Barco ClickShare CS-100 User manual

CS-100
Installation manual
R5900022/01
16/02/2016

Barco NV
President Kennedypark 35, 8500 Kortrijk, Belgium
Phone: [phone]
Fax: [phone]
Support: www.barco.com/en/support
Visit us at the web: www.barco.com
Printed in China

Changes
Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war-
ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the
program(s) described in this publication at any time without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this
publication; these changes are incorporated in new editions of this publication.
The latest edition of Barco manuals can be downloaded from the Barco web site www.barco.com or from the secured Barco web site
https://www.barco.com/en/signin.
Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or
stored in a retrieval system without the prior written consent of Barco.
Guarantee and Compensation
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. On receipt, the purchaser
must immediately inspect all delivered goods for damage incurred during transport, as well as for material and manufacturing faults Barco
must be informed immediately in writing of any complaints.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning,
at latest 30 days after the transfer of risks. In the event of justified notice of complaint, Barco can repair the fault or provide a replacement
at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a
reduction in the purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for direct or
indirect damage, and also damage attributed to the operation of software as well as to other services provided by Barco, being a component
of the system or independent service, will be deemed invalid provided the damage is not proven to be attributed to the absence of properties
guaranteed in writing or due to the intent or gross negligence or part of Barco.
If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly,
in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in
the contract, all guarantee claims of the purchaser will be rendered invalid. Not included in the guarantee coverage are system failures
which are attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as well as normal
maintenance are not subject to the guarantee provided by Barco either.
The environmental conditions as well as the servicing and maintenance regulations specified in this manual must be complied with by the
customer.
Barco ClickShare End-User License Agreement (EULA/Software License)
PLEASE READ THIS DOCUMENT CAREFULLY BEFORE OPENING OR DOWNLOADING AND USING SOFTWARE OR HARDWARE
PROVIDED TO YOU BY BARCO AS IT CONTAINS THE TERMS AND CONDITIONS BY WHICH BARCO OFFERS TO LICENSE THE
SOFTWARE. BY OPENING THE SOFTWARE PACKAGE, OR USING THE HARDWARE IN WHICH THE SOFTWARE IS EMBEDDED,
YOU AGREE TO BECOME BOUND BY THE TERMS OF THIS AGREEMENT.
The Software as supplied by BARCO is licensed, not sold to you, on a non-exclusive basis for use only under the terms of this license,
and BARCO reserve all rights not expressly granted to you. You may own the carrier on which the Software is provided, but the Software
is owned and copyrighted by BARCO or by third party suppliers. Your license confers no title or ownership and is not a sale of any rights
in the Software or its documentation.
By installing, executing and/or using the Software, either as initial version or as an upgrade, update, patch or enhancement of a prior
release, this Software License shall supersede any terms and conditions previously agreed upon (whether or not in writing) between Barco
and you with respect to the subject matter of this Software License and such previous terms shall from the date hereof cease to have any
force or effect; provided, however that this Software License shall not be construed as a renunciation, discharge or waiver of any right or
remedy provided in any terms and conditions previously agreed upon with respect to a failure of either party to perform any of its obligations
under any terms and conditions previously agreed upon.
Software Specifications
The Software contains the following software products: ClickShare
Software License Terms

1. This Software License is between you and BARCO NV, a corporation organized and existing under the laws of Belgium registered
under number BE 0473.191.041, Commercial Companies’ Register of Kortrijk, having its registered office President Kennedypark, 35
at B-8500 Kortrijk, Belgium ("Barco") for the use of the Software.
You hereby undertake to inform all users authorized by you to make use of the computing device on which the Software is loaded/in-
stalled (“Authorized Users”) of the terms of this Software License and to bind all Authorized Users to accept all such terms of this
Software License as applies to them.
2. Barco grants you a limited, non-exclusive, non-assignable, non-transferable user license (without the right to grant sublicenses).
Unless specifically agreed upon otherwise between you and Barco or unless specifically allowed by the Software (or its DRM man-
agement) itself, i) the license under this Software License applies to one (1) copy of the Software to be used on one single computing
device and ii) installation on a computing device that may be concurrently accessed by more than one user shall not constitute a
permitted use and a separate license is required for each active user connected to a computing device on which the Software is being
used.
You and Authorized Users are entitled to use the Software for the purposes and in the manner set out in this Software License (and
documentation), but neither you nor any Authorized User are entitled to: (i) sell or grant a security interest in the Software to other
parties in any way, or to rent, lease or sub-license the Software to others without the express prior written consent of Barco; or (ii)
exploit the Software or any of its component parts for any commercial purpose, other than use by you and/or Authorized Users of the
Software.
Neither you nor any Authorized User may, whether in whole or in part, copy, translate, reverse engineer, derive source code from,
modify, disassemble, decompile, create derivative works based on the Software, or remove any proprietary notices or labels on the
Software, save as may be permitted by law or this Software License, without the prior consent, in writing, of Barco.
3. Barco (and Barco’s licensors, as appropriate) retain ownership of all intellectual property rights in the Software and any copies you
or any Authorized User may make of such Software. The Software is protected by national copyright laws, international copyright
treaties and conventions, and other applicable laws. All rights not expressly licensed to you in this Software License are reserved
to Barco and Barco’s licensors, as appropriate. The Software contains certain other licensed materials and Barco’s licensors may
protect their rights in the event of any violation of this Software License.
4. Barco shall hold you harmless, defend and indemnify you from and against direct damages, losses and expenses arising from in-
fringement or alleged infringement of any patent, trademark or copyright of such third party by the license and the right to install the
Software as permitted by this Software License and settle at its sole expense any amounts awarded in a final judgment or settlement
resulting therefrom, under the condition that (i) you promptly notify Barco in writing after a claim has been asserted against you or
the commencement of any claim, action, suit or proceeding (whichever is the earlier), and (ii) Barco shall be allowed to assume sole
control of the defense and any settlement negotiations related to any claim, action, suit or proceeding, and (iii) you shall not negotiate,
settle or compromise any claim, action, suit or proceeding without the prior written consent of Barco and (iv) you, at your cost, shall
cooperate with Barco and provide assistance and support, as may reasonably be required by Barco, in connection with the defense
and any settlement negotiations related to any claim, action, suit or proceeding. Barco shall have no indemnity obligation for any
Software, or any portion thereof, (i) that is based on specifications, drawings, models or other data furnished by you or, (ii) that is
not provided by Barco or, (iii) that is modified, in spite of the prohibition for you to modify the software or, (iv) to the extent that you
continue allegedly infringing activity after having been provided modifications that avoid the alleged infringement, or (v) where the use
of the Software, or the combination or thereof with other Software, processes or materials or the distribution thereof rather than the
Software itself is the primary cause of an alleged infringement. In case it has been determined by a finally awarded judgment that
Barco infringed or misappropriated such third party rights or earlier, at Barco’s discretion, it may, at its option and cost, (i) modify the
Software in such a way that it shall not infringe upon or misappropriate the rights of the third party or (ii) obtain for you a license or
other right to use the rights allegedly infringed or (iii) replace the Software in question with non-infringing Software. The remedies set
forth in this paragraph shall constitute your sole and exclusive remedy and Barco’s sole and exclusive liability for a third party claim
that the Software infringes or misappropriates any intellectual property right of a third party.
5. The duration of this Software License will be from the date of your acceptance (as set forth above) of the Software (whereby you ac-
knowledge that use of the Software implies acceptance), with no termination date, unless otherwise specified. You may terminate this
Software License at any time by destroying all copies of the Software then in your possession and returning all associated materials
and documentation, to Barco or the appointed Barco reseller that sold or provided these to you. Barco may terminate this Software
License forthwith by informing you at any time if you and/or any Authorized User are in breach of any of the Software License’s terms.

6. YOU UNDERSTAND THAT THE SOFTWARE IS BEING PROVIDED TO YOU "AS IS". BARCO DOES NOT MAKE NOR INTENDS
TO MAKE ANY WARRANTIES OR REPRESENTATIONS, EXPRESS OR IMPLIED AND SPECIFICALLY DISCLAIMS ALL IMPLIED
WARRANTIES OF MERCHANTABILITY FITNESS, FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT OF INTELLEC-
TUAL PROPERTY AND DOES NOT WARRANT THAT THE SOFTWARE WILL BE FREE FROM ERRORS OR THAT SUCH ERRORS
WILL BE CORRECTED BY BARCO AND YOU ARE SOLELY RESPONSIBLE FOR ALL COSTS AND EXPENSES ASSOCIATED
WITH RECTIFICATION, REPAIR OR DAMAGE CAUSED BY SUCH ERRORS.
YOU ALSO ACKNOWLEDGE AND AGREE THAT:
BARCO ACCEPTS NO LIABILITY FOR ANY DAMAGES, LOSSES OR CLAIMS YOU OR ANY THIRD PARTY MAY SUFFER AS
A RESULT OF YOUR USE OF THE SOFTWARE. IN JURISIDCTIONS WHERE BARCO’S LIABILITY CANNOT BE EXCLUDED,
BARCO’S LIABILITY FOR DIRECT DAMAGES SHALL BE LIMITED TO AN AMOUNT OF 250 EURO IN THE AGREGATE (OR TO
THE MAXIMUM EXTENT PERMITTED BY LAW WHERE NO FURTHER EXCLUSION IS LEGALLY ALLOWED).
TO THE MAXIMUM EXTENT PERMITTED BY LAW, IN NO EVENT WILL BARCO BE LIABLE FOR ANY INDIRECT, SPECIAL,
PUNITIVE, INCIDENTAL OR CONSEQUENTIAL LOSS OR DAMAGES OF ANY KIND WHICH MAY ARISE OUT OF OR IN CON-
NECTION WITH THE SOFTWARE, THIS SOFTWARE LICENSE OR THE PERFORMANCE OR PURPORTED PERFORMANCE
OF OR FAILURE IN THE PERFORMANCE OF BARCO’S OBLIGATIONS UNDER THIS SOFTWARE LICENSE OR FOR ANY ECO-
NOMIC LOSS, LOSS OF BUSINESS, CONTRACTS, DATA, GOODWILL, PROFITS, TURNOVER, REVENUE, REPUTATION OR
ANY LOSS ARISING FROM WORK STOPPAGE, COMPUTER FAILURE OR MALFUNCTION OF THE SOFTWARE AND ANY AND
ALL OTHER COMMERCIAL DAMAGES OR LOSSES WHICH MAY ARISE IN RESPECT OF USE OF THE SOFTWARE, EVEN IF
BARCO HAS BEEN ADVISED OF THE POSSIBILITY OF THEIR OCCURRENCE.
YOU HEREBY AGREE TO INDEMNIFY, KEEP INDEMNIFIED, DEFEND AND HOLD HARMLESS BARCO AND BARCO’S AFFILI-
ATES AND SUBSIDIARIES FROM AND AGAINST ANY AND ALL ACTIONS, PROCEEDINGS, LIABILITY, LOSS, DAMAGES, FEES
AND COSTS (INCLUDING ATTORNEYS" FEES), AND OTHER EXPENSES INCURRED OR SUFFERED BY BARCO ARISING OUT
OF OR IN CONNECTION WITH ANY BREACH BY YOU OF THE TERMS OF THIS SOFTWARE LICENSE.
7. You shall treat as confidential all information obtained from the other pursuant to this Software License which is marked "confidential"
or the equivalent or has the necessary quality of confidence about it and shall not divulge such information to any persons without
Barco’s prior written consent provided that this Paragraph 7 shall not extend to information which was rightfully in the possession of
you prior to the commencement of the negotiations leading to this Software License, which is already public knowledge or becomes
so at a future date (otherwise than as a result of a breach of this paragraph 7), is required to be disclosed by law or which is trivial or
obvious. You are aware of and ensure to comply with the provisions of this paragraph 7. The foregoing obligations as to confidentiality
shall survive any termination of this Software License.
8. You will remain responsible for the maintenance of your hardware, operating system, the functioning of your network and in keeping
your systems virus-free. You acknowledge that the Software is a complex computer software application, and that the performance
thereof may vary depending hardware platform, software interactions and configuration. You acknowledge that the Software is not
designed and produced specifically to meet your specific requirements and expectations and the selection of the Software by you is
entirely your own choice and decision. For the avoidance of doubt, nothing in this Software License shall impose any obligation on
Barco to provide support services (on the Software or any other hardware or software product).
9. This Software License is the only understanding and agreement between you and Barco for use of the Software by you and/or Autho-
rized Users. The Software License supersedes all other communications, understandings or agreements we had prior to this Software
License (with the exception of any continuing confidentiality agreement) although nothing in this Software License purports to exclude
liability for fraudulent misrepresentation. You may not export or re-export the Software or any copy or adaptation in violation of any
applicable laws or regulations. This Software License shall not be altered, amended or varied. If any provision of this Software Li-
cense is determined to be illegal, void or unenforceable, or if any court of competent jurisdiction in any final decision so determines,
this Software License shall continue in full force save that such provision shall be deemed to be deleted with effect from the date of
such decision, or such earlier date, and shall be replaced by a provision which is acceptable by law and which embodies the intention
of this Software License a close as possible.
10. You acknowledge that this Software may be subject to U.S. or other governments Export Jurisdiction. You agree to comply with all
applicable international and national laws that apply to the Software, including the U.S. Export Administration Regulations, as well as
end-user, end-use, and destination restrictions issued by the U.S. or other governments.
11. Barco shall be entitled to sub-contract all or any of Barco’s obligations hereunder to a third party and/or any of Barco’s affiliated
companies.
12. The construction, validity and performance of this Software License shall be governed in all respects by the laws of Belgium without
recourse to its conflict of law principles. All disputes arising in any way out of or affecting this Software License shall be subject
to the exclusive jurisdiction of the courts of Kortrijk, without prejudice to enforcement of any judgment or order thereof in any other
jurisdiction. The United Nations Convention on Contracts for the International Sale of Goods (the "Convention") shall not apply to this
Software License, however, if the Convention is deemed by a court of competent jurisdiction to apply to this Software License, Barco
shall not be liable for any claimed non-conformance of the Software under Article 35(2) of the Convention.
Trademarks Software License Terms
Brand and product names mentioned in relation to the Software may be trademarks, registered trademarks or copyrights of their respective
(third party) holders. All such brand and product names mentioned in relation to the Software serve as comments or examples and are not
to be understood as advertising for the products or their manufacturers.
Privacy Policy
You acknowledge and agree that the Software is gathering technical information about the functionality of the products which are connected
through the Software (“Functional Information”) and that Barco may make use of such Functional Information (with the exclusion of any

personal data) for any reason Barco sees fit, including but not limited to providing services to you / your organization, allowing third party
to access to such Functional Information and/or to provide services to you / your organization .
You hereby explicitly give consent that Barco may gather, access, preserve, and/or disclose the personal data you provide to us (e.g.
connected with your account allowing for the gathering of Functional Information as well as any content associated with that account) as
well as personal information we receive from you through the use of the Software:
• For the benefit of the business purposes of Barco and/or its affiliates;
• In order to provide, maintain, protect and/or improve the Software and to develop new software;
• For administration of the relationship between you, your organization and Barco and/or its affiliates ;
• For any other legitimate purpose (including i) direct marketing purposes from Barco, its affiliates or selected third parties, and ii)
allowing third parties to provide services to you related to the Software);
• if required to do so by law or in a good faith belief that such access preservation or disclosure is reasonably necessary to:
- Satisfy any applicable law, regulation, legal process or enforceable governmental request;
- Enforce this Software License, including investigation of potential violations hereof;
- Detect, prevent, or otherwise address fraud, security or technical issues (including, without limitation, the filtering of spam);
- Protect against imminent harm to the rights, property or safety of Barco, its users or the public as required or permitted by law.
Barco shall not process any “sensitive information” whatsoever, including but not limited to medical information.
You understand that the technical processing and transmission of or by the Software, including your content, may involve:
• Transmissions over various networks;
• Changes to conform and adapt to technical requirements of connecting networks, devices and/or services.
You hereby explicitly give consent that Barco may export your personal data to any country worldwide, especially to any country where
Barco and/or its affiliates have infrastructure, or where a third party is making available infrastructure to Barco and/or its affiliates, to process
personal data.
Barco fully adheres to the EU Directive 95/46/EC on the protection of individuals with regard to the processing of personal data and the
free movement of such data, as implemented in the local EU member states. In accordance with these regulations, you have a right of
access to, and rectification of, your personal data. You may exercise these rights by contacting Barco.
Open Source Software provisions:
This product contains software components released under an Open Source license. A copy of the source code is available on request
by contacting your Barco customer support representative.
EACH SEPARATE OPEN SOURCE SOFTWARE COMPONENT AND ANY RELATED DOCUMENTATION ARE PROVIDED "AS IS" WITH-
OUT EXPRESS OR IMPLIED WARRANTY INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL THE COPYRIGHTHOLDER OR ANY OTHER CONTRIBUTOR
BE LIABLE FOR DIRECT, INCIDENTAL, SPECIAL, EXEMPLARY OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE POS-
SIBILITY OF SUCH DAMAGES, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIA-
BILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS OPEN SOURCE
SOFTWARE. MORE INFORMATION/DETAILS IS TO BE FOUND IN EACH SPECIFIC OPEN SOURCE LICENSE.
Copyright on each Open Source Software component belongs to the respective initial copyright holder, each additional contributor and/or
their respective assignee(s), as may be identified in the respective documentation, source code, README file, or otherwise. You shall not
remove or obscure or otherwise alter the respective copyrights.
You acknowledge living up to the conditions of each separate Open Source Software license.
In the development of the Software, the following Open Source Software components have been used (an updated list may be made
available through the (customer section of the) Barco website or other (online) means):
Open Source component Open Source License
acl http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
acpid http://www.gnu.org/licenses/gpl.html
attr http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
http://www.gnu.org/licenses/gpl.html
alsa-lib
http://www.gnu.org/licenses/lgpl.html
http://www.gnu.org/licenses/gpl.html
alsa-utils
http://www.gnu.org/licenses/lgpl.html

Open Source component Open Source License
http://www.gnu.org/licenses/gpl.html
alsa-plugins
http://www.gnu.org/licenses/lgpl.html
avahi http://www.gnu.org/licenses/lgpl.html
Bootstrap (3.1.1) https://github.com/twbs/bootstrap/blob/master/LICENSE
bootstrap-dialog https://github.com/twbs/bootstrap/blob/master/LICENSE
bootstrap-slider.js v2.0.0 http://www.apache.org/licenses/LICENSE-2.0
busybox http://opensource.org/licenses/GPL-2.0
Chart.js https://github.com/nnnick/Chart.js/blob/master/LICENSE.md
Datepicker for Bootstrao (1,6,0-dev) http://www.apache.org/licenses/LICENSE-2.0
dropbear http://opensource.org/licenses/mit-license.php
fakeroot http://www.gnu.org/licenses/gpl.html
coreutils http://www.gnu.org/licenses/gpl.html
crda http://opensource.org/licenses/ISC
cron http://opensource.org/licenses/ISC
Crypto++ http://www.cryptopp.com/License.txt
dbus http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
dhcpd http://opensource.org/licenses/ISC
dm-crypt http://creativecommons.org/licenses/by-sa/3.0/
dmidecode http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
e2fsprogs http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html
eglibc http://www.gnu.org/licenses/lgpl.html
ethtool http://www.gnu.org/licenses/gpl.html
express http://opensource.org/licenses/MIT
FFmpeg http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html
http://freetype.sourceforge.net/FTL.TXT
freetype
http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
gdbserver http://www.gnu.org/licenses/gpl.html
gmp http://www.gnu.org/licenses/lgpl.html
grub http://www.gnu.org/licenses/gpl.html
gstreamer http://www.gnu.org/licenses/lgpl.html
hdparm http://opensource.org/licenses/BSD-3-Clause
hostapd http://opensource.org/licenses/BSD-3-Clause
HTML5 Shiv 3.7.2 http://github.com/aFarkas/html5shiv/blob/master/MIT%20and%20GPL2%20licenses.md
i18next (1.10.0) https://opensource.org/licenses/MIT
i2c-tools http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
iftop http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
imx-bootlets http://www.gnu.org/licenses/gpl.html
iperf http://opensource.org/licenses/BSD-3-Clause
iproute2 http://www.gnu.org/licenses/gpl.html
iptables http://www.gnu.org/licenses/old-licenses/gpl-2.0.html

Open Source component Open Source License
iw http://opensource.org/licenses/BSD-3-Clause
Jasny Bootstrap (3.1.3) http://www.apache.org/licenses/LICENSE-2.0
jQuery Form Plugin (3.51.0-2014.06.20) https://github.com/malsup/form#copyright-and-license
jQuery JavaScript Library (1.11.3) https://jquery.org/license/
https://github.com/ablanco/jquery.pwstrength.bootstrap/blob/master/GPL-LICENSE.txt
jQuery Password Strength plugin for
Twitter Bootstrap https://github.com/ablanco/jquery.pwstrength.bootstrap/com-
mit/19480555e8c7c2f417d78a78dac63056fa221f6a
jQuery Upload File Plugin (4.0.8) https://github.com/hayageek/jquery-upload-file
jQuery Validation Plugin (1.13.1) https://opensource.org/licenses/MIT
kobs-ng http://www.gnu.org/licenses/gpl.html
libarchive http://opensource.org/licenses/bsd-license.php
libav http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html
libavutil http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html
libcap2 http://www.gnu.org/licenses/gpl.html
libdaemon0 http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html
libdrm2 http://opensource.org/licenses/MIT
libexpat1 http://opensource.org/licenses/MIT
libfontconfig1 http://opensource.org/licenses/BSD-3-Clause
libfontenc1 http://opensource.org/licenses/BSD-3-Clause
libgcc1 http://www.gnu.org/licenses/gpl.html
http://www.gnu.org/licenses/gpl.html
http://www.gnu.org/licenses/lgpl.html
libgcrypt11
http://www.gnu.org/copyleft/fdl.html
libglib-2 http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html
libgnutls26 http://www.gnu.org/licenses/lgpl.html
http://www.gnu.org/licenses/gpl.html
http://www.gnu.org/licenses/lgpl.html
libgpg-error0
http://www.gnu.org/copyleft/fdl.html
libimxvpuapi http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html
libjpeg-turbo http://opensource.org/licenses/BSD-3-Clause
libjpeg8 BSD like licensee
libnl2 http://www.gnu.org/licenses/lgpl.html
libNotify https://wiki.gnome.org/FoundationBoard/Resources/LicensingAgreement
libnss-mdns http://www.gnu.org/licenses/gpl.html
libpam http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
libpcap http://opensource.org/licenses/BSD-3-Clause
libpcre0 http://opensource.org/licenses/BSD-3-Clause
libpixman-1-0 http://changelogs.ubuntu.com/changelogs/pool/main/p/pixman/pixman_0.10.0-
0ubuntu1/libpixman-1-0.copyright
libpng12-0 http://www.libpng.org/pub/png/src/libpng-LICENSE.txt
libpopt0 http://opensource.org/licenses/MIT

Open Source component Open Source License
libresample http://www.gnu.org/licenses/lgpl.html
libsm6 http://metadata.ftp-master.debian.org/changelogs//main/libs/libsm/libsm_1.2.2-1_copyright
libstdc++6 http://www.gnu.org/licenses/gpl.html
libswscale http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html
libtalloc2 http://www.gnu.org/licenses/lgpl.html
libusb http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html
libva Copyright (c) 2011, Advanced Micro Devices, Inc. All rights reserved.
libX11 http://opensource.org/licenses/MIT
libXdamage http://opensource.org/licenses/MIT
libXext http://opensource.org/licenses/MIT
libXfixes http://opensource.org/licenses/MIT
libXinerama http://opensource.org/licenses/MIT
libxml2 http://opensource.org/licenses/MIT
libXrender http://opensource.org/licenses/MIT
libXtst http://opensource.org/licenses/MIT
libz1 Free license
lighttpd http://opensource.org/licenses/BSD-3-Clause
linux http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
lmsensors http://www.gnu.org/licenses/gpl.html
logrotate http://www.gnu.org/licenses/gpl.html
makedevs http://www.gnu.org/licenses/gpl.html
memtest86plus http://www.gnu.org/licenses/gpl.html
mesa http://opensource.org/licenses/MIT
modernizr (3.1.0) https://opensource.org/licenses/MIT
module-init-tools http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
modutils http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
monit http://www.gnu.org/licenses/gpl.html
ncurses http://opensource.org/licenses/MIT
netbase http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
node.js https://raw.github.com/joyent/node/v0.10.26/LICENSE
openssl http://www.openssl.org/source/license.html
openssh-sftp-server http://opensource.org/licenses/BSD-3-Clause
opkg http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
passport http://opensource.org/licenses/MIT
passport-http http://opensource.org/licenses/MIT
pciutils http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
http://perldoc.perl.org/perlartistic.html
perl
http://www.gnu.org/licenses/old-licenses/gpl-1.0.html
php http://www.php.net/license/3_01.txt
procps http://www.gnu.org/licenses/gpl.html

Open Source component Open Source License
pulseaudio http://www.gnu.org/licenses/lgpl.html
qt http://doc.qt.io/qt-5/lgpl.html
read-edid Free license
Respond.js https://github.com/scottjehl/Respond/blob/master/LICENSE-MIT
rockbox-imxtools http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
rsync (<3.0.0) http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
rsync (>=3.0.0) http://www.gnu.org/licenses/gpl.html
rsyslog http://www.gnu.org/licenses/gpl.html
splashutils http://www.gnu.org/licenses/gpl.html
sprintf-js https://opensource.org/licenses/BSD-3-Clause
srp http://srp.stanford.edu/license.txt
sscep https://github.com/certnanny/sscep/blob/master/COPYRIGHT
strace http://opensource.org/licenses/BSD-3-Clause
sysfsutils http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
sysvinit http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
tcpdump http://opensource.org/licenses/BSD-3-Clause
Timepicker Component for Twitter
Bootstrap https://opensource.org/licenses/MIT
ttf-arphic-uming http://ftp.gnu.org/non-gnu/chinese-fonts-truetype/LICENSE
ttf-dejavu-common http://dejavu-fonts.org/wiki/License
ttf-dejavu-sans http://dejavu-fonts.org/wiki/License
ttf-dejavu-sans-mono http://dejavu-fonts.org/wiki/License
https://osdn.jp/cvs/view/efont/sazanami/README
ttf-sazanami-gothic
http://metadata.ftp-master.debian.org/changelogs//main/t/ttf-sazanami/ttf-
sazanami_20040629-8_copyright (translation)
https://osdn.jp/cvs/view/efont/sazanami/README
ttf-sazanami-mincho
http://metadata.ftp-master.debian.org/changelogs//main/t/ttf-sazanami/ttf-
sazanami_20040629-8_copyright (translation)
ttf-un-fonts http://www.gnu.org/licenses/gpl.txt
u-boot http://www.denx.de/wiki/U-Boot/Licensing
uClibc http://www.gnu.org/licenses/lgpl.html
udev http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
update-modules http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
update-rc http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
usbutils http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
util-linux-ng http://www.gnu.org/licenses/gpl.html
wireless_tools http://www.gnu.org/licenses/gpl.html
wpa_supplicant http://opensource.org/licenses/BSD-3-Clause
xserver-xorg http://opensource.org/licenses/MIT
xvba-video http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
zeroconf http://www.gnu.org/licenses/gpl.html

EN55022-CISPR22 Class B ITE (Information Technology Equipment)
This is a class B product. In a domestic environment this product may cause radio interference in which case the user may be required to
take adequate measures.
If this equipment does cause interference to radio or television reception, the user may try to correct the interference by one or more of the
following measures :
• Re-orientation of the receiving antenna for the radio or television.
• Relocate the equipment with respect to the receiver.
• Plug the equipment into a different outlet so that the equipment and receiver are on different branch circuits.
• Fasten cables connectors to the equipment by mounting screws.
Federal Communication Commission Interference Statement
You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gen-
erates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
You ma y also find helpful the following booklet, prepared by the FCC: "How to Identify and Resolve Radio-TV Interference Problems." This
booklet is available from the U.S. Government Printing Office, Washington D.C. 20402.
Changes and Modifications not expressly approved by the manufacturer or registrant of this equipment can void your authority to operate
this equipment under Federal Communications Commissions rules.
In order to maintain compliance with FCC regulations shielded cables must be used with this equipment. Operation with non-approved
equipment or unshielded cables is likely to result in interference to radio & television reception.
FCC RF Radiation Exposure Statement: This device is capable of operating in 802.11a mode. For 802.11a devices operating in the
frequency range of 5.15 - 5.25 GHz, they are restricted for indoor operations to reduce any potential harmful interference for Mobile Satellite
Services (MSS) in the US. WIFI Access Points that are capable of allowing your device to operate in 802.11a mode (5 .15 - 5.25 GHz band)
are optimized for indoor use only. If your WIFI network is capable of operating in this mode, please restrict your WIFI use indoors to not
violate federal regulations to protect Mobile Satellite Services.
Base Unit FCC ID: 2AAED-R9861510
Button FCC ID (model R9861006D01): XF6-RS9110N1103
Button FCC ID (model R9861500D01): 2AAED-R9861500D01
ClickShare Button R9861500D01 has been tested and meets the FCC RF exposure guidelines.The maximum SAR value reported is
0.915W/kg.
Canada, Industry Canada (IC) Notices
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Radio Frequency (RF) Exposure Information
The radiated output power of the Barco Wireless Device is below the Industry Canada (IC) radio frequency exposure limits. The Barco
Wireless Device should be used in such a manner such that the potential for human contact during normal operation is minimized.
Base Unit IC ID: IC: 9393B-R9861510
Button IC ID (model R9861006D01): 8407A-RS9110N1103
Button IC ID (model R9861500D01): 9393B-R9861500D01

IC Antenna statement
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
This radio transmitter 9393B-R9861510 has been approved by Industry Canada to operate with the antenna types listed below with the
maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having
a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Type: PIFA
Maximum Peak Gain: 5.85 dBi
Impedance: 50 Ohm
Canada, avis d’lndustry Canada (IC)
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Informations concernant l’exposition aux fréquences radio (RF)
La puissance de sortie émise par l’appareil de sans fil Barco est inférieure à la limite d’exposition aux fréquences radio d’Industry Canada
(IC). Utilisez l’appareil de sans fil Barco de façon à minimiser les contacts humains lors du fonctionnement normal.
IC ID Unité de Base: 9393B-R9861510
IC ID Button (modèle R9861006D01): 8407A-RS9110N1103
IC ID Button (modèle R9861500D01): 9393B-R9861500D01
Déclaration d’antenne d’Industrie Canada (IC)
Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d’un type et d’un gain
maximal (ou inférieur) approuvé pour l’émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique
à l’intention des autres utilisateurs, il faut choisir le type d’antenne et son gain de sorte que la puissance isotrope rayonnée équivalente
(p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établissement d’une communication satisfaisante.
Le présent émetteur radio 9393B-R9861510 a été approuvé par Industrie Canada pour fonctionner avec les types d’antenne énumérés
ci-dessous et ayant un gain admissible maximal et l’impédance requise pour chaque type d’antenne. Les types d’antenne non inclus dans
cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l’exploitation de l’émetteur.
Type: PIFA
Gain maximum: 5.85 dBi
Impédance: 50 Ohm

Table of contents
TABLE OF CONTENTS
1. Introduction to the Installation Guide ......................................................................... 3
1.1 Documentation....................................................................................................................... 3
1.2 Symbols and fonts . . ................................................................................................................. 3
2. CS-100 Specifications ............................................................................................ 5
2.1 About the CS-100 ................................................................................................................... 5
2.2 CS-100 specifications ............................................................................................................... 6
2.3 About the Base Unit ................................................................................................................. 7
2.4 About the Button..................................................................................................................... 9
2.5 Mobile Device Support .............................................................................................................. 10
2.6 Ports used by the CS-100 Base Unit ...............................................................................................10
3. Getting started.....................................................................................................11
3.1 Environmental Condition Check . . .................................................................................................. 11
3.2 Basic Workflow ......................................................................................................................11
4. CS-100 Installation................................................................................................13
4.1 Installation methods for the Base Unit..............................................................................................13
4.2 Table mounting ......................................................................................................................13
4.3 Wall mounting........................................................................................................................13
4.4 Video signal connections to the Base unit . . ........................................................................................14
4.5 Audio connection ....................................................................................................................15
4.6 LAN connection......................................................................................................................15
4.7 Power connection . ..................................................................................................................15
5. Preparing the buttons ............................................................................................17
5.1 Pairing ...............................................................................................................................17
5.2 Pre-install of the Launcher service..................................................................................................18
5.3 ClickShare launcher installer........................................................................................................ 18
6. CS-100 Configurator..............................................................................................21
6.1 Accessing the Configurator .........................................................................................................21
6.2 On-Screen Language and Text Size ................................................................................................25
6.3 Meeting room information ...........................................................................................................26
6.4 Personalisation, wallpaper . .........................................................................................................27
6.5 Personalisation, Personalized wallpaper . . . ........................................................................................28
6.6 Manage configuration files ..........................................................................................................30
6.7 Display setup ........................................................................................................................31
6.8 Audio settings........................................................................................................................32
6.9 WiFi settings .........................................................................................................................33
6.10 LAN settings ......................................................................................................................... 34
6.11 Sharing protocols, ClickShare app..................................................................................................35
6.12 Security, compatibility ............................................................................................................... 36
6.13 Security, passwords ................................................................................................................. 36
6.14 Status information Base Unit........................................................................................................37
6.15 Date & Time setup, manually .......................................................................................................38
6.16 Date & Time setup, time server ..................................................................................................... 39
6.17 Energy savers .......................................................................................................................40
6.18 Buttons...............................................................................................................................41
6.19 Firmware Update ....................................................................................................................42
6.20 Support & Updates, Troubleshoot, log settings. . ...................................................................................43
6.21 Factory defaults......................................................................................................................44
7. Software updates..................................................................................................47
7.1 Software update .....................................................................................................................47
8. Troubleshooting .... ...... ...... .. .... .. ...... ...... ...... ...... ...... ...... .. .... .. .... .. ...... ...... ...... ...... . 49
8.1 Troubleshooting list . .................................................................................................................49
9. Environmental information ......................................................................................51
9.1 Disposal information................................................................................................................. 51
9.2 Rohs compliance ....................................................................................................................51
9.3 Production address ..................................................................................................................52
9.4 Importers contact information .......................................................................................................52
R5900022 CS-100 16/02/2016 1

Table of contents
2R5900022 CS-100 16/02/2016

1. Introduction to the Installation Guide
1. INTRODUCTION TO THE INSTALLATION GUIDE
In this section you get a short introduction to the available CS-100 documentation.
• Documentation
• Symbols and fonts
1.1 Documentation
This guide
Partnumber Description Level
R5900022 Installation Guide Installation engineer
This installation guide explains how to install your CS-100 in a meeting room, It explains also how to make everything operational.
It provides detailed information on how to configure your CS-100.
Available System documentation
This guide is part of the documentation set describing the CS-100 product.
Guide Article number
User Guide R5900024
Installation Guide R5900022
Safety Guide R5900031
Service Guide R5900026
Button Guide R5900007
Recycling Manual R5900028
API Guide R5900018
A printed copy of the Safety Guide and an electronic version of the user and installation guide on USB stick is included in the CS-100
box at purchase.
Always check for the latest version of the manual on www.barco.com/clickshare Click on Visit the ClickShare
product page and go to tab Downloads..
Depending on the CS-100 version, some graphics might be different to the ones used in this manual. This
however does not have any effect on the functionality.
1.2 Symbols and fonts
Symbol overview
The following icons are used in the manual :
Caution
Warning
Info, term definition. General info about the term
R5900022 CS-100 16/02/2016 3

1. Introduction to the Installation Guide
Note: gives extra information about the described subject
Tip: gives extra advice about the described subject
Font overview
• Buttons are indicated in bold, e.g. OK.
• Menu items are indicated in italic.
• Step related notes, tips, warnings or cautions are printed in italic.
• Procedure related notes, tips, warnings or cautions are printed in bold between 2 lines preceded by the corresponding icon.
4R5900022 CS-100 16/02/2016

2. CS-100 Specifications
2. CS-100 SPECIFICATIONS
About this chapter
It gives an overview of the specifications of a CS-100 set. and of the different components in the set.
Overview
• About the CS-100
• CS-100 specifications
• About the Base Unit
• About the Button
• Mobile Device Support
• Ports used by the CS-100 Base Unit
2.1 About the CS-100
CS-100 sets
ClickShare makes connecting to the meeting room’s video system a matter of clicking a Button. This CS-100 only helps the presenter
get the presentation on-screen in a second, but it also allows the other people in the meeting to participate more actively. The result
is enhanced meeting efficiency and better decision-making.
At the moment 3 different sets are available on the market. Each set is sold in its specific region and it can only be used in that
specific region because of WiFi regulations.
Components CS-100 set
A standard CS-100 set consists of a Base Unit and 1 Buttons. If needed, you can buy additional Buttons and a tray to store the
Buttons.
1
2
Image 2-1
1 Base unit
2Button
Accessories included
Depending on the country where you buy the product, the following regionalized accessories are also included in the CS-100 box.
Regional version Contains Accessories included
R9861510xx1
• R9861510
• 1x R9861500D01
• DC adapter with AC clips type A, C,
G, I
• USB stick with user documentation
• Printed safety manual
Contact your local sales representative for the correct regional variant to be used in your country.
1. xx=EU, CN, NA,
R5900022 CS-100 16/02/2016 5

2. CS-100 Specifications
2.2 CS-100 specifications
Base Unit
Weight 600g / 1.32lbs
Dimensions (HxWxD) 205mm x 115mm x 45mm (Min.) / 8.1” x 4.5” x 1.8” (Min.)
Power consumption Operation: 6W (typical) / 18W (max)
Standby: 2.6W (ECO standby) / 0.4W (Deep standby)
Warranty 3 years standard
Certifications FCC/CE
Anti-theft system Kensington lock
Humidity Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing
Temperature range Operating: 0°C to +40°C (+32°F to +104°F)
Max: 35°C (95°F) at 3000m
Storage: -20°C to +60°C (-4°F to +140°F)
Connections 1x Ethernet LAN
1x (back) + 1x (front) USB
Audio analog line out on mini jack socket (3.5mm)
Frequency band 2.4 GHZ and 5 GHz
Reach Adjustable with signal strength modulation; max. 30m (100 ft) between ClickShare
Button and ClickShare Base Unit
Wireless transmission protocol IEEE 802.11 a/g/n
Authentication protocol WPA2-PSK in stand alone mode
iPad, iPhone and Android
compatibility
Sharing of documents, browser, camera for both Android and iOS devices ClickShare app
Audio Via HDMI, analog via Audio Jack 3.5mm
Number of simultaneous
connections
8
Number of sources simultaneous
on screen
1
Noise Level Fanless
Input resolutions 3840 x 2160 (max)
Output resolution 1920x1200
Frame rate Up to 30 fps
Video outputs 1x HDMI
Extended desktop Available (depending on the driver of your graphics card)
Operating system Windows 7/8/8.1/10
Mac OSX 10.10/10.11
Android 4.1 and later (ClickShare app)
iOS 7.0 and later (ClickShare app)
Button
Weight 75 g/0.165 lb
Dimensions (HxWxD) 16.3 mm x 59.3 mm x 162.52 mm / 0.64” x 2.335” x 6.398”
Power consumption Powered over USB
5V DC
350mA Typical
500mA Maximum
Frequency band 2.4 GHZ and 5 GHz
6R5900022 CS-100 16/02/2016

2. CS-100 Specifications
Wireless transmission protocol IEEE 802.11 a/b/g/n
Authentication protocol WPA2-PSK in stand alone mode
WPA2-PSK or IEEE 802.1X in network integration mode
2.3 About the Base Unit
Base Unit
The Base Unit receives the wireless input from the Buttons and controls the content of the meeting room display and
the sound of the meeting room’s audio system.
The Base Unit can be installed in two different ways.
Front and Top layout of the Base Unit
At the front of the Base Unit you can find a power button and a USB port. Status LED ring is mounted around the power button of
the Base unit.
2
1
4
3
Image 2-2
1 USB port
2 Status LED ring
3 Power Button
4 Kensington lock
Tabl e 2 -3
USB port
The USB port is used to update the soft- and firmware of both the Base Unit and the Buttons. For more information about software
update via USB port, see "Software update", page 47.
When plugging in the Button into the Base Unit, the Button is paired to the Base Unit. The Base Unit checks whether the Button’s
software and firmware are up to date. If not, the Base Unit updates the software and/or firmware.
To update the Base Unit software, download the latest version of the software from the Barco website. Copy the file on a USB stick
and plug it into the USB port of the Base Unit. Follow the progress and instructions on the display.
Status LED ring
The color of the LED at the front of the Base Unit give information on the status of the system.
LEDs behavior Explanation
static red
• receiving content from the Buttons and streaming towards the display.
• pairing and software update of the Button is done. You can now unplug the
Button from the Base Unit.
• during the first phase of the Base Unit boot process.
blinking white
• system is starting up (during the second phase)
• Button pairing is in progress
• software update of the Base Unit
R5900022 CS-100 16/02/2016 7

2. CS-100 Specifications
LEDs behavior Explanation
breathing white
• ECO standby mode
static white
• awake and ready (i.e. showing the welcome message on the display)
• pairing is done
red blinking
• an error occurred
dark
• deep standby/off
Power button
The button at the front of the Base Unit has a power on/off function once the Base unit is powered
• When the system is powered on, a push makes the system shut down and power off.
• When the system is shut down, a push triggers the system to start up.
Back layout of the Base Unit
The connection panel is situated at the back of the Base unit.
1
2
3
4
5
6
Image 2-3
Backside Base unit
1 Power connection
2 Reset button
3 LAN Ethernet connection
4 HDMI connector
5USB port
6 Audio out port
Mechanical fixture points
The mechanical fixture points are located at the bottom of the Base Unit
Antenna
The antenna is built-in in the CS-100.
Bottom layout of the Base Unit
The serial number label containing the Barco part number, the revision number, production date (week-year) and the serial number.
The product label with the applicable certification logos.
8R5900022 CS-100 16/02/2016
