Barco BarcoReality SIM6 Ultra R9040150 User manual

SIMULATION PRODUCTS
BARCOREALITY SIM 6 ULTRA
R9040150
R9040151
OWNER’SMANUAL
14052003 R5976420/03

Barco nv Simulation Products
600 Bellbrook Ave, Xenia OH 45385
Phone: [phone]
Fax: [phone]
E-mail: ei[email protected]
Visit us at the web: www.eis.barco.com
Barco nv Simulation Products
Noordlaan 5, B-8520 Kuurne
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Visit us at the web: www.barco.com
Printed in Belgium

Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or
stored in a retrieval system without the prior written consent of Barco.
Changes
Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war-
ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the
program(s) described in this publication at any time without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this
publication; these changes are incorporated in new editions of this publication.
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders.
All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for
the products or their manufactures.
Federal Communications Commission (FCC Statement)
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area may
cause harmful interference, in which case the user will be responsible for correcting any interference.

Table of contents
TABLE OF CONTENTS
1. Packaging andDimensions ....................................................................................... 5
1.1 Lens Packaging . . . .................................................................................................................... 5
1.2 Dimensions............................................................................................................................ 5
2. InstallationGuidelines.............................................................................................. 7
2.1 Installation guidelines ................................................................................................................. 7
2.2 Configuration .......................................................................................................................... 8
2.3 Lenses . . ............................................................................................................................... 9
2.3.1 Lenses . . . . . . ...................................................................................................................10
2.3.2 Lens formulas. . . ...............................................................................................................10
2.3.3 Lens installation ............................................................................................................... 11
2.3.4 Cleaning the lens . . . ...........................................................................................................12
2.4 Batteries .............................................................................................................................. 12
2.4.1 Battery installation.............................................................................................................12
3. Connections.........................................................................................................13
3.1 Power connections ...................................................................................................................13
3.2 Switching on..........................................................................................................................13
3.3 Switching to standby . . ...............................................................................................................15
3.4 Switching off..........................................................................................................................15
3.5 Source Specifications ................................................................................................................15
3.6 Input source connections . ...........................................................................................................16
3.6.1 Input facilities . . . ...............................................................................................................16
3.6.2 Input Selection Mode . . . . . . ....................................................................................................16
3.6.3 Inputs via RCVDS05...........................................................................................................17
3.6.4 Input 1..........................................................................................................................17
3.6.5 Input 2..........................................................................................................................19
3.6.6 Input 3 (Optional) . . . ...........................................................................................................20
3.6.7 Input 4 (Optional) . . . ...........................................................................................................21
3.7 Communications connections. . . . ....................................................................................................22
3.7.1 RS232..........................................................................................................................22
4. Gettingstarted......................................................................................................23
4.1 RCU & Local keypad.................................................................................................................23
4.2 Terminology overview................................................................................................................23
4.3 Operating the projector...............................................................................................................25
4.3.1 Switching on ...................................................................................................................25
4.4 Quick setup adjustments.............................................................................................................26
4.4.1 Quick lens Adjustment.........................................................................................................26
4.4.2 Quick on Screen Color Change. ..............................................................................................27
4.5 Using the RCU .......................................................................................................................28
4.6 Projector Address ....................................................................................................................30
4.6.1 Controlling the projector.......................................................................................................30
4.6.2 Displaying and Programming addresses .....................................................................................31
4.7 Controlling the projector..............................................................................................................31
5. Random Access ....................................................................................................33
5.1 Random Access Overview...........................................................................................................34
5.2 Random Access Start up ............................................................................................................ 35
5.3 File Service...........................................................................................................................35
5.3.1 File annotation . . ...............................................................................................................35
5.3.2 Possible file manipulations ....................................................................................................36
5.3.3 File Service Start up...........................................................................................................36
5.3.4 Load File . . . . ...................................................................................................................37
5.3.5 Edit file ......................................................................................................................... 38
5.3.5.1 Start up..................................................................................................................38
5.3.5.2 Changing the settings. . . ................................................................................................38
5.3.5.3 Correct value............................................................................................................39
5.3.5.4 Rename . . ...............................................................................................................41
5.3.5.5 Copy.....................................................................................................................42
5.3.5.6 Delete....................................................................................................................42
5.3.5.7 File Options .............................................................................................................43
5.4 Picture Tuning........................................................................................................................45
5.4.1 Starting up Picture Tuning.....................................................................................................45
5.4.2 Motion Compensation (TMR) (Optional)......................................................................................45
5.4.2.1 Starting up the Motion Compensation..................................................................................46
5.4.2.2 LCD speed . . . ...........................................................................................................46
5.4.2.3 LCD speed R/G . . . . . ....................................................................................................46
5.4.2.4 LCD speed B/G . . . . . ....................................................................................................47
5.4.3 Color Temperature.............................................................................................................47
5.4.4 Gamma ........................................................................................................................48
5.4.5 Input Balance . . . ...............................................................................................................48
5.4.6 Windowing .....................................................................................................................52
R5976420 BARCOREALITY SIM 6 ULTRA 14052003 1

Table of contents
5.4.6.1 Starting Up Windowing .................................................................................................52
5.4.6.2 Blanking (Windowing)...................................................................................................52
5.4.6.3 Shift (Windowing) . . . ....................................................................................................54
5.4.6.4 Size (Windowing) .......................................................................................................55
5.4.6.5 Geo Soft Edge ..........................................................................................................56
5.4.6.6 Aspect Ratio.............................................................................................................56
5.5 Geometry.............................................................................................................................57
5.5.1 Introduction ....................................................................................................................57
5.5.2 Geometry Start up............................................................................................................. 57
5.5.3 Geometry file annotation . . ....................................................................................................58
5.5.4 Setting up a new Geometry file ...............................................................................................58
5.5.5 Possible Geometry file manipulations ........................................................................................58
5.5.6 Load . . ..........................................................................................................................59
5.5.7 Edit.............................................................................................................................60
5.5.7.1 Introduction. . . ...........................................................................................................61
5.5.7.2 Start up..................................................................................................................62
5.5.7.3 Coarse...................................................................................................................62
5.5.7.3.1 Start up............................................................................................................62
5.5.7.3.2 Corner selection ..................................................................................................62
5.5.7.3.3 Corner adjustment................................................................................................63
5.5.7.3.4 Side Bow selection................................................................................................65
5.5.7.3.5 Bow shaped pre-distortion set up . . . .............................................................................67
5.5.7.3.6 Coarse linearity adjustment using Side Bows ...................................................................67
5.5.7.3.7 Center selection...................................................................................................69
5.5.7.3.8 Center adjustment ................................................................................................69
5.5.7.4 Linearity adjustment ....................................................................................................70
5.5.7.4.1 Start up............................................................................................................70
5.5.7.4.2 Horizontal or Vertical Linearity selection .........................................................................71
5.5.7.4.3 Horizontal Linearity adjustment ..................................................................................71
5.5.7.4.4 Vertical Linearity adjustment .....................................................................................73
5.5.7.5 Fine......................................................................................................................74
5.5.7.5.1 Start up............................................................................................................75
5.5.7.5.2 Horizontal or Vertical Linearity selection .........................................................................75
5.5.7.5.3 Fine Horizontal or Vertical Linearity adjustment . . . ..............................................................76
5.5.7.5.4 Bow Linearity selection ...........................................................................................77
5.5.7.5.5 Bow Linearity adjustment.........................................................................................78
5.5.7.5.6 Quadrant selection................................................................................................79
5.5.7.5.7 Quadrant adjustment . ............................................................................................80
5.5.7.5.8 Local selection....................................................................................................81
5.5.7.5.9 Local adjustment..................................................................................................82
5.5.7.6 Shift......................................................................................................................83
5.5.7.7 Transport Delay ......................................................................................................... 83
5.5.7.8 Blanking .................................................................................................................85
5.5.7.8.1 Blanking Start up..................................................................................................85
5.5.7.8.2 Blanking Active On................................................................................................86
5.5.7.8.3 Blanking Shape Start up . . . . . .....................................................................................86
5.5.7.8.4 Blanking Shape selections . . .....................................................................................86
5.5.7.8.5 Blanking adjustment .............................................................................................. 87
5.5.7.9 Electronic Soft Edge (Optional).........................................................................................88
5.5.7.9.1 Introduction. . . . ....................................................................................................88
5.5.7.9.2 Preparations . . ....................................................................................................89
5.5.7.9.3 Soft Edge Start up ................................................................................................90
5.5.7.9.4 Soft Edge Active On ..............................................................................................90
5.5.7.9.5 Soft Edge Shape Start up . . . .....................................................................................90
5.5.7.9.6 Soft Edge Shape selections . .....................................................................................91
5.5.7.9.7 Basic Soft Edge Shape Set up .. .................................................................................92
5.5.7.9.8 Soft Edge Width Start up .........................................................................................94
5.5.7.9.9 Soft Edge Width selections.......................................................................................94
5.5.7.9.10 Basic Soft Edge Width Set up....................................................................................95
5.5.7.10 Reset .................................................................................................................... 97
5.5.7.10.1 Start up............................................................................................................97
5.5.7.10.2 Coarse Reset .....................................................................................................97
5.5.7.10.3 Linearity Reset ....................................................................................................98
5.5.7.10.4 Reset Fine ........................................................................................................98
5.5.7.10.5 Reset Blanking/Soft Edge ........................................................................................98
5.5.7.10.6 Reset All...........................................................................................................99
5.5.8 Rename . . . . . ..................................................................................................................100
5.5.9 Copy ..........................................................................................................................101
5.5.10 Delete .........................................................................................................................101
5.6 Geometry............................................................................................................................102
5.6.1 Geometry Start up............................................................................................................102
5.6.2 Size ...........................................................................................................................102
5.6.3 Shift ...........................................................................................................................103
5.6.4 Keystone......................................................................................................................103
5.6.5 Blanking – Soft Edge .........................................................................................................104
2R5976420 BARCOREALITY SIM 6 ULTRA 14052003

Table of contents
6. Installation Mode................................................................................................. 105
6.1 Installation Mode Overview .........................................................................................................106
6.2 Build-up..............................................................................................................................106
6.3 Start up ..............................................................................................................................107
6.4 Input Slots ..........................................................................................................................107
6.5 No signal.............................................................................................................................108
6.5.1 Changing the background color . . . ...........................................................................................109
6.5.2 Changing the shutdown setting . . . ...........................................................................................109
6.5.3 Changing the shutdown time . . ...............................................................................................109
6.6 Barco logo...........................................................................................................................110
6.7 Lens Adjustment . . ..................................................................................................................111
6.8 Menu Position .......................................................................................................................112
6.9 800 Peripheral . . . . ...................................................................................................................112
6.9.1 Defining the Output module of the RCVDS05 . . . ............................................................................113
6.9.2 Defining the communication protocol of the RCVDS05 .....................................................................113
6.10 Configuration ........................................................................................................................114
6.11 OSD Color...........................................................................................................................114
6.12 Internal Patterns.....................................................................................................................114
6.13 Shutter (Optional) . ..................................................................................................................115
7. Service Mode...................................................................................................... 117
7.1 Service Mode Overview.............................................................................................................118
7.2 Build-up..............................................................................................................................118
7.3 Start up ..............................................................................................................................119
7.4 Identification .........................................................................................................................119
7.4.1 The different identification screens . . . . . . ....................................................................................119
7.4.2 Displaying the identification screen . . . . . . ....................................................................................120
7.5 Change password...................................................................................................................120
7.6 Change the address.................................................................................................................121
7.6.1 Start up........................................................................................................................121
7.6.2 Projector Address.............................................................................................................122
7.6.3 Common Address ............................................................................................................122
7.7 Change Baudrate . ..................................................................................................................123
7.8 Reset Lamp Runtime................................................................................................................123
7.9 Lamp Runtime history...............................................................................................................123
7.10 I2C Diagnoses. . . . . ..................................................................................................................124
7.11 Dimming .............................................................................................................................125
7.11.1 Lamp Dimming................................................................................................................125
7.11.2 Motorized Dimming (Optional) ...............................................................................................125
7.11.3 Constant Light Output (Optional). . ...........................................................................................126
7.12 Uniformity............................................................................................................................127
7.13 Electronic convergence . . . ..........................................................................................................130
7.14 DynaColor™.........................................................................................................................131
7.15 Gray Level Definition................................................................................................................133
7.16 Purity.................................................................................................................................135
7.17 Display Blanking.....................................................................................................................136
7.18 Panel Adjustments ..................................................................................................................139
7.19 Preset Input Balance................................................................................................................140
A. Standard Sourcesetup files.................................................................................... 141
A.1 Table overview ......................................................................................................................141
B. Source Numbers 81 —86 and91 —96....................................................................... 143
B.1 Projector without any 800 peripheral connected . . . ................................................................................143
B.2 Projector with a 800 peripheral connected . . . . .....................................................................................143
B.2.1 Source numbers 91 — 96....................................................................................................143
B.2.2 Source numbers 81 — 86....................................................................................................144
C. Cleaningthe Dustfilter........................................................................................... 145
C.1 Cleaning .............................................................................................................................145
Index.................................................................................................................... 147
R5976420 BARCOREALITY SIM 6 ULTRA 14052003 3

Table of contents
4R5976420 BARCOREALITY SIM 6 ULTRA 14052003

1. Packaging and Dimensions
1. PACKAGING AND DIMENSIONS
This chapter handles about the way the projector is packed and gives an overview of the dimensions.
• Lens Packaging
• Dimensions
1.1 Lens Packaging
Way of Packaging
Lenses are supplied as an individual item.
Theyarepackedinacartonbox.
Save the original shipping carton and packing material, they will be necessary if you ever have to transport
the lens.
Never transport the projector with the lens mounted on it !
Always remove the lens before transporting the projector.
1.2 Dimensions
Dimensions overview
Dimensions are given in mm (1 inch = 25.4 mm)
187.2
202.4
371.2
53.5 29.6
53.5
97.6 120.2
245.1
152.6 152.6
6
107.5
min 12
max 24
Image 1-1
Front view dimensions projector
R5976420 BARCOREALITY SIM 6 ULTRA 14052003 5

1. Packaging and Dimensions
46 82.7 211.4 169.5
139.6 14
148.9
380.6
526.8
60
43
124.1
217.2
147.8
124.4
42
Image 1-2
Side view dimensions projector
184.4
368.7
Image 1-3
Top view dimensions projector
6R5976420 BARCOREALITY SIM 6 ULTRA 14052003

2. Installation Guidelines
2. INSTALLATION GUIDELINES
Overview
• Installation guidelines
• Configuration
• Lenses
• Batteries
Before installing the projector, read first the safety instructions supplied with the BARCOREALITY SIM6 UL-
TRA.
2.1 Installation guidelines
Ambient Temperature Conditions
Careful consideration of things such as image size, ambient light level, projector placement and type of screen to use are critical to
the optimum use of the projection system.
Max. ambient temperature : 40 °C or 104 °F
Min. ambient temperature : 0 °C or 32 °F
The projector will not operate if ambient air temperature falls outside this range (0°C- 40°C or 32°F-104°F).
Storage temperature: -35°C to +65°C (-25.6°F to 149°F)
Humidity Conditions
Storage: 0 to 98 % RH Non-condensing
Operation: 0 to 95 % RH Non-condensing
Environment
Do not install the projection system in a site near heat sources such as radiators or air ducts, or in a place subject to direct sunlight,
excessive dust or humidity. Be aware that room heat rises to the ceiling; check that temperature near the installation site is not
excessive.
Harmful Environmental Contamination Precaution
Environment condition check
A projector must always be mounted in a manner which ensures the free flow of clean air into the projectors ventilation inlets. For
installations in environments where the projector is subject to airborne contaminants such as that produced by smoke machines or
similar (these deposit a thin layer of greasy residue upon the projectors internal optics and imaging electronic surfaces, degrading
performance), then it is highly advisable and desirable to have this contamination removed prior to it reaching the projectors clean
air supply. Devices or structures to extract or shield contaminated air well away from the projector are a prerequisite, if this is not a
feasible solution then measures to relocate the projector to a clean air environment should be considered.
Only ever use the manufactures recommended cleaning kit which has been specifically designed for cleaning optical parts, never
use industrial strength cleaners on a projectors optics as these will degrade optical coatings and damage sensitive optoelectronic
components. Failure to take suitable precautions to protect the projector from the effects of persistent and prolonged air contami-
nants will culminate in extensive and irreversible ingrained optical damage. At this stage cleaning of the internal optical units will be
non-effective and impracticable. Damage of this nature is under no circumstances covered under the manufactures warranty and
may deem the warranty null and void. In such a case the client shall be held solely responsible for all costs incurred during any
repair. It is the clients responsibility to ensure at all times that the projector is protected from the harmful effects of hostile airborne
particles in the environment of the projector. The manufacture reserves the right to refuse repair if a projector has been subject to
wantful neglect, abandon or improper use.
What about ambient light ?
The ambient light level of any room is made up of direct or indirect sunlight and the light fixtures in the room. The amount of ambient
light will determine how bright the image will appear. So, avoid direct light on the screen. Windows that face the screen should be
covered by opaque drapery while the set is being viewed. It is desirable to install the projection system in a room whose walls and
floor are of non-reflecting material. The use of recessed ceiling lights and a method of dimming those lights to an acceptable level
R5976420 BARCOREALITY SIM 6 ULTRA 14052003 7

2. Installation Guidelines
is also important. Too much ambient light will ‘wash out’ of the projected image. This appears as less contrast between the darkest
and lightest parts of the image. With bigger screens, the ‘wash out’ becomes more important. As a general rule, darken the room to
the point where there is just sufficient light to read or write comfortably. Spot lighting is desirable for illuminating small areas so that
interference with the screen is minimal.
Which screen type ?
There are two major categories of screens used for projection equipment. Those used for front projected images and those for rear
projection applications.
Screens are rated by how much light they reflect (or transmit in the case of rear projection systems) given a determined amount
of light projected toward them. The ‘GAIN’ of a screen is the term used. Front and rear screens are both rated in terms of gain.
The gain of screens range from a white matte screen with a gain of 1 (x1) to a brushed aluminized screen with a gain of 10 (x10)
or more. The choice between higher and lower gain screens is largely a matter of personal preference and another consideration
called the Viewing angle. In considering the type of screen to choose, determine where the viewers will be located and go for the
highest gain screen possible. A high gain screen will provide a brighter picture but reduce the viewing angle. For more information
about screens, contact your local screen supplier. A high gain screen will provide a brighter picture but reduce the viewing angle.
What image size ? How big should the image be ?
The projector is designed for projecting an image size (video) from 1.00m (3.3ft) to 6.00m (19.7ft) with a aspect ratio of 5 to 4.
2.2 Configuration
Which configuration can be used ?
The projector can be installed to project images in four different configurations :
• Front/table
• Rear/table
• Front/ceiling
• Rear/ceiling
Positioning the projector
Drawings are given for a nominal lens position.
8R5976420 BARCOREALITY SIM 6 ULTRA 14052003

2. Installation Guidelines
Screen
PD
B
Floor
Projector
CD
A
CD = B - A
SH
Optical axis projection lens
SH
SW
SIDE VIEW
BACK VIEW
Screen
TOP VIEW
SW
Floor
Image 2-1
B Distance between ceiling and top of the screen or between floor and bottom of the screen.
A Correction value, distance between bottom side of projector (without feet) and middle of the lens. Value to be subtracted from
B to obtain the correct installation position. (A value is a constant value for all screen widths and type of lenses, A = 124.1 mm
or 4.89 inch)
CD Total distance between projector and ceiling or projector and floor.
SW Screen width
SH Screen height (image height)
PD Projector distance, distance between screen and projector
2.3 Lenses
Overview
• Lenses
• Lens formulas
• Lens installation
• Cleaning the lens
R5976420 BARCOREALITY SIM 6 ULTRA 14052003 9

2. Installation Guidelines
2.3.1 Lenses
Available lenses
The following lenses are available, or will become available (contact a BARCO service center) as an option :
Lenses Standard version Scheimpflug version
QFD(1.27:1) R9840400 R9840600
QFD(2.5:1) R9840290 R9840470
QFD(1.4-2.1:1) R9840380 R9840610
QFD(2.1-3.0:1) R9840390 R9840590
QFD(3.4-4.5:1) R9840060 R9840580
QFD(4.5-6.0:1) R9840100 R9840460
QFD(7:1) R9840410 —
QGD(0.8:1) / SW: (1-1.4)m R9829800 R9840480
QGD(0.8:1) / SW: (1.7-2.4)m R9840040 R9840490
QGD(0.86:1) R9840491 R9840492
2.3.2 Lens formulas
Formulas
Lenses Metric Formulas (meter) Inch Formulas (inch)
QFD(1.27:1) PD = 1.29 x SW — 0,0195 + 0,00276 /
SW
PD = 1.29 x SW — 0.768 + 4.278 / SW
QFD(2.5:1) PD = 2.427 x SW + 0,025 + 0,022 / SW PD = 2.427 x SW +0.984 + 34.10 / SW
QFD(1.4-2.1:1) PDmin = 1,44 x SW + 0,0287 — 0,022 /
SW
PDmax = 2,20 x SW — 0,01 + 0,020 / SW
PDmin = 1.44 x SW + 1.13 — 34.10 / SW
PDmax = 2.20 x SW — 0.39 + 31.00 / SW
QFD(2.1-3.0:1) PDmin = 2,13 x SW — 0,10 + 0,056 / SW
PDmax = 2,90 x SW + 0,10 — 0,0745 /
SW
PDmin =2.13xSW—3.937+86.80/
SW
PDmax = 2.90 x SW + 3.937 — 115.48 /
SW
QFD(3.4-4.5:1) PDmin = 3,374 x SW — 0,115 + 0,0575 /
SW
PDmax = 4,433 x SW — 0,133 + 0,0556
/SW
PDmin = 3.374 x SW — 4.53 + 89.13 /
SW
PDmax = 4.433 x SW — 5.24 + 86.18 /
SW
QFD(4.5-6.0:1) PDmin = 4,29 x SW — 0,02 + 0,0009 /
SW
PDmax = 5,86 x SW + 0,15 + 0,0121 /
SW
PDmin = 4.29 x SW — 0.787 + 1.395 /
SW
PDmax = 5.86 x SW + 5.906 + 18.755 /
SW
QFD(7.0:1) PD = 6,882 x SW — 0,045 + 0,048 / SW PD = 6.882 x SW — 1.772 + 74.4 / SW
QGD(0.8:1) / SW: (1-1.4)m PD = 0,775 x SW — 0,048 + 0,0074 /
SW
PD = 0.775 x SW — 1.89 + 11.47 / SW
QGD(0.8:1) / SW: (1.7-2.4)m PD = 0,775 x SW — 0,048 + 0,0072 /
SW
PD = 0.775 x SW — 1.89 + 11.47 / SW
QGD(0.86:1) PD = 0,8376 x SW + 0,00254 — 0,0150
/SW
PD = 0.8376 x SW + 0.1 — 23.25 / SW
10 R5976420 BARCOREALITY SIM 6 ULTRA 14052003

2. Installation Guidelines
Lens program to calculate the projector distance is available on the BARCO web site :
http://www.barco.com/projection_systems/customer_services/lens_program.asp
2.3.3 Lens installation
How to install ?
Follow the next procedure :
1. Open the lens cover of the projector by pivoting it up and take it off. (image 2-2)
2. Pull the lens locks levers backwards to open the lens locks. (image 2-3)
3. Put the lens on the lens holder. (image 2-4)
4. Push the lens locks back in position and lock the levers.
5. Plug the wires of the motor unit into the connector (image 2-5)
6. Re-install the lens cover.
Image 2-2
Image 2-3
Image 2-4 Image 2-5
The procedure for the mounting of a Scheimpflug lens is different.
Refer to the installation manual of the lens.
Never transport the projector with the lens mounted on it !
Always remove the lens before transporting the projector.
R5976420 BARCOREALITY SIM 6 ULTRA 14052003 11

2. Installation Guidelines
2.3.4 Cleaning the lens
To minimize the possibility of damaging the optical coating or scratching exposed lens surface, we have de-
veloped recommendations for cleaning the lens. FIRST, we recommend you try to remove any material from
the lens by blowing it off with clean, dry deionized air. DO NOT use any liquid to clean the lenses.
Necessary tools
Tor a yse e TM cloth (delivered together with the lens kit). Order number : R379058.
Howtocleanthelens?
Proceed as follow :
1. Always wipe lenses with a CLEAN TorayseeTM cloth.
2. Always wipe lenses in a single direction.
Warning: Do not wipe back and forwards across the lens surface as this tends to grind dirt into the coating.
3. Do not leave cleaning cloth in either an open room or lab coat pocket, as doing so can contaminate the cloth.
4. If smears occur when cleaning lenses, replace the cloth. Smears are the first indication of a dirty cloth.
Do not use fabric softener when washing the cleaning cloth or softener sheets when drying the cloth.
Do not use liquid cleaners on the cloth as doing so will contaminate the cloth.
Other lenses can also be cleaned safely with this TorayseeTM cloth.
2.4 Batteries
Overview
• Battery installation
2.4.1 Battery installation
How to install the battery
Two batteries are packed together with the RCU. Before using your RCU, install first these batteries.
1. Remove the battery cover on the backside by pushing the handle a little towards the bottom of the RCU.
2. Lift up the top side of the cover at the same time.
3. Insert the batteries as indicated in the RCU.
4. Put the battery cover on its place.
12 R5976420 BARCOREALITY SIM 6 ULTRA 14052003

3. Connections
3. CONNECTIONS
Overview
• Power connections
• Switching on
• Switching to standby
• Switching off
• Source Specifications
• Input source connections
• Communications connections
3.1 Power connections
AC Power cord connection
Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector
at the front of the projector. The power input is auto-ranging from 90 to 240 VAC.
Fuses
For continued protection against fire hazard :
• refer replacement to qualified service personnel.
• ask to replace with the same type of fuse (T10 AH/250V).
3.2 Switching on
How to switch on.
1. Press the power switch to switch on the projector.
- When ’0’ is visible, the projector is switched off.
- When ’1’ is visible, the projector is switched on
The projector starts in standby mode. The projector mode indication lamp is red.
Starting image projection.
1. Press Stand by key once on the local keypad or on the remote control.
The projector mode indication lamp will be green (image 3-1, image 3-2)
Projector mode indication
Image 3-1
R5976420 BARCOREALITY SIM 6 ULTRA 14052003 13

3. Connections
F1
F2 F3 F4 F5
ADJ EXIT
ENTER
PAUSE
PHASE
TEXT
SHARPN
TINT
COLOR
BRIGHTN
CONTR
TREBLE BALANCE
BASS VOL
90
78
56
34
12
COLOR
PHASE
SHARPN TINT BRIGHTN
STANDBY
ENTER
TEXT
EXIT
PAUSE
2
1
4
3
56
8
0
9
7
CONTRAST
Stand-by key
Image 3-2
Lamp run time indication while running
The lamp run time warning will only be displayed when the time is exceeding the limit. A warning message will be displayed 100
hours beforehand , with the exact run time “x” displayed on the screen. This message is displayed only at the start up of the projector.
Press the EXIT button on the RCU or keypad to remove this warning message.
If the projector is running all the time the lamp warning will never be displayed.
Lamp run time is
x
hours.
Operating the lamp
longer than
x
hours
may damage
the projector.
<ENTER> to reset the
lamp runtime.
Please replace
the lamp.
Menu 3-1
The total lifetime of the lamp for a safe operation is “x” hours max, do not use it longer. Always replace with a same type of lamp.
Call a BARCO authorized service technician for lamp replacement.
Press ENTER to reset the lamp runtime.
14 R5976420 BARCOREALITY SIM 6 ULTRA 14052003

3. Connections
Max Lamp runtimes for the available projectors.
SIM Projector x(Maxlampruntime,inhours)
BARCOREALITY SIM6 ULTRA 1000
Using a lamp for more than its recommended life time is dangerous as the lamp could explode.
3.3 Switching to standby
Howtoswitchtostandby?
1. Press STANDBY for 2 seconds until the messages Saving data please wait is displayed. (image 3-3)
Saving data, please wait
Image 3-3
When switching to standby the projector waits for 30 sec. before it can be restarted. During this period the
LED display will show a jumping square with a dash. After one minute, two dashes will be displayed and the
projector can restart.
3.4 Switching off
How to switch off the projector?
To switch off the projector, handle as follow :
1. Press STANDBY key for 2 seconds. When the message Saving data, please wait is displayed, do not press any longer on the
STANDBY key otherwise the projector will restart.
When switching to standby the projector waits for 1 minute before it can restart again. During this period the LED display will
show a jumping square with a dash. After one minute, two dashes will be displayed and the projector can restart.
Warning: Let cool down the projector at least 10 min.
2. Switch off the projector with the power switch.
3.5 Source Specifications
BARCOREALITY SIM6 ULTRA Source Specifications
Critical source specifications:
• Maximum Horizontal frequency of 115 kHz.
• Maximum pixel frequency of 205 MHz.
R5976420 BARCOREALITY SIM 6 ULTRA 14052003 15

3. Connections
Recommended source specifications:
• The Active number of pixels has to be 1024 x 768 (XGA), 1280 x 1024 (SXGA) or 1600 x 1200 (UXGA).
3.6 Input source connections
3.6.1 Input facilities
Overview Input Facilities
SDI SDO
S-VIDEO
VIDEO
COMPUTER
IEEE 1394 MOUSE
MONITOR
RS232 IN RS232 OUT
AUDIO IN AUDIO IN AUDIO IN AUDIO IN
COMM. PORT RC
C
B
A
RGBH/C
V
5610/100 Base-T
21
12
34
43
Image 3-4
Input Facilities
Input number Type of input
15–Cable Input
2Computer Input
3Video Input1
4Super Video Input1
3.6.2 Input Selection Mode
What can be done with the Input Selection Mode ?
This Input Selection Mode can be set [AUTOMATIC] or [MANUAL].
When [AUTOMATIC] is selected in the Input slots menu, by starting up the projector, it searches for an input source by scanning the
inputs. If only one source is found, this source will be projected. If different sources are found, the priority is as follow.
1. 5 Cable input.
2. Computer.
3. Video (Optional).
4. Super Video (Optional).
When a RCVDS is connected to the projector, the [AUTOMATIC] mode is disabled.
1. Only available when the optional video decoder is installed
16 R5976420 BARCOREALITY SIM 6 ULTRA 14052003
