical display
MDSC-8532

Registered office: Barco NV
President Kennedypark 35, 8500 Kortrijk, Belgium
www.barco.com/en/support
www.barco.com
Barco NV
Beneluxpark 21, 8500 Kortrijk, Belgium
www.barco.com/en/support
www.barco.com

3R5914105 /01 MDSC-8532
1 Welcome!.......................................................................................................................................................................................................... 5
1.1 What’s in the box................................................................................................................................................................................7
1.2 About this user guide .......................................................................................................................................................................7
1.3 Product overview................................................................................................................................................................................8
1.4 Connector pin assignments .........................................................................................................................................................9
1.4.1 Power input connector ................................................................................................................................................9
1.4.2 DVI connector (DVI-D) ................................................................................................................................................9
1.4.3 USB type A connector .............................................................................................................................................. 10
1.4.4 USB type B connector .............................................................................................................................................. 10
1.4.5 DisplayPort connector .............................................................................................................................................. 10
1.4.6 HDMI connector........................................................................................................................................................... 11
2 Display installation................................................................................................................................................................................13
2.1 Cover removal ..................................................................................................................................................................................14
2.2 Interface connection......................................................................................................................................................................14
2.2.1 MDSC-8532 SSTP version....................................................................................................................................14
2.2.2 MDSC-8532 12GP version....................................................................................................................................15
2.3 Power supply connection ...........................................................................................................................................................16
2.4 Cable routing .....................................................................................................................................................................................17
2.5 VESA mount installation .............................................................................................................................................................18
3 Daily operation .........................................................................................................................................................................................19
3.1 On/off switching ...............................................................................................................................................................................20
3.2 Front keyboard locking/unlocking..........................................................................................................................................20
3.3 Power status LED ..........................................................................................................................................................................21
3.4 Front menu ........................................................................................................................................................................................21
3.5 OSD menu ..........................................................................................................................................................................................23
3.6 Control lock.........................................................................................................................................................................................24
4 Advanced operation............................................................................................................................................................................25
4.1 Picture menu .....................................................................................................................................................................................26
4.1.1 Profile.................................................................................................................................................................................26
4.1.2 Brightness .......................................................................................................................................................................26
4.1.3 Contrast............................................................................................................................................................................26
4.1.4 Saturation........................................................................................................................................................................27
4.1.5 Color temperature.......................................................................................................................................................27
Table of contents

R5914105 /01 MDSC-85324
4.1.6 Color space ....................................................................................................................................................................27
4.1.7 Gamma.............................................................................................................................................................................28
4.1.8 Sharpness ......................................................................................................................................................................28
4.2 Picture advance menu .................................................................................................................................................................29
4.2.1 Input range......................................................................................................................................................................29
4.2.2 Image size.......................................................................................................................................................................29
4.2.3 Zoom..................................................................................................................................................................................29
4.2.4 Pan......................................................................................................................................................................................29
4.2.5 Image flip .........................................................................................................................................................................30
4.3 Input select menu............................................................................................................................................................................30
4.3.1 Main source....................................................................................................................................................................30
4.3.2 4K SDI mode (12GP version only) ....................................................................................................................31
4.3.3 SDI config (12GP version only)...........................................................................................................................31
4.3.4 DisplayPort mode........................................................................................................................................................31
4.3.5 Failover input.................................................................................................................................................................32
4.3.6 Picture-by-Picture (PBP).........................................................................................................................................33
4.3.7 Picture-in-Picture (PIP)............................................................................................................................................33
4.4 Configuration menu .......................................................................................................................................................................34
4.4.1 Information......................................................................................................................................................................34
4.4.2 Language.........................................................................................................................................................................35
4.4.3 OSD time-out.................................................................................................................................................................35
4.4.4 Recall Profile..................................................................................................................................................................35
4.4.5 Save Profile ....................................................................................................................................................................35
4.4.6 Front menu user keys...............................................................................................................................................36
4.4.7 Input signal name........................................................................................................................................................36
4.4.8 Display name.................................................................................................................................................................37
4.4.9 Profile name...................................................................................................................................................................37
4.5 System menu ....................................................................................................................................................................................37
4.5.1 Control lock.....................................................................................................................................................................37
4.5.2 Power saving.................................................................................................................................................................38
4.5.3 Video out..........................................................................................................................................................................38
4.5.4 Display status................................................................................................................................................................38
5 Troubleshooting ......................................................................................................................................................................................39
5.1 Troubleshooting list........................................................................................................................................................................40
6 Important information.........................................................................................................................................................................41
6.1 Safety information...........................................................................................................................................................................42
6.2 Cybersecurity ....................................................................................................................................................................................45
6.3 Environmental information.........................................................................................................................................................45
6.4 Biological hazard and returns – Decommissioning......................................................................................................47
6.5 Regulatory compliance information......................................................................................................................................47
6.6 EMC notice ......................................................................................................................................................................................... 49
6.7 Cleaning instructions.....................................................................................................................................................................51
6.8 Explanation of symbols................................................................................................................................................................52
6.9 Legal disclaimer...............................................................................................................................................................................56
6.10 Technical specifications...............................................................................................................................................................56

5R5914105 /01 MDSC-8532
Overview
The MDSC-8532 is an Ultra High Definition (UHD) surgical display. Purpose-built for the operating room, the
MDSC-8532 offers an easy-clean design, smart mechanics and the most detailed images in the operating
room today.
True-to-life colors in the surgical suite
The MDSC-8532 has been designed for endoscopy imaging and the integrated operating room. The display
has a wide color gamut and offers advanced color calibration algorithms. This results in the most accurate
color reproduction, making it the preferred choice for real-time critical imaging.
Multi-source, multi-display imaging: With its broad input connectivity, the MDSC-8532 also offers flexible multi-
modality imaging in new integrated operating rooms. Thanks to its high-bright LED backlight with light output
stabilization (BLOS), the surgical display also ensures a long lifetime and low power consumption.
Ease of installation
The MDSC-8532 comes with a smart cable management system that hides the cables for a clutter-free set-up.
Equipped with VESA 100 interface to allow easy mounting on surgical booms and spring arms. Available in
different models, this surgical display also features a host of connectivity options and remote control.
User friendly
The dual user interface – there is one at the front as well as at the back – makes it easy to operate the display.
The touch screen functions at the front can be programmed to meet the personal preferences of surgical staff.
The intuitive user interface makes it easy to set up the screen or change the layout configurations of the
display to fit the procedure. Three dedicated user keys enable fluent configuration of the display.
Features
• Wide-screen LCD with UHD 4K resolution and 10-bit per color
• Full range of 4K-UHD signals accepted
• Wide viewing angle
• Wide color gamut and calibrated color spaces ITU709, DCI-P3 D65, BT. 2020
• High-brightness LED backlight
• Backlight Output Stabilization over time
• Advanced, full 10-bit image processing algorithms with 14-bit LUT
• UHD (3840x2160), FHD and legacy input accepted
• Easily mountable onto a boom
Innovative features, such as Failover Mode, are also available to give maximum flexibility when installing the
display and ensures a backup signal is always available for safe surgery.
Welcome! 1

R5914105 /01 MDSC-85326
Welcome!

7R5914105 /01 MDSC-8532
1.1 What’s in the box
Overview
• 1x MDSC-8532 display
• 1x DisplayPort cable
• 1x HDMI cable
• 1x coax high speed cable (12GP version only)
• 1x printed User Guide (English)
• 1x documentation disc, containing all translations of the User Guide
• 1x external power supply
• Mains cables
The user guide is available in other languages on www.barco.com/support
Keep your original packaging. It is designed for this display and is the ideal protection during
transport.
1.2 About this user guide
Overview
This manual provides support to the user during the installation, set up and utilization of the MDSC-8532
display. Depending on the specific version that has been purchased, some of the features and options
described in this document may not apply to the display in user’s hands.
Warnings, cautions, notes and tips
There are four levels of precautionary or advisory statements that may be used in this user guide. In
descending order of importance, they are:
WARNING: Describes hazards or dangers that might result in personal injury or death.
CAUTION: Describes hazards that could damage the product.
Gives additional information about the described subject.
Gives extra advice about the described subject.
Welcome!

R5914105 /01 MDSC-85328
1.3 Product overview
Overview
543 61 2
Image 1–1
1. 5-key capacitive front keyboard
By default only the stand-by key ( ) is visible. For keyboard activation please refer to “Front keyboard
locking/unlocking”, page 20
2. Stand-by key and power status LED (see “Power status LED ”, page 21 for the behavior and different
colors of the power status LED)
3. Connector compartment cover
4. Rear keyboard
5. Cable routing cutout
6. VESA mount screw holes (100 x 100 mm)
Connections
5 6 7 8 13 14 151 2 3 4 1211109
Image 1–2
1. BNC connector (*)
2. BNC connector (*)
3. BNC connector (*)
4. BNC connector (*)
5. Potential Equalization pin (POAG)
6. VDC in
7. 3G-SDI in (**)
8. 3G-SDI out (**)
9. DVI-D in
10.HDMI 2 in
11. HDMI 1 in
12.DisplayPort 1.2 in
13.DisplayPort 1.2 out
14.USB 2.0 type A interface
15.USB 2.0 type B interface
(*) 12GP version only.
Welcome!

9R5914105 /01 MDSC-8532
(**) The BNC SDI connectors match the characteristic impedance of 75 ohm cables.
1.4 Connector pin assignments
1.4.1 Power input connector
Overview
1
23
4
Image 1–3
1. +25 VDC
2. +25 VDC
3. GND
4. GND
CAUTION: The ground and the shield connections on the power input connector have no Protective
Earth function. A Protective Earth connection is provided via a dedicated pin (see “Power supply
connection”, page 16).
1.4.2 DVI connector (DVI-D)
Overview
Image 1–4
1. D2_Rx- (T.M.D.S.)
2. D2_Rx+ (T.M.D.S.)
3. GND (data 2 shield)
4. Not connected
5. Not connected
6. SCL (for DDC)
7. SDA (for DDC)
8. Not connected
9. D1_Rx- (T.M.D.S.)
10.D1_Rx+ (T.M.D.S.)
11. GND (data 1 shield)
12.Not connected
13.Not connected
14.+5V output (*)
15.GND (cable sense)
16.Hot plug detect (*)
17.D0_Rx- (T.M.D.S.)
18.D0_Rx+ (T.M.D.S.)
19.GND (data 0 shield)
20.Not connected
21.Not connected
22.GND (clock shield)
23.CK_Rx+ (T.M.D.S.)
24.CK_Rx- (T.M.D.S.)
(*) +5 VDC output selectable on either pin 14 or 16 via the OSD menu. (+5V ± 10% @ 500mA (max))
Welcome!

R5914105 /01 MDSC-853210
1.4.3 USB type A connector
Overview
Image 1–5
1. +5 VDC @ 1A max
2. Data -
3. Data +
4. GND
1.4.4 USB type B connector
Overview
1 2
3 4
Image 1–6
1. Data -
2. +5 VDC
3. Data +
4. GND
1.4.5 DisplayPort connector
Overview (sink side pin-out)
19 17 15 13 11 9 7 5 3 1
20 18 16 14 12 10 8 6 4 2
Image 1–7
1. ML_Lane 3 (n)
2. GND
3. ML_Lane 3 (p)
4. ML_Lane 2 (n)
5. GND
6. ML_Lane 2 (p)
7. ML_Lane 1 (n)
8. GND
9. ML_Lane 1 (p)
10.ML_Lane 0 (n)
11. GND
12.ML_Lane 0 (p)
13.CONFIG1
14.CONFIG2
15.AUX CH (p)
16.GND
17.AUX CH (n)
18.Hot Plug
19.Return
20.DP_PWR (+3.3 VDC @ 500 mA max)
Welcome!

11R5914105 /01 MDSC-8532
1.4.6 HDMI connector
Overview
1
24681012141618
35791113151719
Image 1–8
1. T.M.D.S. Data2+
2. T.M.D.S. Data2 Shield
3. T.M.D.S. Data2-
4. T.M.D.S. Data1+
5. T.M.D.S. Data1 Shield
6. T.M.D.S. Data1-
7. T.M.D.S. Data0+
8. T.M.D.S. Data0 Shield
9. T.M.D.S. Data0-
10.T.M.D.S. Clock+
11. T.M.D.S. Clock Shield
12.T.M.D.S. Clock-
13.CEC
14.Not connected
15.DDC_SCL
16.DDC_SDA
17.DDC/CEC GND
18.+5VDC POWER (in)
19.HDP
Welcome!

R5914105 /01 MDSC-853212
Welcome!

13R5914105 /01 MDSC-8532
Display installation 2

R5914105 /01 MDSC-853214
2.1 Cover removal
To remove the connector cover
1. Gently press and hold the clips at the bottom right and left side of the connector cover.
2. Slide the cover downwards while holding the clips pressed.
Either press the two clips at once, or press and release one side of the cover first and then press
and release the other side.
2
1
Image 2–1
2.2 Interface connection
About
The MDSC-8532 can have multiple video inputs connected. Switching between the different inputs can be
done easily with a programmable key on the front front keyboard.
Futhermore, if more than one video source is connected, the Picture-in-Picture and Picture-by-Picture (PIP/
PBP) functionalities become available, allowing you to view two different video inputs at once. Please refer to
“Picture-in-Picture (PIP)”, page 33 and “Picture-by-Picture (PBP)”, page 33 for more information.
Beside the video input connections, the MDSC-8532 also has video output capabilities allowing you to loop-
through or duplicate all video inputs connected with the MDSC-8532 to another display, projector, video
recorder, ...
This chapter describes how to connect the different video interface types to the MDSC-8532.
2.2.1 MDSC-8532 SSTP version
To connect the interfaces
1. Connect one or more video source(s) to the corresponding video inputs of the display. For a list of
supported video inputs, see “Technical specifications”, page 56.
2. SDI input loop-through: When the SDI video input is connected, an additional SDI video sink can be
connected to the SDI output.
3. Video output: The entire active image on the screen (including OSD) can be duplicated to a FHD (1080p/
1080i) signal on the DisplayPort output connector, to which an additional DisplayPort video sink can be
connected.
4. Connect the USB2.0 type B interface with a workstation to use the remote control protocol.
Display installation

15R5914105 /01 MDSC-8532
5. Connect the USB2.0 type B interface to a USB memory stick for in-field firmware updates. For more
information, please refer to qualified service personnel.
32 15
4
Image 2–2
DisplayPort VESA DP 1.2 certified cables for 5.4 Gbps HBR2 with a length of up to 3 m are
recommended.
Premium certified HDMI 2.0 cables with a length of up to 3 m are recommended.
Use 3G-SDI Belden 1694A cables with a length of up to 50 m.
The video output must be enabled in the OSD menu (see “Video out”, page 38).
A subset of the commands of the remote control protocol is also available on a new DDC protocol
on DVI and DisplayPort1 auxiliary channel.
2.2.2 MDSC-8532 12GP version
To connect the interfaces
1. Connect one or more video source(s) to the corresponding video inputs of the display. For a list of
supported video inputs, see “Technical specifications”, page 56.
2. SDI input loop-through: When the SDI video input is connected, an additional SDI video sink can be
connected to the SDI output.
3. Video output: The entire active image on the screen (including OSD) can be duplicated to a FHD (1080p/
1080i) signal on the DisplayPort output connector, to which an additional DisplayPort video sink can be
connected.
4. Connect the USB2.0 type B interface with a workstation to use the remote control protocol.
5. Connect the USB2.0 type B interface to a USB memory stick for in-field firmware updates. For more
information, please refer to qualified service personnel.
6. 4 BNC connectors available for Quad-link SDI or 2x 12G-SDI In and 2x 12G-SDI Out.
Display installation

R5914105 /01 MDSC-853216
32 15
4
6
Image 2–3
DisplayPort VESA DP 1.2 certified cables for 5.4 Gbps HBR2 with a length of up to 3 m are
recommended.
Premium certified HDMI 2.0 cables with a length of up to 3 m are recommended.
Use 3G-SDI Belden 1694A cables with a length of up to 50 m.
The video output must be enabled in the OSD menu (see “Video out”, page 38).
A subset of the commands of the remote control protocol is also available on a new DDC protocol
on DVI and DisplayPort1 auxiliary channel.
2.3 Power supply connection
To connect the power supply
1. Connect the supplied external DC power supply unit to the +25 VDC power input of your display.
2. Plug the other end of the external DC power supply into a grounded power outlet by means of the proper
power cord delivered in the packaging.
Image 2–4
CAUTION: To avoid risk of electric shock, the external DC power supply must be connected to a
mains with protective earth. The ground connection on the display’s DC power input connector has
no protective earth function. The MDSC-8532 display protective earth connection is provided via a
dedicate pin (see next steps).
Display installation

17R5914105 /01 MDSC-8532
Protective earth
Earth the MDSC-8532 by connecting the protective earth pin to a grounded outlet by means of a yellow/green
AWG18 wire (maximum admitted cable length according to national regulation requirements).
Image 2–5
CAUTION: The display must be earthed.
Potential equalization
When potential equalization between the display and other devices is required then connect the potential
equalization pin (POAG) to the potential equalization terminal of the equipment.
Image 2–6
2.4 Cable routing
To route the cables
Route all cables through the cable routing cutout while reinstalling the connector compartment.
Image 2–7
CAUTION: When the display is assembled in the medical system, take care of the fixation of all
cables, to avoid unwanted detachment.
Display installation

R5914105 /01 MDSC-853218
2.5 VESA mount installation
To install the display on a VESA mounting solution
The display can be attached to a VESA 100 mm arm or stand.
Image 2–8
The VESA mounting holes at the back of the display are provided with M4-type blind fasteners to fix the VESA
mounting plate. Depending on the VESA plate thickness (T) and the thickness of possible washers (W), a
different screw length (L) should be selected.
Please respect the following rule to select an appropriate screw length:
• Lmin = T + W + 16 mm
• Lmax = T + W + 19 mm
T
W
Lmin
Lmax
Image 2–9
CAUTION: Use an arm that is in compliance with VESA requirements.
CAUTION: The monitor VESA interface has been designed for a safety factor 6 (to support 6 times
the monitor weight). In the medical system, use an arm with suitable safety factor (IEC60601–1).
Display installation

19R5914105 /01 MDSC-8532
Daily operation 3

R5914105 /01 MDSC-853220
3.1 On/off switching
The procedures below consider that DC power is supplied to the display. Please check the status of
the power mode LED to verify that your display is supplied with DC power (see “Power status LED ”,
page 21).
When the DC power is supplied to the display, all LEDs of the front keyboard will turn on for 1
second. After this, the front keyboard calibration is performed (all white LEDs will turn off and the
central LED will turn orange).
Do not touch the front keyboard during calibration (less than 4 seconds). When the calibration is
complete, the front keyboard is available and can be used (the central LED will turn steady green or
blinking green / orange).
To switch on your display
With the front keyboard:
1. Press and hold (3-4 seconds) the key until the entire front keyboard starts blinking.
2. While the front keyboard is blinking, release the key again (within 2 seconds, to avoid a keyboard re-
lock) and the display will switch on.
With the rear keyboard:
1. Press and hold (3-4 seconds) the center button until the entire front keyboard starts blinking..
2. While the front keyboard is blinking, release the center button again (within 2 seconds, to avoid a
keyboard re-lock) and the display will switch on.
When the keyboard backlight lights up, the power mode LED will turn full green indicating that the
display is switching on and the logo will be visible for a few seconds.
To switch off your display
With the front keyboard:
1. Unlock the front keyboard (see “Front keyboard locking/unlocking”, page 20).
2. With the keyboard unlocked, press and hold (3-4 seconds) the key until the entire keyboard starts
blinking.
3. While the front keyboard is blinking, release the key again (within 2 seconds) and the display will switch
off.
With the rear keyboard:
1. Press and hold (3-4 seconds) the center button until the entire front keyboard starts blinking.
2. While the front keyboard is blinking, release the center button again (within 2 seconds) and the display will
switch off.
3.2 Front keyboard locking/unlocking
About
In order to avoid unwanted or accidental activation of the front keyboard, a lock/unlock mechanism has been
implemented. This means that the front keyboard needs to be unlocked before it can be used to change any of
the display settings. By default, all keys except the key will be dimmed to indicate that the front keyboard is
locked.
After unlocking the front keyboard, all keys will light up. Touching any of these keys while the backlight is on
will execute the function of the key. However, if no further action is taken within the time defined by the OSD
time-out parameter, the keys will dim again and the keyboard will re-lock.
Daily operation
