Barco FL40 series User manual

FL40 series
Quick Start Guide
Projector Main Components and interfaceProjector Main Components and interface
Warning
Risk Group 2 (RG2) LED product according to IEC EN 62471-5.
Do not stare in to beam
Refer to user manual before operating
Do not attempt to disassemble or modify this projector.
Download Product Manual
Product manuals and documentation are available online at www.barco.com/en/support/fl40-wu
Registration may be required; follow the instructions given on the website.
IMPORTANT!
Read Installation Instructions before connecting equipment to the mains power supply.
1
6
1
435
18217
1Adjustable feet
2Projector lens
3Lens holder
4IR receiver: For receiving remote control signals
5
LCD panel
6Keypad. Used for local operation of the projector
7
Connector panel: Control and communication interface 8Lens lock handle
4

- 2 -
Control & communication connectionsControl & communication connections
1Menu Navigation
2Menu Selection
3Open Menu
4Menu Back
5Power On/O
6OSD On/O
7Input Selection
8Shutter Open/Close
9Test Patterns
10 Lens Menu
11 LCD Panel
10 9 8 7
1 2 3 4 5 6
Local keypad
11
Button backlight status
BUTTON COLOR STATUS DESCRIPTION
Projector starts up (Booting)Blinking WHITE
Projector is in StandbySolid WHITE
Blinking RED Error condition
Blinking BLUE Projectorgoes to ON mode
Projector is ON
Power button
Solid BLUE
O Projector not in power ON state
Solid WHITE Shutter is open
Shutter is closedSolid RED
Shutter button
1288910
3567
7
1
RS-232: 9- pin DB9 Connector
2
Sync Port IN/OUT - BNC / Bidir mini-DIN
3
Trigger: 12VDC - 0,5A (6W)
4
RC: Jack connector for wired remote
5
DP: Standard Display port
6
LAN: Standard RJ45 connector
7
Usb 2.0 type A, 4 pin
8
Dual DVI-I 1.0 (DVI_D Functionallity)
HDMI: Standard HDMI 2.0
9
10
HDBaseT: Standard RJ45 8P8C
4
2

AC
110-240V
Connect power Press Power On Button
Installation ConditionsInstallation Conditions
Ventilation RequirementsVentilation Requirements
Power up procedure
Power down procedure
AC
110-240V
Pull out Connector Press Power Button for 3 sec
250mm
250mm
1. Plug in mains power cord
2. The projector will run a start up procedure. When completed,
the standby button illuminates white. (Standby mode).
3. Press power button again to bring the projector in ON mode.
When the power button backligh is steady blue,
the projector are ready for use.
1. Press the power button for 3 seconds
2. The power button will illuminate white, and
the projector enters the cooling down process.
3. Wait until the cooling down process are
completed before removing the main power
cord from the projector
- Review source information in the status menu (LCD screen or OSD) and verify that the source signal is compatible.
- Use test image to verify that the correct aspect ratio is selected
- Reset color and display settings to factory settings
- Restart the projector. Let the unit cool down for at least 1 minute prior to restarting
- Check the lenght of the source cables, and try shorter cables
Failure indications
What to do when the content or color is not correct
Caution
Do not place heat sensitive
objects in the area of the
orange arrow
Ambient operating conditions:
Temperature: 10 - 40°C
Altitude 1500 - 3000m
Temperature: 10 - 35
°C
Humidity: 10 - 80% RH
Humidity: 10-80% RH
Altitude 0 - 1500m:
Power requirements:
100 - 240 V, 60 - 50 Hz
Dimensions excl. lens:
450 x 471 x 244mm (WxLxH)
Weight excl. lens: 21,5 kg
NOTE !
The operating conditions will change when dust or pollution filters are installed.
Refer to filter installation manual for correct data

RCU batteries
- Two AA size batteries. Use alkaline batteries for optimum range and life time.
- Replacing batteries will reset the broadcast address of the RCU to its default value ’0’.
- Replacing batteries switches on the RCU automatically.
1Button pressed indicator
2Shutter Open
3Shutter Close
4LCD panel On/O
5OSD On/O
6Lens Zoom
7Lens Shift
8MenuOpen/Close
9Menu Selection, OK button
10 Menu Navigation
11 Input Selection
12 Address button
13 Numeric buttons
14 Backspace (when entering values)
15 XLR connector
16 Decimal mark (when entering values)
17 Macro button
18 MenuBack
19 Defaultbutton
20 Lens Focus
21 Color menu
22 Test Patterns
23 Power On
24 Power O
25 3.5 mm jack
26 RCU On/O
25 26
1
2
3
4
5
6
7
8
9
10
11
12
13
15
24
23
22
21
20
19
18
17
14 16
RCU buttons

3
Lens Removal
Installing lens
1. When removing the lens, always close the shutter, see keypad explanation. Press Shutter keypad, and verify
that the shutter keypad turn in to red illumintation. This indicate that the shutter is closed. When new lens is installed,
open shutter by pressing the shutter key again.
Shutter open state is verified when the shutter key illuminates white.
3. Pull the lens straight out of the lens mount.
NOTE!! To prevent damage to the lens, and dust contamination in the projector light processor, always replace the
lens bayonet cap, lens front cap and projector lens cap immediately after removing the lens.
2. Move the lever to the far left position
Always keep shutter closed
when installing or removing the lens.
1. When handling lens in or out, always close shutter, see keypad explanation. Press Shutter keypad, and verify
that the shutter keypad turn in to red illumination. This indicate that the shutter is closed. When the lens is
installed, open shutter by pressing the shutter key. Shutter open state is verified when the shutter key
illuminates white.
2. Verify that the lens release lever is in it’s default position,
at the far left of the slide, as illustrated
3. Remove the protective cap at the lens bayonet end
4. Align the lens so that the red marking on the bayonet
end is facing upwards.
5. Install the lens bayonet into the lens mount, and then move the lever to the right. Check that the lever is firmly
Warning

ENABLING BRIGHT OUTCOMES
Software upgradeSoftware upgrade
The projector is now ready for normal operation.
1. Go to www.barco.com and select your product. All available firmware downloads are filed under
the Technical Downloads tab
2. Download the firmware. Extract and save the file to a USB Stick with FAT file system. Use the eject function on
your PC to safely remove the device from your computer.
3. Place the projector in Standby mode (status indicator is steady white).
4. Insert the USB stick into one of the projector’s rear USB ports.
After a few seconds, the status indicator will flash. (Rate: 3 Hz/180 FPM). This signals that the upgrade is in progress.
If the upgrade file is corrupt or invalid, the status indicator will turn red and the upgrade process will stop.
Note! The upgrade will not be installed in this instance, and the upgrade process must be restarted with a full and correct file.
The projector may restart several times during the upgrade process
5. The LCD display will show the progress of the update procedure, and also when the USB stick must be removed.
The projector will return to standby mode (status indicator is steady) once the upgrade is completed successfully.
NOTE !
Once initiated, the upgrade procedure can take up to 20 minutes to complete.
CAUTION !
Do NOT turn o, power down, or remove mains
power supply to the projector when an upgrade is in progress.
Doc No: R5910124 / 02
