Barco DATA 708 User manual

R9002129
INSTALLATION MANUAL
DATA
708

BARCO PROJECTION SYSTEMS
Date :
260597 Art. No. : R5975987A
R9002129
INSTALLATION MANUAL
DATA
708

Due to constant research, the information in this manual is subject to change without notice.
Produced by BARCO NV, May 1997.
All rights reserved.
Trademarks are the rights of their respective owners.
BARCO nv/Projection Systems
Noordlaan 5
B-8520 Kuurne
Belgium
Printed in Belgium

Table of Contents
i-1
5975987A BARCODATA 708 260597
TABLE OF CONTENTS
i
WARNINGS .................................................................................................................................................................................... 1-1
SAFETY INSTRUCTIONS............................................................................................................................................................... 1-1
On safety ................................................................................................................................................................................. 1-2
On installation .......................................................................................................................................................................... 1-2
On servicing ............................................................................................................................................................................. 1-2
On cleaning .............................................................................................................................................................................. 1-2
On repacking............................................................................................................................................................................ 1-2
On illumination ......................................................................................................................................................................... 1-2
UNPACKING & DIMENSIONS ........................................................................................................................................................ 2-1
Unpacking ................................................................................................................................................................................ 2-1
Projector dimensions ................................................................................................................................................................ 2-2
INSTALLATION GUIDELINES ........................................................................................................................................................ 3-1
* Environment .......................................................................................................................................................................... 3-1
* What about ambient light ?..................................................................................................................................................... 3-1
* Which screen type? ............................................................................................................................................................... 3-1
* What image size? How big should the image be? ................................................................................................................. 3-1
* Where to install the projector?................................................................................................................................................ 3-2
* How to install the projector? ................................................................................................................................................... 3-2
INSTALLATION SET UP ................................................................................................................................................................. 4-1
Access to controls .................................................................................................................................................................... 4-1
Scan adaptation ....................................................................................................................................................................... 4-2
PROJECTOR SET UP .................................................................................................................................................................... 5-1
Projector Set Up ....................................................................................................................................................................... 5-1
Password mode ....................................................................................................................................................................... 5-1
POWER (MAINS) CONNECTION.................................................................................................................................................... 6-1
Power (mains) cord connection ................................................................................................................................................ 6-1
Fuses ....................................................................................................................................................................................... 6-2
Switching on/off........................................................................................................................................................................ 6-2
INSTALLATION ADJUSTMENTS .................................................................................................................................................... 7-1
Entering the adjustment mode .................................................................................................................................................. 7-1
Overview flow chart installation mode. ...................................................................................................................................... 7-2
Installation mode start up ......................................................................................................................................................... 7-2
Scheimpfug adjustment ............................................................................................................................................................ 7-4
Optical lens focusing ................................................................................................................................................................ 7-5
Electrical focusing .................................................................................................................................................................... 7-5
Raster centering ....................................................................................................................................................................... 7-6
CRT projection angle adjustment.............................................................................................................................................. 7-6
Alignment of the projector......................................................................................................................................................... 7-9
Appendix A : G2 adjustment ............................................................................................................................................................A-1

Table of Contents
i-2 5975987A BARCODATA 708 260597

Safety Instructions
1-1
5975987A BARCODATA 708 260597
WARNING
TO PREVENT FIRE OR ELECTRICAL SHOCK
HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE
FEDERAL COMMUNICATION COMMISSION (FCC STATEMENT)
This equipment has been tested and found to comply with the limits
of a class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmfulinterferencewhentheequipmentisoperatedinacommercial
environment. This equipment generates, uses and can radiate radio
frequencyenergyand,ifnotinstalledandusedinaccordancewiththe
instruction manual, may cause harmful interference to radio commu-
nications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required
to correct the interference at his own expense.
Note :
The use of shielded cables is required to comply within the limits of
Part 15 of FCC rules and EN55022.
*Allthesafetyandoperatinginstructionsshouldbereadbeforeusing
this unit.
*Thesafetyand operating instructions manualshouldberetainedfor
future reference.
* All warnings on the equipment and in the documentation manuals
should be adhered to.
* All instructions for operating and use of this equipment must be
followed precisely.
On safety
1. This product should be operated from an AC power source.
This projector may be connected to an IT-power system.
Operating AC power voltage of the projector:
BARCODATA 708
Art.No. R9002129 (
120V AC )
If you are not sure of the type of AC power available, consult your
dealer or local power company.
2.Thisproductisequippedwitha3-wiregroundingplug,aplughaving
a third (grounding) pin. This plug will only fit into a grounding-type
power outlet. This is a safety feature. If you are unable to insert the
plug into the outlet, contact your electrician to replace your obsolete
outlet. Do not defeat the purpose of the grounding-type plug.
WARNING FOR THE CUSTOMERS: THIS APPARATUS MUST BE
GROUNDED (EARTHED) via the supplied 3 conductor AC power
cable.
(If the supplied power cable is not the correct one, consult your
dealer.)
1SAFETY INSTRUCTIONS
Notice on Safety
This equipment is built in accordance with the requirements of the
international safety standards EN60950, UL 1950 and CSA C22.2
No.950, which are the safety standards of information technology
equipment including electrical business equipment.
Thesesafetystandardsimposeimportantrequirementsontheuseof
safetycriticalcomponents,materialsandisolation,inordertoprotect
theuser oroperatoragainstriskofelectricshockand energy hazard,
and having access to live parts.
Safety standards also impose limits to the internal and external
temperaturerises,radiationlevels,mechanicalstabilityandstrength,
enclosure construction and protection against the risk of fire.
Simulated single fault condition testing ensures the safety of the
equipment to the user even when the equipment's normal operation
fails.
INSTALLATION INSTRUCTIONS
Before operating this equipment please read this manual
thoroughly, and retain it for future reference.
Installation and preliminary adjustments should be performed
by qualified BARCO personnel or by authorized BARCO
service dealers.
OWNER’S RECORD
Thepartnumberandserialnumberarelocatedatthebacksideofthe
projector. Record these numbers in the spaces provided below.
Referto themwhenever youcall uponyour BARCOdealer regarding
this product.
PART NUMBER :
SER. NUMBER :
DEALER :
The lightning flash with an arrowhead within a
triangle is intended to tell the user that parts
inside this product may cause a risk of electrical
shock to persons.
The exclamation point within a triangle is in-
tended to tell the user that important operating
and/orservicing instructionsare includedin the
technical documentation for this equipment.

Safety Instructions
1-2 5975987A BARCODATA 708 260597
Power cord with ANSI 73.11 plug:
The wires of the power cord are colored in
accordance with the following code.
Green/yellow: ground
White: neutral
Black: line (live)
3. Do not allow anything to rest on the power cord. Do not locate this
product where persons will walk on the cord.
To disconnect the cord, pull it out by the plug. Never pull the cord
itself.
4. If an extension cord is used with this product, make sure that the
totaloftheampereratingsontheproductspluggedintotheextension
cord does not exceed the extension cord ampere rating. Also make
surethat the totalof all products plugged intothe wall outletdoes not
exceed 15 amperes.
5. Never push objects of any kind into this product through cabinet
slots as they may touch dangerous voltage points or short out parts
that could result in a risk of fire or electrical shock.
Neverspillliquidofany kind ontheproduct.Shouldany liquid orsolid
object fall into the cabinet, unplug the set and have it checked by
qualified service personnel before resuming operations.
6. Lightning - For added protection for this video product during a
lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet. This will prevent
damage to the projector due to lightning and AC power-line surges.
On installation
1. Do not place this equipment on an unstable cart, stand, or table.
The product may fall, causing serious damage to it.
2. Do not use this equipment near water.
3. Slots and openings in the cabinet and the back or bottom are
provided for ventilation; to ensure reliable operation of the product
and to protect it from overheating, these openings must not be
blocked or covered. The openings should never be blocked by
placingthe producton a bed, sofa, rug, orother similarsurface. This
product should never be placed near or over a radiator or heat
register.
The projector should not be placed in a built-in installation or enclo-
sure unless proper ventilation is provided.
4.Do not block the projectorcooling fans or free airmovement under
and around the projector. Loose papers or other objects may not be
nearer to the projector than 4" on any side.
On servicing
Do not attempt to service this product yourself, as opening or
removing covers may expose you to dangerous voltage potentials
and risk of electric shock!
Refer all servicing to qualified service personnel.
Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the equipment.
c.If the product has been exposed to rain or water.
d. If the product does not operate normally when the operating
instructions are followed.
Note : Adjust only those controls that are covered by the operating
instructions since improper adjustment of the other controls may
result in damage and will often require extensive work by a qualified
technician to restore the product to normal operation.
e.Iftheproducthasbeendropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating
a need for service.
Replacement parts - When replacement parts are required, be sure
theservicetechnicianhasusedoriginalBARCOreplacementpartsor
authorizedreplacementpartswhichhavethesamecharacteristicsas
the BARCO original part. Unauthorized substitutions may result in
degraded performance and reliability, fire, electric shock or other
hazards. Unauthorized substitutions may void warranty.
Safety check - Upon completion of any service or repairs to this
projector, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
On cleaning
Unplug this product from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
- To keep the cabinet looking brand-new, periodically clean it with a
soft cloth. Stubborn stains may be removed with a cloth lightly
dampenedwith milddetergentsolution. Neverusestrongsolvents,
such as thinner or benzine, or abrasive cleaners, since these will
damage the cabinet.
- To ensure the highest optical performance and resolution, the
projection lenses are specially treated with an anti-reflective coat-
ing,therefore,avoidtouching the lens. Toremoveduston the lens,
usea soft drycloth. Do notuse a dampcloth, detergent solution, or
thinner.
On repacking
Save the original shipping carton and packing material; they will
comeinhandyifyoueverhavetoshipyourequipment.Formaximum
protection, repack your set as it was originally packed at the factory.
On illumination
Inordertoobtainthebestqualityfortheprojectedimage,itisessential
that the ambient light which is allowed to fall on the screen be kept to
an absolute minimum.
Wheninstalling theprojectorandscreen,caremustbetaken toavoid
exposure to ambient light directly on the screen. Avoid adverse
illumination on the screen from direct sunlight or fluorescent lighting
fixtures.
The use of controlled ambient lighting, such as incandescent spot
light or a dimmer, is recommended for proper room illumination.
Where possible, care should also be taken to ensure that the floors
andwalls ofthe room in which theprojector isto beinstalled are non-
reflecting, dark surfaces. Brighter surfaces will tend to reflect and
diffuse the ambient light and hence reduce the contrast of the
projected image on the screen.

Unpacking and Dimensions
2-1
5975987A BARCODATA 708 260597
2UNPACKINGAND DIMENSIONS
Unpacking
Take the projector out of its shipping carton and place it on a table.
Savetheoriginalshippingcartonandpackingmaterial,theywillcomeinhandyifyoueverhavetoshipyourprojector. Formaximumprotection,
repack your projector as it was originally packed at the factory.
To open de banding, pull on the clip as shown in the first drawing.
Contents of the shipped box :
- 1 BARCODATA 708.
- 1 remote control + 9V battery
- 1 power cable with outlet plug type ANSI 73.11.
- 1 owner's manual.
- 1 installation manual.

Unpacking and Dimensions
2-2 5975987A BARCODATA 708 260597
Projector dimensions
(mm)

Installation Guidelines
3-1
5975987A BARCODATA 708 260597
3INSTALLATION GUIDELINES
Installation guidelines
Careful consideration of things such as image size, ambient light
level,projector placement andtype of screento use arecritical to the
optimum use of the projection system.
* Environment
Do not install the projection system in a site near heat sources such
as radiators or air ducts, or in a place subject to direct sunlight,
excessive dust or humidity. Be aware that room heat rises to the
ceiling; check that the temperature near the installation site is not
excessive.
* What about ambient light ?
The ambient light level of any room is made up of direct or indirect
sunlightandthelightfixturesintheroom. Theamountofambientlight
willdetermine howbright theimage will appear. So, avoid direct light
on the screen.
Windows that face the screen should be covered by opaque drapery
while the set is being viewed. It is desirable to install the projecting
systeminaroomwhosewallsandfloorareofnon-reflectingmaterial.
The use of recessed ceiling lights and a method of dimming those
lightstoanacceptablelevelisalsoimportant. Toomuchambientlight
results in a ‘wash out’ of the projected image. This appears as less
contrast between the darkest and lightest parts of the image. With
biggerscreens,the‘washout’becomesmoreimportant. Asageneral
rule,darken the room to thepoint wherethere is justsufficient lightto
read or write comfortably. Spot lighting is desirable for illuminating
small areas so that interference with the screen is minimal.
* Which screen type?
There are two major categories of screens used for projection
equipment. Thoseusedfor frontprojectedimages andthosefor rear
projection applications.
Screens are rated by how much light they reflect (or transmit in the
case of rear projection systems) given a determined amount of light
projectedtowardthem. The‘GAIN’ofascreenisthetermused. Front
andrearscreens arebothrated intermsof gain. Thegainof screens
range from a white matte screen with a gain of 1 (x1) to a brushed
aluminized screen with a gain of 10 (x10) or more. The choice
betweenhigherandlowergainscreensislargelyamatterofpersonal
preference and another consideration called the Viewing angle.
In considering the type of screen to choose, determine where the
viewerswillbelocatedandgoforthehighestgainscreen possible. A
highgainscreenwillprovidea brighter picture butreducetheviewing
angle.
For more information about screens, contact your local screen
supplier.
* What image size? How big should the image be?
TheBARCODATA708isdesignedforprojectinganimagewidthfrom
1.4m (4.6') to 7m (23') with an aspect ratio of 4 to 3. It leaves the
BARCOfactory,adjustedasaceilingfrontprojectorforascreenwidth
of 2.4m. Changing the image size from the factory preset requires a
realignment of the projector.
Screen width

Installation Guidelines
3-2 5975987A BARCODATA 708 260597
* Where to install the projector?
To indicate a correct installation position it is necessary to know the
distance :
- projector - ceiling
- projector - screen
To find this correct position for the projector, equipped with HD145
lenses, formulas are given in the next paragraph.
Abbreviations used on drawing and diagrams on next pages
B = Distance between ceiling and top of the screen.
A = Correction Value, extra value to be added to B to obtain the
correct installation position. (In some cases the A value can be
negative.)
CD = Total distance between projector and ceiling.
CD = A + B (When the result is negative, enlarge the distance
betweenceilingandtopofthescreen,mountscreenlower,untilCD
becomes zero or positive)
SW = Screen width.
PD = Perpendicular distance between screen and projector.
A
CD
PD
B
screen
projector
ceiling
screen width
SW
Front view
Top view
FormulasforProjectorto screen distance andcorrectionvalueAwith
regard to the screen width for
HD145 lenses (metric).
Formulas (metric)
PD[m] = 1.21 x SW[m] + 0.213
A[cm] = 12.95 x SW[m] - 22.83
FormulasforProjectorto screen distance andcorrectionvalueAwith
regard to the screen width for HD145 lenses (inch).
Formulas (inch)
PD = 1.21 x SW + 8.39
A = 0.1295 x SW - 8.99
* How to install the projector?
Ceiling mount or table mount?
To install the projector, apply always the BARCO kits which are
specially designed for this function.
BARCO ceiling support.
AlwaysusetheBARCOceiling support to attachyourprojectortothe
ceiling. (BARCO order number : R9827990)
Theinstallationinstructionforthissupportisenclosedinthepacketof
the set.
BARCO projection table.
Height adaptable projection table provides a stable stand for your
projector,and makesitpossibletoadapttheprojectorperfectly tothe
local requirements. (BARCO order number R9827740).
Max phosphor width on CRT = 11.5 cm Max phosphor width on CRT = 4.53 inch

Installation Set Up
1-1
5975987A BARCODATA 708 260597
4INSTALLATION SET UP
Access to controls
Opening procedure :
During the projector set up and installation it is neces-
sary to open the top cover.
To gain access, procede as follow :
*Turn both lock screws with a screwdriver or a coin
counter clockwise.
* Lift up and pivot the top cover.
* Support the top cover with the hand, no support is
incorporated.
During some installations it will become handy to
remove the top cover totally.
Therefore,
- pivote the top cover ± 60°
-pushthetopcover to thefrontsideofthe projector
until it jumps out of its hings.
- Turn the top cover till 90° and lift it up.
Re-install the cover :
Hook the top cover into the cabinet hinges. Pivot the top cover 30°
and pull it backwards until it fits in the hinges. Close the cover and
secure the lock screws by turning clockwise with a screwdriver or
coin.

Installation Set Up
4-2 5975987A BARCODATA 708 260597
Scan adaptation
The scanning can be switch by turning the Horizontal and Vertical
scan connectors and the convergence connectors.
To change the scanning, it is necessary to open the projector top
cover and to rotate the chassis.
Foropeningtheprojector'stopcover,see Getting access to controls.
WARNING
TURNOFFPROJECTORANDUNPLUGTHEPOWERCORD
BEFORE CHANGING THE SCAN DIRECTION.
Gaining access to the scan connectors and the convergence con-
nectors.
- Open the top cover (to remove it, see 'Gaining access to controls'.
- To open the chassis, loosen both indicated retaining screws.
Turn the chassis to the front of the projector until it grips in its locks.
COMM PO RT
(800peripherals) REMOTE
R G(S) B S VIDEO S-VIDEO
RS232OUTRS232IN
Horizontal scan
connectors
Vertical scan
connectors
Convergence
connectors
COMM PO RT
(800peripherals)
REMOTE
RG(S)B SVIDEO
S-VIDEO
RS232OUTRS232 IN

Installation Set Up
1-3
5975987A BARCODATA 708 260597
A : Horizontal scan inversion
Three connectors are used, one for each horizontal
deflection coil. When changing the horizontal scan,
insure that all three connectors are set in the same
position. See position of the connectors for the
corresponding projector configuration.
B : Vertical scan inversion
Three connectors are used, one for each vertical
deflection coil. When changing the vertical scan,
insure that all three connectors are set in the same
position. See position of the connectors for the
corresponding projector configuration.
Top view of the connectors; upper three connectors
for horizontal scan inversion, lower three for vertical
scan inversion.
Front / Table Front / Ceiling
Rear / Table Rear / Ceiling
Horizont al scan
connectors
Vertical s can
connectors
C : Convergence connectors
Three connectors are used. The position of these connectors has to
be changed when switching from one configuration to another.
With an open chassis, for a
front-table or a rear ceiling configuration,
the connectors must be plugged in with the
contacts upwards (away
from the tubes). For a front-ceiling or rear-table configuration, the
connectors must be plugged in with the contacts facing the tubes
Contact side
After scan inversion, close the chassis and close the top cover.
Reconnect the power cord to the wall outlet.
Note
Switching over from floor to ceiling or vice versa requires a complete
readjustment of picture geometry and convergence.
Check of the correct connector position
Note : this check procedure can only be done after power (mains)
connection. So, first continue with the
projector set up and the
connections and then return to this checking procedure.
Switch on the BARCODATA 708 and press ADJUST to start up the
adjustment mode. Select with the control disk 'Service' and press
ENTER. The service menu will be displayed. Select 'PROJECTOR
SET UP' and press ENTER. Select 'IDENTIFICATION' and press
ENTER. On this screen, information is given about the projectors
configuration.
Configuration when leaving the factory : ceiling/front configuration.
Follow next procedure to check the configuration :
- switch on the projector.
- the projector starts up on the last selected source.
- press the ADJUST key.
- highlight 'service' with the control disk and press ENTER.
The
'service mode menu' will be displayed
- select with the control disk
'Projector set up' and press ENTER.
The
'Projector set up menu' will be displayed.
- Select with the control disk
'Identification' and press ENTER.
The projector displays the Identification screen
Thisscreengives informationaboutthe projector configurationinthe
subject '
config. '.
ADJUSTMENT MODE
Select a path from
below:
Select with or
then <ENTER>
<EXIT> to return
source 1
GUIDED
RANDOM ACCESS
INSTALLATION
SERVICE
IRIS
Select with or
then <ENTER>
<EXIT> to return.
SERVICE MODE
PROJECTOR SET-UP
MEMORY MANAGEMENT
COMMON SETTINGS
I2CDIAGNOSTICS
Select with or
then <ENTER>
<EXIT> to return.
PROJECTOR SET-UP
IDENTIFICATION
TOTAL RUN TIME
CHANGE PASSWORD
CHANGE LANGUAGE
CHANGE PROJECTOR ADDRESS
CHANGE BAUDRATE
POWER UP MODE : operating
BARCO LOGO
DATA 708
Proj. address : 001
Soft. Version : 5.00
Config. : Ceiling
front
Baudrate PC : 9600
Text : ON
Serial No. : 10359852

Installation Set Up
4-4 5975987A BARCODATA 708 260597

Projector Set Up
5-1
5975987A BARCODATA 708 260597
5PROJECTOR SET UP
Projector Set Up
The strap on the CPU unit allow a set up of the password mode.
Gaining access to the strap
- Open the top cover (see installation set up)
- Open the chassis (see installation set up)
Horizontal scan
connectors
Vertical scan
connectors
Convergence
connectors
COMM PO RT
(800peripherals)
REMOTE
RG(S)B SVIDEO
S-VIDEO
RS232OUTRS232 IN
strap
Password mode
Withastraponthecontrollerunit,theimportantprojectoradjustments
can be protected with a password. When the password feature is
enabled (strap mounted on both legs), the customer has to enter a
password before he can enter the specific adjustment.
When the password menus are disabled (strap mounted only on one
leg), all adjustments are free. This position of the strap is useful for
qualified service technicians because they do not need a password
during service.
Position of the strap :
ON : password disabled
OFF : password enabled
Socket for strap

Projector Set Up
5-2 5975987A BARCODATA 708 260597

Power Connection
6-1
5975987A BARCODATA 708 260597
6POWER CONNECTION
Power (mains) cord connection
Use the supplied power cord to connect your projector to the wall
outlet. Plug the female power connector into the male connector at
the front of the projector. See installation instructions before
connecting to the supply
V NOM 120 Volt
I MAX 5 AMP
FREQ 60 Hz
OFF
ON
See installation instructions before
connecting to the supply
V NOM 120 Volt
I MAX 5 AMP
FREQ 60 Hz
OFF ON
Fuses
Warning
For continued protection against fire hazard :
- replace with the same type of fuse
- refer replacement to qualified service personnel
Fuse type : 2 x T5A/250V (Barco order number : R314104)
Switching on/off
The projector is switched ON and OFF using the power (mains)
switch ON/OFF.
Pressed : ON
Not pressed : OFF
The projector can start now in the 'operational mode' (image dis-
played) or in the 'stand by mode', depending on the position of the
'power up' dip switch on the controller unit. This DIP switch is set
duringinstallationbyaqualifiedtechnician. Ifyouwanttochangethis
start up mode, call a qualified technician.
Stand by indication lamp :
no light up : projector in operational mode
red : projector is in stand by.
-9V SF HOLDDOWN EHT STANDBY
-CONV
-17V +17V +HTHD +CONV +9V +210V +30V
AAAA
AAAA
AAAA
AAAA
COINC HOLD DOWN HD
Leds on the front plate of the projector

Power Connection
6-2 5975987A BARCODATA 708 260597
