Baren B-H05 User manual

B-H05
Thank you for use this product which protected by intellectual property.
Please read this instruction manual carefully before
use and keep it for future use.
Air care series, house use
Ecological intelligent
air purifier with humidifier
H05中性英文说明书 尺寸：142X210MM 材质：书写纸100克
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
Attention:
If the parameter, specification and other information maybe changed, we will not notice specially, please refer to the actual machine.
The “optional” are optional functions, please kindly check with the retailer if your machine with these functions.

● UV light can efficiently kill bacteria and inhibit its activation
Environment self cicatrization
● It can generate 8,000,000 "air vitamin" every second which can improve the home environment.
produces "air vitamin"
Anti bacteria
Restrain the breeding and activity of viruses
Healthy air
Healthy air is the basis of health and life
● needs water per day.
So it is very important to the health to improve the air environment of live.
A child needs 400KG of air everyday, equal to 100 times of an adult
Make an ecotypic home
to avoid viruses
Make an ecotypic home
to avoid viruses
DIRECTORY
INDEX
Air care series, house use
Ecological intelligent air purifier with humidifier ·
09
09
10
10
11
09-12
13-14
13
14
14
15
16
16
03
02
01-03
CAUTIONS
WARNING
ATTENTION
04
04
04
PRODUCT PERFORMANCE
AND TECHNICAL FEATURES
Product performance
Technical features
05-06
06
05
05
COMPONENT INTRODUCTION
Diagram of the outlook
Diagram of unit
Operating parts
OPERATING INSTRUCTION
MAINTENANCE AND
CLEANING INSTRUCTION
Maintenance and cleaning instruction
Methods for replacing UV lamp
Disassembly and installation for UV lamp
FAQ
TECHNICAL PARAMETERS
Parameters of the unit
11
12
16
Filter parameters
16
UV parameters
16
Technical parameters of the atomization
Power setting
Function setting
Fan speed setting
Reset setting
Intelligent setting
Timing setting
Humidification setting
07-08
07
CAUTIONS BEFORE OPERATING
How to touch the control panel?
07
07
08
08
08
Installation of the filters
Placement
Disassembling front cover
Power supply
Instruction of filling water tank and installation

01 02
CAUTIONS
Please supervise your
children and avoid
them from touching
or using machine.
In order to prevent harm or damage happened to users or others, be sure to comply with the requirement as below:
It reminds that misusing or mishandling may cause death.
It reminds that misusing or mishandling may cause hurt.
Warning/Attention
Warning
Attention
FORBID FORCE
AVOID WET
It may cause electrical
shocking.
Do not connect
disconnect the power
with wet hand
or
NO DISASSEMBLE
No disassembly,
reconstruction.
repair and
It may cause fire or damage.
Please send it to the retailer
for repair.
Do plug the power
completely.
into the socket
It may cause fire because of
electrical shocking.
heating or
Do not use the damaged
socket
plug or loose
Do clean the plug termly
If there is dust on the plug, it
may weaken the insulation,
even cause fire
Take out the plug and clean
dry cloth.
it with
Please remove the plug from
socket if not using for a long period.
the
AVOID WET
Avoid any water
the surface of the
unit.
on
It may cause short
circuit or electrical
shocking.
DISCONNECT POWER
Do not insert any
objects into the unit.
metal
It may cause
shocking
hurt or electric
WARNING
FORBID
Do not use the
wiring connector.Do use the rated
voltage.
over run socket or
It may cause fire
FORBID
Do not repair it when the cord
or plug is damaged.
It may cause short circuit, electric
shocking or fire.
Please send it to the retailer for
repair.
Kindly attention: If the power wire is broken,to prevent danger happend,
please send it to agent,after-sales service or technical person for repair.
Kindly attention: FORBID
CAUTIONS
Ecological · intelligent air purifier with humidifier User manual
The appliance must be
disconnected from the
supply mains before
cleaning or other
maintenance
Otherwise the unit may
start working in a sudden
which may cause
electrical shocking or
hurt.

●
● Activated carbon: adopting the porous coconut made by modern biological carbonization synthesis technology,adsorption
capacity is bigger,and can effectively remove smoke, formaldehyde.
● Photo catalyst: using titanium dioxide (TiO2) material,its oxidation function can damage the filter captured the cell
membrane of bacteria, inhibit virus activity.
● UV lamp: air is the main path leading to the spread of the virus,using UV air sterilization technology,the environment of
natural bacteria killing rate can reach more than 96%.
● Anion: negative ion is praised as Air Vitamin.People live in the high negative ionic environment,can promote human new
and old superseded, improve immunity.
● Ozone: strong degradation of organic odor and sterilizing function.
● Intelligent humidity: create a moisture equilibrium quality air environment for you.
(Ozone function is optional,please refer to the actual machine for configuration)
HEPA: using a new generation of composite materials, can effectively remove of particle PM2.5.
●
● Digital display:PM2.5, temperature,humidity,timer indicator,more intuitive and easy to understand.
● Automatic alarm: set filter, UV lamp replacement warning indicator.
● ERP design, standby power≤0.5W
● PG motor,more quiet and more environmental.
● Air quality intelligent detection: built-in Sharp second generation PM2.5 particle sensor and odor sensor.
IMD control panel: using a new generation of IMD technology, more convenient control.
PM2.5 sensor are optional functions,please refer to the actual machine for configuration.
Product performance
Technical features
PRODUCT PERFORMANCE AND TECHNICAL FEATURES
FORBID
Please ventilate timely when
used with fire in the room
Otherwise it may
of Co as the machine is not a
1
ventilator
cause poisoning
Do not power the unit on when
insecticide in the room
using
Otherwise the insecticide may be stored in
the unit and will blow out during the normal
working time.It is harmful to the health.
Please ventilate completely after having
used the insecticide before turn on the unit.
●
●
singularly
● If any peculiar smell, exceptional
noise or vibration
● Any other abnormality or failure
If all switches do not work
If the power cord or plug hot
Please remove the plug from the
socket if any conditions as below:
If the power cord is damaged, please send it to the retailer or service center or technician for repairing. Do not change or repair it by yourself.
ATTENTION
Please hold the plug instead
the cord when unplug the power.
of
Otherwise it may cause short
breaking of the cord,electric shocking
or fire.
circuit,
Keep away from alcohol,
impregnant or insecticide
organic
It may cause cracking,
shocking, hurt or fire
short circuit, electric
Do not use in the room with
lampblack such as kitchen.
It may cause hurt
machine is not a ventilator
because the
Do not use in the watery or high
temperature room such as the
bathroom etc.
Otherwise it may cause
electric shocking or fire.
creepage,
Do not blow in any combustible
or fired cigarette into the unit.
It may cause fire
ATTENTION
03 04
User manual
Ecological · intelligent air purifier with humidifier

Humidify
COMPONENT INTRODUCTION
Operating parts
● Digital indicator
Humidity
Temperature Timing PM2.5
COMPONENT INTRODUCTION
Diagram of the outlook
Diagram of unit
Front view
IMD control panel
Front cover
Right view Back view
Handle
Back cover
Power cord hole
05 06
User manual
● Screen diagram
WIFI
Filter replacement indicator
Air quality indicator
Power on/off
Speed
Function display
UV lamp
Ozone(optional function)
Anion
(optional function) Signal receiver
Water tank indicator
Remark：the indicator light up when the water is used up, otherwise, the indicator light off.
Ecological · intelligent air purifier with humidifier
Nozzle
Particle sensor
Oder sensor
Main body
UV lamp
HEPA filter
Activated carbon+photo catalyst filter
Back
%%% %
%

CAUTIONS BEFORE OPERATING
Installation of the filters
● Take off front cover
● Take out HEAP,activated carbon+photo catalyst filter,tear off filter transparent
bag and put them back into device accordingly.
CAUTIONS BEFORE OPERATING
07 08
User manual
3.Put HEAP filter
1.Take off back cover
Instruction of filling water tank and installation
●When water finish,please fill it as below steps
:
Power supply
● Please don't connect this machine with
wrong voltage of power supply, inserting
the plug firmly into the power socket.
Ecological · intelligent air purifier with humidifier
Disassembling front cover
Placement
● Please keep the machine air inlet and outlet 30cm or more away from the wall and home furniture.
● Do not use the machine in front of heat source outlet.
Disassembling diagram Installation diagram
Left hand tight the device,
then pull out the back cover by right hand.
Please insert two boxout of the back cover into the
device's card trough, then completely cover the back cover.
1. Disconnect the power and pull out
the socket, then pull out nozzle
2.Open the water tank cover 3.Take out water tank 4.Turns on water box lid, fill well full water tank,
and tightens lid, installs in the machine
according to the original order.
Attention： Please make sure to fill clean water for guaranteed that the mist clean and the effective maintenance humidifier.
2.Activated carbon+photo catalyst filter
● Please touch the button with whole finger
How to touch the control panel?
Correct
Wrong

OPERATING INSTRUCTIONOPERATING INSTRUCTION
10
User manual
●
● Humidity sensor is built-in, checking current environment humidity and displayed with data.
The humidification function will be on after pressing the “humidify” icon on the product operating panel.
Humidification setting
Power setting
● To press the “power”icon on the product operating panel , machine is entered the initial working status.
The diagram as following:
● To press the “function” icon on the product operating panel,the anion, ozone and UV can be chosen individually or multiply or
close three functions. The diagram as following:
Function setting
09
Anion
UV lamp
Ozone(optional function)
Ecological · intelligent air purifier with humidifier
Humidify
Humidification indicator
Humidify
Timing setting
● Long press "Timing" icon,the displayed digit is flashing,then the timing mode is started.
● Press"Timing"icon continuously, the time can be chosenfrom 0 to 12 hours the device memory function will be started after
waiting for 5 seconds.
The diagram as following:
,
Remark 1: Press time button on operation panel to preview how long time setting.
Remark 2: Hold on time button if you want to cancel time setting.
Remark 3: When time setting is finished/power off,machine turn to normal working mode.
Humidify
Humidify
%
%
%
%

Humidify
OPERATING INSTRUCTION OPERATING INSTRUCTION
Reset setting
●
● After cleaning or replacing new filters, please press “Reset”icon, then filter icons will stop flashing, the machine starts to
record the filters using time.
If the filter icons are always flashing, it means the filters life time comes to the end, please clean or replace new filters.
Remark :”Reset” icon has refresh function,PM2.5 data can be refreshed after pressing the “ Reset” icon
on the product operating panel .
11
Filter replacement indicator
HEPA
Activated carbon and photo catalyst filter
Fan speed setting
If machine is set as intelligent mode, the “fan speed” icon can't be adjusted.
● Fan speed “high, medium, low” can be selected after pressing the “fan speed” icon on the product operating panel.P1
● Sleep mode: pressing “fan speed” icon and hold on for 3 seconds, the sleep mode will be on, if pressing any icons,
the sleep mode will be cancelled.P2:：
Remark: Sleep mode is night mode,fan speed and noise are very low,all indicators are not lighted.
P1:speed adjustment diagram P2:Sleep mode diagram
● The number of PM2.5 particles, air quality status,and machine intelligently running status as below.
Intelligent setting
●
● Air quality indicator will be lighted after pressing the “Intelligent” icon on the product operating panel , the machine will check
the air quality and control its working status automatically.
Odor sensor is built-in,PM2.5 function is optional( Attention: for standard configuration, please see your purchased machines)
● PM2.5 sensor: it's to check the dust or particles and display it by data.The diagram as following:
12
User manual
Ecological · intelligent air purifier with humidifier
Humidify Humidify
% %
%
Humidify
%
Remarks 1:
Remarks 2:
the quantity of the air quality indicator means air quality level and its working status.
when you choose"intelligent" mode, the device will take 3 minutes to warm up, "function" icon can not use in this mode.
Remarks 3: when air humidity is above 80%, it will affect the sensitivity of sensor, the PM2.5 data is just for your reference.
Humid ify
%
Humid ify
%
Humid ify
%
Humid ify
%
P1 P2
P3 P4
P1:Best
P2:good
P3: Mild-to-moderate polluted
P4: worst polluted

MAINTENANCE AND CLEANING INSTRUCTION
Maintenance and cleaning instruction
●
●
●
Cleaning the body for this device by damp cloth, then wipe it dry.
If machine is too dirty, neutral detergent can be used for cleaning, but please dilute the detergent before use.
Do not clean the unit with the solvent listed on the right which may cause distortion or discolour.
Please remove plug from the socket before
cleaning and maintenance .
Decontamina tion
power
Alkalescence
Benzene Acohol
Scour
Maintenance and cleaning instruction
Hold the UV lamp and rotate it for 90 clockwise or anticlockwise,
then take it out.
Hold the UV lamp and rotate it for 90 clockwise or anticlockwise,
then install it well.
● Take off the front cover, and take out all filters, then UV lamp can be replaced.The diagram as following:
Disassembly and installation for UV lamp
MAINTENANCE AND CLEANING INSTRUCTION
14
User manual
Methods for replacing UV lamp
● Photo sensor is built-in the device, if the UV light is very weak or not lighted, the UV icon on the product operating panel will be
flashing; it means UV lamp should be replaced.
The diagram as following:
13
Humidify
UV lamp replacement indicator
Ecological · intelligent air purifier with humidifier
● PM2.5 abnormal correcting：
After used the PM2.5 sensor for a long time, trace amounts of particulate will adhere to the sensor inductive head,
it may cause the PM2.5 numerical display abnormal.
When you find PM2.5 numerical severly deviated from the normal range, here we advise you collect it as follow steps
based on the weather forecast's PM2.5 numerical in your city.
1. Open the window ventilated for 5 minutes(PM2.5 sensor will re-collection current environmental data).
2. Long press "function" icon, after heard a "click", showing it antomatic switch to PM2.5 display window,
then enter PM2.5 correcting mode.
3
3.Each time you press "function" icon, the machine's PM2.5 numerical will increase 2ug/m , each time you press "smart" icon,
3
PM2.5 numerical will decrease 2ug/m .
4.When the PM2.5 numerical adjust to the PM2.5 numerical of your city's weather forecast,waiting 5 seconds，
PM2.5 sensor collection finished.
%

● If the machine can't work properly,please kindly check as below before you send it out for repair.
If the problem is still existed after above inspections, please disconnect the power and send it for repair.
TECHNICAL PARAMETERS
● Is the PE bag for filter removed?
● Does the using life time for HEPA come to the end?
Solution
Please take out filters and tear off PE bag.
Please replace new HEPA .
Abnormal occurrence Checking methods
Do not work
Odor can not be removed.
● Please check if the plug is disconnected from the socket. Power plug should be plugged properly
● Please check if the front cover is installed completely Recover the front cover correctly
●
(Notes:air should be purified continuously)
Is there a very strong odor in the using environment? Suggesting to ventilate,then start up the
machine.
●
come to the end?
Does the using life time for activated carbon filter Please replace new filters.
High noise
Small changes for
humidity or temperature
data
● Is the machine using area too big? Please use this machine in applicable room.
Air quality indicator can
not work properly
● Is the air humidity very high?
● Is the machine affected by kitchen oil fume or sprays?
Please move the machine to another
room to test again.
FAQ
15 16
User manual
Parameters of the unit UV parameters
Filter parameters
L285XW280XH25mm
L285XW280XH15mm
Description Size Life time
HEPA About 12 months
About 6 months
Ecological · intelligent air purifier with humidifier
T5
6W
254nm 8000h
Description
UV lamp
Model
Power rating
Wave length Life time
32W 34VDCV 120ml/H10000 hours
Technical parameters of the atomization
Discription Power rating(w) Consumption Atomization Life time
Atomizer
B-H05
Model No.:
3
≥300m /h
≤40dB(A)
≥1.4M
8.2kgs
75W
2
33-38m
452x233x438(mm)
3
Air flow volume(m /h):
Noise level :dB(A)
Length of power cord:
Product size:
Net weight:
Power rating (W):
Applicable area:
Voltage Supply: 220V-240V,50Hz
Activated carbon+
photo catalyst filter
